Table of Contents
loading

Related Manuals for Hyundai IONIQ plug-in

Summary of Contents for Hyundai IONIQ plug-in

  • Page 1 Car Multimedia System | User’s Manual (영어 | 미국) 디오디오 G2MS7-D6001...
  • Page 2 SiriusXM service at the end dent, severe personal injury, and death. The HYUNDAI multimedia system. Be cautious not to spill water or introduce for- severe personal injury, and death. The driver’s •...
  • Page 3 Read the following safety precautions for your Notations used within this User ’ s Manual safety Before using the product, read the contents of this user’s manual WARNING carefully and use this product safely. • A WARNING indicates that a condition may result in harm, serious bodily injury or death if the warning is ignored. CAUTION • A CAUTION indicates that a condition may result in damage to your ※ T he design and specifications of this product may change without prior vehicle if the caution is ignored.
  • Page 4 HYUNDAI VEHICLE OWNER PRIVACY POLICY Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information. You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at: https://www.hyundaiusa.com/owner-privacy-policy.aspx If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact our Customer Connect Center at: Hyundai Customer Care P .O. Box 20850 Fountain Valley, CA 92728 800-633-5151 consumeraffairs@hmausa.com Hyundai’s Customer Connect Center representatives are available Monday through Friday, between the hours of 5:00 AM and 7:00 PM PST and Saturday and Sunday between 6:30 AM and 3:00 PM PST (English). For Customer Connect Center assistance in Spanish or Korean, representatives are available Monday through Friday between 6:30 AM and 3:00 PM PST.

  • Page 5: Table Of Contents

    Table of Contents 1. Basic 2. Plug-in Hybrid Electric 3. Radio/Media Vehicle (PHEV) Warnings and Cautions ......1-2 FM/AM .............3-2 Starting Plug-in Hybrid mode .....2-2 Component Names and Functions ..1-4 HD Radio™ Technology ......3-4 Head Unit … …………………………… 1-4 Menu screen for Plug-in Hybrid HD Radio™ ……………………………...
  • Page 6 4. Bluetooth 5. Blue Link Control 6. Voice Recognition ® (For Blue Link Model) Before Using the Bluetooth What is Voice Recognition? ....6-2 ® Handsfree ..........4-2 Rear View Mirror Switch ......5-2 Precautions Required for Successful Voice Recognition ........6-2 What is Bluetooth ®...
  • Page 7 9. Setup Siri Eyes Free ........6-13 Sound Settings ........9-2 Keyboard Settings ........9-8 How to start Siri ………………………6-13 Display Settings ........9-3 Screen Saver Settings ......9-9 How to use Siri … ………………………6-13 Bluetooth Settings .........9-3 Advanced Settings .........9-9 Bluetooth Connection ………………… 9-4 System Info ..........9-9 7. Data Services Auto Connection Priority ……………… 9-5 System Update ………………………9-10 SiriusXM™...
  • Page 8 HD Radio™ Technology ® iPod is a registered trademark of Apple Inc. HD Radio™ Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. For patents see http://patents.dts.com/. HD Radio™ and the HD, Bluetooth ® Wireless Technology HD Radio™, and “ARC” logos are registered trademarks or trademarks of The Bluetooth ® word mark and logos are registered trademarks owned iBiquity Digital Corporation in the United States and/or other countries. by Bluetooth SIG, Inc. and any use of such marks by HYUNDAI is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth ® Wireless Technology enabled cell phone is required to use Bluetooth Wireless Technology. Bluetooth ® ® Wireless Technology phone compatibility can be checked by visiting https://www.hyundaiusa.com/ bluetooth.

  • Page 9: Basic

    Basic part.1 Warnings and Cautions Component Names and Functions Starting the System for the First Time...
  • Page 10 Basic Warnings • Do not disassemble, assemble, or mod- • For most Audio and multimedia modes, ify the Multimedia system. Such acts the display will not operate when the Park the vehicle before operating the could result in accidents, fire, or electric vehicle is in motion.
  • Page 11 Cautions Pay attention to traffic conditions while • When cleaning the device, make sure driving. to turn off the device and use a dry and Turn on the car ignition before using this • Upon using the Multimedia system smooth cloth. Never use tough materi- device.

  • Page 12: Head Unit

    Component Names and Functions Head Unit Name Description Name Description • When power is off, press to turn power on. When the key is pressed quickly (less than 0.8 • When power is on, press and hold (over 0.8 seconds), seconds) to turn the power off.
  • Page 13 For Blue Link Model For NON Blue Link Model Name Description Name Description Resets the system settings. (Preset radio channels Moves to the Apps/Info screen. APPS RESET and other data will not be deleted) Moves to the Blue Link mode. DISP Turns the screen on/off.

  • Page 14: Steering Wheel Controls

    Steering Wheel Controls Name Description • Each time this is pressed, the mode is changed in the following order: FM → AM → SiriusXM™ → USB or iPod → AUX → Bluetooth Audio → FM You can select which mode to use in Advanced Settings.
  • Page 15 Name Description When the key is pressed quickly (less than 0.8 sec- onds), • When pressed in the dial screen, makes a call • When pressed in the incoming call screen, answers the call • When pressed during call waiting, switches to waiting call (Call Waiting) When the key is pressed and held (over 0.8 sec- onds),...

  • Page 16: Starting The System For The First Time

    Starting the System for the NOTICE System Reset First Time • You cannot operate the system while it is booting up. It may take some time for all of features of the system, particularly the voice Turning the System On/Off recognition system, to be ready for use.

  • Page 17: Battery Warning Message

    Battery Warning Message Restrictions on Features for Safety Measures Always use the system while the car engine is running. If you turn on the sys- Several features are limited while driving. tem while the engine is off, a battery warn- The restriction screen will disappear when ing message will appear.

  • Page 18: Home Screen

    Home Screen Information Display on the Status Bar Controls Menu Configuration for the Home Screen Displays the date and time, along with the system status shown by Tap the icon on any screen to display the Home Screen below. the various icons to the right of the clock. The icons in the following table indicate the various types of sys- tem status details and events.

  • Page 19: On-Screen Touch Controls

    On-Screen Touch Controls Adding a Feature to My Menu Drag & Drop Select on the Home Screen to Learn how to touch the screen to operate Select a menu or item you want, then drag My Menu add the most frequently used menus, the system.
  • Page 20 Flick (Quick Scrolling) Select and Hold Selecting and holding the button in the music player will rewind or fast forward the music. Quickly moves up and down in the list. NOTICE • Moving the list when there are many items will display a handler on the right of the display.

  • Page 21: Plug-In Hybrid Electric Vehicle (Phev)

    Plug-in Hybrid Electric part.2 Vehicle (PHEV) Starting Plug-in Hybrid mode Menu screen for Plug-in Hybrid mode ECO Driving Energy Information Charging Settings Charging Stations Gas Stations PHEV Settings...
  • Page 22 Plug-in Hybrid Electric Vehicle (PHEV) Starting Plug-in Hybrid mode Menu screen for Plug-in Features Description Hybrid mode D i s p l ay s a r e a l - t i m e PHEV : Plug-in Hybrid Electric Vehicle image for fuel economy or ECO level based on the Select the...

  • Page 23: Eco Driving

    ECO Driving ECO Level Features Description Shows average fuel economy Average according to the vehicle’s Displays fuel economy, information about driving. ECO level, and history of ECO driving. Resets information of the fuel Reset economy graph displayed. Fuel Economy Shows fuel economy for the last 30 minutes (the graph is History updated every 2 minutes and...

  • Page 24: History

    Energy Information History Features Description Current level of battery Battery Gauge charge Displays detailed information about the Time required to com- battery and the flow of energy. Expected plete charging when a Charging Time charging cable is con- Battery Information nected Information •...

  • Page 25: Energy Flow

    Energy Flow Driving Status of Hybrid Mode Hybrid Vehicle Status of power delivery is shown for each The engine’s power and the motor’s power component according to the vehicle’s driv- are both used for driving the vehicle. Idle Mode ing. The vehicle is in the Idle mode with no delivery of power.
  • Page 26 Idle Mode Charging 1 Charging Electric Mode Charging While the vehicle is in the Idle mode, the The deceleration energy from braking is The engine’s power is used for charging engine’s power is used for charging the used for charging the battery. the battery, and the motor’s power is used battery.

  • Page 27: Charging Settings

    Charging Settings Features Description Idle Mode Charging 2 Sets the time when the Both the engine’s power and the decel- Departure car will be driven after Time eration energy from braking are used for This function enables charging to start charging.

  • Page 28: Charging Stations

    Charging Stations Once the settings have been saved, the setting information will be displayed on the screen. Shows the list of nearby EV charging sta- tions within a driving distance. Name Description Check a box to use the respec- tive settings. Select to change the set values.

  • Page 29: Gas Stations

    Gas Stations PHEV Settings Energy Information Search for gas stations. You can change the settings for which real-time information will be displayed on the Home Screen. ECO Driving You can select for the widget to display either information about the battery or the flow of energy.

  • Page 30: Charging Current

    Charging Current The Charging Current for AC Charger 240V mode and AC Charger 120V mode can be set. 2-10 I Plug-in Hybrid Electric Vehicle (PHEV)

  • Page 31: Radio/Media

    Radio/Media part.3 FM/AM HD Radio™ Technology SiriusXM™ iPod ® Bluetooth Audio...

  • Page 32: Fm/Am

    Radio/Media FM/AM Features Description • The stored preset frequencies are displayed for user selection. You can access the radio player either by pressing the RADIO • After selecting frequency, press and hold key or by selecting the Radio menu from on the Home the preset button for over 0.8 seconds.
  • Page 33 Features Description • When the key is pressed quickly (less than 0.8 seconds): Seeks the previous/next frequency. • When the key is pressed and held (over 0.8 SEEK/TRACK seconds): Moves quickly through all of the frequencies. The moment that you release the button, the system seeks the next avail- able frequency.

  • Page 34: Hd Radio™ Technology

    HD Radio™ Technology If an HD Radio™ broadcast is received, Program Info: Presents song name, the radio mode will switch from analog artist, station IDs, and other relevant broadcast to HD Radio™ broadcast. data streams. Information HD Radio™ • screen is displayed only Digital, CD-quality sound.

  • Page 35: Hd Radio

    HD Radio™ Name Description Displays main HD Radio™ channels and used to directly select the current available HD Radio™ channels. Reception & The HD Radio™ related icon display Channel buttons becomes active within regions where an HD Radio™ signal can be received. Analog station and corresponding HD HD Channel Radio™...

  • Page 36: Siriusxm

    SiriusXM™ Features Description • Shows the stored presets for user selection. • After selecting frequency, press and hold You can access the radio player either by pressing the RADIO Preset the preset button for more than 0.8 seconds. key or by selecting the Radio menu option from on the Frequencies A beep sound will be heard and the fre-...
  • Page 37 Features Description Pauses/plays the current broadcasting Play/Pause program. Skip Forward Moves to the next segment. Channel List Moves to the channel list. • Delete Presets: Delete saved radio stations from the preset list. • What is on My Presets? The program schedule saved in my preset. (For more details, see Section 3.9 Viewing Menu.) Menu...

  • Page 38: Selecting Through Channel

    If you select the button, you can Selecting through Skip Viewing Menu scan channels using the Channel/Category List Using the button on the right, you SEEK TRACK Menu key or the knob by skipping the TUNE ▶ Select the Select the can view the program schedule and infor- Channel List channels that you chose to skip.
  • Page 39 Name Description What is on My Presets? (Program Schedule) By selecting this option, you can select a broad- casting date and time zone. Broadcast information will be provided for one week from the current date. Change Broadcast Date Shows saved presets for user selection Preset A total of 40 frequencies for SiriusXM™...
  • Page 40 Featured Favorites Featured Favor ites feature allows SiriusXM™ to broadcast additional pre- sets. • Example 1: “Martha’s Favorites” may represent Martha Stuart’s favorites pre- sets on her radio. • Example 2: During holidays, “Holiday Music” may represent all the SiriusXM™ channels that are playing the holiday music for easy access by users.

  • Page 41: Usb

    • Take caution so that the USB connector does not come in con- tact with body parts or objects. Before Playing a USB MP3 • Repeated connecting/disconnecting of USB devices within short periods of time may result in product malfunction. Connect the USB device after turning on the engine.
  • Page 42 • The device may not operate normally if MP3 Players, cellu- lar phones, digital cameras, or other electronic devices (USB Plug Type Connector devices not recognized as portable disk drives) are connected with the device. • Charging through the USB may not work for some mobile Product Name Manufacturer devices.

  • Page 43: Supported Usb Music Specifications

    Information Supported USB music specifications • The sound quality of audio files that use bitrates exceeding 192 kbps cannot be guaranteed. When using files without fixed bit rates, some Name Description features (FF/REW features) may not operate properly. Audio File MPEG-1/2 layer3 ,OGG (Vorbis), FLAC, WAV, Specification WMA (Standard/Professional)

  • Page 44: Usb Music

    USB Music Features Description • If the button is selected (less than 0.8 seconds): Moves to the previous file or play the current file from the beginning (depends on the play time). – If play time is less than 3 seconds, moves Previous File to previous file.
  • Page 45 Features Description List Moves to the list screen. • Hide Current File: a selected file can be deleted. Deleted file can be found in the ‘Hidden_’ folder. Menu This function is only supported when USB format is compatible with FAT16 or FAT32. •...
  • Page 46 Features Description Folder/ Displays the folder/category name in the list. Category Name Current Song Displays the current playing file name. Back Button Move to the previous screen. Upper Folder/ Moves to Upper Folder/Category. Category Now Playing: When moving to a different list screen, moves to the list page where the cur- Menu rent file is located (becomes disabled when the...

  • Page 47: Ipod

    iPod • If the iPod malfunctions due to an iPod • To prevent this symptom, Bluetooth device defect, reset the iPod and try Audio function in the Multimedia system Using iPod Devices again. (To learn more, refer to your iPod is limited if iPod/iPhone is connected manual) to the system through both cable and...
  • Page 48 • When connecting to iPod Nano/Classic, other categories in iPod mode. charging only. the HYUNDAI logo appears on the • The screen of multimedia system can Apple device. For the iPod Nano 6 gen- be different when you run other music eration, however, the logo image does players (e.g.
  • Page 49 • While using a connected iPhone/iPod • If you control pause, repeat, shuffle, or • If AUX cable connected to iPod/iPhone Touch device, it may not operate nor- seek songs when the play time is less but not connect to the Multimedia sys- mally if the user changed some func- than 3s before the song is finished play- tem, it may occur sound will not output...
  • Page 50 • iPhone and iPod Touch devices are • We recommend that your Apple device guaranteed to work normally on iOS uses the latest firmware since some 9.3.2 or below. However, they may not problems may occur due to an outdated work normally on future iOS versions firmware or other software related as their operations have not yet been...

  • Page 51: Ipod

    iPod Features Description • If the button is selected (less than 0.8 seconds): Moves to the previous file or play the current file from the beginning (Depends on the play time). – If play time is less than 3 seconds, moves to Previous File previous file.
  • Page 52 Features Description List Moves to the list screen. Menu Sound Settings: Moves to the Sound Settings Back Button Move to the previous screen. Turn the knob to search a desired TUNE track. If the desired track is displayed, press knob to play the track. TUNE TUNE If you do not anything with the...
  • Page 53 Features Description Category Name Displays the category name Displays the contents of selected category If there are many items in the list, items are Category List added in order and the scroll bar on the right is adjusted accordingly. Back Button Move to the previous screen.

  • Page 54: Aux

    NOTICE • If only a cable is connected to the AUX without an external device, the mode will be Connecting an External Device changed to AUX, but noise may occur. When If an external device connector is con- an external device is not being used, remove nected with the AUX terminal, then AUX the connector jack.

  • Page 55: Bluetooth ® Audio

    ® Bluetooth Audio Features Description • If play time is less than 3 seconds, moves to the previous file • If play time is over 3 seconds, plays the current Previous File file from the beginning This function may differ depending on the model of mobile phone.

  • Page 56: Bluetooth Connection Settings

    Thus check if the music is playing in the Bluetooth device after changing to audio streaming mode. Audio streaming may not be supported for some mobile phones. • Please check the Bluetooth compatibility in below website: HYUNDAI Motor America https://www.hyundaiusa.com/bluetooth 3-26 I Radio/Media...

  • Page 57: Bluetooth

    Bluetooth part.4 ® Before Using the Bluetooth Handsfree Bluetooth Connection Bluetooth Phone...

  • Page 58: What Is Bluetooth ® Wireless

    For more information on mobile phone ers to make handsfree calls. Connecting ® What is Bluetooth Wireless ® compatibility, visit the HYUNDAI website the head unit with a Bluetooth phone Technology? - HYUNDAI Motor America: https://www. allows the user to conveniently make ®...

  • Page 59: Cautions Upon Connecting

    CAUTIONS upon Connecting • If you do not want automatic connection • The Handsfree call volume and quality ® Bluetooth Phone ® with your Bluetooth device, turn the may differ depending on the mobile ® ® • Before connecting the head unit with Bluetooth feature off of the Bluetooth phone.

  • Page 60: Bluetooth Connection

    Bluetooth Connection Connecting Bluetooth Devices Pairing a New Device Through the Phone Settings Connects the Bluetooth devices that you Pairing a New Device key. ▶ Select Press the add. SETUP Bluetooth ▶ S e l e c t . ▶ S e l e c t Before you can use the Bluetooth feature, Bluetooth Connection .

  • Page 61: Disconnecting Bluetooth Devices

    Disconnecting Bluetooth Deleting Bluetooth Devices Connecting Devices Through the Devices Phone Settings Deletes the Bluetooth devices that you key. ▶ Select . ▶ Press the Disconnects Bluetooth devices that are added. Note that deleting a Bluetooth SETUP Bluetooth . ▶ Select the Select connected.

  • Page 62: Bluetooth Phone

    Bluetooth Phone Information Icons Description • The battery level icon and the call signal You can use Bluetooth phones strength indicator may not be supported in when a Bluetooth Hands-free Phone Status Icons some Bluetooth devices. connection is established. Shows the current phone status in the •...

  • Page 63: Dial

    Dial Accept/Reject Call Name Description ▶ ▶ Use the keypad to enter Select All Menus Phone the phone number that you want to call. Select and hold Keypad the last number of a speed dial to dial a number that you added to the Speed Dial list in the phone.
  • Page 64 Information Using the Menu During a Name Description • If the caller’s number is listed in Contacts, the Phone Call Switches a voice call caller’s name will be displayed. Otherwise, Use Private from the car Hands-free only the number will be displayed. In some to the mobile phone.

  • Page 65: Call History

    Call History Contacts Name Description ▶ ▶ ▶ ▶ Activate the privacy mode Select Select All Menus Phone All Menus Phone to protect your personal Privacy information. In the privacy Mode mode, personal data will not be displayed. Change Search for and connect another Bluetooth device.

  • Page 66: Favorites

    Information Favorites • U p t o 5 0 0 0 p h o n e nu m b e r s c a n b e • The status bar displays a ( ) while ▶ ▶ Select All Menus Phone downloading contacts.

  • Page 67: Blue Link ® Control (For Blue Link Model)

    Blue Link Control ® part.5 (For Blue Link Model) Rear View Mirror Switch Before Use Getting Started with Blue Link...

  • Page 68: Rear View Mirror Switch

    ® Blue Link Control (For Blue Link Model) Rear View Mirror Switch Auto Crash Notification Instructions Contents Display Provides immediate assistance when an Blue Link Selecting the Rear View mirror switch accident occurs and an airbag is deployed. • Starts or ends the will allow you to make service required In this event, an ACN signal, containing cus- Blue Link call.

  • Page 69: Sos

    Stolen Vehicle Recovery Vehicle Immobilization Customers request emergency Blue Link In the event a customer’s vehicle is Used with Stolen Vehicle Recovery, this emergency services by pressing the dedi- reported stolen (and a stolen vehicle enables law enforcement to send a signal cated key in the vehicle.

  • Page 70: Before Use

    Reception of Radio Waves What Is Blue Link? For radio wave transmission/reception status, refer to the status This is a Hyundai telematics service based on our cutting-edge IT displayed on the Blue Link screen. system that makes your driving experience more convenient and...

  • Page 71: Getting Started With Blue Link

    Getting Started with Connecting with the Select from Home Screen display. All Menus Blue Link Blue Link Center ▶ Select icon. Blue Link Press the key in the rear-view Use Blue Link features such as Driving mirror to connect with the Blue Link center. Info and Vehicle Diagnostics.

  • Page 72: Driving Info

    Driving Info Vehicle Diagnostics Blue Link Settings Select from Home Screen display. Displays information such as Driving All Menus For more details, refer to part 9. Setup > ▶ Select . ▶ Time/Idle Time, Deceleration/Acceleration Blue Link Settings. Blue Link Vehicle Diagnostics Distribution, Driving Speed and Driving icon.

  • Page 73: Voice Recognition

    Voice Recognition part.6 What is Voice Recognition? Precautions Required for Successful Voice Recognition Starting/Ending and Setting Voice Recognition Voice Recognition Screen Overview Voice Commands Siri Eyes Free...

  • Page 74: Recognition

    Voice Recognition What is Voice Recognition? Precautions Required 4. The microphone used for the voice for Successful Voice recognition system is located in the Recognition The voice recognition feature operates the headliner directly above the driver’s multimedia system by recognizing voice head.

  • Page 75: Starting Voice Recognition

    Starting/Ending and Setting Ending Voice Recognition Combining Voice Recognition Voice Recognition with On-Screen Commands 1. Select “Exit” to the left of the bottom to After pressing the key, say a com- end voice recognition. Starting Voice Recognition 2. Press and hold (more than 0.8 sec- mand after the beep.

  • Page 76: Extending The Listening Time

    Extending the Listening Time When the system is waiting for your com- mand, after the voice prompt and beep have been heard, if you press the key (less than 0.8 seconds), then the beep will sound again and standby mode will restart.

  • Page 77: Skipping Prompt Messages

    Skipping Prompt Messages Adjusting Voice Recognition Volume When you hear the prompt message, press the key on the steering During voice recognition, rotate the vol- wheel control to skip the message and go ume knob to adjust the message volume. directly to listening mode to say your com- mand.

  • Page 78: Voice Recognition Screen

    Voice Recognition Screen Help Display Name Description Overview Standby Voice Voice guidance recognition Voice command status icons process Recognized Displays the voice rec- results ognition result. User’s speaking Displays the voice com- volume mand level real time as being it is being spoken. recognized Displays all available Name...
  • Page 79 Information Instructions for Using • In the instructions screen, no voice is Voice Recognition recognized, so you must manually issue commands. Because the instructions screen displays a lot of content, you cannot view it while driving for safety precautions. Name Description This section describes Detail...

  • Page 80: Voice Commands

    Voice Commands Command Operation Displays downloaded Contacts, after this ● Call you can make a call by saying the name. Types of Commands You can directly call a person by <Name> ● Voice recognition commands are classified as “Global Commands” Call <Name>...

  • Page 81: Radio Commands

    Radio Commands Command Operation Directly calls at the number that you last ● Redial dialed. Command Operation Displays your Call History, where you can ● Plays the most recent radio channels from Call History ● Radio say the list number to make a call. FM, AM, and SiriusXM™.

  • Page 82: Media Commands

    Media Commands Command Operation ● Music Continues the last media you played. * Check the following before you use media commands. 1. If no media is connected or if no playable files exist at the time Plays the iPod currently connected. This will work the same when an iPhone is con- ●...
  • Page 83 1. USB Music/iPod Command 2. Bluetooth audio/AUX command For Bluetooth audio and external devices (AUX), local commands are unavailable, including Play, Pause, Repeat and Shuffle. Command Operation Plays a selected file. ○ Play Maintains the current settings during playback. Pauses a file that is playing. ○...

  • Page 84: Other Commands List

    Other Commands List (Commands used in List/Help) Command Operation Moves to the voice recognition help screen. ● Help All available commands can then be identified and used. When you cannot select a certain name, such as in Call History, you can select it Line 1~4 ○...

  • Page 85: Siri Eyes Free

    Siri Eyes Free How to use Siri When you access the Siri screen while How to start Siri pressing and holding key on the If you want to use Siri, you have to con- steering wheel control, you can select the nect your iOS device to the Multimedia button and then you can speak Speak...
  • Page 86 MEMO...

  • Page 87: Data Services

    Data Services part.7 SiriusXM™ Data...

  • Page 88: Siriusxm™ Data

    Data Services SiriusXM™ Data SiriusXM™ Weather Announcement The SiriusXM™ Data Service is a paid At the “SiriusXM Data” screen, select membership satellite radio service that icon to enter the Weather Weather provides users with information such as Announcement mode. Weather, Sports, Stocks, Fuel Prices and Weather Forecast Movies.

  • Page 89: Siriusxm™ Sports Information

    SiriusXM™ Sports Information Warnings and Advisories My Teams This service provides weather warnings Select the icon to enter the Sports You can save teams which you are inter- Sports and advisories, such as tornado, storm, mode. ested in as part of My teams to easily view flood, etc.
  • Page 90 Select the team name to check daily results and recent schedules for that team. You can always check the list of teams that you added in the “My Teams” menu. Select the button on the right side of the team name to delete the team from “My Teams”...

  • Page 91: Siriusxm™ Stock Information

    SiriusXM™ Stock Information My Favorites Stock Search In the “SiriusXM Data” screen, select the My Favorites shows a list of stocks added Use the Stock Search menu to search for icon to enter the Stocks mode. by the user. When entering the Stocks specific stocks.

  • Page 92: Siriusxm™ Fuel Price Information

    SiriusXM™ Fuel Price Search for Nearby Stations, and Select the button to the right of the list Information Register Key Locations as Favorite to register key locations as a Favorite Stations. At the “SiriusXM Data” screen, select the Station so that you can go there again with icon to enter the Fuel Prices Search for nearby stations with the “Nearby the “Favorite Stations”...

  • Page 93: Siriusxm™ Movie Information

    SiriusXM™ Movie Information My Fuel Type Settings Search for Nearby Theaters, and Register Any Key Locations as Favorite With the “Filters” menu, you can select fuel Select the icon to enter the Movie Movies Theaters. types and favorite brands. mode. When searching for Nearby Stations, the You can check recent movies and nearby In the “Nearby Theaters”...
  • Page 94 Select the button to the right of the list In the “Top Movies” menu, you can check to register your favorite theater so that you for any movies that are currently popular. Select the button to the right of a can always check it again using the “Favorite Theaters”...

  • Page 95: Other Features

    Other Features part.8 Camera Using Voice memo...

  • Page 96: Camera

    Other Features Camera NOTICE WARNING • The rear view screen remains active while you are backing up. When When backing up, make sure to follow the guidelines below: you move the transmission shift lever to any position other than • Before entering your vehicle, always check the area behind your vehicle. the "R"...

  • Page 97: Steering-Linked Camera

    Steering-linked camera Driving direction lines (yellow) When you put the transmission shift lever These lines show the directions of the in the “R” (Reverse) position while the vehicle according to the steering angle. engine is running, the system screen will automatically display what is behind you.

  • Page 98: Using Voice Memo

    Using Voice Memo Features Description • Delete: Delete voice memos. • Save to USB Device: Save voice memos to You can record voice memos using the microphone installed in a USB storage device. your vehicle and play voice memos on your system.  T his option is available only for USB Menu storage devices formatted in FAT16/32...

  • Page 99: Setup

    Setup part.9 Sound Settings Display Settings Bluetooth Settings Blue Link Settings (For Blue Link Model) Phone Projection Settings Home Screen Settings Voice Recognition Settings Date/Time Settings Language Settings Keyboard Settings Screen Saver Settings Advanced Settings System Info...

  • Page 100: Sound Settings

    Setup Sound Settings Setup is the screen to control Multimedia Features Description sys tem settings. Select the Up/Down/Left/ Right button to control To enter the screen, press the Adjusts the sound effects for the whole SETUP sound positioning. Position key or the icon in system.

  • Page 101: Display Settings

    Display Settings Bluetooth Settings Information • Advanced sound settings may differ according to selected AMP option. Adjusts the level of illumination for the Changes Bluetooth phone settings. • The seat shape may differ according to key ▶ Select Press the entire system.

  • Page 102: Bluetooth Connection

    Information Bluetooth Connection Features Description • Some options will be displayed only when a key ▶ Select Displays the paired Press the SETUP Bluetooth mobile phone is connected to the system. Bluetooth device list. ▶ Paired Device Bluetooth Connection • Up to 5 Bluetooth devices can be paired.

  • Page 103: Auto Connection Priority

    Auto Connection Priority Bluetooth Voice Prompts Bluetooth System Info key ▶ Select key ▶ Select key ▶ Select Press the Press the Press the SETUP Bluetooth SETUP SETUP Bluetooth Bluetooth ▶ ▶ ▶ Auto Connection Priority Bluetooth System Info Bluetooth Voice Prompts Set whether to hear voice prompts for View or edit your system’s Bluetooth infor- events related to Bluetooth connections.

  • Page 104: Blue Link Settings

    Blue Link Settings Service Activation Modem Information (For Blue Link Model) Press the key Select Press the key Select Blue Link Blue Link SETUP SETUP Service Activation Modem Information Press the key Select SETUP Blue Link Features Description Activation may take up to five minutes. USIM USIM Identity number Do not turn the engine off while activation...

  • Page 105: Phone Projection Settings

    Phone Projection Settings Home Screen Settings Voice Recognition Settings For more details, refer to the Phone pro- You can customize the three menu items Configure how to make a call with jection guide. at the bottom right of the Home Screen Voice Recognition Guidance and Voice into the ones you want.

  • Page 106: Date/Time Settings

    Date/Time Settings Language Settings Keyboard Settings Configure the settings for time and date. You can configure the displayed system You can configure the keyboard layout for Using the arrow buttons, you can change language. each language. the values. Date/Time settings do not automat ically change when crossing into different time zones.

  • Page 107: Screen Saver Settings

    Screen Saver Settings Advanced Settings System Info You can select any of the following screen Sets alerts per function if desired by the System version information and update formats to be displayed when the screen user. details are available. or power is turned off (press and hold the Power button).

  • Page 108: System Update

    System Update At the System Info screen, insert the USB memory with the latest file downloaded, and then select the button to begin Update updating. The system will then reboot automatically. Information • This product needs supplemental software updates and additional functions, which collectively may take some time to complete, depending on the amount of data.

  • Page 109: Appendix

    Appendix part.10 Product Specification Troubleshooting...

  • Page 110: Product Specification

    Appendix Product Specification Common Operating Power Supply DC 14.4V DC 9V to DC 16V TFT-LCD Power Screen Size 7 inch(152.4 x 91.44mm) • Average current within 96 hours of ACC off: Sleep Current 10 mA or less (For Blue Link Resolution 384,000 pixels (Resolution: 800 x 480) •...
  • Page 111 Bluetooth ® MODEM RF SPEC (For Blue Link Model) Wireless Technology 2110 MHz to 2155 MHz (B4), Supported Frequency Frequency 746 MHz to 756 MHz (B13) 2400 to 2483.5 MHz Bluetooth ® Range Specification -96.3 dBm under@10M (B4), Sensitivity -93.3 dBm under@10M (B13) Supported Handsfree (1.6), A2DP (1.2), (Throughput ≥...

  • Page 112: Troubleshooting

    USB, iPod, or ® Bluetooth streaming mode, the most 3. If the problems persist, contact your Hyundai dealer. recently played mode screen prior to turning Upon turning power on, off power may not properly load Problem...
  • Page 113 The power your point of purchase or not set properly Display Setup does not turn Hyundai dealer • The volume level • Adjust the volume level • Check to see that the device is set to the lowest Device is not properly...
  • Page 114 Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • USB memory is • Please use the USB after • There are no titles • Use iTunes to download and which can be played save MP3 files into the iPod damaged formatting it.

  • Page 115: About Pairing Mobile Phones

    About Pairing Mobile Phones What is a Passkey? I cannot pair my mobile phone. What is the cause? A passkey is the password used to authenticate the connection ® Check to see that the mobile phone supports Bluetooth func- between the head unit and mobile phone. The passkey only tion.

  • Page 116: About Making/Answering Phone

    ® About Making/Answering Phone Calls About Bluetooth Wireless Technology/ Multimedia System Use Environment How can I answer a call? When there is an incoming call, a notification pop-up will What is the range of my wireless connection? become displayed. To answer the incoming call, select the The wireless connection can be used within 15 yards.
  • Page 117 Index About Bluetooth ® Wireless Battery Information …………………… 2-4 Call Commands ……………………… 6-8 Technology/Multimedia System Battery Warning Message …………… 1-9 Call History …………………………… 4-9 Use Environment ……………………10-8 Before Playing a USB MP3 ………… 3-11 Camera ……………………………… 8-2 About Making/Answering Before Use …………………………… 5-4 CAUTIONS upon Connecting Phone Calls …………………………...
  • Page 118 Date/Time Settings …………………… 9-8 FAQ ………………………………… 10-7 Instructions for Using Voice Recognition …………………………… 6-7 Default Factory Settings ……………… 9-5 Favorites …………………………… 4-10 iPod ………………………………… 3-17 Deleting Bluetooth Devices …………… 4-5 FM/AM ………………………………… 3-2 iPod Mode Display Controls ……… 3-21 Dial …………………………………… 4-7 Fuel Economy …………………………...
  • Page 119 On-Screen Touch Controls ……………1-11 Screen Saver Settings ………………… 9-9 Starting/Ending and Setting Voice Recognition …………………………… 6-3 Other Commands List Selecting through Channel/ (Commands used in List/Help) ………6-12 Category List ………………………… 3-8 Starting Plug-in Hybrid mode ………… 2-2 Service Activation …………………… 9-6 Starting the System for the First Time ………………………………...
  • Page 120 Troubleshooting …………………… 10-4 Vehicle Diagnostics …………………… 5-6 Turning the System On/Off …………… 1-8 Viewing Menu ………………………… 3-8 Types of Commands ………………… 6-8 Voice Commands …………………… 6-8 Voice Recognition Screen Overview … 6-6 Voice Recognition Settings …………… 9-7 USB ………………………………… 3-11 USB Mode Display Controls ………...
  • Page 121 Important Information Before using your Multimedia system, read and follow all instructions and safety information provided in this end user manual (“User’s Guide”). Not following precautions found in this User’s Guide can lead to an accident or other serious consequences. Keep User’s Guide in Vehicle When kept in the vehicle, the User’s Guide will be a ready reference for you and other users unfamiliar with the Multimedia system.
  • Page 122 General Operation Voice Command Control Functions within the Multimedia system may be accomplished using only voice commands. Using voice commands while driving allows you to operate the system without removing your hands from the wheel. Prolonged Views of Screen Do not access any function requiring a prolonged view of the screen while you are driving. Pull over in a safe and legal manner before attempting to access a function of the system requiring prolonged attention.
  • Page 123 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 124 MEMO...
  • Page 125 MEMO...
  • Page 126 MEMO...
  • Page 127 MEMO...
  • Page 128 MEMO...
  • Page 129 MEMO...
  • Page 130 MEMO...
  • Page 131 (영어 | 미국) 디오디오 Car Multimedia System Quick Reference Guide G2MS7-D6001...
  • Page 132 This user’s manual explains how to use the HYUNDAI Motor multimedia system. bill at then-current rates until you call Sirius XM at 1-866-635-2349 to cancel. See Before using the product, read the contents of this user’s manual carefully and use...
  • Page 133 Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.
  • Page 134 Table of Contents Component Names and Functions ........On-Screen Touch Controls ............ Home Screen ................FM/AM ..................HD Radio™ Technology ............SiriusXM™ ................USB Music ................Bluetooth ..................Voice Recognition ................................

  • Page 135: Component Names And Functions

    Component Names and Functions Head Unit Name Description • When power is off, press to turn power on. • When power is on, press and hold (over 0.8 seconds) to turn PWR/ the power off. • When power is on, press quickly (less than 0.8 seconds) to turn Audio off.
  • Page 136 Component Names and Functions For Blue Link Model For NON Blue Link Model Name Description Moves to the Apps/Info screen. APPS Moves to the Blue Link mode. Moves to the Setup screen. SETUP • FM/AM mode: Changes the frequency. • SiriusXM™ mode: Changes the channel. TUNE •...
  • Page 137 Steering Wheel Controls Name Description When the key is pressed quickly (less than 0.8 seconds), • Activates voice recognition When the key is pressed and held (over 0.8 seconds), • Ends voice recognition • If iOS device is connected through Bluetooth, activates or ends Siri Eyes Free VOL + Use to adjust the volume of audio or call.
  • Page 138 Name Description When the key is pressed quickly (less than 0.8 seconds), • When pressed in the dial screen, makes a call • When pressed in the incoming call screen, answers the call • When pressed during call waiting, switches to waiting call (Call Waiting) When the key is pressed and held (over 0.8 seconds), ®...

  • Page 139: On-Screen Touch Controls

    On-Screen Touch Controls Flick (Quick Scrolling) Learn how to touch the screen to operate the system. Select Tap lightly on a menu or an item to select it. NOTICE • The system will not recognize your Quickly moves up and down in the touch if you wear a glove or other non- list.

  • Page 140: Home Screen

    Home Screen Controls Menu Configuration for the Home Screen Tap the icon on any screen to display the Home Screen below. Features Description • Shows brief information on the radio or media that is now Radio/ playing. Media Widget • Tap the area to move to the mode that you are listening to. Phone Projection Shows any connected devices such as iPod and Bluetooth.
  • Page 141 Information Display on the Status Bar Displays the date and time, along with the system status shown by the various icons to the right of the clock. The icons in the following table indicate the various types of system status details and events.

  • Page 142: Fm/Am

    FM/AM You can access the radio player either by pressing the key or by RADIO selecting the Radio menu from on the Home Screen. All Menus Information • If you press the key when power is off, the power will turn on and a radio RADIO broadcast will be tuned from the current mode.
  • Page 143 Features Description • When the key is pressed quickly (less than 0.8 seconds): Seeks the previous/next frequency. • When the key is pressed and held (over 0.8 seconds): SEEK/TRACK Moves quickly through all of the frequencies. The moment that you release the button, the system seeks the next available frequency.

  • Page 144: Hd Radio™ Technology

    HD Radio™ Technology HD Radio™ Name Description Displays main HD Radio™ channels and used to directly HD Radio™ select the current available channels. Reception & The HD Radio™ related icon display becomes active Channel within regions where an HD Radio™ signal can be buttons received.

  • Page 145: Siriusxm

    SiriusXM™ You can access the radio player either by pressing the key or by RADIO selecting the Radio menu option from on the Home Screen. All Menus Select the SiriusXM™ band from the radio player. Information • If you press the key when the power is off, the power will turn on and a radio RADIO broadcast will be tuned from the current mode.
  • Page 146 SiriusXM™ Features Description • Shows the stored presets for user selection. Preset • After selecting frequency, press and hold the preset button Frequencies for more than 0.8 seconds. A beep sound will be heard and the frequency is to be stored in the selected preset button. Channel Logo Displays the current channel logo.
  • Page 147 Features Description Play/Pause Pauses/plays the current broadcasting program. Skip Forward Moves to the next segment. Channel List Moves to the channel list. • Delete Presets: Delete saved radio stations from the preset list. • What is on My Presets? The program schedule saved in my preset. (For more Menu details, see Section 3.9 Viewing Menu.) •...

  • Page 148: Usb Music

    USB Music Features Description Mode Displays the current operating mode. Number of Number of files on the current playlist. files Repeat/ From Repeat/Shuffle, displays the current operating function. Shuffle Play Time Displays the current play time/total play time. Song Info Displays the artist/title/album info.
  • Page 149 Features Description List Moves to the list screen • Hide Current File: a selected file can be deleted. Deleted file can be found in the ‘Hidden_’ folder. Menu This function is only supported when USB format is compatible with FAT16 or FAT32. •...

  • Page 150: Bluetooth

    Bluetooth Bluetooth Connection Pairing a New Device Before you can use the Bluetooth feature, you must first pair/connect your mobile phone to your car. Up to 5 Bluetooth devices can be The default passkey is 0000. paired. The vehicle name above is an exam- Only one Bluetooth device can be ple.
  • Page 151 Name Description Connecting Devices Through the Use the keypad to Phone Settings e n t e r t h e p h o n e key. ▶ Select Press the SETUP nu m b e r t h a t yo u .
  • Page 152 Bluetooth Using the Menu Name Description During a Phone Call Switches a voice call from the car Use Private Hands-free to the mobile phone. Ends a call. Mutes the micro- Mute phone during a call. Displays the Mic Volume settings. Outgoing You can adjust the Volume...
  • Page 153 Call History Contacts ▶ ▶ ▶ ▶ Select Select All Menus Phone All Menus Phone Name Description Name Description Lists the all call his- The list of Contacts. Contacts tory. Select from the list List to dial the number. Lists the calls that Dialed you made.
  • Page 154 Favorites Name Description ▶ ▶ Lists the phone Select All Menus Phone numbers saved as Favorites Favorites. Select from the list to dial the number. Add or delete num- Edit bers from Favorites. Deletes numbers Delete that you select from Favorites.

  • Page 155: Voice Recognition

    Voice Recognition Precautions Required 4. The microphone used for the for Successful Voice voice recognition system is Recognition located in the headliner directly above the driver’s head. To make 1. Voice recognition supports only your commands better under- the commands that are displayed stood, keep your body straight in on the screen and written in the the driver’s seat when speaking...
  • Page 156 Voice Recognition Starting/Ending Ending Voice Recognition and Setting Voice 1. Select “Exit” to the left of the bot- Recognition tom to end voice recognition. 2. Press and hold (more than 0.8 Starting Voice seconds) the key on the Recognition steering wheel control to end Press the key briefly (less voice recognition.
  • Page 157 Combining Voice Skipping Prompt Recognition with On- Messages Screen Commands When you hear the prompt mes- After pressing the key, say sage, press the key on the a command after the beep. The steering wheel control to skip the voice recognition system will execute message and go directly to listening the desired operation after under- mode to say your command.
  • Page 158 Voice Recognition Voice Recognition Screen Overview Name Description Representative Displays frequently used commands. Commands Unavailable voice commands are grey, a precondition was Not available not met so the command is grey and unavailable. The con- command ditions required for using the unavailable commands will be described under each command.
  • Page 159 Voice Commands Types of Commands Voice recognition commands are classified as “Global Commands” and “Local Commands”. ● 1. Global Commands ( ): Commands that can be used immediately after acti- vating voice recognition. ○ 2. Local Commands ( ): Commands that can be used when a multimedia or Bluetooth function is running, or displayed on the screen, after activating voice recognition.
  • Page 160 Voice Recognition Command Operation Displays downloaded Contacts, after this you can make ● Call a call by saying the name. You can directly call a person by <Name> in the down- ● Call <Name> loaded Contacts. You can call a person <name> directly to the number Call <Name>...
  • Page 161 Radio Commands Command Operation Plays the most recent radio channels from FM, AM, and ● Radio SiriusXM™. ● Plays FM radio. Tunes to FM <Frequency> according to what you say. ● <87.5~107.9> e.g.) FM 87.5: FM eighty seven point five ●...
  • Page 162 Voice Recognition Media Commands * Check the following before you use media commands. 1. If no media is connected or if no playable files exist at the time when you use these commands, a voice message will tell you that this is not available. 2.
  • Page 163 1. USB Music/iPod Command Command Operation Plays a selected file. ○ Play Maintains the current settings during playback. Pauses a file that is playing. ○ Pause Maintains current settings while paused during playback. Plays tracks or files randomly. ○ Shuffle Maintains current settings during shuffled playback.

  • Page 164: Other Commands List

    Voice Recognition Other Commands List (Commands used in List/Help) Command Operation Moves to the voice recognition help screen. ● Help All available commands can then be identified and used. When you cannot select a certain name, such as in Call Line 1~4 History, you can select it using numbers.
  • Page 165 Siri Eyes Free How to start Siri If you want to use Siri, you have to connect your iOS device to the Multimedia system through Bluetooth. Information (Please check whether your iOS • Functions and feedbacks from voice device supports Siri and turning Siri commands via Siri are executed in the iOS device.

  • Page 166: Faq

    About Pairing Mobile Phones I cannot pair my mobile phone. What is the cause? ® Check to see that the mobile phone supports Bluetooth function. Verify if Bluetooth on the cell phone is set to OFF. If so, set it to ON. If the cell phone still can’t be registered, try again after turning Bluetooth off and on, or delete the device registration on the multimedia system and cell phone and then register the cell phone again.
  • Page 167 About Making/Answering Phone Calls How can I answer a call? When there is an incoming call, a notification pop-up will become displayed. To answer the incoming call, select the button on the screen or Accept press the key on the steering wheel control. To reject the call, select the button on the screen or press the Reject...
  • Page 168 MEMO...
  • Page 169 MEMO...
  • Page 170 MEMO...
  • Page 171 MEMO...
  • Page 172 MEMO...

Table of Contents
