Replacing the Lamp

Use a screwdriver to remove the screw(s) from the cover, and then pull out the lamp.
The projector will detect the lamp life. It will be shown you a warning message
"Lamp is approaching the end of its useful life in full power operation.
Replacement Suggested!" When you see this message, change the lamp as soon
as possible. Make sure the projector has been cooling down for at least 30
minutes before changing the lamp.
Warning: Lamp compartment is hot! Allow it to cool down before
changing lamp!
To change the Lamp
1 Turn off the projector by pressing the "Power" button.
2 Allow the projector at least 30 minutes to cool down.
3 Disconnect the power cord.
4 Place your hands on the top cover.
5 Find the "OPEN" buttons on both sides of the projector and push it at the
same time. (Illustration #1)
6 Gently push the top cover out slightly and slide it away to open the top
cover. (Illustration #2)
7 Remove the two screws that secure the lamp module and pull up the lamp
bar. (Illustration #3)
8 Pull out the lamp module by force. (Illustration #4)
To replace the lamp module, reverse the previous step.
Warning: To reduce the risk of personal injury, do not drop the
lamp module or touch the lamp bulb. The bulb may shatter and
cause injury if it is dropped.
1 1
4
a
b
2
a
3
