Sony CDX-1300 Product Guide Specifications

2000 MOBILE PRODUCT GUIDE – PART 1
• X-tal Lock SSIR-EX Tuner
• 18FM + 6AM Presets, Best Tuning Memory
• 8X Oversampling, 1-Bit D/A, CD-R Playback
• Active Servo Control
• Repeat 1/2, Shuffle Play
General
Output Lead
Tone Controls
Power Requirements
Dimensions (w/h/d)
Mounting Dimensions (w/h/d)
Weight
Supplied Accessories
Tuner Section
FM
Tuning Range
Antenna Terminal
Intermediate Frequency
Usable Sensitivity
Selectivity
Signal-to-Noise Ratio
Harmonic Distortion @ 1 kHz
Separation
Frequency Response
CD Player Section
Mechanism Type
Optical Pickup Name
System
Frequency Response
Signal-to-Noise Ratio
Wow and Flutter
Preamplifier Section
Line Outputs
Line Output Impedance
Bus Input Impedance
Max Line Output Level
Power Amplifier Section
Speaker Outputs
Speaker Impedance
Maximum Power Output
RMS Power Output
Distortion
12
CDX-1300
CD Receiver
†
Power Antenna Relay Control, Power Amplifier Control
Bass ±8 dB at 100 Hz; Treble ±8 dB at 10 kHz
12VDC Car Battery (negative ground)
Approx. 188 x 58 x 183 mm (7
Approx. 182 x 53 x 162 mm (7
Approx. 1.2 kg (2 lb. 10 oz.)
Parts for Installation and Connections (1 set)
87.5-107.9 MHz
External Antenna Connector
10.7 MHz
12 dBf
75 dB at 400 kHz
65 dB (stereo); 68 dB (mono)
0.7% (stereo); 0.5% (mono)
35 dB (@ 1 kHz)
30-15,000 Hz
MG-310-153
KSS-521A
Compact Disc Digital Audio System
10-20,000 Hz
90 dB
Below measurable limit
Rear (RCA)(1)
10k ohms
N/A
2.1 Volts, < 1.0% THD
Front/Rear (sure seal connectors)
4-8 ohms
45 W x 4 (@ 4 ohms)
18 W x 4 (20-20kHz, 4 ohms)
1% THD
Design and specifications subject to change without notice.
• D-Bass, Electronic Vol/Bas/Tre/Fad/Bal
• 45 W x 4 High Power, Rear Preout
• 7-seg, 1-Color Negative LCD/Quartz Clock
• Rotary Encoder and Level Control
• Full Detachable Face/60 Degree Mount
1 / x 2 3 / x 7 1 / in.) (including trim)
2 8 4
1 / x 2 1 / x 6 1 / in.)
4 8 2
AM
Tuning Range
Antenna Terminal
Intermediate Frequency
Sensitivity
Harness Plug Configuration
Plug shown with wires facing viewer
Pin Number Wire Color
1 White
2 Green
3 Violet
4 Grey
5 Blue/White
6 Blue
7 Red
8 Black
9 White/Black
10 Green/Black
11 Violet/Black
12 Grey/Black
13 N/C
14 N/C
15 N/C
16 Yellow
530-1,710 kHz
External Antenna Connector
450 kHz
30 µV
Description
Left Front Positive
Left Rear Positive
Right Rear Positive
Right Front Positive
Amp Remote
Antenna Remote
Accessory +12 VDC
Ground
Left Front Negative
Left Rear Negative
Right Rear Negative
Right Front Negative
Constant +12 VDC
