Acoustic Energy Aegis Evo Sub Owner's Manual

Active subwoofer loudspeaker
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Owner's manual

Advertisement

Table of Contents
loading

Related Manuals for Acoustic Energy Aegis Evo Sub

Summary of Contents for Acoustic Energy Aegis Evo Sub

  • Page 1 Owner’s manual...
  • Page 2 Introduction Congratulations on choosing the AEGIS Compact Sub — a powerful, active subwoofer loudspeaker which is capable of outstanding Hi-Fi and Home Cinema performance. Please take a few moments to read this manual. The advice it contains will enable you to get the very best performance out of your Acoustic Energy loudspeaker.

  • Page 3: Operation

    POWER INPUT 230–240V ~AC 50/60Hz 150W PHASE POWER FUSE T1.0A 250V 0ϒ Auto 180ϒ Designed and engineered by Acoustic Energy Limited, England POWER SERIAL NO: CAUTION ATTENTION Risk of electrical shock Risque de choc electrique Do not open Ne pas ouveré...
  • Page 4 (For best results we would recommend our own AESC-C3 high performance speaker cable with any Acoustic Energy loudspeaker.) 1. For use with amplifiers having a Subwoofer Out jack Connect from the dedicated subwoofer line output on the amplifier to the line input(s) on the AEGIS Compact Sub.
  • Page 5 AMPLIFIER TUNER TAPE IN TAPE OUT PRE OUT MAIN IN LOUDSPEAKERS 150W ACTIVE COMPACT SUBWOOFER HI LEVEL SPEAKER OUT HI LEVEL SPEAKER IN LEFT SPEAKER LINE IN CROSSOVER LINE OUT LEVEL FREQUENCY (Hz) AMPLIFIER TUNER TAPE IN TAPE OUT LOUDSPEAKERS 150W ACTIVE COMPACT SUBWOOFER HI LEVEL SPEAKER OUT HI LEVEL SPEAKER IN LEFT SPEAKER...
  • Page 6 150W ACTIVE SUBWOOFER TELEVISION HI LEVEL SPEAKER OUT HI LEVEL SPEAKER IN OUTPUT (VARIABLE) LINE IN CROSSOVER LINE OUT LEVEL FREQUENCY (Hz) 4. For use with televisions with a variable audio output (diagram above) Some of the latest televisions are equipped with variable audio outputs. These can be connected directly to the Line level inputs on the AEGIS Compact Sub to enhance the bass response of the television’s built-in speaker.

  • Page 7: How To Use The Controls

    How to use the SUB VOLUME CONTROL knob, CROSSOVER FREQUENCY knob and PHASE switch The VOLUME CONTROL, FREQUENCY knob and PHASE switch can be adjusted to match the condition of the listening room and/or the characteristics of the left and right front speakers. Due to the positioning of the subwoofer in the room and the associated room boundaries, the available bass response from the existing speakers and whether or not the filtered connection (nominally 100Hz is used), the actual...

  • Page 8: Specifications

    Specifications Power amplifier 150 watts rms into 8 ohms Drive unit One front facing 220 mm pulp cone bass unit S/N ratio >75 dB Power handling 150 watts programme rating Crossover frequency range 35 Hz – 100 Hz active/passive Connections Line level gold-plated RCA phono jacks 5-way binding posts Cabinet...

  • Page 9: Warranty

    3 years from the date of purchase. Please retain all original packaging materials for possible future use. Under this warranty Acoustic Energy agrees to repair any defect or, at the company’s discretion, replace the faulty component(s) without charge for parts and labour.

This manual is also suitable for:

Aegis compact sub
