Summary of Contents for Blaupunkt IVMR 1042P
-
Page 3: Table Of Contents
TABLE OF CONTENTS Monitor overview ....3 IR remote control overview ..5 Notes for the user ... . 6 Precautionary measures . -
Page 4: Monitor Overview
MONITOR OVERVIEW (IVMR-7002P Shown) *Note: Buttons 6-9 are located on the right side of the display screen on Model IVMR-1042P. -
Page 5: Monitor Overview
Black wire = Ground Red RCA plug = Audio In (R) White RCA plug = Audio In (L) Yellow RCA plug = Video In Blue phono plug = IR pass through for Blaupunkt DVD players (DVD- ME2, DVD-ME3 & DVD-ME R). MONITOR OVERVIEW... -
Page 6: Ir Remote Control Overview
IR REMOTE CONTROL OVERVIEW POWER On/off button for the monitor. TV/VIDEO Input selector: switch between AV1 and AUX. VOL arrow button (Not used) MUTE CH arrow button (Not used) MENU See Instructions / OSD menu Battery compartment... -
Page 7: Notes For The User
Thank you for choosing a Blaupunkt product. We hope you enjoy using this new piece of equipment. Please read these operating instructions before using the equipment for the first time. Precautionary measures Please observe all the warning notices, precautionary measures and... -
Page 8: Supplied Parts
SUPPLIED PARTS The monitor is supplied with all the parts listed below. Please check that the range of parts supplied with your device is complete. If one of the listed parts is missing, please contact your dealer immediately. • Monitor (including mounting plate and screws) •... -
Page 9: Installing The Monitor
Installing the monitor (mechanical) Select a suitable position for secure installation of the monitor: • The device must not distract the driver or restrict the driver’s view. • The ability to enter and get out of the vehicle must not be impeded. •... -
Page 10: Cables
Red wire = Constant +12V White wire = To the door switch (Negative Door Trigger) Black wire = Ground to connect to Red wire = +12V Ignition Black wire = Ground Blaupunkt DVD players (DVD-ME2, DVD-ME3 & DVD- ME R). and the... -
Page 11: Operation
Controlling the interior lighting (monitor) There are two switches for the lights: and interior lighting This button is used to switch the lights on/off. Interior lighting If activated, the lights only come on when the vehicle’s doors are opened. Opening the monitor •... -
Page 12: Adjusting The Position Of The Monitor
OPERATION Adjusting the position of the monitor Closing the monitor Pull the display screen towards you and up into its base, until it snaps securely into the locking/releasing mechanism. Powering on the monitor Press the power-on button main unit or the button remote control to switch the monitor on/off. -
Page 13: Osd Menu
OSD menu Operation • Press the MENU button display or the MENU button the remote control to open the OSD menu. • Use the arrow buttons to select the options. After you press the MENU button you can use the arrow buttons to change the settings. -
Page 14: Changing The Light Bulb
OPERATION Changing the dome light • Detach the monitor from the ceiling plate (4 screws). Screws for securing the ceiling-mounted monitor • Remove the 3 screws of the metal cover (see picture below). • Take out the old bulb. • Put in a new bulb (12 Volts, 3 Watts). •... -
Page 15: Specifications
Model TFT-LCD Size Aspect Ratio Open to Close Dome Light Screen Size Pixel Format (WxRGBxH, pixels) Contrast Ratio Signal System Power Supply Video Input Level Audio Input Level Operating Temp Storage Temp Display Method Viewing Area (WxH,mm) Viewing Angle left-right Viewing Angle top-bottom Brightness Monitor Dimension (WxHxD, mm) - Page 16 Robert Bosch Corporation Sales Group - Blaupunkt Division 2800 S. 25th Avenue, Broadview, Illinois 60155 U.S.A. www.blaupunktusa.com Copyright 2004 by the Robert Bosch Corporation No portion of this work may be reproduced in any form without the written consent of the Robert Bosch Corporation...
