Fiat UCONNECT 4.3 Manual

For freemont
Hide thumbs

Advertisement

Quick Links

Download this manual
F
R
E
E
M
O
N
T
F
I
A
T
U
C
O
N
N
E
C
T
®
4
.
3
/
8
.
4

Advertisement

loading

Related Manuals for Fiat UCONNECT 4.3

Summary of Contents for Fiat UCONNECT 4.3

  • Page 1 ®...
  • Page 2 TABLE OF CONTENTS INTRODUCTION ..............3 UCONNECT®...

  • Page 4: Introduction

    INTRODUCTION • Uconnect® 4.3 INTRODUCTION ....4 • Uconnect® 4.3 System .....4 •...
  • Page 5 Uconnect® 4.3 INTRODUCTION Uconnect® 4.3 System 1 — ON/OFF & Volume Control 5 — Radio hard-key 8 — Screen Off hard-key 2 — Manual Climate Controls 6 — Settings hard-key 9 — Enter/Browse & Tune/Scroll knob 3 — Climate Controls hard-key 7 —...
  • Page 6 Uconnect® 4.3 System (2)(3) CLIMATE CONTROLS (7) MORE Manual Climate Controls and Climate Press the MORE hard-key to access ad- WARNING! Control Hard-key. Refer to Climate ditional options. Options available such Driving while distracted can result Controls in your vehicles Owner's as: Uconnect®...
  • Page 7 Uconnect® 8.4 Uconnect® 8.4 System 1 — ON/OFF & Volume Control 5 — Controls soft-key 9 — More soft-key 2 — Climate Control hard-keys 6 — Climate soft-key 10 — Enter/Browse & Tune/Scroll knob 3 — Radio soft-key 7 — Nav soft-key (if equipped) 11 —...
  • Page 8 Uconnect® 8.4 System (2) CLIMATE CONTROLS (6) CLIMATE (On-Screen Controls) (Manual Controls) Refer to Climate Controls in your WARNING! Refer to Climate Controls in your vehicles Owner's Manual for further ALWAYS drive safely with your vehicles Owner's Manual for further details.
  • Page 9 (11) SD CARD SLOT Insert an SD Card containing audio media files in order to play them through the vehicle’s sound system. (12) DISC SLOT When inserting a disc, make sure the label is facing up. Press the Eject but- ton to eject the disc.

  • Page 10: Uconnect® 4.3

    Uconnect® 4.3 • RADIO MODE ......11 • Overview ......11 •...
  • Page 11 • Shuffle ....... .17 • Audio ....... . .17 •...
  • Page 12 RADIO MODE Common Radio Functions counterclockwise to decrease the radio station frequency. Push the ENTER/ The following operations offer the Overview BROWSE button to choose a selection. same functionality across all Radio The radio can be equipped with the Info Modes, and further instructions are following tuners: provided where differences exist.
  • Page 13 Seek And Direct Tune Exit Alerts Functions The Exit soft-key, provides a means to Touch the alerts soft-key at the bot- close the Direct Tune Screen. tom of the screen set up Traffic and The Seek Up and Down functions are Emergency alerts.
  • Page 14 Setting Presets Fast Seek Up Direct Tune Touch and hold the Seek Up soft-key The Direct Tune soft-key screen is The Presets are available for all Radio to advance the radio through the available in all radio modes and can Modes, and are activated by touching available stations or channels at a be used to direct tune the radio to a...
  • Page 15 Audio Balance/Fade Touch the Balance/Fade soft-key to 1. Press the SETTINGS hard-key on adjust the sound from the speakers. the right side of the unit. Use the arrow soft-key to adjust the 2. Scroll down and press the Audio sound level from the front and rear or soft-key to open the Audio menu.
  • Page 16 Seek Up/Down Inserting Compact Disc CAUTION! (Continued) Gently insert one CD into the CD Touch and release the right arrow • Uconnect® 4.3 is a single CD player with the CD label facing up. soft-key for the next selection on the player.
  • Page 17 Source OPERATING USB/iPod®® device. Touch and re- lease the left arrow soft-key to return INSTRUCTIONS – Touch the Source soft-key to select the to the beginning of the current selec- USB/iPod® MODE desired audio source, CD, AUX or tion, or return to the beginning of the USB.
  • Page 18 Source AUX MODE NOTE: The vehicle radio unit is acting as the amplifier for audio Touch the Source soft-key to select the Overview output from the Auxiliary device. desired audio source, CD, AUX or Therefore if the volume control on AUX Mode is entered by inserting a USB/iPod®.
  • Page 19 OPERATING Info – If Equipped the left arrow soft-key to return to the beginning of the current selection, or INSTRUCTIONS — Touch the Info soft-key to display the return to the beginning of the previ- Bluetooth® MODE current track information. Touch the ous selection if the Bluetooth®...
  • Page 20 Settings Main Menu • Phone • Press the Settings hard-key on the right side of the display, then Refer to "Understanding The Fea- Press the Settings hard-key to display press the Clock soft-key. The tures Of Your Vehicle," "Uconnect®" the Settings Main Menu. The Settings Time setting screen is displayed section in your vehicle Owner’s Main Menu contains the following op-...
  • Page 21 Display • Heated Seats • Mode Refer to "Understanding The Fea- Touch the Mode soft-key to adjust the Your Uconnect® display can be cus- tures Of Your Vehicle", "Seats" sec- display screen brightness for Day, tomized by following the steps: tion in your vehicle Owner’s Manual Night or Auto selection.

  • Page 22: Uconnect® 8.4 & 8.4N

    Uconnect® 8.4 & 8.4N • RADIO MODE ......24 • Overview ......24 •...
  • Page 23 • Repeat – If Equipped .....31 • Shuffle ....... .31 •...
  • Page 24 • NAVIGATION (8.4N ONLY) ....36 • Getting Started ......36 •...
  • Page 25 RADIO MODE Common Radio Functions counterclockwise to decrease the radio station frequency. Push the ENTER/ The following operations offer the Overview BROWSE button to choose a selection. same functionality across all Radio Modes, and further instructions are Screen Close provided where differences exit. The Red X Soft-key at the top right, provides a means to close the Direct ON/OFF &...
  • Page 26 Setting Presets Fast Seek Up Direct Tune Touch and hold the Seek Up soft-key Press the Tune soft-key located at the Presets are available for all Radio to advance the radio through the bottom of the radio screen. The Direct Modes, and are activated by touching available stations or channels at a Tune soft-key screen is available in all...
  • Page 27 Audio Tune Knob, or by touching the Up Equalizer and Down arrow keys, located on the Touch the Equalizer soft-key to acti- Touch of the Audio soft-key to acti- right of the screen. vate the Equalizer screen. vate the Audio settings screen to ad- Preset Selection from List just Balance\Fade, Equalizer, And Speed Adjusted Volume.
  • Page 28 Surround Sound – If Equipped Touch the On soft-key to activate Sur- round Sound. Touch Off to deactivate this feature. When Surround Sound is On, you can hear audio coming from every direc- tion as in a movie theatre or home theatre system.
  • Page 29 If you insert a disc with the ignition in EJECT Button - Ejecting a Disc Fast Seek Down the ACC or RUN position and the Touch and hold the left arrow soft-key radio ON, the unit will switch from to Press the EJECT button to and the Disc player will begin to re- Disc mode and begin to play when you...
  • Page 30 USB/iPod® MODE change of pace. Touch the soft-key a Inserting USB/iPod® Device second time to turn this feature off. Gently insert the USB/iPod® device into the USB Port. If you insert a Info – If Equipped USB/iPod® device with the ignition Touch the Info soft-key to display the in the ACC or RUN position and the current track information.
  • Page 31 NOTE: Many features of this sys- Up Arrow Touch the Up Arrow soft- Fast Seek Down tem are speed dependent. For your key to toggle between Upper Case and Touch and hold the left arrow soft-key own safety these features may be Lower Case keys.
  • Page 32 Source Tracks Playlists – If Equipped Touch the Playlists soft-key on the left Touch the Source soft-key to select the Touch the Trks soft-key to display a side of the screen to display the cur- desired audio source, Disc/USB/SD pop up with the Song List. The cur- rent playlist information.
  • Page 33 AUX MODE SD CARD MODE Controlling the Auxiliary Device The control of the auxiliary device Overview Overview (e.g., selecting playlists, play, fast for- AUX Mode is entered by inserting an SD Card Mode is entered by inserting ward, etc.) cannot be provided by the AUX device using a cable with a a SD Card containing music into the radio;...
  • Page 34 Browse number, and index time in minutes NOTE: Many features of this sys- and seconds. Play will begin at the tem are speed dependent. For your Touch the browse soft-key to display start of track 1. own safety these features may be the browse window.
  • Page 35 Up Arrow Albums Touch the Albums soft-key on the left Touch the Up Arrow soft-key to toggle side of the screen to display the Al- between Upper Case and Lower Case bums list in which you can Scroll, keys. Search, and Jump to operations. ABC, ÅØÜ...
  • Page 36 Shuffle Once the Bluetooth® device is paired to the Uconnect® System, touch the Touch the Shuffle soft-key to play the Player soft-key located on the bottom selections on the Auxiliary device in of the display. Once in Player Mode, random order to provide an interest- touch the source soft-key and select ing change of pace.
  • Page 37 Source Audio Touch the Source soft-key to select the Refer to Operating Instructions – Radio desired audio source, Disc/USB/SD Mode for adjusting the audio settings. Card/AUX/Bluetooth®. NAVIGATION (8.4N ONLY) Repeat – If Equipped Getting Started Touch the Repeat soft-key to toggle the repeat functionality.
  • Page 38 2. Select a Point of Interest. 5. Select a destination. destination. The lower-left corner in- dicates the distance to your next ma- neuver. If you depart from the original route, your navigation system recal- culates the route and provides new directions.
  • Page 39 Taking a Detour NOTE: Garmin is not responsible Deleting Custom POIs for the consequences of using a If a road on your route is closed, you To delete all custom POIs from your custom POI database, or for the can take a detour. navigation system: accuracy of the safety camera or 1.
  • Page 40 • A Recent Destination — search 3. Touch to return to the previous 2. Touch Change State/Country, if near a recent destination. page. necessary. • A Favorite Destination — search 4. Touch Press for More to view more 3. Touch Search All. near a favorite destination.
  • Page 41 1. Touch Where To?, then touch Finding Places in a Different Area Saving Places You Find Points of Interest and then Spell You can search for locations in a dif- 1. After you have found a place you Name. ferent area, such as a different city or want to save, touch Save on the Go! near your destination.
  • Page 42 Saving Your Current Location • Use my current location – sets 4. Touch Edit. your current location as your Home 1. Touch View Map. 5. Touch the item you want to edit. Location. 2. Touch • Change Name – enter a new name •...
  • Page 43 The Main Pages NOTE: • A speed limit icon may ap- This section provides details about pear as you travel on major the Map Page, the Trip Computer, the roadways. This icon displays the Turn List, Lane assist, and the GPS current speed limit of the road- Info Page.
  • Page 44 be driving. To view the Lane Assist The sky view shows the satellites you page, touch the upper-left corner of are receiving. The satellite signal- the Map page. You can also access the strength bars indicate the strength Lane Assist page from the Next Turn of each satellite you are receiving.
  • Page 45 NOTE: Perform Finding a Point of Your changes are saved automatically 4. Touch Start. Interest procedure to find your when you exit any of the route edit Deleting All Saved Routes ending point. pages. 1. Touch Tools. 8. Touch + to add another location to Saving and Modifying the Active your route.
  • Page 46 Customizing the Settings Changing the Map Settings • Info – view the maps loaded on your navigation system and their Touch Settings, then touch Map. This section describes how to custom- version. Touch a map to enable ize the settings of your GPS naviga- •...
  • Page 47 • Time Format – select a 12–hour, ers. Visit http://Fiat.navigation.com 24–hour or UTC time format. or ask your Dealer or Service Center Failure to avoid the following for details.
  • Page 48 • Do not become distracted by the signals will soon be received, how- • The Global Positioning System navigation system while driving, ever, and the correct position will (GPS) is operated by the United and always be fully aware of all be displayed.
  • Page 49 Map Data Information nary executable form in the normal NAVTEQ® End-user License operation of the product. Title, Agreement • One of our goals is to provide cus- ownership rights, and intellectual tomers with the most complete and • The software embedded in your property rights in and to the Soft- accurate cartography that is avail- Garmin product (the “Software”) is...
  • Page 50 • IMPORTANT: CAREFULLY License Terms and Conditions otherwise reproduce, copy, modify, READ THIS LICENSE BEFORE decompile, disassemble, reverse en- • Garmin (“we” or “us”) provides USING THIS PRODUCT. gineer or create derivative works of you with storage media containing STALLING, COPYING, OR OTH- any portion of the Product, and the computer Software (the “Soft- ERWISE USING THIS PRODUCT...
  • Page 51 products containing the Data to PURPOSE OR NONINFRINGE- INDIRECT, WHICH MAY RE- their rental customers are permit- MENT. NO ORAL OR WRITTEN SULT FROM THE USE OR POS- ted to rent out such products. ADVICE INFORMATION SESSION OF THE INFORMA- PROVIDED BY Garmin OR ITS TION;...
  • Page 52 Some States, Territories and Coun- direct product thereof except in the subject matter hereof, and su- tries do not allow certain liability compliance with, and with all li- persedes in their entirety any and all exclusions or damages limitations, censes and approvals required un- written or oral agreements previ- so to that extent the above may not der, applicable export laws, rules...
  • Page 53 of Goods, which is explicitly ex- agency technical data and noncom- Licensed Product are protected un- cluded. You agree to submit to the mercial computer software clause); der copyright laws and interna- jurisdiction of Illinois for any and and/or FAR 12.211 and FAR tional copyright treaties.
  • Page 54 software, and with compatible • You may not reproduce, sell, rent, dealer, has been advised of the pos- Garmin products that you person- lease, loan, distribute or sublicense sibility of the damages, or for any ally own. Your use of the data is the Licensed Product(s) or other- claim by any other party.
  • Page 55 OTHERWISE, INCLUDING BUT provisions herein. Nor does or will • DMTI Spatial is an authorized user NOT LIMITED TO WARRANTIES DMTI Spatial warrant any services and distributor of selected Statistics EFFECTIVENESS, COM- it may provide in connection with Canada Computer files under Li- PLETENESS, ACCURACY, MER- the use of the Licensed product(s), censing Agreement 6230.
  • Page 56 Settings Main Menu • Lights • Audio Refer to "Understanding Your Instru- Refer to this section for more details. ment Panel", "Uconnect® System" • Phone/Bluetooth® section in your vehicle Owner’s Refer to "Understanding The Fea- Manual for details. tures Of Your Vehicle", "Uconnect® •...
  • Page 57 5. Touch the + or – soft-key to change 2. Press the Clock soft-key to enter the Brightness. Or touch the check the Clock Menu mark or empty box to change a selec- tion. NOTE: The check-mark indicates the current selection is active. 6.

  • Page 58: Safety Guidelines

    SAFETY GUIDELINES • Warnings ....... .58 • Safety References ......58 •...
  • Page 59 Warnings System Care Keep drinks, rain, and other sources of moisture away from your system. This manual contains WARNINGS Safe Usage of the Uconnect® Besides damage to your system, mois- against operating procedures that System ture can cause electric shocks as with could result in an accident or bodily any electronic device.
  • Page 60 If necessary, use a lint-free cloth antenna will decrease performance. genre and artist information. Data dampened with a cleaning solution, Do not place items directly on or will be found for most Audio CDs such as isopropyl alcohol, or an iso- above the antenna.
  • Page 61 by Gracenote" logo are either regis- Data to any third party. YOU AGREE Gracenote service to count queries tered trademarks or trademarks of EXPLOIT without knowing anything about who Gracenote in the United States and/or GRACENOTE DATA, you are. For more information, see the other countries.
  • Page 62 LIMITED IMPLIED WAR- RANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NON- INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RE- SULTS THAT WILL BE OBTAINED YOUR GRACENOTE SOFTWARE OR ANY GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LI- ABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR LOST...
  • Page 63 Notes...
  • Page 64 Notes...
  • Page 65 Notes Fiat Group Automobiles S.p.A. - Parts & Services - Technical Services - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italia) Print n. 530.04.534 - 09/2013 - Edition 1...
  • Page 66 ENGLISH The data contained in this publication is intended merely as a guide. FIAT reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer.
