Shure 92E User Manual

M92E
Biradial (elliptical),
.4 x .7 mil
N78S
78 rpm , spherical,
†Output voltages given for stereo cut record; for MONO cut record, output voltage
at both left channel and right channel cartridge terminals will be 71% of figure above.
*Do not exceed maximum indicated tracking force.
Optimum Load: 47,000 ohms resistance in parallel with 200 to 300 picofarads capacitance
per channel. Load resistance can be up to 70,000 ohms with almost no audible change in
frequency response. Total capacitance includes both tone arm wiring and amplifier input
circuit.
Certification: Conforms to European Union directives, eligible to bear CE marking; meets
European Union EMC Immunity Requirements: EN 50 082-1, 1992.
Net Weight: 7.3 grams including standard 1/2 in. mounting adapter. Without adapter,
cartridge is compatible with pre-set P-Mount arm.
THiS CaRTRidGE FEaTURES THE SHURE BiRadiaL NUdE diaMONd Tip
Its contact area is longer and narrower
than the traditional spherical tip-groove
contact area. This results in dramatic
reduction of both harmonic distortion
and inter modulation distortion.
VIEW IN DIRECTION A
©2005, Shure Incorporated
27B2172 (Rev. 2)
27B2172_M92E.indd 1
Specifications
Red 5.0 mV
Green 4.0 mV
A
Model 92E
Users Guide
20 to Within
18,000 Hz 2 dB
20 to
Mono
17,000 Hz
Stylus Cleaning
To clean the stylus, use a soft brush
with alcohol or an alcohol-distilled
water solution. Brush only from back to
front as shown. Commercial cleaning
solutions may cause stylus damage.
0.75 to 1.5
20 dB
grams
at 1
(1.25 grams
kHz
optimum)
1.5 to
Mono
3 grams
Printed in U.S. A.
