Contents Welcome to BlackBerry! ... 3 Set up your device ... 5 Insert the SIM card and battery ... 5 Charge the battery ... 8 Complete the setup wizard ... 10 Learn the basics ... 15 Move around the screen ... 16 Open a menu ...
Page 4
Add a contact ... 27 Take a picture ... 27 Visit a web page ... 28 Pair with a Bluetooth enabled device ... 28 About using your device with a computer ... 29 Transfer a file between your device and your computer using the media manager tool ... 31 About accessories ...
Get ready to experience the freedom and connectivity of your all-in-one mobile solution. Setting up your BlackBerry® device is easy. Simply verify that your SIM card and battery are inserted in your device, charge the battery, and complete the setup wizard.
10. Slide the SIM card holder door away from its hinges to lock it. 11. Insert the battery so that the BlackBerry logo faces up and the metal contacts on the battery align with the metal contacts on your device.
Page 8
12. Slide the battery cover back onto the device so that it clicks into place. If the battery is charged, the device turns on. If the device does not turn on, charge the battery. Figure 1. Remove the battery cover...
Page 9
Figure 2. Insert the SIM card Figure 3. Insert the battery...
• Fold the plug blades down. 2. Connect the small end of the travel charger cable to the USB port on the side of your BlackBerry® device. 3. Plug the power adapter into a power outlet. 4. Charge the battery to full power.
If you have an available USB port on your computer and you have installed the BlackBerry® Desktop Software, you can use the USB cable that came with your device to connect your device to your computer for charging. For more information, see the "About using your device with a computer "...
Complete the setup wizard The setup wizard is designed to help you learn about typing, change options to personalize your BlackBerry® device, and set up one or more email addresses. The setup wizard takes approximately 10 minutes to complete. 1. In the setup wizard dialog box, roll the trackball to highlight Run Setup Wizard.
Page 13
About email setup options Use one of the following options to set up email on your BlackBerry® device: • BlackBerry Internet Service option: Use this email setup option to create a new email address for your device or to associate your device with one or more (up to ten) existing email addresses.
Page 14
• BlackBerry Desktop Redirector option: Use this email setup option to associate your device with a Microsoft Outlook (Workgroup Installation) email account. You can set up email using this option by installing the BlackBerry Desktop Software and selecting the BlackBerry Desktop Redirector option. If you use this email setup option, you must keep your computer turned on to receive your email messages.
Page 15
8. Record your user name and password in a safe place. 9. Perform one of the following actions: • If your service creates a BlackBerry email address for you automatically and you want to change options for the email address, click View Account or Next.
• To return to the Home screen, press the Open a menu • To open a list of the applications on your BlackBerry® device, press the key on the Home screen. • To open a menu of all the available actions for a highlighted item in an application, press the •...
Typing basics Typing indicators Shift mode Alt mode Typing tips • To capitalize a letter, hold the letter key until the capitalized letter appears or press the Shift Figure 9. Change the value in a field key and the letter key. number lock mode...
• To turn off NUM lock, press the Applications Take some time to explore the applications that are available on your BlackBerry® device. Here are a few applications to get you started. Click Setup Wizard to learn about typing, change options to personalize your device, and set up your email address.
Click Browser to visit web pages or view the browser bookmark list. Click Call Log to make a call or view a list of recent calls. Click Camera to take a picture. Click Media to view saved songs, ring tones, videos, or pictures. Click Messages to view a list of your messages.
unopened message count missed calendar reminder voice mail message Bluetooth® technology is turned on Message list status indicators unopened message opened message message with an attachment message is high priority SMS text message sending data receiving data roaming paired with Bluetooth enabled device MMS message...
Wireless network coverage indicators Indicators on the Home screen display the wireless coverage level for the area in which you are using your BlackBerry® device. A wireless coverage level might limit the use of some device features. You can use the phone, send and receive email, PIN, SMS text, and MMS messages, and use the browser with a high-speed data connection.
Page 25
You can only make emergency calls. Your connection to the mobile network is turned off. You are not in a wireless coverage area.
Start using your device Make a call 1. On the Home screen or in the phone, perform one of the following actions: • Type a phone number. • Type part of a contact name. Highlight a contact or phone number. 2.
5. Click the trackball. 6. Click Send. Note: If your BlackBerry® device is associated with more than one email address, in the Send Using field, you can set the email address that you want to use to send the email message.
4. Click the trackball. 5. Click Save. Take a picture By default, when you take a picture, the camera saves the picture to the BlackBerry® device memory. 1. In the camera, click the trackball. 2. Perform one of the following actions: •...
1. In the Bluetooth setup application, click OK. 2. Click a Bluetooth enabled device. 3. If required, type the passkey for the Bluetooth enabled device on your BlackBerry® device. key. key. key. key. Click Edit. Change the...
About using your device with a computer You can install the BlackBerry® Desktop Software on your computer and connect your BlackBerry device to your computer to perform any of the following actions: • Synchronize organizer data such as contacts, calendar entries, tasks, and memos between your device and your computer.
Install the BlackBerry Desktop Software 1. Verify that your BlackBerry® device is not connected to your computer. 2. Insert the BlackBerry User Tools CD into the CD drive on your computer. 3. Click BlackBerry Desktop Software. 4. Complete the instructions on the screen.
About accessories You can buy accessories such as batteries, carrying solutions, headsets, and charging solutions for your BlackBerry® device. Contact your wireless service provider or visit www.shopblackberry.com for more information. CAUTION: Use only accessories that Research In Motion has approved for use with your device model.
About adding applications to your device You can download applications for your BlackBerry® device from a web site such as mobile.blackberry.com using the browser on your device. You can also download application files from a web site such as www.handango.com/blackberry/ using a browser on your computer.
Page 35
5. Place the media card into the slots in the media card holder door so that the metal contacts on the media card align with the metal contacts on your device when the media card holder door is closed. 6. Close the media card holder door. 7.
• To view the BlackBerry 101 tutorial, user guide, safety and product information booklet, or software license agreement and warranty for your device, insert the BlackBerry User Tools CD that came with your device into the CD drive on your computer.
I cannot connect to a wireless network Try performing the following actions: • Verify that your SIM card is inserted in your BlackBerry® device correctly. • Verify that you have turned on the connection to the wireless network. • Verify that you are connected to your wireless service provider's network. If...
• Select the I want to use a work email account with a BlackBerry Enterprise Server option if a system administrator has provided you with a password that you can use to activate your device over the wireless network.
• You have already visited the email setup web site and have set up an email address using a browser on your computer. • You have an existing email account and have access to a BlackBerry® Enterprise Server, but your system administrator has not provided you with a password that you can use to activate your device over the wireless network.
• Verify that your BlackBerry® device is connected to the wireless network. If you are not in a wireless coverage area, your device should send the messages when you return to a wireless coverage area. • If the menu item for sending a message does not appear, verify that you have added an email address or PIN for your contact.
• If you created an email address or added an existing email address to your device using the email setup web site, verify that you have received an activation message on your device from the BlackBerry Internet Service. If you have not received an activation message (the message might take a short period of time to arrive), use the email setup web site to send a service book to your device.
Page 42
• If you have traveled to another country and you have not changed your smart- dialing options, dial the full phone number, including the country code and area code, for your contact. • If you are not receiving calls, verify that call blocking and call forwarding are turned off.
Page 44
information and/or trade secrets, this document may describe some aspects of RIM technology in generalized terms. RIM reserves the right to periodically change information that is contained in this document; however, RIM makes no commitment to provide any such changes, updates, enhancements, or other additions to this document to you in a timely manner or at all.
Page 45
Information in this document does not imply endorsement by RIM of the Third-Party Information or the third party in any way. Installation and use of Third-Party Information with RIM's products and services may require one or more patent, trademark, or copyright licenses in order to avoid infringement of the intellectual property rights of others.
Page 46
200 Bath Road Slough, Berkshire SL1 3XE United Kingdom Published in Canada...
