American Dynamics MegaPower 3200 Datasheet page 3

System Components
Central Processing Unit
ADMPCPU . . . . . . . . . . . . . . . . . MegaPower CPU for MP 3200 systems,
100-240 VAC
ADACQORJ45 . . . . . . . . . . . . . . Quick on RJ45 connector for easy
and clean installation
Switcher Bays
AD2010N . . . . . . . . . . . . . . . . . . Standard Matrix Bay, 120 VAC, UL & CSA
AD2020N . . . . . . . . . . . . . . . . . . Bi-Level Matrix Bay, 120 VAC, UL & CSA
AD2010P . . . . . . . . . . . . . . . . . . Standard Matrix Bay, 100-240 VAC, CE
AD2020P . . . . . . . . . . . . . . . . . . Bi-Level Matrix Bay, 100-240 VAC, CE
AD2010PS . . . . . . . . . . . . . . . . . Power Supply Module for AD2010N, AD2020N
AD2010PS-1 . . . . . . . . . . . . . . . Power Supply Module for AD2010P, AD2020P
Video Input
AD2016PC . . . . . . . . . . . . . . . . . Input Card
AD2016AVIM-1 . . . . . . . . . . . . . Input Module, Single Level
AD2016AVIM-2 . . . . . . . . . . . . . Input Module, Level 1 of Multi Level System
AD2016AVIM-3 . . . . . . . . . . . . . Input Module, Level 2 of Multi Level System
AD2016AVIM-4 . . . . . . . . . . . . . Input Model for Looping/ Additional Multi
Level Systems
AD2016BP-1 . . . . . . . . . . . . . . . VIM-1 Input Card Rear Panel
AD2016BP-2 . . . . . . . . . . . . . . . VIM-2 Input Card Rear Panel
AD2016BP-3 . . . . . . . . . . . . . . . VIM-3 Input Card Rear Panel
AD2016BP-4 . . . . . . . . . . . . . . . VIM-4 Input Card Rear Panel
Video Output
AD2024BVOM-1 . . . . . . . . . . . . Output Module, 960 Input systems
w/ Rear Panel
AD2024BVOM-3 . . . . . . . . . . . . Output Module, 1920 Input systems
w/ Rear Panel
AD2024BVOM-4 . . . . . . . . . . . . Output Module, 3200 Input systems
w/ Rear Panel
AD2024BP-1 . . . . . . . . . . . . . . . VOM-1 Output Card Rear Panel
AD2024BP-3 . . . . . . . . . . . . . . . VOM-3 Output Card Rear Panel
AD2024BP-4 . . . . . . . . . . . . . . . VOM-4 Output Card Rear Panel
AD2024BPC . . . . . . . . . . . . . . . . Video Output Card (no Rear panel)
Data Buffers
AD2010DB . . . . . . . . . . . . . . . . . Data Receiver/Buffer Module
AD2010DBVLKIT . . . . . . . . . . . . Video Loss Detection Module
Looping Panel Accessories
AD2016CB . . . . . . . . . . . . . . . . . Matrix cable, 30 in (76 cm), for looping
AD2016CB8 . . . . . . . . . . . . . . . . Matrix cable, 96 in (244 cm), for looping
ADULP . . . . . . . . . . . . . . . . . . . . Looping Panel
ADULP-30 . . . . . . . . . . . . . . . . . Looping Panel, w/ two AD2016CB 30"
(76 cm) Cables
ADULP-96 . . . . . . . . . . . . . . . . . Looping Panel, w/ two AD2016CB8 96"
(244 cm) Cables
AD2016TERM . . . . . . . . . . . . . . Matrix terminator cap for AD2016AVIM-3,
AD2016AVIM-4, & AD168VIM-4 (16 inputs)
ADACTP01BNC . . . . . . . . . . . . . Unshielded Twisted Pair Adaptor Module
This allows installation with simple
UTP cable for video lines
(5) Includes AD2016CB 30" (76 cm) cables.
5
5
5
5
Optional Accessories
AD2088, AD2088R, . . . . . . . . . . Full system keyboards allow for video switching,
AD2088-1, AD2088R-1, pan/tilt control, dome control, auxiliary control,
AD2089, AD2089R, macro and recorder control (ADCC1100, AD2088
AD2089-1, AD2089R-1, and AD2089 only), and system programming. The
ADTTE, ADCC1100, keyboards support bi-directional communication with
ADCC0200P, ADCC0300P the ADMPCPU via RS-232 ASCII commands
AD2081, AD2081X . . . . . . . . . . Expands one RS-232 port on a system into
Port Expander four ports. This provides connections to multiple
system keyboards.
AD2091, AD2091-1 . . . . . . . . . . Interfaces with the matrix switcher/controller system
Manchester Code via AD Data Line and provides 64 AD Manchester
Generator/Distributor code outputs for use by receiver/drivers and
suitably-equipped pan/tilts and domes.
AD2083-02C, . . . . . . . . . . . . . . Interfaces with the matrix switcher/controller system
AD2083-02C-1 RS-422 via AD Data Line and provides 16 SEC RS-422
Generator/Distributor outputs for use by suitably equipped domes.
AD2096A, . . . . . . . . . . . . . . . . . Supervises up to 64 alarm inputs and provides
AD2096-1 Alarm Interface RS-232 ASCII alarm commands to the system.
Alarm inputs can be programmed to call any video
input, display any preset, or to initiate any auxiliary
action. Up to 16 units can be cascaded on a single
RS-232 line.
AD2031, . . . . . . . . . . . . . . . . . . Activates relays when designated video inputs are
AD2031-1 Switcher Follower called to designated video outputs. It interfaces with
the matrix switcher/controller system and provides
up to 32 Form A relays, via AD Data Line, that can
be grouped in series and addressed to a single video
output, or in two groups of 16 relays for two specific
video outputs.
AD2032, . . . . . . . . . . . . . . . . . . Activates relays when associated video outputs are
AD2032-1 Alarm Responder in their alarming condition. Interfaces with matrix
switcher/controllers and provides up to 32 Form A
relays via AD Data Line.
AD2033, . . . . . . . . . . . . . . . . . . Activates relays when a specific auxiliary
AD2033-1 Auxiliary Follower is triggered either manually or automatically for
an associated video input. Interfaces with matrix
switcher/controllers and provides up to 32 Form A
relays via AD Data line.
AD100XA/AD100XA-1A . . . . . . . CPU of the recorder interface network; can
Recorder Controller accommodate the entire network and it enables
programming of the control devices.
AD100IR16/AD100IR16-1A . . . . Controls any recorder that has IR capability and is
IR Interface Module supplied with an IR remote (used to learn the
IR commands).
AD100RL8/AD100RL8-1 . . . . . . Controls recorders that can be controlled via
Resistive Ladder Module resistive ladder.
AD100RS8/AD100RS8-1 . . . . . Controls RS-232 VCRs and DVRs
RS-232 Module
Model Number Configurator
The configuration tool adds
flexibility to any job, allowing
change as the customers'
requirements change.
Pre-configured systems from
4 to 128 outputs include one
MPCPU; pre-configured
systems >128 outputs include "–" = standard BNC inputs on VIM Back Panels
"S" = all VIM4 & Remote Panels (30" cables)
two MPCPU.
"L" = all VIM4 & Remote Panels (96" cables)
A D M P R V x x x x - y y y 1
"blank" = standard system
"V" = factory installed
video loss
# of inputs, increments
of 16, up to 3200
(i.e. 16, 32...3200)
# of outputs, increments of 4,
up to 256 (i.e. 4, 8...256)
"N" = 120 VAC (+or - 10%),
50-60 Hz, UL & CSA
"P" = 100-240 VAC, 50-60 Hz, CE
