- Page 1 EchoLife HG8040H/HG8012H/HG8010H GPON Terminal V300R013C00 Product Description Issue Date 2013-08-08 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
-
Page 3: About This Document
CAUTION indicates a potentially hazardous situation that, if not avoided, could result equipment damage, data loss, performance degradation, or unexpected results. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 4 Changes between document issues are cumulative. Therefore, the latest document issue contains all changes made in previous issues. Issue 01 (2013-08-08) This is the first official release for the V300R013C00 version. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 5: Table Of Contents
3.3 Convenient Automatic Provisioning, Maintenance, and Management of the Remote Service........20 4 Port Specifications........................21 4.1 GPON Port Specifications............................22 4.2 GE Port Specifications..............................22 4.3 CATV Port Specifications............................23 5 Acronyms and Abbreviations....................24 Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 6: Introduction
This topic introduces the specification differences between ONTs in V300R013C00, specifically, features supported by different ONTs. 1.4 Product Overview This topic introduces the appearances, ports, and LEDs of ONTs in V300R013C00. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 7: Product Positioning
Ethernet port, which can be connected to terminals such as the PC, STB, and video phone to provide the high-speed data and video services. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 8: Specifications Differences Between Different Product Models
This topic introduces the appearances, ports, and LEDs of ONTs in V300R013C00. 1.4.1 HG8040H Introduced the appearance, interfaces, LEDs and device parameters of the HG8040H. Appearance Figure 1-2 Appearance of the HG8040H Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 9 (longer than Reset 10s) to restore the device to the default settings and reset the device. Figure 1-5 shows optical ports on the HG8040H. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 10 Indicates an optical port. The optical port is equipped with a rubber plug and is connected to an optical fiber for upstream transmission. OPTICAL The type of the optical connector connected to the OPTICAL port is SC/APC. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 11 The Ethernet connection is in the Always on normal state. Ethernet port Data is being transmitted on the LAN1–LAN4 Blinking Ethernet port. The Ethernet connection is not set Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 12 About 500 g Working environment Operating temperature: 0ºC to +40ºC Environment humidity: 5% RH to 95% RH (non-condensing) Pressure environment: 86 kPa to 106 kPa Altitude: 2000 m Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 13: Hg8012H
Figure 1-9 show the ports on the rear panel and side panel of the HG8012H respectively. Figure 1-8 Ports and buttons on the rear panel of the HG8012H Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 14 Indicates the reset button. Press the button for a short time to reset the device; press the button for a long time (longer than Reset 10s) to restore the device to the default settings and reset the device. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 15 Table 1-9 Indications of the LEDs on the HG8012H Description Status Description Always on The device is powered on. Power supply POWER The power supply is cut off. Authentication Table 1-10. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 16 (twice per (once two dBm to –8 dBm) of the Rx second) seconds) sensitivity. Blinks slowly Blinks slowly The hardware is faulty. (once two (once two seconds) seconds) Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 17: Hg8010H
Power consumption l Static power consumption: 3 W l Maximum power consumption: 6 W 1.4.3 HG8010H Introduced the appearance, interfaces, LEDs and device parameters of the HG8010H. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 18 Figure 1-13 show the ports on the rear panel and side panel of the HG8010H respectively. Figure 1-12 Ports and buttons on the rear panel of the HG8010H Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 19 Indicates the reset button. Press the button for a short time to reset the device; press the button for a long time (longer than RESET 10s) to restore the device to the default settings and reset the device. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 20 Figure 1-14 LEDs on the HG8010H Table 1-14 Indications of the LEDs on the HG8010H Description Status Description Power supply POWER Green: always on The device is powered on. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 21 (twice per (once two dBm to –8 dBm) of the Rx second) seconds) sensitivity. Blinks slowly Blinks slowly The hardware is faulty. (once two (once two seconds) seconds) Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 22 50 Hz to 60 Hz System power supply: 11 V DC to 14 V DC, Power consumption l Static power consumption: 3 W l Maximum power consumption: 3.5 W Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 23: Product Functions And Features
Dual system protection of the software Ethernet features l VLAN filtering, VLAN transparent transmission l VLAN N:1 aggregation and VLAN 1:1 switch NOTE For details about the features, see the Feature Description. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 24: Product Highlights
3.3 Convenient Automatic Provisioning, Maintenance, and Management of the Remote Service The ONT applies the OMCI management, manages terminal services without additional IP networks, which facilitates automatic provisioning, maintenance, and management of the remote service. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 25: Comprehensive Triple Play Service
Supports remote fault locating of the ONT through the NMS. Through alarm reporting and remote loopback diagnosis, the fault can be located remotely, which decreases the maintenance cost. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 26: Port Specifications
This topic describes the specifications and standards compliance of Gigabit Ethernet (GE) ports. 4.3 CATV Port Specifications This topic describes the specifications of cable TV (CATV) ports. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 27: Gpon Port Specifications
Maximum transmission distance 100 m Working mode Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s Cable specifications Category 5 UTP Compliant standard IEEE 802.3i IEEE 802.3u IEEE 802.3ab Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 28: Catv Port Specifications
Table 4-3 Specifications of a CATV port Parameter Specifications Connector type F-type Bandwidth 54-870 MHz Output resistance 75 ohms Cable specifications CATV cable NOTE Only HG8012H supports CATV. Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 29: Acronyms And Abbreviations
Operations, Administration, and Maintenance Optical Line Terminal OMCI Optical Network Termination Management and Control Interface Optical Network Terminal PLOAM Physical Layer OAM Passive Optical Network VLAN Virtual Local Area Network Issue 01 (2013-08-08) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
