Deep Freezer
Operation Manual
• Read the Operation Manual carefully before using your appliance.
• Keep the Operation Manual in a safe place.
• Appearance , color and layout of the door may vary.
• Translation of the original instruction.
• The product is fit for low temperature storing goods.
Model :
DW-60W138
DW-60W258
DW-60W388
DW-40W100J
DW-40W255J
DW-40W380J
Advertisement
Table of Contents
Related Manuals for Haier DW-60W138
Summary of Contents for Haier DW-60W138
- Page 1 DW-60W258 DW-60W388 DW-40W100J DW-40W255J DW-40W380J Manufacturer: Qingdao Haier Biomedical Co., Ltd. Address: Haier Industrial Park, Economic Technology Development Zone, Qingdao P.R. China Web:www.haiermedical.com Revision Date:09/2018 Version:3rd,2018 Dedicated code:0270501299WD V13026 • Read the Operation Manual carefully before using your appliance.
-
Page 3: Product Feature
Storage basket and so on. Name DW-40W100J DW-40W255J DW-40W380J Inner temperature: Manual DW-60W138/258/388 -30℃ to-60℃ Plastic bag Temperature DW-40W100J/255J/380J -20℃ to-40℃ control It is computer-based control and displays temperature in digital with the Ice scraper accuracy of 0.1℃ Storage basket... - Page 4 Content Specifi cation Name Deep Freezer Model DW-40W100J DW-40W255J DW-40W380J Exterior dimensions 790×770×950 1210×770×950 1655×770×950 (W × D × H) (mm) Interior dimensions 580×445×620 1000×445×620 1450×445×620 (W × D × H) (mm) Effective volume(L) Product Feature ..............1 Door Foaming door Content .................2 Insulation CFC-Free foamed-in-place urethane...
-
Page 5: Specification
Safety Precautions Dear Customers, Specifi cation Thank you for choosing Haier deep freezer. Please make sure that you have carefully read the manual and follow the instruction as outlined. This is to prevent personal injury and damage to Name Deep Freezer products. -
Page 6: Circuit Diagram
Circuit Diagram If the supply voltage is lower or higher than the rated voltage, an automatic voltage regulator of at least 4,000W should be installed with the refrigerator. If the power cord needs to be lengthened, the cross section area of the extension line’s conductor should be at least 2 mm²... - Page 7 Disposal of discarded freezer shall be conducted by the relevant personnel. Dismantle the door DW-40W100J/255J/380J to prevent occurrence of accidents such as suffocation. Do not set off hazardous articles that are infl ammable, explosive or volatilizable in the freezer, nor use the fl ammable spraying agent in the vicinity of the freezer, or otherwise, it may trigger Capillary tube an explosion or fi...
-
Page 8: Application Guidelines
• Storage and withdrawal of stored articles a. Before putting any article in the freezer, you should confi rm that whether the storage temperature DW-60W138/258/388 of article complies with the setting temperature of the freezer in advance; b. Before putting any article in the freezer, you should confi rm that whether the temperature within the Capillary tube freezer has already reached to the setting temperature in advance;... -
Page 9: Product Installation
Product installation Installation environment • Ambient temperature:10℃ to 32℃ , with maximum beyond 32℃ , the optimal temperature is 18℃ to Any of the following event will be normal, please do not worry about any of it: 25℃ , the air conditioning system shall be used when necessary. •For initial use or start-up, the working time of refrigerating system will be longer and the noise will •... -
Page 10: Preparation Before Use
Preparation before Use If you have any questions about the operation of the unit, please refer 1. Disassemble all packaging materials, including the base to the following fi rst. If an issue persists, contact your after sales offi ce. Take out all packaging materials of product at suitable site, including the base, and dissemble all fi xed Do not maintain and dismantle the freezer by yourself! tapes or other fi... -
Page 11: Cleaning & Maintenance
Cleaning maintenance Initial power-on Cleaning component Please observe the following rules when conducting initial start-up and continuous running: Turn off the power before any maintenance work is performed. Connect the power cord to the dedicated socket of proper gauge when the bin is empty, make sure the power supply is 220V~/50Hz. -
Page 12: Operation After A Power Failure
Alarm • A person shall be specially assigned for daily check and record of the product operating • When the temperature captured by sensor is higher than+5℃ (or higher than the setting value of conditions, in case the temperature inside the bin is on the high side or on the low side, just high-temperature alarm), "AH"... -
Page 13: Name Of Parts
Name of parts Test hole Foaming door Handle Lock Test hole Test hole Cabinet • Purpose 1. Relevant test should be carried out by putting the test line in the freezer to test the articles or environment within it. 2. Balance the pressure in and out of the bin in order to open the door cover easily. •... -
Page 14: Application Method
Application method •Display setting temperature Electronic temperature controller A few seconds after the low temperature freezer power on, the display screen shows the current temperature in the cabinet, If you need to check the setting temperature, operate as the following steps: An electronic digital display thermostat is installed on the control panel of the low temperature freezer, and the digital display can show the actual temperature in the cabinet after power on.
