Page 1
MODELS: PW18024V (HPD2301A) COBRA LI-ION PRESSURE WASHER OWNER’S MANUAL Cobra Garden Machinery Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK www.cobragarden.co.uk WARNING: For your own safety please read this manual before attempting to operate your new tool. Failure to follow instructions can result in serious personal injury.
Page 2
GENERAL SAFETY WARNINGS 5. Do not subject the battery pack to mechanical shock. Read all safety warnings and 6. If the battery leaks, do not expose the instructions. Failure to follow the leaked liquid directly to the skin or eyes. If warnings and instructions may result contact occurs, flush the affected area with in electric shock, fire and/or serious...
Page 3
Symbols Warning Reading instructions The battery contains lithium. To protect the environment, discarded batteries should sorted recycled. Do not throw them into the trash can. Don't throw it into the trash Don't put in water Don't put it in the fire...
Page 4
Pressure Washer Parts Identification Pressure Selector Pipe connector Trigger lock Inlet pipe Trigger Hose clamp Battery pack lock Water pipe filter Battery pack Soap bottle Water inlet connector Long lance Multi-function nozzle Long brush Wheel brush Charger...
Page 8
Machine Specification PW18024V (HPD2301A) Model Charger voltage / 100V-240V~50/60Hz frequency Rated voltage High 2.2MPa Rated pressure 0.8MPa Rated flow rate (high) 180L/h 0.5MPa Maximum inlet pressure Water absorption height 最高 1.8m (Max 1.8m) Machine weight 1.8kg...
Page 9
Accessories PW18024V (HPD2301A) Water Inlet pipe Multi-function nozzle Long lance Long brush Wheel brush Storage bag Battery pack Charger We recommend that you purchase accessories from the store where you purchased the product. A detailed description of the accessories can be found in the accessory package. The in-store staff will help and advise you.
Page 10
from the washer before cleaning begins. The entire process takes about 15 seconds. Select the required water spray mode Note: The water spray effect must be selected according to the working conditions. The 0°, 15°, 25° and 40° modes are suitable for cleaning and See Figure C are suitable for watering.
Save all warnings and instructions for review. Read the instructions before charging: -Only use the charger indoors. -Do not charge non-rechargeable batteries If the power cord or charger is damaged, do not use. Please contact a Cobra service agent.
Page 12
Symbol Warning mark Reading instructions For indoors, beware of rain Double insulation Positive electrode Negative electrode Charger specifications Rated input voltage 100-240V~50/60Hz The output voltage Recharging current Rechargeable battery type Lithium battery Charging time Approximately 2 hours Weight 0.24kg Charging procedure Note: Please read the instructions carefully before using the machine.
Page 13
Green light Finished charging always on Flashing red light Battery failure Check with a Cobra Service centre Problem solving Why can't I insert a) First check if the charger and battery pack are compatible. the battery pack b) The battery pack can only be inserted into the charger in one direction.
Any damage that occurs from the use of non-genuine Cobra parts will not be covered. We reserve the right to reject any claim where the purchase cannot be verified or when it is clear that the product was not maintained properly.
EC-DECLARATION OF CONFORMITY Cobra Garden Machinery, Henton & Chattell Ltd, We herewith declare, London Road, Nottingham NG2 3HW UK That the following machine complies with the appropriate basic safety and health requirements of the EC Directive based on its design and type, as brought into circulation by us.
