global_main.book.book Page 1 Thursday, November 26, 2020 5:50 PM
OWNER'S MANUAL
FRIDGE & FREEZER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG GBB566PZHZN
Summary of Contents for LG GBB566PZHZN
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH www.lg.com Copyright © 2020 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Moving the Appliance for Relocation ............13 OPERATION Before Use ......................14 Product Features....................17 Control Panel ....................19 Water Dispenser....................20 Icemaker ......................21 Fridge Drawer....................22 Door Basket ......................23 Shelf ........................23 Freezer Drawer....................23 SMART FUNCTIONS LG ThinQ Application ..................25 Smart Diagnosis ....................27 MAINTENANCE Cleaning ......................29 TROUBLESHOOTING Before Calling for Service................30... -
Page 3: Safety Instructions
global_main.book.book Page 3 Thursday, November 26, 2020 5:50 PM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. - Page 4 global_main.book.book Page 4 Thursday, November 26, 2020 5:50 PM SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 5 • Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 6 global_main.book.book Page 6 Thursday, November 26, 2020 5:50 PM SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials • If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
- Page 7 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
- Page 8 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
-
Page 9: Caution
global_main.book.book Page 9 Thursday, November 26, 2020 5:50 PM SAFETY INSTRUCTIONS Disposal • When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place and keep children away from the appliance. CAUTION CAUTION • To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Operation... -
Page 10: Caring For The Environment
They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • To remove frost from the appliance, contact an LG Electronics customer information centre. • Dispose of the ice inside the ice bin in the freezer compartment during an extended power outage. -
Page 11: Installation Before Installation
global_main.book.book Page 11 Thursday, November 26, 2020 5:50 PM INSTALLATION INSTALLATION Before Installation Dimensions and Clearances Too small of a distance from adjacent items may result in the degradation of freezing capability and increased electricity costs. Allow over 50 mm of clearance from each adjacent wall when installing the appliance. -
Page 12: Levelling The Appliance
• Reversing the doors must be performed by the • The climate class can be found on the rating qualified personnel of LG Electronics. If not, the label. doors will not be covered by the warranty. Climate Class Ambient Temperature Range ºC... -
Page 13: Moving The Appliance For Relocation
global_main.book.book Page 13 Thursday, November 26, 2020 5:50 PM INSTALLATION food into the appliance. If you add food before the appliance has cooled completely, your food may spoil. Moving the Appliance for Relocation Preparing for Relocation Remove all food from inside the appliance. Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance. -
Page 14: Operation Before Use
1 minute. the repair technician from the our information centre may have difficulty finding the problem. NOTE • Contact the LG Electronics customer information centre if the alarm sound continues even after Suggestion for Energy Saving closing all doors. - Page 15 global_main.book.book Page 15 Thursday, November 26, 2020 5:50 PM OPERATION • Note that a temperature rise after defrosting has temperature lower than the required a permissible range in the appliance temperature for the food to be stored correctly. specifications. If you wish to minimise the impact •...
- Page 16 global_main.book.book Page 16 Thursday, November 26, 2020 5:50 PM OPERATION OK Temperature Label The OK mark of the OK label appears when the fridge temperature reaches 4 °C or lower. This label indicates that this is a storage space where food can be stored fresh at a temperature of 4 °C or lower.
-
Page 17: Product Features
global_main.book.book Page 17 Thursday, November 26, 2020 5:50 PM OPERATION Product Features The appearance or components of the appliance may differ from model to model. Interior *1 This feature is only available on some models. Control Panel Sets the fridge temperature and freezer temperature. Water Dispenser Dispenses cold water. - Page 18 global_main.book.book Page 18 Thursday, November 26, 2020 5:50 PM OPERATION Folding Shelf This is adjustable to meet individual storage needs. Bottle Rack Stores containers and tall bottles using the bottle rack. CAUTION • Do not store short bottles on the bottle rack. The items may fall and cause an injury or appliance damage.
-
Page 19: Control Panel
global_main.book.book Page 19 Thursday, November 26, 2020 5:50 PM OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Control Panel 1: On the Fridge Door Control Panel 2: Inside the Fridge Fridge Press this button repeatedly to select a desired temperature between 1 °C and 7 °C. -
Page 20: Water Dispenser
• When this mode is on, the other buttons except Lock and Wi-Fi buttons will not operate. Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to SMART FUNTIONS for information on the initial setup of the LG ThinQ application. Lock This locks the buttons on the control panel. -
Page 21: Icemaker
global_main.book.book Page 21 Thursday, November 26, 2020 5:50 PM OPERATION Cleaning the Dispenser Outlet • If water does not come out, fill the water tank with potable water. Wipe the dispenser outlet frequently with a clean cloth as it may get dirty easily. NOTE •... -
Page 22: Fridge Drawer
global_main.book.book Page 22 Thursday, November 26, 2020 5:50 PM OPERATION Rotate the icemaker handle clockwisely. As a chill compartment, the temperature in the Fresh Converter can be controlled by sliding the lever , where located in front of compartment, in either direction. -
Page 23: Door Basket
global_main.book.book Page 23 Thursday, November 26, 2020 5:50 PM OPERATION Removing/Refitting the Fridge Store taller items, such as a gallon container or bottles, by pushing the front half of the shelf Drawer underneath the back half the shelf. • Pull the front of the shelf forward to return to a Remove the contents of the drawer. - Page 24 global_main.book.book Page 24 Thursday, November 26, 2020 5:50 PM OPERATION Lift the drawer up and remove it by pulling it out. Refit the drawer in the reverse order of the removal process.
-
Page 25: Smart Functions
Internet service provider or refer to your appliance improvement purposes without notice wireless router manual. to users. • LG ThinQ is not responsible for any network • Functions may vary by model. connection problems or any faults, malfunctions, or errors caused by network connection. - Page 26 20 cm between the device and the body. Connecting to Wi-Fi Declaration of Conformity The Wi-Fi button, when used with the LG ThinQ application, allows the appliance to connect to a home Wi-Fi network. The icon shows the status Hereby, LG Electronics declares that the radio of the appliance’s network connection.
-
Page 27: Smart Diagnosis
• Launch the LG ThinQ application and select the LG Electronics will also provide open source code to Smart Diagnosis feature in the menu. Follow you on CD-ROM for a charge covering the cost of... - Page 28 global_main.book.book Page 28 Thursday, November 26, 2020 5:50 PM SMART FUNCTIONS Press and hold the Freezer button for 3 seconds or longer while holding your phone to the speaker until the data transfer is complete. After the data transfer is complete, the diagnosis will be displayed in the application.
-
Page 29: Maintenance Cleaning
global_main.book.book Page 29 Thursday, November 26, 2020 5:50 PM MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • When removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to •... -
Page 30: Troubleshooting
global_main.book.book Page 30 Thursday, November 26, 2020 5:50 PM TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Check the power of other appliances. •... - Page 31 global_main.book.book Page 31 Thursday, November 26, 2020 5:50 PM TROUBLESHOOTING Symptoms Possible Cause & Solution The appliance contains Is the fridge or freezer temperature set to 'Warm'? a bad smell. • Set the fridge or freezer temperature to a colder setting. Did you put in food with a strong smell? •...
- Page 32 global_main.book.book Page 32 Thursday, November 26, 2020 5:50 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Frost has formed in the Doors may not be closed properly? freezer compartment. • Check if the food item inside the appliance is blocking the door and make sure that the door is tightly closed.
- Page 33 Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp. Noises Symptoms Possible Cause & Solution...
- Page 34 global_main.book.book Page 34 Thursday, November 26, 2020 5:50 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Rattling noises Appliance is not resting evenly on the floor. • Floor is weak or uneven or levelling legs need to be adjusted. Appliance with linear compressor was moved while operating. •...
- Page 35 • Spare parts referenced in Regulation EU 2019/2019 are available for 7 years (only door gaskets are available for 10 years). • To purchase spare parts, contact an LG Electronics customer information centre or our website at www.lg.com. NOTE •...
- Page 36 global_main.book.book Page 36 Thursday, November 26, 2020 5:50 PM TROUBLESHOOTING NOTE • The model name can be found on the rating label of the appliance.
- Page 37 global_main.book.book Page 37 Thursday, November 26, 2020 5:50 PM Memo...
- Page 38 global_main.book.book Page 40 Thursday, November 26, 2020 5:50 PM...
