Art 341 EQ Specifications

Dual 15-band 2/3 octave graphic equalizer

Advertisement

Quick Links

341 EQ
DUAL 15-BAND 2/3 OCTAVE GRAPHIC EQUALIZER
T
he Model 341 Dual 15-Band 2/3 Octave Graphic Equalizer may be used in a
variety of applications such as live sound, recording studios, instrument racks,
DJ sound systems and fixed equipment installations. Designed to interface into
any audio system, the Model 341 is a powerful tool for solving audio problems
and creating interesting sound textures.
The Model 341 possesses a long list of impressive features including: constant Q
circuitry, 20mm center detent sliders (with a selectable boost/cut range of 6dB or
12dB), balanced XLR and 1/4" and unbalanced RCA input and output connec-
tions, variable input level controls, signal clip level indicators, ground lift switch,
internal power supply and selectable line voltage switch. The rugged, all-steel
constructed chassis occupies 1U rack spaces and is intended for installation into
standard 19" equipment racks.
The 341 Dual Channel 15 Band EQ has the features and performance you need
for any of your audio applications requiring precise equalization. For the latest in
equalizer technology today, check out the 341 at your favorite A R T dealer.
~ Using in a 2-Way Speaker System ~
High Output
Channel Insert
Send
Channel Insert
Return
L
R
Stereo Mix
Low Outputs
~ In the Insert of a Mixer ~
To Input of 341
From Output of 341
High Output
FEATURES:
DUAL CHANNEL 15-BAND
GRAPHIC EQUALIZER
CONSTANT-Q FILTERING
BALANCED XLR, ACTIVE
BALANCED 1/4", AND
UNBALANCED RCA INPUT
AND OUTPUT
CONNECTORS
+/- 6DB OR +/-12DB
LEVEL ADJUSTMENTS
20MM CENTER DETENTED
FREQUENCY BAND SLIDERS
INDEPENDENT LEVEL AND
BYPASS CONTROLS PER
CHANNEL
DESIGNED FOR YEARS OF
CONTINUOUS, RELIABLE
PERFORMANCE
RUGGED ALL STEEL
CONSTRUCTION
ONE YEAR WARRANTY

Advertisement

loading

Summary of Contents for Art 341 EQ

  • Page 1 341 EQ DUAL 15-BAND 2/3 OCTAVE GRAPHIC EQUALIZER he Model 341 Dual 15-Band 2/3 Octave Graphic Equalizer may be used in a variety of applications such as live sound, recording studios, instrument racks, DJ sound systems and fixed equipment installations. Designed to interface into any audio system, the Model 341 is a powerful tool for solving audio problems and creating interesting sound textures.
  • Page 2: Specifications

    341 EQ SPECIFICATIONS SPECIFICATIONS: Dimensions: 1.75”H x 19” W x 8.5” D Weight: 4.5lbs. (2.5kg) Frequency Bands: 2X15, 2/3 octave, ISO spacing Filter Type: Constant Q - 3% center accuracy Slider Travel: 20mm w/ positive center detent Range: +/-6dB or +/-12dB selectable Input Connections: Active balanced XLR and 1/4”...
