Summary of Contents for AIPTEK AHD-1
-
Page 2: Safety Notice
Welcome: Dear user, thank you for purchasing this product. Much investment in time and effort has gone into its development, and it is our hope that it will give you many years of trouble-free service. FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Preparing The Camcorder
Preparing the Camcorder Product overview LCD display SD card slot Tripod socket Zoom out/Volume down Battery cover Wrist strap holder (back) USB connector Wrist strap holder (front) Speaker Shutter Power TV-out / earphone connector Zoom in/Volume up Playback As Joystck - Up: Icon Down: Video resolution Left: Flash... -
Page 4: Getting Started
Getting Started Loading the battery Detach the USB connector as indicated, and then unfasten the battery cover to remove the cover. Place the accessory Li-Ion battery into the compartment. Note that the metallic contacts must be aligned with the contacts in the compartment. Replace the cover. -
Page 5: Inserting The Sd Card
Inserting the SD card Lift the memory card cover to open it as indicated. Insert the card as the direction of indication until it reaches the end of the slot. When the card is inserted successfully, the icon ( will appear on screen. To remove the card, push the card to release it and then pull it out gently. -
Page 6: Recording A Video Clip
Realizing the battery life indicator Icon Note: To avoid sudden outage of power supply, you are recommended to replace the battery when the icon indicates low battery life. Recording a video clip Set the focus to an appropriate setting. Normally, you may set the focus to ( Select ( ) only for close-ups. - Page 7 Exporting to a standard TV and HDTV TV : Traditional CRT TV The TV system is different across areas. If you need to adjust the TV-out setting, please refer to the “Advanced settings” section for more information. (Taiwan: NTSC; America: NTSC;...
-
Page 8: Advanced Settings
Advanced settings Key tips Item Option On ( Flash Strobe (Joystick Left) Auto ( Off ( Video Resolution (Joystick Down) Please refer to the package printing for resolution specification. Icon (Joystick Up) On/Off Setting menu ( Press the Joystick Right ( Item Option Video... - Page 9 Setting menu ( Item Option Off ( Beep On ( Shutter On ( NTSC ( TV System PAL ( 50Hz ( Flicker 60Hz ( Auto ( NightShot Off ( * Flicker settings reference: Region England Germany Setting 50Hz Region Portugal Setting 50Hz Note: The flicker setting is based on the frequency standard of your local power supply.
