Contents Welcome to BlackBerry! ... 3 Set up your device ... 5 Insert the SIM card and battery ... 5 Charge the battery ... 8 Complete the setup wizard ... 10 Learn the basics ... 15 Move around the screen ... 16 Open a menu ...
Page 4
Add a contact ... 27 Visit a web page ... 27 Pair with a Bluetooth enabled device ... 28 About using your device with a computer ... 28 About accessories ... 30 About adding applications to your device ... 30 Insert a media card ...
Get ready to experience the freedom and connectivity of your all-in-one mobile solution. Setting up your BlackBerry® device is easy. Simply verify that your SIM card and battery are inserted in your device, charge the battery, and complete the setup wizard.
One end of the SIM card should be hidden below the plastic casing on your device. 8. Insert the battery so that the BlackBerry logo faces up and the metal contacts on the battery align with the metal contacts on your device.
Page 8
If the battery is charged, the device turns on. If the device does not turn on, charge the battery. Figure 1. Remove the battery cover...
Page 9
Figure 2. Insert the SIM card Figure 3. Insert the battery...
Charge the battery 1. Connect the small end of the travel charger cable to the USB port on the side of your BlackBerry® device. 2. If required, perform one of the following actions: • Insert the plug blade attachment into the power adapter.
Figure 5. Insert plug attachment or fold plug blades down (if required) If you have an available USB port on your computer, you can use the USB cable that came with your device to connect your device to your computer for charging. Battery power level indicators full battery power low battery power...
Complete the setup wizard The setup wizard is designed to help you learn about typing, set options to personalize your BlackBerry® device, and set up one or more email addresses. The setup wizard takes approximately ten minutes to complete. 1. In the setup wizard dialog box, roll the trackball to highlight Run Setup Wizard.
Page 13
About email setup options Use one of the following options to set up email on your BlackBerry® device: • BlackBerry Internet Service option: Use this email setup option to create a new email address for your device or to associate your device with one or more (up to ten) existing email addresses.
Page 14
• BlackBerry Desktop Redirector option: Use this email setup option to associate your device with a Microsoft Outlook (Workgroup Installation) email account. You can set up email using this option by installing the BlackBerry Desktop Software and selecting the BlackBerry Desktop Redirector option. If you use this email setup option, you must keep your computer turned on to receive your email messages.
Page 15
10. Perform one of the following actions: • To associate an existing, supported email address with your BlackBerry® device, type the email address information. • To create a new email address for your device, click Create a BlackBerry email address.
• To close a menu or move back a screen, press the Open a menu • To open a list of the applications on your BlackBerry® device, press the key on the Home screen. • To open a menu of all the available actions for a highlighted item in an application, press the •...
Typing basics Typing indicators Shift mode Alt mode Typing tips • To capitalize a letter, hold the letter key until the capitalized letter appears or press the key and the letter key. Figure 9. Change the value in a field number lock mode...
• To turn off NUM lock, press the Applications Take some time to explore the applications that are available on your BlackBerry® device. Here are a few applications to get you started. Click Setup Wizard to learn about typing, set options to personalize your device, and set up your email address.
Click Call Log to make a call or view a list of recent calls. Click Media to view saved videos, ring tones, pictures, or songs. Click Messages to view a list of your messages. More than one message list might appear on your device. Click Options to view the main list of device options.
voice mail message Bluetooth® technology is turned on Message list status indicators unopened message opened message message with an attachment message is high priority SMS text message roaming paired with Bluetooth enabled device MMS message sent message message is sending message not sent...
Wireless network coverage indicators Indicators on the Home screen display the wireless coverage level for the area in which you are using your BlackBerry® device. A wireless coverage level might limit the use of some device features. You can use the phone, send and receive email, PIN, SMS text, and MMS messages, and use the browser with a high-speed data connection.
Page 25
You can only make emergency calls. Your connection to the mobile network is turned off. You are not in a wireless coverage area.
Start using your device Make a call 1. On the Home screen or in the phone, perform one of the following actions: • Type a phone number. • Type part of a contact name. Highlight a contact or phone number. 2.
5. Click the trackball. 6. Click Send. Note: If your BlackBerry® device is associated with more than one email address, in the Send Using field, you can set the email address that you want to use to send the email message.
Add a contact 1. In the address book, press the 2. Click New Address. 3. Type the contact information. 4. Click the trackball. 5. Click Save. Visit a web page 1. In the browser, press the 2. Click Go To. 3.
About using your device with a computer You can install the BlackBerry® Desktop Software on your computer and connect your BlackBerry device to your computer to perform any of the following actions: • Synchronize organizer data such as contacts, calendar entries, tasks, and memos between your device and your computer.
• available USB port • CD drive Install the BlackBerry Desktop Software 1. Verify that your BlackBerry® device is not connected to your computer. 2. Insert the BlackBerry User Tools CD into the CD drive on your computer. 3. Click BlackBerry Desktop Software.
About adding applications to your device You can download applications for your BlackBerry® device from a web site such as mobile.blackberry.com using the browser on your device. You can also download application files from a web site such as www.handango.com/blackberry/ using a browser on your computer.
Insert a media card Use a microSD media card to extend the memory available on your BlackBerry® device for storing media files such as videos, ring tones, pictures, or songs. The media card might be sold separately from your device.
• To view the BlackBerry 101 tutorial, user guide, safety and product information booklet, or software license agreement and warranty for your device, insert the BlackBerry User Tools CD that came with your device into the CD drive on your computer.
Page 35
• To try a free 30-minute introductory training course (available in English only) for your device or to purchase additional training, visit www.blackberry.com/ go/onlinetraining. • To find information about your wireless network or your wireless service plan, visit your wireless service provider web site.
• On the email setup web site, verify that you have typed all the email address information correctly. • Log in to the email setup web site and add an email address to your BlackBerry® device using a browser on your computer. To log in to the email setup web site, type the email setup web site address provided by your wireless service provider in a browser on your computer.
BlackBerry® device or associate your device with an existing, supported email address. • Select the I want to use a work email account with a BlackBerry Enterprise Server option if a system administrator has provided you with a password that you can use to activate your device over the wireless network.
• You have already visited the email setup web site and have set up an email address using a browser on your computer. • You have an existing email account and have access to a BlackBerry Enterprise Server, but your system administrator has not provided you with a password that you can use to activate your device over the wireless network.
I am not receiving messages Try performing the following actions: • Verify that your BlackBerry® device is connected to the wireless network. If you are not in a wireless coverage area, you should receive messages when you return to a wireless coverage area.
I cannot make or receive calls Try performing the following actions: • Verify that your BlackBerry® device is connected to the wireless network. • If you cannot make calls and fixed dialing is turned on, verify that the phone number for your contact appears in your fixed dialing list or turn off fixed dialing.
Page 42
• If you are not receiving calls, verify that call blocking and call forwarding are turned off.
