- Page 1 Technical Guide | BRC-X400/SRG-X400/X120 SRT introduction Version 1.0...
-
Page 2: Table Of Contents
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 C O N T E N T S CONTENTS ....................1 1. Overview ..................... 2 2. Flowchart .................... 3 3. Pre-configuration Settings ..............4 3.1. HTTP/RTSP setting ................4 3.2. Set IP address by using the RM-IP Setup Tool........4 3.3. -
Page 3: Overview
・Services and software content are subject to change without notice. ・Separate registration and/or payment may be required. Please note that Sony Corporation is not responsible for any claim, from customers or third parties, arising from any use of services and software provided by other companies Sony Version 1.0... -
Page 4: Flowchart
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 Flowchart The flowchart shows outline of the procedure for enabling the SRT connectivity function of the camera described in the following chapter. *Please refer to the manual of the devices to be connected. Sony... -
Page 5: Pre-Configuration Settings
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 Pre-configuration Settings This section describes some pre-configuration settings you will need before activating the SRT function for the cameras. 3.1. HTTP/RTSP setting The HTTP/RTSP communication setting need to be enabled in order to communicate via network before the SRT function of the camera is enabled. -
Page 6: Camera's Codec Setting
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.4. Camera’s Codec Setting For SRT function, available channel is Image 1, fixed with H.264. 3.4.1. Audio setting Please enable Audio to use SRT function. SRT function cannot be used when Audio is not enabled. -
Page 7: Srt Setting
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5. SRT Setting Before starting SRT transmission, Port to be used and whether Camera is set to Caller mode or Listener mode needs to be fixed. Caller means it starts the transmission, while Listener means it waits for it. - Page 8 SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5.1. When setting camera as Caller Open [Streaming] tab of the Administrator Settings menu, and select [SRT-Caller] of [Streaming mode]. Set IP address or URL, then [:] followed by Port number for [URL(Destination)]. Press [OK] to complete the setting.
- Page 9 SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5.2. When setting camera as Listener Open [Streaming] tab of the Administrator Settings menu, and select [SRT-Listener] of [Streaming mode]. Set Port number of the destination for [Port number]. Press [OK] to complete the setting.
- Page 10 SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5.3. Setting of Latency and TTL Set [Latency] and [TTL] upon the transmission environment. Recommended to set enough latency according to RTT to the destination measured in advance. For the recommended setting value, please refer to the information announced from SRT Alliance.
- Page 11 SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5.4. Encryption setting Set when data needs to be encrypted by passphrase. Select the length of encryption by [Encryption]. If encryption is not required, select [OFF]. Set the passphrase to use in [Passphrase]. To change it, press [Reset] to clear the previous setting, then set new passphrase.
- Page 12 SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 3.5.5. Adaptive Rate Control (ARC) setting To enable ARC, open [Streaming] tab and check[ARC]. When ARC is enabled, distortion of the image affected by congestion of the line etc. can be reduced. Sony Version 1.0...
-
Page 13: Troubleshooting
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 Troubleshooting This section describes how to manage the problems might happen for SRT function of the cameras. Unable to connect [Case 1] Check the network connection. [Case 2] Check the Caller/Listener mode. If camera is Caller, set destination as Listener. If Camera is Listener, set destination as Caller. -
Page 14: Revision History
SRT introduction Technical Guide | BRC-X400/SRG-X400/X120 Revision History Date Revision Description 2021/06/11 Released Sony Version 1.0... - Page 15 This document, in whole or in part, may not be reproduced or transferred for any purpose without prior written approval from Sony Corporation. Sony Corporation reserves the right to make any modification to this document or the information contained herein at any time without notice.
