Page 2: Table Of Contents
Safety ... 4 National Conventions ... 4 Power ... 5 Installation ... 6 Cleaning... 7 Other ... 8 Setup ... 9 Contents in Box ... 9 Setup Stand & Base ... 10 Adjusting Viewing Angle ... 11 Connecting the Monitor ... 12 Wall Mounting ... - Page 3 EPEAT Declaration ... 57 TCO DOCUMENT ... 58 Service ... 59 Warranty Statement for Europe... 59 Warranty Statement for North & South America (excluding Brazil) ... 61...
-
Page 4: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 5: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 6: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 7: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 8: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 9: Setup
Monitor Base Stand Power Cable Audio Analog Cable DVI Cable HDMI Not all signal cables (Analog, DVI, and HDMI cables,QSG) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 10: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:... -
Page 11: Adjusting Viewing Angle
Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from -4°... -
Page 12: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. Power 2. Analog (DB-15 VGA cable) To protect equipment, always turn off the PC and LCD monitor before connecting. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. -
Page 13: Wall Mounting
Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted : VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. -
Page 14: Adjusting
Adjusting Setting Optimal Resolution Windows Vista For Windows Vista: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Personalization. 4 Click Personalization... - Page 15 5 Click Display Settings. 6 Set the resolution SLIDE-BAR to 1366 by 768.
-
Page 16: Windows Xp
Windows XP For Windows XP: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Click Appearance and Themes. 5 Double click DISPLAY. -
Page 17: Windows Me/2000
6 Click SETTINGS. 7 Set the resolution SLIDE-BAR to 1366 by 768. Windows ME/2000 For Windows ME/2000: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Double click DISPLAY. 5 Click SETTINGS. 6 Set the resolution SLIDE-BAR to 1366 by 768. -
Page 18: Hotkeys
Hotkeys ECO(DCR)/- 4:3 or Wide/+ Auto/Exit Menu/Enter Power Power Press the Power button to turn on/off the monitor. Eco (DCR)/ - Press the Eco key continuously to select the Eco mode of brightness and DCR on when there is no OSD. ( Eco mode hot key may not be available in all models). -
Page 19: Osd Setting
OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press - or + to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it . press - or + to navigate through the sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it. -
Page 20: Luminance
Luminance Press (Menu) to display menu. Press to select (Luminance), and press to enter. Press to select submenu, and press to enter. - Page 21 Press to adjust. Press to exit...
- Page 22 Brightness 0-100 Contrast 0-100 Standard Text Eco mode Internet Game Movie Sports Gamma1 Gamma Gamma2 Gamma3 Backlight Adjustment Contrast from Digital-register. Standard Mode Text Mode Internet Mode Game Mode Movie Mode Sports Mode Adjust to Gamma1 Adjust to Gamma 2 Adjust to Gamma 3 Disable dynamic contrast ratio Enable dynamic contrast ratio...
-
Page 23: Image Setup
Image Setup Press (Menu) to display menu. Press to select (Image Setup), and press to enter. Press to select submenu, and press to enter. - Page 24 Press to adjust. Press to exit Clock 0-100 Phase 0-100 Sharpness 0-100 H.Position 0-100 V.Position 0-100 Adjust picture Clock to reduce Vertical-Line noise. Adjust Picture Phase to reduce Horizontal-Line noise Adjust picture sharpness Adjust the horizontal position of the picture. Adjust the vertical position of the picture.
-
Page 25: Color Setup
Color Setup Press (Menu) to display menu. Press to select (Color Setup), and press to enter. Press to select submenu, and press to enter. - Page 26 Press to adjust. Press to exit Color setup. Warm Normal Cool sRGB User DCB Mode Full Enhance Nature Skin Green Field Sky-blue AutoDetect DCB Demo Recall Warm Color Temperature from EEPROM. Recall Normal Color Temperature from EEPROM. Recall Cool Color Temperature from EEPROM. Recall SRGB Color Temperature from EEPROM.
-
Page 27: Picture Boost
Picture Boost Press (Menu) to display menu. Press to select (Picture Boost), and press to enter. Press to select submenu, and press to enter. - Page 28 Press to adjust. Press to exit Frame Size 14-100 Brightness 0-100 Contrast 0-100 H. position 0-100 V.position 0-100 Bright Frame on or off Adjust Frame Size Adjust Frame Brightness Adjust Frame Contrast Adjust Frame horizontal Position Adjust Frame vertical Position Disable or Enable Bright Frame...
-
Page 29: Osd Setup
OSD Setup Press (Menu) to display menu. Press to select (OSD Setup), and press to enter. Press to select submenu, and press to enter. - Page 30 Press to adjust. Press to exit H.Position 0-100 V.Position 0-100 Timeout 5-120 Transparence 0-100 Language Adjust the horizontal position of Adjust the vertical position of OSD Adjust the OSD Timeout Adjust the transparence of OSD Select the OSD language...
-
Page 31: Extra
Extra Press (Menu) to display menu. Press to select (Extra), and press to enter. Press to select submenu, and press to enter. - Page 32 Press to adjust. Press to exit...
- Page 33 Input Select Analog Auto Config yes or no Off timer 0-24hrs Image Ratio wide or 4:3 DDC-CI yes or no Yes or no Reset Information Select Analog Sigal Source as Input Auto adjust the picture to default Select DC off time Select wide or 4:3 format for display Turn ON/OFF DDC-CI Support Reset the menu to default...
-
Page 34: Exit
Exit Press (Menu) to display menu. Press to select (Exit), and press to enter. Press to exit Exit Exit the main OSD... -
Page 35: Led Indicator
LED Indicator Status Full Power Mode Active-off Mode LED Color Green or Blue Orange or red... -
Page 36: Driver
Driver Monitor Driver Windows 7 1.Start Windows® 7 2.Click on the 'Start' button and then click on 'Control Panel'. 3. Click on the 'Display' icon. - Page 37 4.Ckick on the “Change display settings” button. “ Click the Advanced Settings” button. Click the “Monitor” tab and then click the “Properties” button.
- Page 38 7.Click the “Driver” tab. 8. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “and then click the "Browse my computer for driver software" button. 9. Select "Let me pick from a list of device drivers on my computer".
- Page 39 10. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 11. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 12.
-
Page 40: Windows Vista
Windows Vista 1. Click "Start " and "Control Panel". Then, double-click on "Appearance and Personalization". 2. Click "Personalization" and then "Display Settings". 3. Click "Advanced Settings...". - Page 41 4. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is. If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue". 5.
-
Page 42: Windows Xp
Windows XP 1. Start Windows® XP 2. Click on the 'Start' button and then click on 'Control Panel'. 3. Select and click on the category „Appearance and Themes‟ 4. Click on the 'Display' Item. - Page 43 5. Select the 'Settings' tab then click on the 'Advanced' button. 6. Select 'Monitor' tab - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active, click on 'Properties' button. Please follow the steps below.
- Page 44 8. Select the 'Install from a list or specific location [advanced]' radio button and then click on the 'Next' button. 9. Select the 'Don't Search. I will choose the driver to install' radio button. Then click on the 'Next' button. 10.
-
Page 45: Windows 2000
Windows 2000 1. Start Windows® 2000 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...'. 5. Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. -
Page 46: I-Menu
Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide. -
Page 47: E-Saver
Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). -
Page 48: Screen
Screen+ Welcome to "Screen+" software by AOC, Screen+ software is a desktop screen splitting tool, it splits the desktop into different panes, each pane displays a different window. You only need to drag the window to a corresponding pane, when you want to access it. It supports multiple monitor display to make your task easier. Please follow the... -
Page 49: Troubleshoot
Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Press to auto adjust. - Page 50 Monitor Is Stuck In Active Off-Mode" Missing one of the primary colors (RED, GREEN, or BLUE) Screen image is not centered or sized properly Picture has color defects (white does not look white) Horizontal or vertical disturbances on the screen The Computer Power Switch should be in the ON position.
-
Page 51: Specification
Width Depth Weight (monitor only) Weight (with packaging) Temperature: Operating Environmental Non-Operating Humidity: Operating e950Sw TFT Color LCD 470mm diagonal 0.3mm(H) x 0.3mm(V) R, G, B Analog lnterface H/V TTL 16.7M Colors 85.5 MHz 30 kHz - 60 kHz 409.8mm 50 Hz - 76 Hz 230.4mm... -
Page 52: Preset Display Modes
Non-Operating Altitude: Operating Non-Operating Preset Display Modes STAND RESOLUTION 640×480 @60Hz 640×480 @67Hz 640×480 @72Hz 640×480 @75Hz Dos-mode 720×400 @70Hz SVGA 800×600 @56Hz SVGA 800×600 @60Hz SVGA 800×600 @72Hz SVGA 832×624 @75Hz Mac-mode 832×624 @75Hz 1024×768 @60Hz 1024×768 @70Hz 1024×768 @75Hz 1024×768 @75Hz wXGA 1360×768 @60Hz... -
Page 53: Pin Assignments
Pin Assignments Pin Number 15-Pin Side of the Signal Cable Video-Red Video-Green Video-Blue N.C. Detect Cable GND-R GND-G GND-B Ground N.C. DDC-Serial data H-sync V-sync DDC-Serial clock... -
Page 54: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 55: Regulation
Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 56: Weee Declaration
WEEE Declaration Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. -
Page 57: Epeat Declaration
AOC believes in protecting the environment. With a key concern for the conservation of natural resources, as well as landfill protection, AOC announces the launch of AOC monitor‟s packaging recycling program. This program is designed to help you discard of your monitor carton and filler materials properly. -
Page 58: Tco Document
TCO DOCUMENT... -
Page 59: Service
AOC Color Monitors sold within Europe AOC International (Europe) GmbH warrants this product to be free from defects in material and workmanship for a period of Three (3) years after the original date of consumer purchase. During this period, AOC International (Europe) GmbH will, at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below. - Page 60 THE PRICE OF THE INDIVIDUAL UNIT WHOSE DEFECT OR DAMAGE IS THE BASIS OF THE CLAIM. IN NO EVENT SHALL AOC INTERNATIONAL (EUROPE) GMBH BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE OR FACILITIES OR EQUIPMENT, OR OTHER INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE.
-
Page 61: Warranty Statement For North & South America (Excluding Brazil)
In the United States and Canada contact your Dealer or EPI Customer Service, RMA Department at the toll free number (888) 662-9888. Or you can request an RMA Number online at www.aoc.com/na-warranty. * This limited warranty does not cover any losses or damages that occur as a result of:... - Page 62 States, Alaska, and Hawaii. Outside the United States of America, this limited warranty is only valid for Products purchased in Canada. Information in this document is subject to change without notice. For more details, please visit: USA: http://us.aoc.com/support/warranty ARGENTINA: http://ar.aoc.com/support/warranty BOLIVIA: http://bo.aoc.com/support/warranty CHILE: http://cl.aoc.com/support/warranty...
