Provides information on using this projector, using the Configuration menu, troubleshooting, and maintenance. You can find this manual on the Document CD-ROM supplied with this projector. • Specifications Provides information on the projector specifications, external dimensions, supported lenses, and so on. Contact your local Epson dealer.
Introduction Notations Used in This Guide The documentation and the projector use graphical symbols to show how to use it correctly and safely to avoid personal injury, injury to others, and damage to property. The indications and their meaning are as follows. Make sure you understand them properly before reading the guide.
Transport and Installation Handbook Notes on Carrying and Transporting Caution Before carrying this projector, make sure you turn it off and disconnect all cables. When carrying without packing Note the following points when moving the projector by hand or by using a forklift to a close location without packing it up.
Transport and Installation Handbook Caution When lifting this projector with a forklift, do not insert the fork from the front of the projector (the lens side). Otherwise, the lens unit or the projector could be damaged. Insert the fork from the rear or the side. When packing and transporting Note the following points when packing up this projector and transporting it on a track and so on.
Transport and Installation Handbook Notes on Installation Notes on the Installation Environment Warning Do not use or install the projector where it may be subject to water or rain, or high humidity, such as outdoors, in a bathroom, or shower room, and so Otherwise, it could cause a fire or electric shock.
Transport and Installation Handbook Caution When using the projector in smokey environments such as at events and so on, make sure you replace the air filter within 24 hours. Do not install the projector in an airtight location. Heat exhausted from the projector will become trapped in the location which could cause the projector to malfunction.
Page 9
Transport and Installation Handbook Warning You may need dedicated installation mounts to tilt and install the projector. Contact a professional and prepare the mount. • Plan so that the mount does not fall. • Make sure the mount is strong enough to support the projector. •...
Page 10
Transport and Installation Handbook Caution Note the following points when installing a projector directly on top of another. • Do not stack three or more projectors. • Install the feet in the indentations on the top at the four corners. •...
Transport and Installation Handbook Notes on Connections Warning Be careful when handling the power cord. Otherwise, it could cause a fire or electric shock. Note the following when handling the power cord. • Only use the specified power-supply voltage. • Do not plug multiple power cords in a single electric outlet.
Page 12
Transport and Installation Handbook Caution Do not attach the lens unit when the lens insertion section is facing up. Dust or dirt could enter the projector. While pressing the tabs on both sides of the lens replacement cover, pull it towards you to remove it.
Page 13
Transport and Installation Handbook Insert the lens unit straight so that the protruding points on the lens fit through the holes (2 points) at the top of the lens unit. When attaching the lens unit, do not touch the motor covers shown in the following illustration (2 points).
