Asko D3350 Use And Care Manual

Asko D3350 Use And Care Manual

Asko d3350: use & care guide
Hide thumbs Also See for D3350:
Table of Contents

Advertisement

Quick Links

See also: Uso Y Cuidado
Use & Care Guide
Dishwasher
ASKO D3350

Advertisement

Table of Contents
loading

Related Manuals for Asko D3350

Summary of Contents for Asko D3350

  • Page 1 Use & Care Guide Dishwasher ASKO D3350...
  • Page 2 And this is what we try to give you. When you buy an ASKO product, we want you to feel assured that the inside is as good as the outside and that the ethics and morals on which we built this machine are just as high as the quality and performance you get from it.

  • Page 3: Table Of Contents

    Contents Contents Before doing your first wash Read through the directions for use Take care with certain materials Check the door Check the water hardness level Machines with water softener Safety General Winter storage/Transport Overfill protection Cleaning Packaging materials Scrapping Child safety Child-safe button lock Child-safe dishwashing...
  • Page 4 Settings Reprogramming Child-safe button lock Super rinse Setting water hardness Fault indications Troubleshooting The dishes are not clean Stains or a film on the china The china has a whitish-blue sticky film Stains on stainless steel or silver Stains which remain after dishwashing Rattling sounds during dishwashing The machine will not start Water remains in the machine...

  • Page 5: Before Doing Your First Wash

    Before doing your first wash Read through the directions for use Read the directions of use before starting to use your machine, especially the Safety, Child Safety and Basic Course sections. Take care with certain materials Read the section ‘Fragile Dishes’ before washing china with unglazed decoration or other household goods made of plastic, wood or crystal requiring careful treatment.

  • Page 6: Safety

    Safety General: • Read and keep the directions for use! • Installation of water, drainage and elec- tricity must be carried out by a qualified professional. • Do not use the dishwasher for any pur- poses other than those stated in these directions for use.

  • Page 7: Child Safety

    Child safety! Child-safe button lock To prevent children starting the machine, you can activate a button lock. Proceed as follows: 1. Switch off the dishwasher at the main switch. 2. Hold in the High temperature and Extra dry buttons, and at the same time switch on the main switch.

  • Page 8: Parts Of The Dishwasher

    Parts of the dishwasher* 1. Knife basket 2. Upper basket 3. Lamp 4. Spray arms 5. Lower basket 6. Cutlery basket 7. Rinse Aid Filling 8. Dishwasher detergent compartment 9. Main switch 10. Program panel 11. Filter 12. Type plate * Details may differ depending on model and market! Technical information...

  • Page 9: Baskets

    Baskets* Upper basket Lower basket Cutlery basket Knife basket 1. Wine glass shelf 2. Cup rack 3. Folding plate stand 4. Cutlery basket with folding door and handle *Details may differ depending on the model and market!

  • Page 10: Control Panel

    Control panel P R O G P R O G 1. Program selector 2. Pots & Pans 3. Heavy wash 4. Normal wash 5. Delicate wash 6. Quick wash 7. Rinse & Hold 8. Start/Stop Dispenser S T A R T S T A R T S T A R T S T O P...

  • Page 11: Basic Course

    Basic Course Below are step by step instructions to help you achieve the best possible dishwashing results. Load the baskets correctly! Your dishwasher has a Super Clean- ing System™, which means that there is no need to rinse the dishes before washing. Simply remove large food particles and de- bris.

  • Page 12: Select Program

    Only use dishwasher detergent Detergent for washing by hand cannot be used as the build-up of foam impedes the machine’s performance. Press the Power main switch and close the door Select program Select a program by pressing the program button one or more times until the required program symbol lights up.

  • Page 13: Options

    Options Select options To select an option, press one of the option buttons. Upper basket/ Lower basket/ Both By pressing the option button for upper basket/lower basket (see display picture page 10), you can choose to wash only the upper basket, the lower basket or both baskets.

  • Page 14: Press Start

    Press start The dishwasher will now start. It manages the entire wash automatically. Close the door properly, or the machine will not start. Changing options If you want to change program after having started the machine, press the Start/Stop button for three seconds. Then select a new program and press the Start/Stop button.

  • Page 15: Eco-Dishwashing

    Eco-dishwashing Only wash with a full load Waiting to run the wash until the machine is full saves energy. Wash at a lower temperature If the load is only lightly soiled, you can lower the temperature: in Delicate Wash to 40°C and Quick Wash to 30°C.

  • Page 16: Fragile Dishes

    Fragile dishes A number of household goods are not suit- able for machine washing. There can be many reasons for this. Certain materials cannot withstand intense heat, others can be damaged by the dishwasher detergent. Fragile decoration China with decoration on top of the glaze (the article has a rough feel) should not be machine washed.

  • Page 17: Standard Program

    Standard program Option Program Temp. Drying wash Pots & pans High Long Heavy wash High Long Normal wash High Normal Normal wash * Normal Upper basket Normal Delicate wash High Normal Quick wash High Normal Quick wash Normal Rinse & dry Long Rinse &...
  • Page 18 This page is empty for printing reasons...

  • Page 19: Display

    Display When you have selected a program, the display shows the length of time the pro- gram took the last time it was used. When you have started the machine, the display window shows an approximate duration. This time can vary a little from one occasion to another depending on the temperature of the incoming water, the amount of dishes, the ambient temperature, etc.

  • Page 20: Cleaning

    Cleaning Cleaning The dishwasher’s inner container is made of stainless steel and is kept clean through normal use. However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in the dishwasher detergent compartment.

  • Page 21: Spray Arms

    If you still cannot start the machine and a humming noise can be heard, then the overfilling protection has been activated. • Shutoff the water • Remove the plug from the wall socket • Call Service CAUTION! Do not forget to replace the pump plug. Spray arms The holes and bearings can occasionally become clogged.

  • Page 22: Rinse Aid

    Rinse aid Pour in rinse aid Rinse aid, helps quicker the drying process. When the rinse aid runs out, the rinse aid symbol lights up on the panel.* Certain machines do not have this function. There is a refill indicator in the middle of the dispenser (see picture).

  • Page 23: Salt

    Salt Pour in salt Before using a dishwasher with a water softening filter, you must fill the salt com- partment with salt. Use coarse salt or spe- cial salt for dishwashers. It is best to fill with salt when you are about to do a wash, as the dishwasher needs to be rinsed out immediately after filling.

  • Page 24: Settings

    Settings Reprogramming Some of the machine’s functions can be reprogramd. You get into the machine’s change program using the machine’s ordinary buttons as per the instructions below. The selection will be retained until the next time you reset this function. Even if the machine is turned off at the main switch or loses power for any other reason, all selections registered before the interruption of power will be retained.

  • Page 25: Super Rinse

    Super rinse Super rinse means that two extra rinses will be addes at the end of the main dish. Cannot be used in the Quick wash and Rinse & Hold programs. Switch off the dishwasher with the main switch. Hold in the Express button while pressing the main switch. The Express button and Start will flash.

  • Page 26: Setting Water Hardness

    Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery. Switch off the dishwasher at the main switch.

  • Page 27: Fault Indications

    Fault indications Display Type of fault Too much water in the machine Fault with water inlet Valve leakage Blocked outflow Clogged filter To remove the fault indications from the display, turn off the main switch and then turn it back on again. Action Phone service Check that the tap is open...

  • Page 28: Troubleshooting

    Troubleshooting Problems The dishes are not clean. Stains or a film on the china. Possible causes • The spray arms are not rotating. • Old dishwasher detergent. NB! Detergent is a perishable. • Incorrect dosage of detergent. • Insufficiently powerful dishwashing program.

  • Page 29: The China Has A Whitish-Blue Sticky Film

    Problems The china has a whitish- blue sticky film. Stains on stainless steel or silver. Stains which remain after dishwashing. Rattling sound during dishwashing. The machine will not start. To restart the machine, press Start/stop for 3 seconds. Now select a new programme and press Start/stop.

  • Page 30: Water Remains In The Machine

    Problems Water remains in the machine. Bad odour in the machine Possible causes • Obstruction in the drain hose. • Kinks in the drain hose. • The filters are clogged. • Objects in the drain pump. • Dirt along the strips and in corners Action •...

  • Page 31: Performance Information

    Performance information Test dosage Heavy wash/Normal wash Main wash 25 gram Standard detergent. Rinse aid dosage 3. Energy labelling Australia: Dishwasher program: Normal wash, 45°C normal dry Program time: Connection: Test method noise measurement: Example of dishwasher loading AS/NZS 2007.1:2003 Technical information Height: Width:...

  • Page 32: Installation

    Installation Suggestions for positioning the dishwasher The dishwasher can be built in, fully free- standing or semi-freestanding. CAUTION! Connection to electricity, water and drain- age must be carried out by a suitably quali- fied person. A. Built-in The dishwasher can be built in under a worktop with a working height of 820 - 870 mm.

  • Page 33: Connection To Water

    Connection to water There must be a shut-off tap on the water supply pipe. The shut-off tap should be positioned above the work surface or at the front of the sink unit. The water supply pipe has a connection with a 1/2” or 3/4” internal thread depending on country.

  • Page 34: Positioning The Machine

    Positioning the machine A. Adjusting machines with 6 feet (freestanding dishwasher) 1. Adjust the height of the dishwasher with the four steel feet. 2. Lock the feet with the nuts. NB! The dishwasher must not be allowed to lean more than 5 mm. Stålfötter Steel feet 3.

  • Page 35: Screw The Dishwasher Into Place

    To prevent kinks, pull the drain hose and the connecting pipe. Adjusting the plinth (Only with kick-plate as accessory) The dishwasher has two kick-plates (some models). The taller one should be used if the machine is to be 850 - 870 mm high and the plinth depth can be varied between 45 - 105 mm.

  • Page 36: Setting Water Hardness

    Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery. Switch off the dishwasher at the main switch.

  • Page 37: Service & Guarantee

    Service & guarantee Service Before calling for service, check to see whether the faults are due to something that you can put rectify. See Trouble shooting pages 28-30. Guarantee For guarantee details, see the guarantee card.

  • Page 38: Own Comments

    Own comments...

  • Page 39: Search Words

    Search words Advice! 7, 14 After dishwashing 14 Child safe 3, 5, 7, 24 Child safety lock 7 Citric acid 20, 22 Cleaning 6, 20, 21, 29 Connection 8, 17, 30, 31, 32 Control panel 10, 22 Crystal 5, 16, 27 Cutlery basket 9 Delicate wash 10, 12, 13, 15 Dishwasher detergent 6, 7, 11, 23...

  • Page 40: Quick Guide

    Quick Guide 1. Loading baskets Remove large food particles and debris. There is no need to rinse thanks to the Super Cleaning System ™ 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash.
