Operator's Manual
3600 Watts
030231
5400 STARTING WATTS
Questions?
WARNING
Help is just a moment away!
Find your Briggs and Stratton distributor
Before using this product, read
at www.briggsandstratton.com
this manual and follow all Safety
or contact your local Briggs and Stratton dealer.
Rules and Operating Instructions.
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
Manual No. 199454GS
JEFFERSON,WISCONSIN, U.S.A.
Revision 0 (02/09/2006)
Advertisement
Table of Contents
Related Manuals for Briggs & Stratton 30231
Summary of Contents for Briggs & Stratton 30231
- Page 1 Operator’s Manual 3600 Watts 030231 5400 STARTING WATTS Questions? WARNING Help is just a moment away! Find your Briggs and Stratton distributor Before using this product, read at www.briggsandstratton.com this manual and follow all Safety or contact your local Briggs and Stratton dealer. Rules and Operating Instructions.
-
Page 2: Table Of Contents
SAVE THESE INSTRUCTIONS TABLE OF CONTENTS Safety Rules ........2-4 Features and Controls . -
Page 3: Safety Rules
SAFETY RULES WARNING Running generator gives off carbon monoxide, an odorless, colorless, poison gas. Breathing carbon monoxide can cause nausea, fainting or death. • Operate generator ONLY outdoors. • Keep exhaust gas from entering a confined area through windows, doors, ventilation intakes or other openings. •... - Page 4 WARNING Rapid retraction of starter cord (kickback) will pull hand and arm toward engine faster than you can let go. Broken bones, fractures, bruises or sprains could result. • When starting engine, pull cord slowly until resistance is felt and then pull rapidly to avoid kickback. •...
-
Page 5: Features And Controls
FEATURES AND CONTROLS KNOW YOUR GENERATOR Read this Operator’s Manual and safety rules before operating your generator. Compare the illustrations with your generator, to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. Petrol Tank Hour Meter Double Pole... -
Page 6: Assembly
ASSEMBLY Your generator requires some assembly and is ready for use after it has been properly serviced with the recommended oil and petrol. Remove Generator From Carton Set the carton on a rigid flat surface. Open carton completely by cutting each corner from top to bottom. - Page 7 OPERATION USING THE GENERATOR System Ground The generator has a system ground that connects the generator frame components to the ground terminals on the AC output receptacles.The system ground is connected to the AC neutral wire (see “Equipment Description”, earlier in this manual). Special Requirements There may be National regulations, local codes, or ordinances that apply to the intended use of the...
-
Page 8: Operation
OPERATING THE GENERATOR Starting the Engine Disconnect all electrical loads from the generator. Use the following start instruction steps in numerical order: Make sure unit is on a level surface. IMPORTANT: Failure to start and operate unit on a level surface will cause the unit not to start or shut down during operation. - Page 9 OPERATION Check oil level daily or after every eight (8) hours of operation. Maintain generator following “Maintenance Schedule” in engine operator’s manual. Shelter unit from elements. Creating a Temporary Shelter In an emergency, use the original shipping carton. Cut off top carton flaps and one long side of carton to expose muffler side of unit.
- Page 10 RECEPTACLES A double pole rocker switch circuit breaker is provided to protect all the receptacles and generator against electrical overload. CAUTION Receptacles may be marked with rating value greater than generator output capacity. • NEVER attempt to power a device requiring more amperage than generator or receptacle can supply.
-
Page 11: Ground Fault Protection
OPERATION Ground Fault Protection The duplex receptacles are equipped with Ground Fault Circuit Interrupter (GFCI) protection.This device meets applicable federal, state and local codes.The generator’s locking receptacle is not protected by a GFCI. The GFCI protects against electrical shock that may be caused if your body becomes a path which electricity travels to reach the ground.This could happen if you touch a “Live”... - Page 12 DON'T OVERLOAD GENERATOR Capacity You must make sure your generator can supply enough rated (running) and surge (starting) watts for the items you will power at the same time. Follow these simple steps: Select the items you will power at the same time. Total the rated (running) watts of these items.
-
Page 13: Specifications
SPECIFICATIONS AND MAINTENANCE SPECIFICATIONS Starting Wattage ..... . 5,400 Watts Wattage ......3,600 Watts Rated AC Load Current At 110 Volts . -
Page 14: Storage
STORAGE The generator should be started at least once every seven days and allowed to run at least 30 minutes. If this cannot be done and you must store the unit for more than 30 days, use the following guidelines to prepare it for storage. -
Page 15: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Engine is running, but no AC output is available. Engine runs good but bogs down when loads are connected. Engine will not start; or starts and runs rough. Engine shuts down during operation. Engine lacks power. Cause Circuit breaker is open. -
Page 16: Warranty
Effective February 1, 2006 replaces all undated Warranties and all Warranties dated before February 1, 2006 Briggs & Stratton Power Products Group, LLC will repair or replace, free of charge, any part(s) of the portable generator that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.
