- Page 1 EC-1 AES/EBU NTERFACE M20 P FOR THE IRST PPLIES TO OPERATING SOFTWARE 1998 A LESIS ROFESSIONAL ECORDER ’ WNER ANUAL 1.00 DITION ERSION LESIS ORPORATION IGITAL 1.11 ERSION...
- Page 2 EC-1 AES/EBU Interface, Appendix E EC-1 M 1.00 ANUAL...
-
Page 3: Table Of Contents
This document covers only those aspects unique to the EC-1 card and should be inserted into the binder with the M20 manual. ABLE OF ONTENTS Important Safety Instructions...2 Safety symbols used in this product ...2 CE Declaration of Conformity...2 About the EC-1 ...4 Overview of Main Functions ...5 About AES/EBU Digital Audio...5 Digital Audio Cables ...5... -
Page 4: Important Safety Instructions
Standards: Application of Council Directive: Safety: EMC: European Contact: NSTRUCTIONS ONFORMITY Alesis Corporation 1633 26th Street Santa Monica, CA 90404 EC-1 Expansion Card for Digital Multitrack 89/336/EEC; 73/23/EEC Exempt from Low Voltage Directive EN 55022:1995 Class A, EN50082-1:1992 (IEC 801-2:1991 2nd Edition, 4kV direct, IEC 801-3:1984 2;... - Page 5 Appendix E, EC-1 AES/EBU Interface October, 1998 EC-1 M 1.00 ANUAL...
-
Page 6: About The Ec-1
The EC-1 expansion card is designed for use only with M20 software version 1.11 or higher. If your M20 has a lower software version, contact Alesis Technical Support at (800) 5-ALESIS or visit our web site at www.alesis.com to download the latest M20 software in the form of a... -
Page 7: Overview Of Main Functions
VERVIEW OF AES/EBU D BOUT The AES/EBU protocol is the most common professional standard for transmitting digital audio. It is a two-channel protocol designed for stereo pairs, so transmitting from the eight-channel ADAT M20 requires the use of four sets of AES/EBU jacks: four XLR male jacks for output, and four XLR female jacks for input. -
Page 8: Installation
EC-1 AES/EBU Interface, Appendix E NSTALLATION RECAUTIONS Install the EC-1 only if you have had some experience with similar devices and feel competent to do so. If the following instructions are not clear to you, have your dealer or a trained technician install it for you. Hazardous voltages are present within the chassis. -
Page 9: Basic Operation
The I/O CARD option will appear in the display only if an I/O card (such as the Alesis EC-1 card) is installed in the M20. With the EC-1 card installed, pressing the Digital Source button (next to the meter display) toggles through the available sources, such as ADAT OPTICAL, TRACK COPY, and I/O CARD. -
Page 10: If The Ec-1 Is Not Installed In The Master M20
EC-1 AES/EBU Interface, Appendix E Once again, we must remind you: if independent (non-synchronous) AES/EBU sources are connected to the EC-1 card, audio cannot be monitored (or recorded) simultaneously since the clock for each input channel pair is independent. When monitoring AES/EBU digital audio from more than one channel pair, all of the AES/EBU sources must be synchronous, i.e., controlled by the same sample clock. -
Page 11: If The Input Selection Is Analog And Aes/Ebu Simultaneously
