Page 2 CDMA Mobile Subscriber Unit KF600w SERVICE MANUAL SERVICE MANUAL DUAL BAND CDMA [PCS/Cellular/GPS] CDMA MOBILE PHONE...
Page 3: Table Of Contents
Table of Contents General Introduction……………………………………………………………….……………...3 CHAPTER 1. System Introduction ……………..………………………………………...4 1. CDMA Abstract…….……………………………………………………………….….…….…..4 2. Features and Advantages of CDMA Mobile Phone………….........5 3. Structure and Functions of Dual-band CDMA Mobile Phone……………….……….….8 4. Specification……………………………………………………………………………………..9 5. Installation………………………………………………………………………………………14 CHPATER 2. NAM Input Method ………………………………………..……………….16 1.
Page 4: General Introduction
General Introduction General Introduction The KF600w phone has been designed to operate on the latest digital mobile communication technology, Code Division Multiple Access (CDMA). This CDMA digital technology has greatly enhanced voice clarity and can provide a variety of advanced features. Currently, CDMA mobile communication technology has been commercially used in Cellular and Personal Communication Service (PCS).
Page 5: Chapter 1. System Introduction
Chapter1. System Introduction Chapter1. System Introduction 1. CDMA Abstract The CDMA mobile communication system has a channel hand-off function that is used for collecting the information on the locations and movements of mobile telephones from the cell site by automatically controlling several cell site through the setup of data transmission routes, and then enabling one switching system to carry out the automatic remote adjustment.
Page 6: Features And Advantages Of Cdma Mobile Phone
2. Features and Advantages of CDMA Mobile Phone 2.1 Various Types of Diversities When employing the narrow band modulation (30kHz band) that is the same as the analog FM modulation system used in the existing Cellular system, the multi-paths of radio waves create a serious fading. However, in the CDMA broadband modulation (1.25MHz band), three types of diversities (time, frequency, and space) are used to reduce serious fading problems generated from radio channels in order to obtain high-quality calls.
Page 7 2.3 Voice Encoder and Variable Data Speed The bi-directional voice service having variable data speed provides voice communication which employs voice encoder algorithm having power variable data rate between the base station and the mobile station. On the other hand, the transmit voice encoder performs voice sampling and then, creates encoded voice packets to be sent out to the receive voice encoder, whereas the receive voice encoder demodulates the received voice packets into voice samples.
Page 8 Total interference from all the adjacent cell sites is the ratio of interference from all the cell sites versus total interference from other mobile stations in the same cell site (about 65%). In the case of directional cell site, one cell normally uses a 120°sector antenna in order to divide the sector into three.
Page 9: Structure And Functions Of Dual-Band Cdma Mobile Phone
3. Structure and Functions of tri-band CDMA Mobile Phone The hardware structure of CDMA mobile phone is made up of radio frequency (RF) part and logic part. The RF part is composed of Receiver part (Rx), Transmitter part (Tx) and Local part (LO). For the purpose of operating on tri- band, It is necessary dual Tx path, tri Rx path, dual PLL and switching system for band selection.
Page 10: Specification
4. Specification 4.1 General Specification 4.1.1 Transmit/Receive Frequency Interval : 1)CELLULAR : 45 MHz 2)PCS : 80 MHz 4.1.2 Number of Channels (Channel Bandwidth) 1)CELLULAR : 20 Channels 2) PCS : 48 Channels 4.1.3 Operating Voltage : DC 3.3~4.2V 4.1.4 Battery Power Consumption : DC 3.7V SLEEP IDLE MAX POWER...
Page 11 4.2 Receive Specification 4.2.1 Frequency Range CELLULAR : 869.820 MHz ~ 893.190 MHz PCS : 1930 MHz ~ 1990 MHz GPS : 1575.42 MHz 4.2.2 Local Oscillating Frequency Range CELLULAR : 1738.08MHz ~ 1787.94MHz PCS : 1715.56MHz ∼ 1768.89MHz GPS : 3150.84MHz 4.2.3 Sensitivity CELLULAR : -104dBm (C/N 12dB or more) PCS : -104dBm (C/N 12dB or more)
Page 12 4.3.11 CDMA TX Frequency Deviation : 1) CELLULAR: +300Hz or less 2) PCS: ± 150Hz 4.3.12 CDMA TX Conducted Spurious Emissions 1) CELLULAR: 900kHz : - 42 dBc/30kHz below 1.98MHz : - 54 dBc/30kHz below 2) PCS: 1.25MHz: - 42 dBc/30kHz below 1.98MHz : - 50 dBc/30kHz below 4.3.13 CDMA Minimum TX Power Control 1) CELLULAR: - 50dBm below...
Page 13 1860.00 1880.00 1000 1900.00 1861.25 1881.25 1025 1901.25 1862.50 1882.50 1050 1902.50 1863.75 1883.75 1075 1903.75 1865.00 1885.00 1100 1905.00 1866.25 1886.25 1125 1906.25 1867.50 1887.50 1150 1907.50 1868.75 1888.75 1175 1908.75 MS (Mobile Station) Receiver Frequency 4.5.1 CELLULAR mode Ch.
Page 14 1942.50 1962.50 1050 1982.50 1943.75 1963.75 1075 1983.75 1945.00 1965.00 1100 1985.00 1946.25 1966.25 1125 1986.25 1947.50 1967.50 1150 1987.50 1948.75 1968.75 1175 1988.75 4.5.3 GPS mode : 1575.42 MHz 4.5.4 Bluetooth mode : 2400 MHz ~ 2483.5 MHz 4.6 AC Adaptor : See Appendix 4.7 Cigar Lighter Charger : See Appendix...
Page 15: Installation
5. Installation 5.1 Installing a Battery Pack 1) The Battery pack is keyed so it can only fit one way. Align the groove in the battery pack with the rail on the back of the phone until the battery pack rests flush with the back of the phone. 2) Slide the battery pack forward until you hear a “click”, which locks the battery in place.
Page 16 5.3.5.1 Power and Ignition Cables Connect the red wire to the car battery positive terminal and the black wire to the car ground. Connect the green wire to the car ignition sensor terminal. ( In order to operate HFK please make sure to connect green wire to ignition sensor terminal.) Connect the kit’s power cable connector to the interface box power receptacle.
Page 17: Chpater 2. Nam Input Method
CHAPTER 2. NAM Input Method CHAPTER 2. NAM Input Method (Inputting of telephone numbers included) (Inputting of telephone numbers included) 1. NAM Programming Method 1) Press “##83587” and then, press “000000” 2) ESN Press “3”key. You can see the ESN number. 3) Eentering “Service Prg.”...
Page 18 You can edit the NAM1 Phone Number (MDN). Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 5) NAM1 Phone Number (MIN) You can edit the NAM1 Phone Number (MIN). Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 19 You can edit the NAM1 Name. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 8) More NAM1 Programming You can decide to edit more NAM1 Name. Press softkey “OK” to exit Service Programming. Press softkey “More”...
Page 20 10) NAM1 MNC You can edit NAM1 Mobile Network Code. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 11) NAM1 NMSID You can edit NAM1 NMSID. Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 21 You can edit NAM1 True IMSI NMSID. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 14) NAM1 PRL Enabled You can see NAM1 PRL Enabled. Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 22 You can edit NAM1 CDMA Pri. Channel A. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 17) NAM1 CDMA Sec. CH A You can edit NAM1 CDMA Secondary Channel A. Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 23 You can edit NAM1 CDMA Secondary Channel B. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 20) Lockout SID/NID You can edit Lockout SID/NID pair. Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 24 You can edit NAM1 Foreign SID Registration. Press softkey “OK” to edit more NAM1 items. Press softkey “Back” to edit previous NAM1 items. 23) NAM1 Forn NID Reg You can edit NAM1 Foreign NID Registration. Press softkey “OK” to edit more NAM1 items. Press softkey “Back”...
Page 25 25) Slot Cycle Index You can edit Slot Cycle Index. Press softkey “OK” to save Slot Cycle Index. Press softkey “Back” to edit previous items. 26) Powering Down Restart. 27) Press “##83587” and then, press “000000”...
Page 26 28) NAM2 Setting You can edit NAM2 items such as NAM1 items...
Page 27: Chapter 3. Circuit Description
CHAPTER 3. Circuit Description CHAPTER 3. Circuit Description 1. RF Transmit/Receive Part 1.1 Overview The TX and RX part employs the Direct-Conversion system. The TX and RX frequencies are respectively 824.04~848.97 and 869.04~893.97 for cellular and 1850~1910 and 1930~1990 for PCS. The block diagram is shown in [Figure 1-1].
Page 28 [Figure 1-1] RF Block Diagram of CX8800 Logic Device...
Page 29 1.2 Description of RX Part Circuit 1.2.1 Diplexer (U102) The main function of Diplexer is to prohibit the other band signals from flowing into the one band circuit and vice versa. RF designer can use common tri-band antenna regardless of frequency band (800, 1575 and 1900 MHz). The specification of CX8800 Diplexer is described below: Cellular Frequency Range...
Page 30 1.2.3 RFR6500 – LNA part (U112) The RFR6500 has cellular, and PCS LNA, respectively. The characteristics of Low Noise Amplifier (LNA) are low noise figure, high gain, high intercept point and high reverse isolation. The frequency selectivity characteristic of mobile phone is mostly determined by LNA. The specification of CX8800 LNA is described below: Parameter Low gain...
Page 31 1.2.6 RFR6500 - Down-converter Mixers part (U112) The RFR6500 device performs signal down-conversion for Cellular, PCS and GPS tri-band applications. It contains all the circuitry (with the exception of external filters) needed to support conversion of received RF signals to Base- band signals.
Page 32 RFT6150 Cellular and PCS CDMA RF Specifications Parameter Condition Min. Type. Max. Units Average CDMA Cellular Rated Output Power Average CDMA PCS Average CDMA Cellular Min Output Power Average CDMA PCS CDMA Cellular -136 RX band noise power dBm/Hz CDMA PCS -133 Cellular: Fc±885kHz ACPR...
Page 33: Digital/Voice Processing Part
2. Digital/Voice Processing Part 2.1 Overview The digital/voice processing part processes the user's commands and processes all the digital and voice signal processing in order to operate in the phone. The digital/voice processing part is made up of a main keypad/touch keypad/LCD, receptacle part, voice processing part, mobile station modem part, memory part, and power supply part.
Page 34 2.3 Circuit Description 2.3.1 Keypad/LCD and Receptacle Part Once the keypad is pressed, the key signals are sent out to MSM6550 for processing. In addition, when the key is pressed, the keypad/LCD lights up through the use of 7 LEDs. The terminal status and operation are displayed on the screen for the user with the characters and icons on the LCD.
Page 35 D i ple x er...
Page 36 2.3.4 Memory Part MCP contents 2048Mbits NAND FLASH memory and 1024Mbits SDRAM. In the NAND Flash Memory part of MCP are programs used for terminal operation. The programs can be changed through downloading after the assembling of terminals. On the SDRAM data generated during the terminal operation are stored temporarily. 2.3.5 Power Supply Part When the battery voltage (+3.7V) is fed and the PWR key of keypad is pressed, U5002(PMIC) is activated by the PWR_ON_SW signal, and The PWRON signal is held high, Buck and LDO1,2,3 are turned on;...
Page 37: Chapter 4. Trouble Shooting
CHAPTER 4. Trouble Shooting CHAPTER 4. Trouble Shooting 4.1 Rx Part Trouble 4.1.1 DCN Rx Test Point Test Point VCTCXO RFR6500 Diplexer Mobile S/W Check flow Check flow Start Rx TEST SETUP (Joyphone) - Test Channel: 384 - Test Band : US Cellular - SID: 2004 - Sector Power: - 30 dB m Spectrum Analyzer Setting...
Page 38 4.1.1.1 Checking DC Power supply circuit (PMIC) Test Point Test Point C329 R323 Circuit Diagram Circuit Diagram...
Page 39 Checking Flow Checking Flow Start Check C329(TP2) The Problem may be Lo gic part Refer to Logic troubleshoot + 2 .9 V_ RX is OK? Check R323(TP1) The Problem may be Lo gic part +2.6V_MSMP2 is OK? Refer to Logic troubleshoot DC Po wer supply Circuit is OK.
Page 40 4.1.1.2 Checking VCTCXO circuit Test Point Test Point F104 pin4 F104 pin3 Circuit Diagram Circuit Diagram...
Page 41 Checking Flow Checking Flow Start Check F 104 pin3(TP1) VCTCXO circuit is Ok . See next page Is it 19.2MHz? (Refer to to check control signal . figure 4.1.1 (a)) Check F 104 pin4(TP2) The Problem ma y b e Logic part Is it 2.8V? (Refer to R efer to Logic troubles hoot figure 4.1.1 (b))
Page 42 4.1.1.3 Checking Control signal Test Point Test Point U112 pin51(SBCK0) pin50(SBDT0) pin49(SBST0) Circuit Diagram Circuit Diagram...
Page 43 Checking Flow Checking Flow Start Check pin49, 50, 51 at U112 Control signal is Ok . See next page Check if there is any major difference referring to check RF signal path . To Figure 4.1.1 (c), (d) Redownload S/W Check pin49, 50, 51 at U112 Control signal is Ok .
Page 44 4.1.1.4 Checking RF signal path (Mobile S/W, Diplexer, Duplexer) Test Point Test Point L119,L124,C137 DP101 Pin3 U101 Pin2 U102 Pin4 L103,L112 PCS Tx DCN Tx PCS Rx Circuit Diagram Circuit Diagram DCN Rx RFR6500...
Page 45 Checking Flow Checking Flow Start Check pin2(TP1) at U101 Check if there is any major difference referring Replace U101 To Figure 4.1.1 (e). Is any signal detected at that point? Check pin4(TP2) at U102 Check if there is any major difference referring Replace U102 To Figure 4.1.1 (f).
Page 46 Waveform Waveform U101 pin2 4.1.1 (e) U102 pin4 4.1.1 (f) DP101 pin6...
Page 47 4.1.1.5 Checking Rx I/Q data Test Point Test Point U112 Pin7 (RX0_QM) Pin8 (RX0_QP) Pin9 (RX0_IM) Pin10 (RX0_IP) Circuit Diagram Circuit Diagram...
Page 48 Checking Flow Checking Flow Start Check pin7, 8, 9, 10 at U112 Check if there is any major difference referring Replace U 112 To Figure 4.1.1 (h), (i) Redownload S/W, and then recalibrate the Main B/D Check pin7, 8, 9, 10 at U112 Check if there is any major difference referring Replace Main B /D To Figure 4.1.1 (h), (i)
Page 49: Pcs Rx
4.1.2 PCS Rx Test Point Test Point VCTCXO RFR6500 Diplexer Mobile S/W Checking Flow Checking Flow Start Rx TEST SETUP(Joyphone ) - Test C hannel: 675 - Tes t Band : U S PCS - SID: 4182 - Sect or Power: - 30 dB m Spec trum Analyzer Setting Osc illosc ope Setting 3.
Page 50 4.1.2.1 Checking DC Power supply circuit (PMIC) Test Point Test Point C329 R323 Circuit Diagram Circuit Diagram...
Page 51 Checking Flow Checking Flow Start Check C329(TP2) The Problem may be Lo gic part Refer to Logic troubleshoot + 2 .9 V_ RX is OK? Check R323(TP1) The Problem may be Lo gic part +2.6V_MSMP2 is OK? Refer to Logic troubleshoot DC Po wer supply Circuit is OK.
Page 52 4.1.2.2 Checking VCTCXO circuit Test Point Test Point F104 pin4 F104 pin3 Circuit Diagram Circuit Diagram...
Page 53 Checking Flow Checking Flow Start Check F 104 pin3(TP1) VCTCXO circuit is Ok . See next page Is it 19.2MHz? (Refer to to check control signal . figure 4.1.2 (a)) Check F 104 pin4(TP2) The Problem ma y b e Logic part Is it 2.8V? (Refer to R efer to Logic troubles hoot figure 4.1.2 (b))
Page 54 4.1.2.3 Checking Control signal Test Point Test Point U112 pin51(SBCK0) pin50(SBDT0) pin49(SBST0) Circuit Diagram Circuit Diagram...
Page 55 Checking Flow Checking Flow Start Check pin49, 50, 51 at U112 Control signal is Ok . See next page Check if there is any major difference referring to check RF signal path . To Figure 4.1.2 (c), (d) Redownload S/W Check pin49, 50, 51 at U112 Control signal is Ok .
Page 56 4.1.2.4 Checking RF signal path (Mobile S/W, Diplexer, Duplexer) Test Point Test Point C124,L117,C128 U101 Pin2 DP102 Pin3 U102 Pin6 L109,C198,C114 PCS Tx DCN Tx PCS Rx Circuit Diagram Circuit Diagram DCN Rx RFR6500...
Page 57 Checking Flow Checking Flow Start Check pin2(TP1) at U101 Check if there is any major difference referring Replace U101 To Figure 4.1.2 (e). Is any signal detected at that point? Check pin4(TP2) at U102 Check if there is any major difference referring Replace U102 To Figure 4.1.2 (f).
Page 58 Waveform Waveform U101 Pin 2 4.1.2 (e) U102 Pin 6 4.1.2 (f) DP102 Pin 3...
Page 59 4.1.2.5 Checking Rx I/Q data Test Point Test Point U112 Pin7 (RX0_QM) Pin8 (RX0_QP) Pin9 (RX0_IM) Pin10 (RX0_IP) Circuit Diagram Circuit Diagram...
Page 60 Checking Flow Checking Flow Start Check pin7, 8, 9, 10 at U112 Check if there is any major difference referring Replace U 112 To Figure 4.1.2 (h), (i) Redownload S/W, and then recalibrate the Main B/D Check pin7, 8, 9, 10 at U112 Check if there is any major difference referring Replace Main B /D To Figure 4.1.2 (h), (i)
Page 61: Tx Part Trouble Shooting
4.2 Tx Part Trouble 4.2.1 DCN Tx Test Point Test Point DCN_Tx SAW filter RFT6150 DCN PAM Diplexer DCN_Duplexer Mobile S/W Checking Flow Checking Flow Start 4. Check RF SAW Press “##5473784236368” + “SEND” key + “000000” in Phone idle state. 5.
Page 62 4.2.1.1 Checking DC Power supply circuit (PMIC) Test Point Test Point C325 R323 Circuit Diagram Circuit Diagram...
Page 63 Checking Flow Checking Flow Start The Problem may be Lo gic part Check C325(TP2) Refer to Logic trouble shoot + 2 .9 V_TX is OK? Check R323(TP1) The Problem may be Lo gic part + 2 .6V_MSMP2 is OK? Refer to Logic trouble shoot DC Po wer supply Circuit is OK.
Page 64 4.2.1.2 Checking VCTCXO circuit Test Point Test Point F104 pin4 F104 pin3 Circuit Diagram Circuit Diagram...
Page 65 Checking Flow Checking Flow Start Check F 104 pin3(TP1) VCTCXO circuit is Ok . See next page Is it 19.2MHz? (Refer to to check control signal . figure 4.2.1 (a)) Check F 104 pin4(TP2) The Problem ma y b e Logic part Is it 2.8V? (Refer to R efer to Logic troubles hoot figure 4.2.1 (b))
Page 66 4.2.1.3 Checking RFT6150 circuit Test Point Test Point CELL_OUT PIN23 PIN15 TCXO TX_QP PIN 27 TX_QM PIN 28 U113 PIN 29 PIN 30 TX_IP PIN 1, 2, 3, 4 TX_IM TX_ON, SBCK0, SBDT0, SBST0 Circuit Diagram Circuit Diagram...
Page 67 Checking Flow Checking Flow Start Check pin23(TP1) at U113 Check if there is any major difference referring RFT6150 circuit is OK. See next page To Figure 4.2.1(c ). Is it similar? Check I/Q data(TP2) at U113 Check if there is any major difference referring Check U 201 MSM6550 To Figure 4.2.1 (d ).
Page 68 Waveform Waveform Graph 4.2.1(c) Graph 4.2.1 (f) Tx_IP & Tx_IM Tx_IP & Tx_QP Graph 4.2.1(d) Graph 4.2.1 (e)
Page 69 4.2.1.4 Check DCN RF Tx SAW Test Point Circuit Diagram Test Point Circuit Diagram F106 RF_IN RF_OUT Checking Flow Waveform Checking Flow Waveform Start RF_IN fed up with CW signal RF_IN Check pin1(TP1) Check at F 106 . Referring to U113(RFT6150) Figure 4.2.1(g) Is it similar ?
Page 70 4.2.1.5 Check DCN PAM circuit Test Point Test Point RFIN_CELL VMODE VEN_CELL VBATT VCCA RFOUT_CELL Circuit Diagram Circuit Diagram...
Page 71 Checking Flow Checking Flow Start Check pin 7 (TP2) at U110 Check if there is any major difference referring PAM circuit is OK. See next page To Figure 4.2.1(i) Is it similar? at U110 ( Vcc) Check pin 5 (TP3) Check Vcc line whether it is higher than 3.4V.
Page 72 4.2.1.6 Check DCN Duplexer Test Point Circuit Diagram Test Point Circuit Diagram TX_PORT DP101 ANT_PORT Checking Flow Waveform Checking Flow Waveform Start Tx Port Check pin1(TP1) , 6(TP2) Duplexer is at DP 101 . Referring to Figure 4.2.1(j) Is it similar ? Replace DP 101 ANT Port Figure 4.2.1(j)
Page 73 4.2.1.7 Check Diplexer Test Point Circuit Diagram Test Point Circuit Diagram Ant Port U102 DCN Port Checking Flow Waveform Checking Flow Waveform Start DCN Port Check pin2(TP1) at U102, Diplexer is pin6(TP2) at DP101. Referring to Figure 4.2.1(k) Is it similar ? Replace U102 ANT Port Figure 4.2.1(k)
Page 74 4.2.1.8 Check Mobile S/W Test Point Circuit Diagram Test Point Circuit Diagram RF IN RF OUT Checking Flow Waveform Checking Flow Waveform Start RF IN Check pin1(TP1) , 2(TP2) Mobile S/W is at U101 . Referring to Figure 4.2.1(l) Is it similar ? Replace U101 RF OUT Figure 4.2.1(l)
Page 75: Pcs Tx
Test Point Test Point PCS_Tx SAW filter RFT6150 PCS PAM Diplexer DCN_Duplexer Mobile S/W Circuit Diagram Circuit Diagram Start 4. Check RF SAW Press “##5473784236368” + “SEND” key + “000000” in Phone idle state. 5. Check Press “6” to enter FCC Test RF Dual PAM Press “2”...
Page 76 4.2.2.1 Checking DC Power supply circuit (PMIC) Test Point Test Point C325 R323 Circuit Diagram Circuit Diagram...
Page 77 Checking Flow Checking Flow Start The Problem may be Lo gic part Check C325(TP2) Refer to Logic trouble shoot + 2 .9 V_TX is OK? Check R323(TP1) The Problem may be Lo gic part + 2 .6V_MSMP2 is OK? Refer to Logic trouble shoot DC Po wer supply Circuit is OK.
Page 78 4.2.2.2 Checking VCTCXO circuit Test Point Test Point F104 pin4 F104 pin3 Circuit Diagram Circuit Diagram...
Page 79 Checking Flow Checking Flow Start Check F 104 pin3(TP1) VCTCXO circuit is Ok . See next page Is it 19.2MHz? (Refer to to check control signal . figure 4.2.2 (a)) Check F 104 pin4(TP2) The Problem ma y b e Logic part Is it 2.8V? (Refer to R efer to Logic troubles hoot figure 4.2.2 (b))
Page 80 4.2.2.3 Checking RFT6150 circuit Test Point Test Point CELL_OUT PIN23 PIN15 TCXO TX_QP PIN 27 TX_QM PIN 28 U113 PIN 29 PIN 30 TX_IP PIN 1, 2, 3, 4 TX_IM TX_ON, SBCK0, SBDT0, SBST0 Circuit Diagram Circuit Diagram...
Page 81 Checking Flow Checking Flow Start Check pin23(TP1) at U113 Check if there is any major difference referring RFT6150 circuit is OK. See next page To Figure 4.2.2(c ). Is it similar? Check I/Q data(TP2) at U113 Check if there is any major difference referring Check U 201 MSM6550 To Figure 4.2.2 (d ).
Page 82 Waveform Waveform Graph 4.2.2(c) Graph 4.2.2 (f) Tx_IP & Tx_IM Tx_IP & Tx_QP Graph 4.2.2(d)
Page 83 4.2.2.4 Check PCS RF Tx SAW Test Point Circuit Diagram Test Point Circuit Diagram RF_IN F105 RF_OUT Checking Flow Waveform Checking Flow Waveform Start RF_IN fed up with CW signal RF_IN Check pin1(TP1) Check at F 105 . Referring to U113(RFT6150) Figure 4.2.2(g) Is it similar?
Page 84 4.2.2.5 Check PCS PAM circuit Test Point Test Point VEN_PCS VMODE RFIN_PCS VBATT RFOUT_PCS VCCA Circuit Diagram Circuit Diagram...
Page 85 Checking Flow Checking Flow Start Check pin2(TP1),7(TP2) at U111 Check if there is any major difference referring PAM circuit is OK. See next page To Figure 4.2.2(i) Is it similar? Check pin4, 12(TP3) at U111 ( Vcc) Check Vcc line whether it is higher than 3.4V.
Page 86 4.2.2.7 Check Diplexer Test Point Circuit Diagram Test Point Circuit Diagram Ant Port PCS Port U102 Checking Flow Waveform Checking Flow Waveform Start PCS Port Check pin3(TP1) at DP102 Diplexer is 2(TP2) at U102 . Referring to Figure 4.2.2(k) Is it similar ? Replace U 102 ANT Port Figure 4.2.2(k)
Page 87 4.2.2.6 Check PCS Duplexer Test Point Circuit Diagram Test Point Circuit Diagram TX_PORT DP102 ANT_PORT Checking Flow Waveform Checking Flow Waveform Start Tx Port Check pin1(TP1) , 3(TP2) Duplexer is at DP 102 . Referring to Figure 4.2.2(j) Is it similar ? Replace DP 102 ANT Port...
Page 88 4.2.2.8 Check Mobile S/W Test Point Circuit Diagram Test Point Circuit Diagram RF IN RF OUT Checking Flow Waveform Checking Flow Waveform Start RF IN Check pin1(TP1) , 2(TP2) Mobile S/W is at U101 . Referring to Figure 4.2.2(l) Is it similar ? Replace U 101 RF OUT Figure 4.2.2(l)
Page 89: Logic Part Trouble Shooting
4.3 Logic Part Trouble 4.3.1 Power 4.3.1.1 Power-On Trouble Circuit Diagram Circuit Diagram L301 +1.4_MSMC L302 +1.8_MSMP1 R323 +2.6V_MSMP2 R324 +2.6V_MSMA +2.9V_RX R327 +2.8V_TCXO C329 Test point Test point +2.9V_RX U301 +2.8V_TCXO +2.6V_MSMA +2.6V_MSMP2 +1.8V_MSMP1 +1.4V_MSMC...
Page 90 Checking Flow Checking Flow START Charge of Change Battery and try again Check battery voltage > 3.4V Push power - on key and Check the contact of power-key check the level change of U301 PWR_ON Check the voltage of the following port at U301 +1.4V_MSMC Replace U301 +1.8V_MSMP 1...
Page 91 Circuit Diagram Circuit Diagram +5V_USB +5V_CHAR Battery Vcc +VPWR Test point Test point U302 +5V_USB of C343 +5V_CHAR of D301 pin1 Q305 Pin4 CON 302...
Page 92 Checking Flow Checking Flow START Charging Connector CON501 Re-soldering CON501 Well-soldered? of D301 Voltage at Pin1 The charging adaptor (TA) or USB cable(USB port CON302 of Pin4 = 5V? of computer) is out of order. 0.1V < Voltage of CHAR_MON< 1.22V Replace U301 Voltage of pin 4 CON302 = Check the soldering...
Page 93: Dsp
4.3.2 DSP 4.3.2.1 DSP Trouble Circuit Diagram Circuit Diagram R701 Clock out – 28MHz C703 DSP_RESET/ TP700 TP701 TP702 TP703 TP704 TP705...
Page 94 R415 +1.8V_DSP_IO1 R416 +1.2V_DSP_CORE1 R426 R427 +1.2V_DSP_IO2 +2.6V_DSP_IO2 Test point Test point R426 C703 R701 TP704 TP702 TP701 R415 TP703 R416 TP700 TP705...
Page 95 Checking Flow Checking Flow START Check the voltage of the following LDOs Replace U406, U407, U410, U411 +1.2V_DSP_CORE1 , +1.2V_DSP_CORE2 , +1.8V_DSP_IO1 +2.6V_DSP_IO2 Check DSP Clock at R701 Replace X701 Check the control signal Replace U701 TP700 ~TP705 & C703 DSP will operate properly...
Page 96: Lcd
4.3.3 LCD 4.3.3.1 LCD Trouble Circuit Diagram Circuit Diagram Check point - The assembly status of the LCD Module - The assembly status of the main connector - The Soldering of connector F603 F601 F606 F605 F604 F602 LCD Control signals From DSP : LCD_D[0:15], MLCD_CS/, SLCD_CS/, LCD_WE From MSM : LCD_RESET/, Test point...
Page 97 Checking Flow Checking Flow START Does LCDwork properly Change the LCDModule Check the DSP Trouble (4.3.2) Replace U701 Check theV oltage of R325 = 2.8V? Replace U301 Check the Con trol signal Data [ 0:15] Check F601 ~ F606(Signal line ) LCD_RESET/, LCD_CS/, WE/ Check CON 601soldering Re-solderCON601...
Page 98: Camera
4.3.4 Camera 4.3.4.1 Camera Trouble Circuit Diagram Circuit Diagram R602 CAM_SDA R601 CAM_SCL R619 CAM_MCLK R620 C619 CAM_PCLK CAM_RESET/ R617 +1.8V_CAM_DVDD R318 +1.8V_CAM_IO R618 +2.8V_CAM_AVDD Test point F607 F608 Test point R618 R617 R601 R602 U604 C619 R619 R620...
Page 99 Checking Flow Checking Flow START Check the DSP Trouble Replace U701 or Main board Check the clock from Camera Replace the Camera module at R620; CAM_PCLK Check the Voltage of the following LDOs: +1.8V_CAM_DVDD, Replace U604, U301 +1.8V_CAM_IO, +1.8V_CAM_A Check the Control signal Check F608, F607, C619, R601, R602 CAM_DATA[0:7], CAM_RESET/, (Signal line)
Page 100: Audio
4.3.5 Audio 4.3.5.1 Speaker Trouble Circuit Diagram Circuit Diagram R410 Level C431 HPH_L C432 HPH_R translated clock R403 +2.8V_TCXO CODEC part R413 R409 +3.0V_DSP_SD +1.8V_MSMP1 MIC Analog S/W part R414 +VPWR Headset Amp. part...
Page 101 Test point Test point R403 R410 R409 R413 U409 R414 C431 C432 U404 Checking Flow Checking Flow START Check the DSP Trouble Check the soldering at Check audio signal at C 431, C432 Replace MSM or Main B/D C431, C432 Resolder C431.
Page 102 Circuit Diagram Circuit Diagram C616 RCV+ C617 RCV- Test point Test point C616 C617...
Page 103 Checking Flow Checking Flow START Check the soldering at Check audio signal at C616, C617 Replace MSM or Main B/D C616, C617 Resolder C616, C617 Check whether the internal lines of FPCB are open or not between the pin Replace FPCB 46/47 of 50pin connector and the receiver pad RCV+/RCV- Check the soldering of receiver...
Page 104 Circuit Diagram Circuit Diagram Headset Amp. part C434 EAR_L C433 EAR_R R425 +2.6V_MSMA EAR_MIC_KEY part U301 PMIC C408 RHP_EJ C412 LHP_EJ 4pole Earjack part...
Page 105 Test point Test point C408 C412 CON401 C434 C433 R425 U404 U409...
Page 106 Checking Flow Checking Flow START Insert 4pole headset to 4pole earjack Does the audio profile of : Headset detect the phone change to the headset Mode? problem Set the audio part of the test equipment to echo mode Can you hear your Change headset voice from headset ? and try again...
Page 107 Checking Flow: Headset receiving path problem Checking Flow: Headset receiving path problem Check the soldering at Check audio signal at C431, C432 Redownload S/W C431, C432 Resolder C431. C432 Check the soldering at Resolder U409 Check the audio signal at C433 , C434 C433, C434 with heat gun Resolder C433, C434...
Page 108 Checking Flow: Headset detect problem Checking Flow: Headset detect problem Check the voltage at pin4 of Check the soldering of CON401 CON401 Whether its range is 1.65~2.1V Resolder CON401 with heat gun Replace CON401 Check Redownload S/W EAR_JACK_SENSE/ is low?
Page 109 Checking Flow: Headset sending path problem Checking Flow: Headset sending path problem Level of pin4 of CON401 Re-solder Is 1.65~2.10V? CON401 Does it work? Download SW Change main Does it work well? board...
Page 110 Circuit Diagram Circuit Diagram CON602 MIC Bias MIC+ MIC Network MIC- MIC PAD + MIC PAD -...
Page 111 Test point Test point MIC Network U408 R538...
Page 112 Checking Flow Checking Flow Setting: After initialize 5515C,and then test handset. START Check the voltage of 3pin of U408 Check the soldering at Replace MSM or Main B/D Whether its range is 1.2~1.5V U408 Resolder U408 Check the signal level at Resolder U408 Each side of MIC Check the signal level at 4 pin of U408...
Page 113: Backlight
4.3.6 Backlight 4.3.6.1 Numeric key backlight Circuit Diagram Circuit Diagram LED902 side LED901 side lighting lighting Q305 LED Switching Tr. Test point Test point Q600...
Page 114 Checking Flow Checking Flow START Is the voltage level of +VPWR Charge battery 3.3 ~ 4.2V? Check the soldering of each R andLEDS, Are all LEDs working ? or replace if not wor king Is Q305 working ? Replace Q 305 Main key backlight w ill work properly...
Page 115 Circuit Diagram Circuit Diagram Sub LCD Charge Pump Sub LCD Charge Pump Main LCD Charge Pump Main LCD Charge Pump Back Light out Back Light out Q305 LED Switching Tr. Single Wire Pulse Control Pin Single Wire Pulse Control Pin Test point Test point C808...
Page 116 Checking Flow Checking Flow START Replace Charge pump Checking the Back Light out Main & Sub ? Checking the Connector (Con601)? Change FPCB Checking the Connector (Con803)? Change FPCB Main key backlight w ill work properly CHANNEL 3= VPWR CHANNEL 4=LCD BACK LIGHT OUT...
Page 117: Vibrator
4.3.7 Vibrator Circuit Diagram Circuit Diagram Motor LDO Motor driving Amp. Motor pwm check Test point Test point R450 MOTOR CONNECTOR Q401...
Page 118 Checking Flow Checking Flow Setting: “ON” at the motor test of “test mode” Start Checking the Motor LDO Voltage 3.1V? Change the LDO U412 Checking PWM SIGNAL(Q401)? Change the MSM Checking The Motor connector ? Change the AMP(U413) Replace Vibrator The vibrator will Work properly Motor + Motor -...
Page 119: Touch Key
4.3.8 Touch key Circuit Diagram Circuit Diagram Checking SCL,SDA,IRQ 2.6V TOUCH POWER Checking Signal X+,X-,Y+,Y- Test point Test point SCL,SDA 2.6V_TOUCH Y-,X- X+,Y+...
Page 120 Checking Flow #1 Checking Flow #1 Start : Make sure that the trouble is about mechanical thing at first. Re assembly touch panel Check the touch panel? Checking the 2.6V touch power ? Replace charge pump(U501) Checking the signal X+,Y+,X-,Y-? Replace touch panel Replace touch IC (U802) Checking the SCL,SDA,IRQ ?
Page 121: Bluetooth Part Trouble Shooting
4.4 Bluetooth Part Trouble Test Point Test Point C519(TP3) U502 C524(TP2) R513(TP4) C525(TP1) C524(TP2) Circuit Diagram Circuit Diagram C519(TP3) R513(TP4) C525(TP1)
Page 122 Checking Flow Checking Flow Start 1. Press ##5473784236368 + SEND Key ( to set Bluetooth Test Mode) 2. Press #5. FCC Test 3. Press #3. Bluetooth FCC 4. Press #8. DUT Mode Compare with Figure 1. Check VCTCXO circuit. Is it similar? Check VDD_MSM.
Page 123: Chapter 5. Safety
CHAPTER 5. Safety CHAPTER 5. Safety ▣ IMPORTANT Read This Information Before Using Your Hand-Held Portable Cellular Telephone First introduction in 1984, the hand-held portable Cellular telephone is one of the most exciting and innovative electronic products ever developed. With it you can stay in contact with your office, your home, emergency service, and others. For the safe and efficient operation of your phone, observe these guidelines.
Page 124 ▣ Driving Check the laws and regulations on the use of Cellular telephones in the areas where you drive. Always obey them. Also, when using your phone while driving, please: Give full attention to the driving. Use hands-free operation, if available, and pull off the road and park before making or answering a call if driving conditions require.
Page 125 Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle which contains your phone or accessories. Vehicles using liquefied petroleum gas (such as propane or butane) must compl7y with the National Fire Protection Standard (NFPA-58). For a copy of this standard, contact the National Fire Protection Association, One Battery march Park, Quincy, MA 02269, Attn: Publication Sales Division.
Page 126: Chapter 6. Glossary
CHAPTER 6. Glossary CHAPTER 6. Glossary General Terms Abbreviated Alert. An abbreviated alert is used to remind the mobile station user that previously selected alternative routing features are still active. AC. See Authentication Center. Access Attempt. A sequence of one or more access probe sequences on the Access Channel containing the same message.
Page 127 Analog Access Channel. An analog control channel used by a mobile station to access a system to obtain service. Analog Color-Code. An analog signal (see Supervisory Audio Tone) transmitted by a base station on an analog voice channel and used to detect capture of a mobile station by an interfering base station or the capture of a base station by an interfering mobile station.
Page 128 CDMA Channel Number. An 11-bit number corresponding to the center of the CDMA frequency assignment. CDMA Frequency Assignment. A 1.23MHz segment of spectrum centered on one of the 30KHz channels of the existing analog system. Code Channel. A subchannel of a Forward CDMA Channels. A Forward CDMA Channel contains 64 code channels. Code channel zero is assigned to the Pilot Channel.
Page 129 Discontinuous Transmission (DTX). A mode of operation in which a mobile station transmitter autonomously switches between two transmitter power levels while the mobile station is in the conversation state on an analog voice channel. Distance-Based Registration. An autonomous registration method in which the mobile station registers whenever it enters a cell whose distance from the cell in which the mobile station last registered exceeds a given threshold.
Page 130 Forward Traffic Channel. A code channel used to transport user and signaling traffic from the base station to the mobile station. A basic timing interval in the system. For the Access Channel, Paging Channel, and Traffic Channel, a frame is 20 ms long.
Page 131 Local Control. An optional mobile station feature used to perform manufacturer-specific functions. A PN sequence with period 242-1 that is used for scrambling on the Forward CDMA Channel and spreading on the Reverse CDMA Channel. The long code uniquely identifies a mobile station on both the Reverse Traffic Channel and the Forward Traffic Channel.
Page 132 Modulation Symbol. The output of the data modulator before spreading. On the Reverse Traffic Channel, 64-ary orthogonal modulation is used and six code symbol (when the data rate is 9600bps) or each repeated code symbol (when the data rate is less than 9600bps) is one modulation symbol. Ms.
Page 133 Ordered Registration. A registration method in which the base station orders the mobile station to send registration related parameters. Overhead Message. A message sent by the base station on the Paging Channel to communicate base-station-specific and system-wide information to mobile station. Overload Class.
Page 134 PN Chip. One bit in the PN sequence. PN Sequence. Pseudonoise sequence. A periodic binary sequence. Power Control Bit. A bit sent in every 1.25ms interval on the Forward Traffic Channel to signal the mobile station to increase or decrease its transmit power. Power Control Group.
Page 135 Response. A layer 3 message generated as a result of another message, typically a request. Reverse Analog Control (RECC). The analog control channel used from a mobile station to a base station. Reverse Analog Voice Channel (RVC). The analog voice channel used from a mobile station to a base station. Reverse CDMA Channel.
Page 136 Soft Handoff. A handoff occurring while the mobile station is in the Mobile Station Control on the Traffic Channel State. This handoff is characterized by commencing communications with a new base station on the same CDMA frequency assignment before terminating communications with the old base station. See also Hard Handoff. SOM.
Page 137 TOLR. See Transmit Objective Loudness Rating. Traffic Channel. A communication path between a mobile station and base station used for user and signaling traffic. The term Traffic Channel implies a Forward Traffic Channel and Reverse Traffic Channel pair. See also Forward Traffic Channel and Reverse Traffic Channel.
Page 138: Appendix
Appendix Appendix Assembly and Disassembly diagram Block and Circuit diagram Part List Component Layout BGA Pin Map...
Page 139 1. Assembly and Disassembly Diagram...
Page 141 2. Block and Circuit Diagram...
Page 142 Internal Use Only VX8800 BLOCK DIAGRAM Power CODEC YMU 800 PMIC MAX 8676 MIC IN EBI1 MSM Core DSP Core 512MBit Mono ARM 926EJ -S 8bit ADC for SDRAM JTAG I /F 48kHz sampling & Li-Ion Linear battery 32bit H/W Video Codec (MPEG 4/H.263) ARM 926EJS A- IN Charger Control...
Page 143 VX8800 Circuit Diagram ( Main/FPCB )
Page 144 Main Board Circuit...
Page 145 Internal Use Only CDMA ANT DCN ANT DCN TX DCN RX PCS ANT PCS TX PCS RX...
Page 146 Internal Use Only...
Page 147 Internal Use Only...
Page 148 Internal Use Only...
Page 149 Internal Use Only...
Page 150 Internal Use Only...
Page 151 Internal Use Only...
Page 152 FPCB Circuit...
Page 153 Internal Use Only...
Page 154 3. Part List...
Page 155 Main PCB Component List Ref No. Part Description Part No. Value Part Name MLAZ00 LABEL MLAZ0038301 PID Label 4 Array LG-VX6000 PCB ASSY,MAIN,SMT SAFC00 SAFC0095601 BOTTOM 4 ,-6 dB,Internal, Bluetooth, SMD, Pb ANT501 ANTENNA,MOBILE,FIXED SNMF0036001 ACS2450HFL57 Free ,; ,SINGLE , , ,...
Page 156 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C140 CAP,CERAMIC,CHIP ECCH0002001 100000 pF,6.3V ,K ,B ,HD ,1005 ,R/TP C1005JB0J104KT C141 CAP,CERAMIC,CHIP ECCH0002001 100000 pF,6.3V ,K ,B ,HD ,1005 ,R/TP C1005JB0J104KT C142 CAP,CERAMIC,CHIP...
Page 157 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C175 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK C176 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT C177 CAP,CERAMIC,CHIP ECCH0002001 100000 pF,6.3V ,K ,B ,HD ,1005 ,R/TP C1005JB0J104KT C178...
Page 158 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C211 CAP,CERAMIC,CHIP ECCH0002001 100000 pF,6.3V ,K ,B ,HD ,1005 ,R/TP C1005JB0J104KT C212 CAP,CERAMIC,CHIP ECCH0002001 100000 pF,6.3V ,K ,B ,HD ,1005 ,R/TP C1005JB0J104KT C213 CAP,CERAMIC,CHIP...
Page 159 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C401 CAP,TANTAL,CHIP ECTH0003701 10 uF,6.3V ,M ,L_ESR ,1608 ,R/TP TCSCM0J106MJAR C402 CAP,CHIP,MAKER ECZH0001121 470 pF,50V ,K ,X7R ,HD ,1005 ,R/TP C1005X7R1H471KT C405 CAP,CERAMIC,CHIP...
Page 160 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C605 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT C610 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT C612 CAP,CERAMIC,CHIP...
Page 161 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C728 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT C729 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT CONN,JACK/PLUG,E CON401...
Page 162 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name 881.5 F102 FILTER,SAW SFSY0030001 SAFEB881MFM0F00 MHz,1.35*1.05*0.6 ,SMD ,DCN_Rx_SAW 1960 MHz,1.4*1.1*0.6 ,SMD ,1930M~1990M, IL F103 FILTER,SAW SFSY0034601 SAFEB1G96FL0F00 3.3, 5pin, U-B, 50-100, USPCS Rx ,;...
Page 163 INDUCTOR,CHIP ELCH0010401 2.2 uH,M ,1005 ,R/TP , LK10052R2K-T L137 INDUCTOR,CHIP ELCH0001424 5.6 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL5N6J L303 FILTER,EMI/POWER SFEY0001602 SMD ,LG-P610 KNH21104 SSOP5-P-0.65A ,5 PIN,R/TP ,INVERTER, Q101 EUSY0073401 TC7SH04FU Pb Free Q304 TR,BJT,ARRAY EQBA0000601 UMT5 ,.2 W,R/TP , KRX102U 1206-8 ChipFET ,1.25 W,-20 V,-3.8...
Page 164 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name R109 RES,CHIP,MAKER ERHZ0000457 30 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ300 R110 RES,CHIP,MAKER ERHZ0000522 24 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJX240 R111 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1202...
Page 165 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name R216 RES,CHIP,MAKER ERHZ0000281 39.2 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF3922 R217 RES,CHIP,MAKER ERHZ0000204 100 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1003 R218 THERMISTOR SETY0001401 NTC ,68 Kohm,SMD , NCP18WD683E03RB...
Page 166 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name R708 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ104 R718 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ101 R719 RES,CHIP,MAKER ERHZ0000433 180 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ184...
Page 167 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name DFN ,8 PIN,R/TP ,Li-ion charger IC, 8 Ld U302 EUSY0292601 2 x 3 DFN, Pb-free ISL6294 SON1612 ,6 PIN,R/TP ,3.3V, 150mA U402 EUSY0333001 LDO Pb-Free, Active High...
Page 168 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C325 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT C326 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT C327 CAP,CERAMIC,CHIP...
Page 169 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name C433 CAP,CHIP,MAKER ECZH0001216 220 nF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A224KT C434 CAP,CHIP,MAKER ECZH0001216 220 nF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A224KT C435 CAP,CERAMIC,CHIP...
Page 170 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name WHITE ,ETC ,R/TP ,SIDEVIEW ,; ,[empty ] ,2.9~3.75 ,30mA , , ,120mW ,[empty] ,[e LED301 DIODE,LED,CHIP EDLH0013701 mpty] ,2P LEWWS44PA WHITE ,ETC ,R/TP ,SIDEVIEW ,;...
Page 171 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name R411 RES,CHIP,MAKER ERHZ0000506 6800 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ682 R412 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ513 R417 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1202...
Page 172 Internal Use Only Main PCB Component List Main PCB Component List Ref No. Part Description Part No. Value Part Name Micropak ,6 PIN,R/TP ,Single SPDT U408 EUSY0186502 FSA4157L6X Analog Switch, Pb Free WCSP ,16 PIN,R/TP ,80-mW Capless U409 EUSY0261501 TPA4411YZH Stereo Headphone Driver SON1612-6 ,6 PIN,R/TP ,2.6V, 150mA U410...
Page 173 Internal Use Only Internal Use Only FPCB Component List FPCB Component List Ref No. Part Description Part No. Value Part Name SACC00 ASSY,FLEXIBLE,SMT SACC0034001 BOTTOM C801 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT C802 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT C803 CAP,CHIP,MAKER...
Page 174 4. Components Layout...
Page 175 F103 F102 U102 F104 DP102 PCS RX SAW FILTER DCN RX SAW FILTER CON702 DIPLEXER PCS DUPLEXER VCTCXO U106 U103 CON602 SAFEB1G96FL0F00 SAFEB881MFM0F00 SLF-S080HL TG-5010LH(19.2M)-75A SD CARD SOCKET GPS MOBILE S/W GPS LNA Module ACMD-7402 24PIN CAMERA Can't receive signal Can't receive signal GCC111-8S-S-E1000 Can't make a call...
Page 176 U301 U405 U412 U413 MAX8676ELB+ HALL EFFECT SWITCH MOTOR LDO AUDIO AMP Internal Use Only No Power on A3212EELLT-T R1114D311D-TR-F LM4923LQX No charge Can't detect Folder open Can't operate Motor No Audio U604 SUB LCD CHARGE PUMP SC624 No Sub LCD Backlight U409 STEREO HAEDPHONE DRIVER TPA4411YZH...
Page 177 Internal Use Only...
Page 178 Internal Use Only...
Page 179 5. BGA Pin Map...
Page 180 Internal Use Only MSM6550-V5 (EUSY0216903) U201 Used Not used PIN #A1 corner...
Page 181 Internal Use Only MV8635 (EUSY0330801) U701 PIN #A1 corner Used Not used...
Page 182 Internal Use Only YMU800-WZ (EUSY0306402) U404 Used Not used PIN #A1 corner...

LG KF600w Service Manual

CHAPTER 1. System Introduction

CHAPTER 3. Circuit Description

CHAPTER 4. Trouble Shooting

CHAPTER 5. Safety

CHAPTER 6. Glossary

Appendix

Quick Links

Troubleshooting

Related Manuals for LG KF600w

Summary of Contents for LG KF600w

Table of Contents
