Mitsubishi Heavy Industries KXZW Series Service Manual

Vrf inverter multi-system air-conditioners
Hide thumbs

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
SERVICE MANUAL
VRF INVERTER MULTI-SYSTEM AIR-CONDITIONERS
KXZW Heat source units

Water cooled series
Single use (Used also for combination)
FDC224KXZWE1, 280KXZWE1, 335KXZWE1
Combination use
FDC450KXZWE1, 500KXZWE1, 560KXZWE1, 615KXZWE1, 670KXZWE1, 730KXZWE1, 775KXZWE1,
850KXZWE1, 900KXZWE1, 950KXZWE1, 1000KXZWE1
Note:
•
(1) Regarding the Indoor unit series, refer to the No.'14
Manual No. '14
updated March 30, 2018
KX-DB-206
•
KX-SM-200
•
