D-Link DWM-311 User Manual page 15

4G Modem
IP Type
IP Mode
PIN Code
MTU Setup
Keep Alive
Static IP Configuration
Item
IP
Subnet Mask
Default Gateway
Primary DNS
Secondary DNS
1. A Must filled setting
2. By default IPv4 is
selected
1. A Must filled setting
2. By default Dynamic IP
is selected
1. An Optional setting
2. String format :
interger
1. An Optional setting
2. Uncheck by default
1. An optional setting
2. Box is unchecked by
default
Value setting
1. IPv4 format.
2. A Must filled setting
255.255.255.0 (/24) is
set by default
1. IPv4 format.
2. An Optional setting
1. IPv4 format.
2. An Optional setting
1. IPv4 format.
When Auto is selected, it means it will authenticate with the server either
PAP or CHAP.
Specify the IP type of the network service provided by your 3G/4G network.
It can be IPv4, IPv6, or IPv4v6.
Dynamic IP
The unit will get IP from cellular service..
Static IP
The unit will set IP according Static IP Config.
Enter the PIN (Personal Identification Number) code if it needs to unlock your
SIM card.
Check the Enable box to enable the MTU (Maximum Transmission Unit) limit,
and specify the MTU for the 3G/4G connection.
MTU refers to Maximum Transmission Unit. It specifies the largest packet size
permitted for Internet transmission.
Value Range: 68 ~ 1500.
Check the Enable box to activate the keep alive function.
Input IP Address and interval to send an ICMP packet to check the network
status.
Description
The Static IP Address setting of this unit.
The Subnet Mask of this configed static IP.
The gateway setting of this configed static IP.
Assigned DNS server of this configed static IP.
Assigned DNS server of this configed static IP.
15
