2. Interface Panel
EAP110
■
EAP120/EAP220
■
Please note that EAP110 does not have the CONSOLE port, POWER port or ON/OFF
button. The interface panel components of the EAP, from left to right, are described
in the following list.
Kensington Security Slot
Secure the lock (not provided) into the security slot to prevent the device from
being stolen.
RESET
With the device powered on, press and hold the RESET button for about 8 seconds
until the LED flashes red, then release the button. The device will restore to factory
default settings.
CONSOLE
This port is used to connect to the serial port of a computer or a terminal to check
and monitor system information of EAP120/EAP220.
Note: CLI commands are not available in current software version. We will release
a new version supporting CLI commands soon. Please pay close attention to our
official website.
03
RESET ETHERNET
ARROW 1
RESET CONSOLE ETHERNET ON/OFF POWER
ARROW 1
