HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
GN1T
CHASSIS
ORIGINAL MANUAL ISSUE DATE: 6/2015
Segment: XB
Version
Date
Subject
1.0
6/2015
Original manual issue.
LCD TV
9-888-574-01
