The company behind Python
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology.
Quality
Directed
products
are
serviced throughout North America and around
the world.
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
Auto Security
sold
and
O W N E R' S
S E C U R I T Y F O R T H E B E S T
®
M
G U I D E
O
D
E
L
4 8 1 1 P
4 8 1 6 P

Advertisement

Table of Contents
loading

Related Manuals for Python 4811P

Summary of Contents for Python 4811P

  • Page 1 ® The company behind Python Auto Security Systems is Directed. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security and accessories available. The recipient of nearly 100 pat- ents and Innovations Awards in the field of advanced electronic technology.

  • Page 2: What You Get

    Congratulations Congratulations on the purchase of your remote start system. This sys- tem has been designed to provide years of trouble-free operation. By carefully reading this owner’s guide prior to using your system, you will maximize the use of this system and its features. What you get •...
  • Page 3 Important Information Government Regulations and Safety Information Read the "Government Regulations" and "Warning! Safety First" sections of this manual prior to operating this system. Warning! Failure to heed this information can result in death, personal injury or property damage and may also result in the illegal use of the system beyond its intended purpose.

  • Page 4: Using Your System

    Using Your System Commands At a Glance System State Press/Release Press/Hold for 3 sec. ENGINE OFF START ENGINE CAR FINDER ENGINE ON UNLOCK DOORS STOP ENGINE Note: If a feature cannot be activated when performing a command with the 2-way remote control or if the system is out of range, a fault tone plays as an alert.

  • Page 5: Using Remote Start

    Car Finder When the engine is OFF, press and hold the remote control button for three seconds. The horn sounds once (if connected) and the parking lights flash multiple times. The 2-way remote control emits a single tone. Using Remote Start This feature allows you to remotely start and run your vehicle for a programmable period of time.
  • Page 6 * The factory setting is one press but this can also be programmed for two presses (See your authorized Directed installer for the amount of presses programmed). Record the number of presses to activate remote start here:______ Key Takeover When you are ready to drive the vehicle: Unlock the doors.
  • Page 7 • Engine over-rev protection (Tachometer mode only) Pit Stop and Turbo Timer Modes This remote start can keep the engine running during short trips away from the vehicle or to cool down turbo timers. Enabling Pit Stop mode: Park in a well ventilated area. With the engine running engage the parking brake and release the foot brake.
  • Page 8 Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system, please refer to the vehicle specific instructions included with the owner's guide of the interface module or consult your authorized dealer. Manual Transmission Vehicles Manual Transmission Mode (MTS), Pit Stop mode, Turbo Timer Mode Enabling MTS mode Park in a well ventilated area with all the doors closed.
  • Page 9 door prior to Step 4. Then, instead of pressing the remote control but- ton, press and release the optional dash mounted activation button*. The engine continues running for the shorter Turbo Mode runtime after the doors are closed. * Turbo Timer mode must be turned on and an optional activation but- ton also installed by an authorized dealer.

  • Page 10: Rapid Resume Logic

    or driven by someone unfamiliar with remote start system operations. Location Of Remote Start shutoff switch: _______________________ Remote Start Faults For user safety, the system must be properly configured or remote start will not activate. A Remote Start Fault may be caused by any of several configuration issues.

  • Page 11: Remote Pairing

    Remote Pairing Your system comes with two remote controls that are already paired to the system. An additional two remote controls can be stored in the sys- tem's memory (for a maximum of four). However, additional or replace- ment remote controls need to paired to the system first before use. Use the following procedure to pair an additional or replacement remote control to the system.

  • Page 12: Programming Options

    The learn routine Exits if any of the following occurs: • The ignition is turned off. • There is no activity for 60 seconds. • The control button is pressed too many times. Programming Options Programming options control your system's normal operational set-up. Most options do not require additional parts, but some may require installation labor.

  • Page 13: Battery Information

    Battery Information The 1-way remote controls are powered by a single coin cell battery (CR-2016), and the 2-way remote controls are powered by two coin cell batteries (CR-2016) that can be purchased at most retailers. Oper- ating range diminishes as battery charge depletes. Low Battery Alert When unlocking the vehicle using a remote control with a low battery charge, the system provides a notification by emitting a third horn honk...

  • Page 14: Glossary Of Terms

    Battery Disposal Directed cares about the environment. If you need to dispose of the battery, please do so in accordance with your munici- pal requirements for battery disposal. Glossary of Terms Document Terminology Control Module The “brain” of your system. Usually hidden underneath the dash area of the vehicle.

  • Page 15: Patent Information

    Patent Information This product is covered by one or more of the following United States patents: Vehicle Security Patents 5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591; 5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484 Remote Start 5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786;...

  • Page 16: Government Regulations

    Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.
  • Page 17 Warning! Safety First Please read the safety warnings below before proceeding. Improper use of the product may be dangerous or illegal. Remote Start Capable When properly installed, this system can start the vehicle via a command signal from the remote control transmitter. Therefore, never operate the system in an enclosed area or partially enclosed area without ventilation (such as a garage).
  • Page 18 Before remote starting a manual transmission vehicle, be sure to: • Leave the vehicle in neutral and be sure no one is standing in front or behind the vehicle. • Only remote start on a flat surface • Have the parking brake fully engaged WARNING! It is the responsibility of the owner to ensure the parking/emer- gency brake properly functions.
  • Page 19 ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU- THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE.
