Rotel RSDX-02 Technical Manual

T echnical
Manual
Table of Contents
Specification......................................1
Parts List...........................................2~19
Trouble Reference, Update Procedure...20~24
Specifications
Amplifier
Output Power, Stero OIperation:
80 W per ch, min. RMS, 8 ohms, 40 Hz – 20 kHz
with no more than 0.8% total harmonic distortion.
Output Power, Surround operation: r
80 W per ch, min. RMS, 8 ohms at 1 kHz, with no
more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
TV, TAPE/CDR, DBS, VCR: 240mV/47kohm
Audio Input (DIGITAL IN):
Coaxial: 0.5 V(p-p)/75 ohms
Optical: –21 dBm to –15 dBm (660 nm ±30 nm)
Digital formats:
Linear PCM, Dolby Digital, and DTS (with sampling
frequency–32 kHz, 44.1 kHz, 48 kHz)
Signal-to-Noise Ratio ('66 IHF/'78 IHF):
TV, TAPE/CDR, DBS, VCR: 87dB/67dB
Frequency Response:
TV, TAPE/CDR, DBS, VCR: 20 Hz to 20 kHz (±1 dB)
Tone Control:
Bass (100 Hz): ±10 dB
Treble (10 kHz): ±10 dB
FM tuner (IHF)
Tuning Range:
87.5 MHz to 108.0 MHz
AM tuner
Tuning Range:
530 kHz to 1 710 kHz
THE ROTEL CO., LTD.
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Quality Uncompromised
Video
Video Input Sensitivity / Impedance (1kHz):
Composite video: 1 V(p-p)/75 ohm
S-Video (Y:luminance): 1 V(p-p)/75 ohm
S-Video (C:chrominance): 0.286 V(p-p)/75 ohm
Video Output Level / Impedance (1 kHz):
Composite video:1 V(p-p)/75 ohm
S-video (Y:luminance):1 V(p-p)/75 ohm
S-video (C:chrominance): 0.286 V(p-p)/75 ohm
Component video (Y): 1.0 V(p-p)/75 ohm
Component video (P
Color System:
NTSC or P AL
Horizontal Resolution:
500 lines or more
Signal-to-Noise Ratio (S/N):
63 dB
Synchronize:
Negative
General
Power Requirements:
US version : AC 120 V , 60 Hz
EU version : AC 230 V , 50 Hz
Power Consumption:
US version : 200 W
EU version : 180 W
2 W (in standby mode)
Dimensions (W x H x D):
435 mm x 118 mm x 415 mm
(17 in. x 4
3/16 5/8
Weight:
9.6 kg (21.2 lbs)
®
DVD AUDIO SURROUND RECEIVER
RSDX-02
PCB Assembly..................................25~29
Schematic Diagram ..........................30~43
/P ): 0.7 V(p-p)/75 ohm
B R
in. x 16 in.)
3/8
Serial. NO.
Beginning
(EU)
Y-374A-0403/pdf
