TOYOTA
TUNDRA D-CAB
Preparation
Part Number: PTS20-34040 (VSE)
PTS20-34041 (Non-JBL Wire Harness)
VSE Kit Contents
Item #
Quantity Reqd.
1
1
4
4
5
1
Wire Harness Bag Contents
Item #
Quantity Reqd.
1
1
2
1
3
14
3
1
Additional Items Required For Installation
Item #
Quantity Reqd.
1
Conflicts
None:
Recommended Tools
Personal & Vehicle
Protection
Vehicle Protection
Part Protection
Special Tools
Installation Tools
Panel Removal Tool
Socket/Ratchet
Socket Extension
Torque Wrench
Pliers
Screwdriver (Manual or
Electric)
Clip Removal Tool
Special Chemicals
Cleaner
Issue: A
08/16/04
Description
Vehicle Specific Enclosure
(VSE) Subwoofer
Product Feature Placard
Service Care Card
Description
Non-JBL Audio VSE Wire
Harness
Instruction sheet
7" Wire Ties
10mm Ground Bolt
Description
Notes
Seat/Floor Covers
Blankets
Notes
Notes
Nylon Removal Tool (NRT)
10mm
6 inch (optional)
3 lbf·ft , and 10 lbf·ft
1. Diagonal Cutters
2. Long Nose (optional)
Magnetized Philips # 2
Notes
TM
3M
Prep Solvent–70 (if
required)
Page 1 of 12 pages
2004 -
VSE SUBWOOFER (NON-JBL)
NOTE: Part number of this accessory may not be
the same as the part number shown.
General Applicability
All Tundra D-Cab Grades w/ NON JBL AUDIO
Recommended Sequence of Application
Item #
Accessory
1a
Install Security/Audio
1b
Install VSE Subwoofer
2
Install Molded Dash
Vehicle Service Parts
Item #
Quantity Reqd.
1
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out t
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
Bass Tube Specifications
Woofer Size
Voice Coil Size
Magnet Size
Frequency Response
Efficiency
Power Handling
Dimensions
Weight
Impedance
*Mandatory
(may be required for reassembly)
Description
6"
1"high power/high
temp.
15 oz.
39 – 85 hz.
105dB
100 watts
18.125" x 8.5" x 10"
14 lbs.
2 ohms DVC
he
