Samsung SM-T700 Manual

Gsm telephone
Hide thumbs Also See for SM-T700:

Advertisement

Quick Links

N
GSM TELEPHONE
GSM TELEPHONE
SM-T700
CONTENTS
2. Specification
3. Product Function
6. Level 1 Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.

Advertisement

loading

Related Manuals for Samsung SM-T700

Summary of Contents for Samsung SM-T700

  • Page 1: Table Of Contents

    -es of the product are subject to change without notice. Samsung reserves the right to alter this doc -ument or the product described herein at anytime, without obligation to provide notification of such...
  • Page 2 This Service Manual is a property of Samsung Electronics Co.,Ltd. ⓒ Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2014. 05. Rev.1.0...
  • Page 3 2. Specification Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 4 - Quad-core 1.9GHz Quad core + 1.3GHz Quad core - Battery 4,900 mAh Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 5 ― TDM : Time Division Multiplexing ― TS : Transport Stream Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 6: Safety Precautions

    Always use the replacement parts that are registered in the SEC system. Third-party replac ement parts may not function properly. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 7 Increase the airflow to the working area to decrease the chance of accidental static electricity discharges. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 8 PC to Phone Using Data Cable Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 9  Open up the S/W Installation Program by executing the "Odin3 v3.09.exe" Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 10 * Note : "Odin v3.06 or above" checks MD5 checksum just after file selection. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 11 Power Button simultaneously followed by pressing Volume up button as a direction of the phone. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 12 The device is now connected with the PC and ready to download the binary files in it. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 13 You can perform Factory Reset by Settings → Accounts → Backup and reset Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 14: Exploded View And Parts List

    4. Exploded View and Parts List 4-1. Cellular phone Exploded View Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 15: Main Electrical Parts List

    1203-007961 1203-008004 U7000 MAX14681EWC-T 1203-008158 U5001 S2MPS11B02-6430 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 16 2007-008049 2007-008051 R7026 RC0603J332CS 2007-008052 R4047,R4048,R4066 ERJ1GENJ472X Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 17 2007-009111 2007-009155 R2001 MCR006YZPJ474 2007-009157 R4072,R4073,R4074 MCR006YZPF1003 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 18 2203-005729 2203-005731 C4000,C4001,C6056 GRM0335C1E180J 2203-005731 C6057 GRM0335C1E180J Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 19 2203-006423 2203-006423 C9001,C910,C911 GRM33X5R104K6.3 2203-006556 C2001 GRM0335C1E470JD01D Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 20 2203-007385 2203-007385 C8036,C8037,C9012 CL05A106MR5NRNC 2203-007385 C9013,C9014,C9016 CL05A106MR5NRNC Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 21 2203-007860 2203-008097 C2089 CL03A104KA3NNNC 2203-008126 C4103,C5093,C5094 CL05A475KP5NRNZ Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 22 2703-004035 2703-004038 L2035 LQP03TN1N5B02D 2703-004249 L8000,L8004 PIME061E4R7MS Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 23 2911-000294 2911-000295 F2006,F2010 RFFM8550B 3003-001215 MIC6000 SPV1840LR5H Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 24 GH62-00029A CON1008,CON1009 SMR-TS-2-1.2-1.25DGR2 GH62-00029A CON1010,CON1011 SMR-TS-2-1.2-1.25DGR2 5-10 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 25 P l e a s e c o n s u l t t h e G S P N w e b s i t e ( S a m s u n g P o r t a l ) f o r t h e m o s t r e c e n t v e r s i o n o f t h e p r o d u c t ' s p a r t l i s t . 5-11 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 26: Level 2 Repair

    Be careful not to damage the FPCB. Torque : 1.1 ~ 1.3 Kgf·cm Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 27: Level 3 Repair

    Be careful not to damage the connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 28 Be careful not to damage the FPCB. Torque : 1.0 ~ 1.2 Kgf·cm Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 29 Be careful not to damage the FPCB. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 30 Be careful not to damage the FPCB. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 31 Be careful not to damage the FPCB. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 32 Be careful not to damage the FPCB. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 33 Be careful not to damage the front a'ssy. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 34 (FPF2195BUCX) DLVDD_5.0V V_BTP_IN VCC_1.8V_AP SENSOR ELVSS_- 6.4V Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 35 8-2. PCB Diagrams 8-2-1. Main PCB Top 8-2-2. Bottom Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 36  8960 & Spectrum Analyzer  Soldering iron Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 37 So, Change the PBA. Check the initial operation Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 38 Level 3 Repair Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 39 R5001 R8006 L5000 C8029 R8004 C5009 C5014 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 40 Do not use Blank MEMORY. Abnormal Change PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 41 C4090 C4091 VMEM_VDD_1.8V TP4007 C4089 C4092 VMEM_VDDF_2.85V VMEM_VDD_1.8V Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 42 Resolder or replace C6039,C6040,L6000,L6001 C6039,C6040,L6000,L6001 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 43 Level 3 Repair 8-10 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 44 Resolder or replace U6001 statuses of U6001 8-11 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 45 Level 3 Repair 8-12 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 46 U6001 statuses of U6001 8-13 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 47 Level 3 Repair HDC6001 8-14 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 48 Battery is Charging? Resolder or Replace U504 8-15 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 49 Level 3 Repair 8-16 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 50 ANT2002, ANT 2003 Resolder or Replace U2002 8-17 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 51 Level 3 Repair 8-18 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 52 ANT2000, ANT2002, ANT2003 Resolder or Replace U2002 8-19 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 53 Level 3 Repair 8-20 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 54 Level 3 Repair 8-21 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 55 F2005, ANT2002, ANT2003 Resolder or Replace U2001 8-22 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 56 Level 3 Repair 8-23 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 57 Level 3 Repair 8-24 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 58 U5001 - TSP_3.3V VLDO24(C5038) TSP_3.3V(C8034) Replace OCTA Module 8-25 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 59 C8033 C8034 C8032 C8035 R8013 R8014 8-26 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 60 24MHz Replace the camera module 8-27 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 61 R4027 R4082 R4084 R4102 R4099 R4097 8-28 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 62 24MHz Replace the camera module 8-29 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 63 C4047 R4082 R4084 R4102 R4099 R4097 8-30 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 64 U5001 - KEY LED_3.3V VLDO38(C5049) Replace Touch Key Module 8-31 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 65 Level 3 Repair 8-32 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 66 Check U7000 Change the IF FPCB 8-33 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 67 C5095 C5069 C5075 C5068 C5094 R5021 8-34 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 68 Check the U5001 C8024(3.3V), C8026(1.2V), C8028(1.8V) Replace U8003 8-35 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 69 Level 3 Repair 8-36 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 70 Level 3 Repair 8-37 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 71 1.7Vrms Check ZD6000, Replace U5007 ZD6001 8-38 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 72 Level 3 Repair 8-39 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 73 Level 3 Repair 8-40 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 74 Check the AP(UCP4000-1) BTP_SPI_MISO(C9030), BTP_SPI_CLK(C9028), BTP_SPI_CS_N(C9027) 8-41 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 75 Level 3 Repair 8-42 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 76 Level 3 Repair 8-43 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 77 T_FLASH_CMD R7005 T_FLASH_CLK R7006, T_FLASH_DETECT R7000 8-44 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 78 Level 3 Repair SD7000 8-45 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 79 R4082 R4084 R9010 R4102 R4099 R4097 C9001 8-46 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 80 Check the IRDA_CONTROL_OUT(R9001), Q9000, U9000 IRDA_CONTROL(R9015) 8-47 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 81 Level 3 Repair 8-48 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 82 Level 3 Repair 8-49 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
