- Page 1 Wireless Keyboard & Optical Mouse User Manual...
-
Page 2: Table Of Contents
Quick Installation Setup for PS/2 Connections (PC-only) ... 5 Quick Installation Setup for USB Connections (PC or Mac computers) ... 7 Software Driver Installation for Windows 98, Me, 2000, and XP ... 9 About your Belkin Software ... 10 Function Setting ...11 Display Setting ... 13 Battery Power... -
Page 3: Introduction
Although the F8E829-BNDL will function out-of-the-box as a Human Interface Device (HID), for advanced programmability and functionality we highly recommend the use of the F8E829-BNDL driver. Installing this software will give you added flexibility and allow you to customize your settings and reassign keys to fit your preference. -
Page 4: Product Features
Product Features Power Management keys require no software to get this feature to work. Important: Power Management keys are controlled by your system. If you are experiencing difficulty with their functioning, please contact your computer manufacturer for information on compatibility and functionality of Power Management keys on your system. - Page 5 Product Features cont. F-Lock: Activates MS Office hot keys. My Music: Opens your “My Music” folder. Note: This feature does not work in Windows 98 SE. Media: Opens your default Media Player for music only. Back: In Windows Media Player, moves you back one track or to the beginning of the current track.
- Page 6 Product Features cont. Office Hot Key Features: With your F-lock key on, F1 through F12 turn into Office hot keys. F1 = New F2 = Open F3 = Save F4 = Close F5 = Print F6 = Undo F7 = Redo F8 = Help F9 = Reply F10 = Forward...
-
Page 7: Quick Installation Setup For Ps/2 Connections (Pc-Only)
Quick Installation Setup for PS/2 Connections (PC-only) Be sure that your computer is powered off. Connect the receiver to your computer’s PS/2 ports. The receiver has a two-head connector for the Keyboard and Mouse connections (purple is for the Keyboard and the USB connection;... - Page 8 Quick Installation Setup for PS/2 Connections (PC-only) cont. Power on your computer. The receiver automatically scans for and synchronizes the Keyboard and Mouse when you power on the computer. Your Keyboard and Mouse should now be functioning. If synchronization does not occur automatically, please refer to the information on “Synchronizing”...
-
Page 9: Quick Installation Setup For Usb Connections (Pc Or Mac Computers)
Quick Installation Setup for USB Connections (PC or Mac Be sure that your computer is powered on. If you are running Windows 98, Me, or 2000, you will need to have your old keyboard and mouse connected during the installation. Connect only the receiver to your computer with the USB connector. - Page 10 Quick Installation Setup for USB Connections (PC or Mac computers) cont. The receiver automatically scans for and synchronizes the Keyboard and Mouse when you power on the computer. Your Keyboard and Mouse should now be functioning. If synchronization does not occur automatically, please refer to the information on “Synchronizing”...
-
Page 11: Software Driver Installation For Windows 98, Me, 2000, And Xp
Note: If you have previously installed any keyboard or mouse driver on your computer, you must uninstall it/them before proceeding with this installation procedure. Insert your F8E829-BNDL software into your CD/DVD driver on your computer. The installation wizard window should appear and installation should begin automatically. -
Page 12: About Your Belkin Software
About your Belkin Software The F8E829-BNDL software provides a suite of tools that will enhance your Belkin Wireless Keyboard and Optical Mouse experience. It allows you to customize your hot keys and gives you quick access to your media keys, as well as other short cuts. -
Page 13: Function Setting
About your Belkin Software Function Setting... - Page 14 About your Belkin Software Function Setting cont. Click on the “Select a Hot Key” drop-down list to choose programmable hot keys including WWW, E-mail, Search, My Documents, My Computer, To Desktop, and Calendar. “Hot Key Label” allows you to assign a name for your hot key sequence.
-
Page 15: Display Setting
About your Belkin Software Display Setting... - Page 16 About your Belkin Software Display Setting cont. “Taskbar icons” displays selected icons in the task bar’s pop-up menu. “Hot Key Label Setting” configures the way your label will be displayed on bottom-right corner of screen when you use the hot key.
-
Page 17: Battery Power
About your Belkin Software Battery Power “Keyboard Battery Power” shows battery power status. -
Page 18: Mouse Properties Manager
About your Belkin Software Mouse Properties Manager Six Tabs Comprise your Mouse Properties Manager: • Buttons • Pointers • Pointer Options • Magic Wheel • Scroll Speed • Battery Power... - Page 19 About your Belkin Software Mouse Properties Manager cont. Magic Wheel...
- Page 20 About your Belkin Software Mouse Properties Manager cont. “Select a Button” is a drop-down list for button assignment. Button 1 Button 2 Button 3 “Function Assignment” provides five modes of functioning for the Mouse. (Refer to image on page 17)
- Page 21 About your Belkin Software Mouse Properties Manager cont. Magic Wheel Performs 10 Functions: Fixed functions: 5 fixed functions for Internet browser: Home Page Stop Refresh Back Forward Programmable functions: 5 programmable functions for you to define. Right-click the button of the Magic Wheel User Interface to...
- Page 22 About your Belkin Software Mouse Properties Manager cont. Internet Function: A drop-down menu for you to select the functions Favorites or Search. My Web Site: You can type in your favorite website and launch it with the default Internet browser.
-
Page 23: Synchonizing The Receiver With The Keyboard And Mouse
Synchronizing the Receiver with the Keyboard and Mouse Press the connect button on top of the receiver, then press the button on the bottom of the Keyboard within 10 seconds. - Page 24 Synchronizing the Receiver with the Keyboard and Mouse cont. Press the connect button on top of the receiver, then press the connect button on the bottom side of the Mouse within 10 seconds. If the Keyboard did not connect, please repeat step 1. If the Mouse did not connect, please repeat step 2.
-
Page 25: Switching Channels
Switching Channels If interference occurs while using the Keyboard and/or Mouse, switch channels by following the steps below: Keyboard: Press the button on the bottom of the Keyboard to switch channels. Mouse: Press the connect button on the bottom side of the Mouse to switch channels. -
Page 26: Troubleshooting
Troubleshooting If the Keyboard and/or Mouse is/are not working after installation: • Be sure the receiver cables are plugged into either the computer’s PS/2 ports or a USB port. If you are connecting it via PS/2, make sure that both plugs are being used (purple keyboard connector and the USB connection with the green PS/2 adapter). - Page 27 Troubleshooting cont. • Be sure you have properly established communication and synchronization between the receiver and the Mouse and Keyboard. • Be sure that the LED on the receiver flashes when you push any of the Keyboard keys or Mouse buttons, or move the Mouse.
-
Page 28: Information
Belkin Corporation warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 29 Belkin Components B.V. +31 (0) 20 654 7300 Schiphol-Rijk • The Netherlands © 2003 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Mac and Mac OS are trademarks of P74444 Apple Computer, Inc., registered in the U.S. and other countries.
