NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference. 169893en.indd 1 169893en.indd 1 User Manual for your...
Description of the appliance ... 7 Using your Baumatic refrigerator ... 9 Arranging and storing food in your refrigerator ... 11 Cleaning and maintenance ... 12 Installation ... 14 Troubleshooting ... 18 Baumatic ltd. - Conditions of guarantee ... 20 12.10.2006 11:41:40 12.10.2006 11:41:40...
Environmental note NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference. for you or any person not familiar with the operation of the appliance.
• Your appliance is only designed to be used in the home. It is suitable for freezing and storing frozen food. If it is used for any other purpose or it is not used correctly, then Baumatic Ltd. Will accept no liability for any damage that may be caused.
Page 6
Child safety General safety 169893en.indd 5 169893en.indd 5 situated in should be thoroughly ventilated. • Do not place any objects on top of the appliance, as this may damage the table top. • Packaging material should be kept away from children. •...
169893en.indd 6 You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Baumatic Service Department. Congratulations on purchasing a Baumatic refrigerator •...
Description of the appliance 169893en.indd 7 169893en.indd 7 1. Control panel 2. Fan* 3. Interior light 4. Shelf (adjustable height) 5. Foldable egg rack (closed- 6 eggs, open- 12 eggs). 6. Crisper drawer with pull out guides 7. Door shelves 8.
Page 9
Description of the product features 169893en.indd 8 169893en.indd 8 1) Shelves • The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. • To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove.
169893en.indd 9 169893en.indd 9 • Make sure that it has been installed by a suitably qualifi ed person, as per the information contained in Baumatic’s installation instructions. • After delivery, wait for eight hours before connecting the appliance to your mains supply. This will allow any refrigerant gasses that may have been disturbed during the transportation process, are allowed to settle.
Page 11
Turning on the appliance and setting the thermostat The digital display 169893en.indd 10 169893en.indd 10 You switch on your appliance by connecting it to your mains supply and setting the thermostat. The thermostat is located on the right hand side of the control panel. •...
Arranging and storing food in your refrigerator 169893en.indd 11 169893en.indd 11 • Warm food or evaporating liquids should not be stored in your refrigerator, as this will increase the humidity inside of the appliance. • All foods should be wrapped or covered, this is particularly important if the food has a strong fl...
Cleaning and maintenance 169893en.indd 12 169893en.indd 12 Food Fruit, beef Vegetables, veal, poultry Venison Pork Chopped (minced ) meat Bread, pastry, TV-dinner, fat free fi sh Intestines Smoked sausages, fat fi sh WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT.
Page 14
Defrosting the refrigerator compartment 169893en.indd 13 169893en.indd 13 • Clean the accessories separately with soap and water. Do not clean them in a dishwasher. • Do not sure abrasive products, detergents or soaps. • After washing the appliance, wipe over the area that you have cleaned with a damp cloth and then dry it thoroughly.
fi tted by the factory. • Please dispose of the bulb correctly. • The light bulb is not covered by Baumatic’s guarantee. • Replace the light cover and after waiting fi ve minutes, reconnect your plug to your mains supply.
Page 16
Positioning 169893en.indd 15 169893en.indd 15 marked “E” (earth), or by the earth symbol, or coloured green and yellow. • When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath.
Page 17
Reversing the door of your appliance 169893en.indd 16 169893en.indd 16 Caution! After unscrewing any of the fi xing hinges, hold the door to prevent it from falling and causing damage. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use. Required tools;...
Page 18
169893en.indd 17 169893en.indd 17 • Unscrew, remove and then replace the position of the end switch (E) and decorative peg (F) (for models with forced door closing system). • Unscrew the three screws fi xing the bottom hinge and then fi x the bottom hinge on the opposite side.
OF MY FRIDGE 169893en.indd 18 169893en.indd 18 IMPORTANT: If your refrigerator appears not to be operating properly, before contacting the Baumatic Service Department, please refer to the checklist below. What to do Check that the plug is fully inserted into the power socket.
Page 20
169893en.indd 19 What to do Follow the “Defrosting the refrigerator compartment” section on page 14-15. Contact the Baumatic Service Department on telephone number 0118 933 6911. Contact the Baumatic Service Department on telephone number 0118 933 6911. If the above hints do not seem to cure the diffi culty...
Baumatic appliance. * In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fi tted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date.
Page 22
In the course of the work carried out it may be necessary to remove the appliance from it operating position. Whilst all reasonable care will be taken, Baumatic Ltd cannot accept responsibility for damage sustained to any property whatsoever in this process.
