Notebook PC
Hardware User's Manual
E1966 / Feb 2005

Advertisement

Table of Contents
loading

Related Manuals for Asus S5N

Summary of Contents for Asus S5N

  • Page 1 Notebook PC Hardware User’s Manual E1966 / Feb 2005...

  • Page 2: Safety Statements

    Safety Statements Federal Communications Commission Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two condi- tions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Macrovision Corporation Product Notice

    Nordic Cautions IMPORTANT! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. (English) ATTENZIONE! Rischio di esplosione della batteria se sostituita in modo errato. Sostituire la batteria con un una di tipo uguale o equivalente consigliata dalla fabbrica.
  • Page 4 Safety Statements Safety Statements WARNING! The following safety preIMPORTANTs will increase the life of the Note- book PC. Follow all preIMPORTANTs and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, or other peripherals.

  • Page 5: Transportation Precautions

    Transportation Precautions To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external periph- erals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport the Notebook PC while the power is still ON.
  • Page 6 Safety Statements CTR 21 Approval (for Notebook PC with built-in Modem) Danish Dutch English Finnish French German Greek Italian Portuguese Spanish Swedish...

  • Page 7: Ul Safety Notices

    UL Safety Notices Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).

  • Page 8: Table Of Contents

    Contents 1. Introducing the Notebook PC ... 11 About This User’s Manual ... 12 Notes For This Manual ... 12 Preparing your Notebook PC ... 13 2. Knowing the Parts ... 15 Top Side ... 16 Bottom Side ... 18 Left Side ...
  • Page 9 4. Using the Notebook PC ... 39 Pointing Device ... 40 Using the Touchpad ... 40 Touchpad Usage Illustrations ... 41 Caring for the Touchpad ... 42 External Optical Drive ... 43 Connecting the External Optical Drive ... 43 Ejecting a Disc from the External Optical Drive ... 44 Using the External Optical Drive ...
  • Page 10 Contents Appendix ... 59 Optional Accessories... 60 USB Hub (Optional) ... 60 USB 2.0 Slim Combo Drive (Optional) ... 60 Wireless LAN Cardbus Card or USB (Optional) ... 61 USB Flash Memory (Optional) ... 61 USB Communication Cable (Optional) ... 61 USB Floppy Disk Drive (Optional) ...

  • Page 11: Introducing The Notebook Pc

    1. Introducing the Notebook PC About This User’s Manual Notes For This Manual Preparing your Notebook PC...

  • Page 12: About This User's Manual

    Introducing the Notebook PC About This User’s Manual You are reading the Notebook PC User’s Manual. This User’s Manual provides information on the various components in the Notebook PC and how to use them. The following are major sections of this User’s Manuals: 1.

  • Page 13: Preparing Your Notebook Pc

    Preparing your Notebook PC These are only quick instructions for using your Notebook PC. Read the later pages for detailed infor- mation on using your Notebook PC. 1. Install the battery pack (1) Insert the battery pack until it clicks into place. 2.
  • Page 14 Introducing the Notebook PC...

  • Page 15: Knowing The Parts

    2. Knowing the Parts Top Side Bottom Side Left Side Right Side Rear Side Front Side...

  • Page 16: Top Side

    Knowing the Parts Top Side Refer to the diagram below to identify the components on the top side of the Notebook PC. Status Indicators (when display panel closed) Power4 Gear Button Audio Speaker (mono) Status Indicators Display Panel Latch One spring-loaded latch on the front of the Notebook PC locks the display panel in the closed position when the Notebook PC is not in use.

  • Page 17: Display Panel

    Audio Speaker (mono) The built-in speaker allows you to hear mono audio without additional attachments. The multimedia sound system features an integrated digital audio controller that produces rich, vibrant sound in high quality 16-bit stereo (when used with external stereo headphones or speakers). All audio features are software controlled.

  • Page 18: Bottom Side

    Knowing the Parts Bottom Side Refer to the diagram below to identify the components on the bottom side of the Notebook PC. Battery Lock Hard Disk Drive Compartment IMPORTANT! The bottom of the Notebook PC can get very hot. Be careful when han- dling the Notebook PC while it is in operation or recently been in operation.

  • Page 19: 2 Knowing The Parts

    Knowing the Parts Battery Pack and Locks Usage details are described in the battery section later in this manual. CPU Compartment The CPU compartment contains a socket for mounting a central processing unit. CPU installation/ upgrades must be done by an authorized retailer or else warranty will be void. Memory Compartment The memory compartment contains an expansion slot for additional memory.

  • Page 20: Left Side

    Knowing the Parts Left Side Refer to the diagram below to identify the components on the left side of the Notebook PC. Monitor Output Monitor Port The 15-pin D-sub monitor port supports a standard VGA-compatible device such as a monitor or pro- jector to allow viewing on a larger external display.

  • Page 21: Right Side

    Right Side Refer to the diagram below to identify the components on the right side of the Notebook PC. PC Card (PCMCIA) Socket One PCMCIA 2.1 compliant socket is available to support one type I/II PC card. The socket supports 32-bit CardBus.

  • Page 22: Rear Side

    Knowing the Parts Rear Side Refer to the diagram below to identify the components on the rear side of the Notebook PC. ® Kensington Lock Port ® Kensington Lock Port ® The Kensington lock port allows the Notebook PC to be secured using Kensington book PC security products.

  • Page 23: Front Side

    Knowing the Parts Front Side Refer to the diagram below to identify the components on the front side of the Notebook PC. Status Indicators W I R E L E S S L A N S Y S T E M Display Panel Latch Status Indicators Status indicator details are described in section 3.

  • Page 25: Getting Started

    3. Getting Started Using the Battery Pack Operating Systems Power Connection Powering ON The Notebook PC Power Management - Stand By and Hibernate Restarting or Rebooting Powering OFF The Notebook PC Using the Keyboard Buttons and Indicators...

  • Page 26: Using The Battery Pack

    Getting Started Using the Battery Pack Installing and Removing the Battery Pack Your Notebook PC may or may not have its battery pack installed. If your Notebook PC does not have its battery pack installed, use the following procedures to install the battery pack. To install the battery pack: 1.

  • Page 27: Charging The Battery Pack

    Charging the Battery Pack Before you use your Notebook PC on the road, you will have to charge the battery pack. The battery pack begins to charge as soon as the Notebook PC is connected to external power. Fully charge the battery pack before using it for the first time.

  • Page 28: Power Connection

    Getting Started Power Connection Your Notebook PC comes with a universal AC-DC adapter. That means that you may connect the power cord to any 110V-120V as well as 220V-240V outlets without setting switches or using power converters. Different countries may require that an adapter be used to connect the provided US-stan- dard AC power cord to a different standard.

  • Page 29: Powering On The Notebook Pc

    Powering ON The Notebook PC The Notebook PC’s power-ON message appears on the screen when you turn it ON. If necessary, you may adjust the brightness by using the hot keys. If you need to run the BIOS Setup to set or modify the system configuration, press [F2] upon bootup to enter the BIOS Setup.

  • Page 30: Power Management - "Stand By" & "Hibernate

    Getting Started Power Management - “Stand By” & “Hibernate” Power management settings can be found in the Windows control panel. The following shows the power options properties in Windows. You can define “Stand By” or “Shut down” for closing the display panel, pressing the power button, or activating sleep mode.

  • Page 31: Restarting Or Rebooting

    Getting Started Restarting or Rebooting After making changes to your operating system, you may be prompted to restart the system. Some installation processes will provide a dialog box to allow restart. To restart the system manually: Click the Start button and select Shut Down | and choose Restart. In case the operating system hangs (stops, freezes, crashes), try a “warm boot”...

  • Page 32: Powering Off The Notebook Pc

    Getting Started Powering OFF the Notebook PC In Windows XP, the Notebook PC can be powered OFF by using Start | Shut Down... | Turn off (or Shut down). For operating systems without proper power management (DOS, Windows NT), you must power OFF the Notebook PC by holding the power switch for 2 seconds (as opposed to 1 second to power ON) after closing applications and exiting operating systems.

  • Page 33: Using The Keyboard

    Using the Keyboard Colored Hot Keys The following defines the colored hot keys on the Notebook PC’s keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. NOTE: The Hot Key locations on the function keys may vary depending on model but the functions should remain the same.

  • Page 34: Colored Hot Keys (Cont')

    Getting Started Colored Hot Keys (Cont’) NOTE: Hot Keys work only on the Notebook PC’s own keyboard and not on any exter- nally connected keyboards. Speaker Icons (F10): Toggles the speakers ON and OFF (only in Windows OS) Down Speaker Icon (F11): Decreases the speaker volume (only in Windows OS) Up Speaker Icon (F12): Increases the speaker volume (only in Windows OS)

  • Page 35: Keyboard As A Numeric Keypad

    Keyboard as a Numeric Keypad The numeric keypad is embedded in the keyboard and consists of 15 keys that make number intensive input more convenient. These dual-purpose keys are labeled in orange on the key caps. Numeric as- signments are located at the upper right hand corner of each key as shown in the figure. When the numeric keypad is engaged by pressing board is connected, pressing the keyboards simultaneously.

  • Page 36: Keyboard As Cursors

    Getting Started Keyboard as Cursors The keyboard can be used as cursors while Number Lock is ON or OFF in order to increase navigation ease while entering numeric data in spreadsheets or similar applications. With Number Lock OFF, press up, [Fn][K] for down, [Fn][U] for left, and [Fn][O] for right. With Number Lock ON, use [Shift] and one of the cursor keys shown below.

  • Page 37: Buttons And Indicators

    Buttons and Indicators Top Left Power4 Gear Button The Power4 Gear button toggles power savings ON or OFF. When power savings is activated, CPU speed and LCD brightness will be decreased. Power Indicator The green LED lights to indicate that the Notebook PC is turned ON and blink when the Notebook PC is in the Suspend-to-RAM (Standby) mode.

  • Page 38: Power4 Gear Modes

    Getting Started Power4 Gear Modes The Power4 Gear button toggles power savings between various power saving modes. The power sav- ing modes control many aspects of the Notebook PC to maximize performance versus battery time during various events. When you are using an AC power adapter, Power4 Gear will switch between three modes in the AC power mode segment.

  • Page 39: Using The Notebook Pc

    4. Using the Notebook PC Pointing Device External Optical Drive Flash Memory Card Reader PC Card (PCMCIA) Socket Modem and Network Connections AC Power System Battery Power System Power Management Modes System Memory Expansion Hard Disk Drive Upgrades Processor Upgrades...

  • Page 40: Pointing Device

    Using the Notebook PC Pointing Device The Notebook PC’s integrated touchpad pointing device is fully compatible with all two/three-button and scrolling knob PS/2 mice. The touchpad is pressure sensitive and contains no moving parts; therefore, mechanical failures can be avoided. A device driver is still required for working with some application software.

  • Page 41: Touchpad Usage Illustrations

    Using the Notebook PC Touchpad Usage Illustrations Clicking/Tapping - With the cursor over an item, press the left button or use your fingertip to touch the touchpad lightly, keeping your finger on the touchpad until the item is selected. The selected item will change color.

  • Page 42: Caring For The Touchpad

    Using the Notebook PC Dragging - Dragging means to pick up an item and place it anywhere on the screen you wish. You can move the cursor over the item you select, and while keeping the left button depressed, moving the cursor to the desired location, then release the button.

  • Page 43: External Optical Drive

    External Slim Optical Disk Drive (optional) The USB 2.0 port provides a convenient solution to connect an external slim optical disk drive. This Notebook PC features a power output jack to replace the bulky AC adapter. IMPORTANT! When disconnecting the external optical drive, you must select the device icon on the taskbar and select “Disconnect”...

  • Page 44: Ejecting A Disc From The External Optical Drive

    Using the Notebook PC Using the External Slim Optical Disk Drive 1. Press the stop/open button on the top cover panel of the drive to open the top cover. 3. Hold the disc by the edge and face the disc’s printed side up.

  • Page 45: Using The Drive's Emergency Manual Eject

    Ejecting a Disc from the External Slim Optical Disk Drive 1. Press the open/stop button on the top cover panel of the drive to open the top cover. 2. Carefully remove the disc from the drive. 3. Close the top cover by gently pressing it downwards. NOTE: The eject button is electronic and requires power in order to use.

  • Page 46: Using The External Optical Drive On Other Computers (Optional)

    Using the Notebook PC Using the Slim Optical Drive on Other Computers (Optional) Using the Slim Optical Drive’s Power Adapter (Optional) In case you use the external optical drive on USB (2.0 or 1.1) ports other than this Notebook PC, you will need to use the power adapter. NOTE: Although the power adapter accepts voltages from 100v to 240v, plug types may vary in different countries or regions around the world.

  • Page 47: Hard Disk Drive Module

    External Drive Modules (optional) The USB 2.0 port provides a convenient solution to connect external drive modules. This Notebook PC features a power output jack for use with a proprietary external drive module. Hard disk drive module Passthrough port for other USB devices Model 1: Dual USB for a hard disk drive module.

  • Page 48: Using The Optical Drive

    Using the Notebook PC Using the Optical Drive Optical discs and equipment must be handled with care because of the precise mechanics involved. Keep in mind the important safety instructions from your CD suppliers. Unlike desktop optical drives, the Notebook PC uses a hub to hold the CD in place regardless of the angle. When inserting a CD, it is important that the CD be pressed onto the center hub or else the optical drive tray will scratch the CD.

  • Page 49: Flash Memory Card Reader

    Flash Memory Card Reader Normally a PCMCIA memory card reader must be purchased separately in order to use memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs. This Notebook PC has a built-in memory card reader that can read the following flash memory cards: Secure Digital (SD), Multi-Media Card (MMC), Memory Stick (MS), Memory Stick Select (MS Select), Memory Stick Duo (with MS adapter), Memory Stick Pro, and Memory Stick Pro Duo (with MS Pro adapter).

  • Page 50: Pc Card (Pcmcia) Socket

    Using the Notebook PC PC Card (PCMCIA) Socket The Notebook PC supports PC Cards (or sometimes referred to as PCMCIA cards) to allow expansion like PCI cards on desktop computers. This allows you to customize your Notebook PC to meet a wide range of application needs.

  • Page 51: Removing A Pc Card (Pcmcia)

    Inserting a PC Card (PCMCIA) Insert the PC card with the connector side first and label side up. Standard PC cards will be flush with the Notebook PC when fully inserted. IMPORTANT! Do not force. Be sure the PC card is level when inserting. Removing a PC Card (PCMCIA) To remove the PC card, first remove all cables or adapters attached to the PC card, then left click the PC card icon on the Windows taskbar and stop the PC card you want to remove.

  • Page 52: Modem Connection

    Using the Notebook PC Modem and Network Connections The built-in modem and network model comes with both an RJ-11 and an RJ-45 port. RJ-11 telephone cables have two or four wires and are used to connect telephones to telephone outlets found in the walls of residential homes and some commercial buildings (some commercial buildings may have telephone wir- ing designed for dedicated phone systems that may not be compatible).

  • Page 53: Modem And Network Connections

    Network Connection Connect a network cable, with RJ-45 connectors on each end, to the modem/network port on the Note- book PC and the other end to a hub or switch. For 100BASE-TX speeds, your network cable must be category 5 (not category 3) with twisted-pair wiring. If you plan on running the interface at 100Mbps, it must be connected to a 100BASE-TX hub (not a 100BASE-T4 hub).

  • Page 54: Ac Power System

    Using the Notebook PC AC Power System The Notebook PC power is comprised of two parts, the power adapter and the battery power system. The power adapter converts AC power from a wall outlet to the DC power required by the Notebook PC.

  • Page 55: Using Battery Power

    Using Battery Power A fully-charged battery pack provides the Notebook PC a few hours of working power. But the actual figure varies depending on how you use the power saving features, your general work habits, the CPU, system memory size, and the size of the display panel. Checking Battery Power To check the remaining battery power, move your cursor over the power icon.

  • Page 56: Acpi

    Using the Notebook PC Power Management Modes The Notebook PC has a number of automatic or adjustable power saving features that you can use to maximize battery life and lower Total Cost of Ownership (TCO). You can control some of these fea- tures through the Power menu in the BIOS Setup.

  • Page 57: Power Management Modes

    Power Savings In addition to reducing the CPU clock, this mode puts devices including the LCD backlight in their lower active state. The Notebook PC enters “Stand by” mode (low priority) when the system remains idle for a specified amount of time. The timeout can be set through Windows power management (higher priority).

  • Page 58: Notebook Pc Upgrades

    Using the Notebook PC Notebook PC Upgrades System Memory Expansion Additional memory is optional and not required to use the Notebook PC. Additional memory will increase application performance by decreasing hard disk access. This is more noticeable on newer software that require more and more system resources. The BIOS automatically detects the amount of memory in the system and configures CMOS accordingly during the POST (Power-On-Self-Test) pro- cess.

  • Page 59: Appendix

    Appendix Optional Accessories Optional Connections DVD-ROM Drive Information Internal Modem Compliancy Glossary Safety Statements Notebook PC Information...

  • Page 60: Optional Accessories

    Appendix Optional Accessories These items, if desired, come as optional items to complement your Notebook PC. USB Hub (Optional) Attaching an optional USB hub will increase your USB ports and allow you to quickly connect or disconnect many USB peripherals through a single cable. USB 2.0 Slim Combo Drive (Optional) The slim combo drive features FlextraLink™...

  • Page 61: Wireless Lan Cardbus Card Or Usb (Optional)

    Notebook PC’s, Desk- top PC’s, or a combination of both. Appendix The ASUS USB Wireless LAN Adapter (WL- 167g) is thumb-sized and creates a wireless net- work using the IEEE 802.11g/b wireless standards and connects to any computer using USB2.0 con-...

  • Page 62: Usb Floppy Disk Drive (Optional)

    Appendix Optional Accessories (Cont.) These items, if desired, come as optional items to complement your Notebook PC. USB Floppy Disk Drive The Notebook PC features an optional USB-interface disk drive that accepts a standard 1.44MB (or 720KB) 3.5-inch floppy diskette. The eject button is on the top edge of the floppy disk drive for easy access, unlike desktop PCs with the eject button on the bottom of the floppy disk drive.

  • Page 63: Optional Connections

    Appendix Optional Connections These items, if desired, may be purchased from third-parties. Monitor Out Connection Attaching an optional VGA/LCD monitor is just like that of a standard desktop PC (some configu- rations may require additional display driver set- tings. You can view the Notebook PC display panel while simultaneously allowing others to view the external monitor.

  • Page 64: Ieee1394 Connection

    Appendix Optional Connections (Cont.) These items, if desired, may be purchased from third-parties. IEEE1394 Connection 1394 is a high speed serial bus like SCSI but has simple connections and hot-plugging capabilities like USB. Up to 63 devices such as hard disk drives, scanners, removable drives, and digital cameras/ video cameras with an 1394 port can all be con- nected (more 1394 devices can be connected us-...

  • Page 65: Regional Playback Information

    DVD-ROM Drive Information The Notebook PC comes with an optional DVD-ROM drive or a CD-ROM drive. In order to view DVD titles, you must install your own DVD viewer software. Optional DVD viewer software may be purchased with this Notebook PC. The DVD-ROM drive allows the use of both CD and DVD discs. Regional Playback Information Playback of DVD movie titles involves decoding MPEG2 video, digital AC3 audio and decryption of CSS protected content.

  • Page 66: Internal Modem Compliancy

    Appendix Internal Modem Compliancy The Notebook PC with internal modem model complies with JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved in accordance with Council Decision 98/ 482/EC for pan-European single terminal connection to the public switched telephone network (PSTN). However due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
  • Page 67 This table shows the countries currently under the CTR21 standard. Country Applied Austria Belgium Czech Republic Denmark Finland France Germany Greece Hungary Iceland Ireland Italy Israel Lichtenstein Luxemburg The Netherlands Norway Poland Portugal Spain Sweden Switzerland United Kingdom This information was copied from CETECOM and is supplied without liability. For updates to this table, you may visit http://www.cetecom.de/technologies/ctr_21.html National requirements will apply only if the equipment may use pulse dialling (manufacturers may state in the user guide that the equipment is only intended to support DTMF signalling, which would...

  • Page 68: Glossary

    Appendix Glossary ACPI (Advanced Configuration and Power Management Interface) Modern standard for reducing power usage in computers. APM (Advanced Power Management) Modern standard for reducing power usage in computers. AWG (American Wire Gauge) Gauge Diam Area (mm) (mm2) 0.04 0.0013 0.05 0.0020 0.06...
  • Page 69 Appendix BIOS (Basic Input/Output System) BIOS is a set of routines that affect how the computer transfers data between computer components, such as memory, disks, and the display adapter. The BIOS instructions are built into the computer’s read-only memory. BIOS parameters can be configured by the user through the BIOS Setup program. The BIOS can be updated using the provided utility to copy a new BIOS file into the EEPROM.
  • Page 70 Appendix Hardware Hardware is a general term referring to the physical components of a computer system, including pe- ripherals such as printers, modems, and pointing devices. IDE (Integrated Drive Electronics) IDE devices integrate the drive control circuitry directly on the drive itself, eliminating the need for a separate adapter card (in the case for SCSI devices).
  • Page 71 CLASS 3B: Class 3B lasers, and Class 3A lasers with outputs of 2.5mW, are hazardous to person- nel who are within the beam path and look at the beam source directly or by specular reflection. These lasers cannot produce hazardous diffuse reflections. Personnel working with these lasers should wear appropriate protective eyewear during any operation of the laser.

  • Page 72: Notebook Pc Information

    Appendix System Disk A system disk contains the core file of an operating system and is used to boot up the operating system. Twisted-Pair Cable The cable used to connect the Ethernet card to a host (generally a Hub or Switch) is called a straight- through Twisted Pair Ethernet (TPE).

  • Page 73: Declarations And Safety Statements

    Declarations and Safety Statements DVD-ROM Drive Information The Notebook PC comes with an optional DVD-ROM drive or a CD-ROM drive. In order to view DVD titles, you must install your own DVD viewer software. Optional DVD viewer software may be purchased with this Notebook PC.

  • Page 74: Network Compatibility Declaration

    Appendix Internal Modem Compliancy The Notebook PC with internal modem model complies with JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved in accordance with Council Decision 98/ 482/EC for pan-European single terminal connection to the public switched telephone network (PSTN). However due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
  • Page 75 Internal Modem Compliancy (Cont.) This table shows the countries currently under the CTR21 standard. Country Applied Austria Belgium Czech Republic Denmark Finland France Germany Greece Hungary Iceland Ireland Italy Still Pending Israel Lichtenstein Luxemburg The Netherlands Norway Poland Portugal Spain Sweden Switzerland United Kingdom...
  • Page 76 Appendix Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undes- ired operation.
  • Page 77 UL Safety Notices Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).

  • Page 78: Optical Drive Safety Information

    Appendix Optical Drive Safety Information Laser Safety Information Internal or external optical drives sold with this Notebook PC contains a CLASS 1 LASER PRODUCT (LASER KLASSE 1 PRODUKT). Laser classifications can be found in the glossary at the end of this user’s manual.
  • Page 79 Appendix Nordic Cautions (for Notebook PC with Lithium-Ion Battery) CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. (English) ATTENZIONE! Rischio di esplosione della batteria se sostituita in modo errato.
  • Page 80 Appendix CTR 21 Approval (for Notebook PC with built-in Modem) Danish Dutch English Finnish French German Greek Italian Portuguese Spanish Swedish...
  • Page 81 Appendix...
  • Page 82 Appendix Notebook PC Information This page is provided for recording information concerning your Notebook PC for future reference or for technical support. Keep this User’s Manual in a secured location if passwords are filled out. Owner’s Name: ____________________________ Owner’s Telephone: ______________ Manufacturer: _______________ Model: ___________ Serial Number: ______________ Display Size: ____________ Resolution: _____________ Memory Size: ______________ Retailer: _________________ Location: ___________ Purchase Date: ______________...

  • Page 83: Copyright Information

    ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringe- ment under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
  • Page 84 44370 Nobel Drive, Fremont, CA 94538, USA General Fax: +1-510-608-4555 Technical Support General Support: +1-502-995-0883 Notebook (Tel): +1-510-739-3777 x5110 ASUS COMPUTER GmbH (Germany & Austria) Company Address: Harkort Str. 25, D-40880 Ratingen, Germany General Telephone: +49-2102-95990 General Fax: +49-2102-959911 Technical Support...
