Land Pride BX Third Function Valve Kit Installation Instructions Manual

BX Third Function Valve Kit
#380-289A & #380-339A Installation Instructions
For Kubota 80 Series BX Tractors
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of others
depend on it!
California Proposition 65
WARNING: Cancer and reproductive harm.
!
www.P65Warnings.ca.gov
IMPORTANT: Before you begin, thoroughly read
these instructions and check to be sure all parts are
accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
General Information
Your BX Third Function Valve Kit is exclusively designed
for your Kubota 80 series BX tractors. Please read these
installation instructions thoroughly before assembling
this kit to your Kubota tractor and loader. Especially read
information relating to safety concerns.
These assembly instructions apply to the Third Function
Valve Kit Accessories listed below:
• 380-339A: 3FVK FF BX2680. . . . . . . . . . . . . . . page 2
• 380-289A: 3FVK PC BX2680 . . . . . . . . . . . . . . page 5
Further Assistance
Your Land Pride dealer wants you to be satisfied with your
new BX Third Function Valve Kit. If for any reason you do
not understand any part of this manual or are not
satisfied with the service received, the following actions
are suggested:
1. Discuss any problems you have with your Third
Function Valve Kit with your dealership service
personnel so they can address the problem.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
question/problem, and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
© Copyright 2018 Printed 11/11/20
Manual No. 380-304M
Assembly Instructions
A detailed listing of parts for this kit is provided on page
10 for kits. Use the list that is for your specific Third
Function Valve Kit as a checklist to inventory parts
received. Please contact your local Land Pride dealer for
any missing hardware.
Direction Reference
All directional references are made from the operator
seat while facing the direction the machine will operate.
U
F
L U = up
L = left
B
R
D
B = back
Directional Arrows Used in Illustrations
Initial Preparations
!
WARNING
To avoid serious injury or death: Hydraulic fluid under high
pressure can penetrate the skin and/or eyes causing a serious
injury. Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.
The steps listed below must be followed before installing
this kit:
1. If attached, dismount loader from tractor. If loader is
not attached, skip to step 4.
2. Turn tractor off, then relieve all hydraulic pressure
from hydraulic lines by operating the loader control
lever in all directions. Proceed with locking the control
lever.
3. Disconnect loader hydraulic lines.
4. Restart tractor and slowly back away from loader.
5. Park tractor on a flat, level surface. Put tractor in park
or set park brake, turn off engine, and remove switch
key to prevent unauthorized starting.
6. As a safety precaution, disconnect the negative
battery cable from the battery terminal. Move cable
away from the terminal to avoid accidental contact.
KEY:
D = down
R = right
F = front
1
