GNSS Module Series
L26-LB EVB User Guide
5

Usage of PowerGPS

PowerGPS tool is used to check the status of GNSS receivers. This chapter illustrates the usage of the
tool.

5.1. COM and Baud Rate Setting

Step 1: After EVB accessories are assembled, turn on the EVB and start PowerGPS (PowerGPS Trial
2.3.6 as an example herein). After the tool is started, the following interface will be displayed.
Figure 13: PowerGPS Interface (Not Connected)
Step 2: At the bottom of the interface, select a correct COM port and baud rate (L26-LB module supports
"Create Connection", and then the following interface in
9600 bps by default), click the button
default layout will be shown:
L26-LB_EVB_User_Guide 18 / 28
