Essential Circuit Selection - Briggs & Stratton 01897-0 Installation And Owner's Manual

The wattage reference guide shown in Figure 2 will assist
the owner with their decision-making process. It provides
the wattage used by many ordinary household devices. Use
it as a guide when selecting essential circuits. Review this
information with the owner and convey any technical
considerations that might affect the cost of installation.

Essential Circuit Selection

When selecting the essential circuits that will be switched to
"Standby Power, " it is important that the sum of the combined
circuit loads does not exceed the wattage/amperage capacity
of the generator.To help you with your selection of essential
circuits, please consider the following:
Add up the total wattage of all electrical devices to be
connected at one time.This total should NOT be
greater than the generator's wattage capacity.
The rated wattage of lights can be taken from light bulbs.
The rated wattage of tools, appliances and motors can
usually be found on a data plate or decal affixed to the
device.
If the appliance, tool or motor does not give wattage,
multiply volts times the ampere rating to determine
watts (Volts x Amps = Watts).
Some electric motors (induction types) require about
three times more watts of power for starting than for
running.This surge lasts for only a few seconds. Be sure
you allow for this high starting wattage when selecting
electrical devices that will be energized by the Standby
Generator:
• Figure the watts required to start the largest motor.
• Add that to the total running watts of all other
connected loads.
This Briggs & Stratton Standby Generator complies
with the following "stationary standby power rating":
The standby power rating is applicable for supplying power
for the duration of normal power interruption. NO
sustained overload capability is available for this rating.
This rating is applicable to installations served by a
reliable normal utility source.This rating is only applicable
to variable loads with an average load factor of 80% of
the standby rating.The standby rating is only applicable
for optional standby power where the generator set
serves as the backup to the normal utility source.
Use the "Wattage Reference Guide" provided and mark
those circuits you consider "critical" or "essential". Make
sure you and your installer consider the generator's
altitude above sea level and the ambient temperature range
when determining total generator load.
Briggs & Stratton Power Products Standby Generator
Installation, Start-Up and Owner's Manual
10
Figure 2 — Wattage Reference Guide
Device
Air Conditioner (12,000 Btu)*
Air Conditioner (24,000 Btu)*
Air Conditioner (40,000 Btu)*
Battery Charger (20 Amp)
Circular Saw (6-1/2")
Clothes Dryer (Electric)*
Clothes Dryer (Gas)*
Clothes Washer*
Coffee Maker
Compressor (1 HP)*
Compressor (1/2 HP)*
Compressor (3/4 HP)*
Curling Iron
Dehumidifier*
Electric Blanket
Electric Range (per element)
Electric Skillet
Freezer*
Furnace Fan (3/5 HP)*
Garage Door Opener*
Hair Dryer
Hand Drill
Iron
Jet Pump*
Light Bulb
Microwave Oven
Milk Cooler*
Oil Burner on Furnace
Oil Fired Space Heater (140,000 Btu)
Oil Fired Space Heater (30,000 Btu)
Oil Fired Space Heater (85,000 Btu)
Radio
Refrigerator
Slow Cooker
Submersible Pump (1 HP)*
Submersible Pump (1/2 HP)*
Submersible Pump (1-1/2 HP)*
Sump Pump*
Table Saw (10")*
Television
Toaster
*Allow three (3) times listed watts for starting device
