Grandstream Networks, Inc.
GWN76XX Wi-Fi Access Points
User Manual
GWN7630
Enterprise 802.11ac Wave-2
4x4 Wi-Fi Access Point
GWN7615
Enterprise 802.11ac Wave-2
3×3:3 Wi-Fi Access Point
GWN7610
Enterprise 802.11ac
Wi-Fi Access Point
GWN7605
Enterprise 802.11ac Wave-2
2x2 Wi-Fi Access Point
GWN7600
Enterprise 802.11ac Wave-2
Wi-Fi Access Point
GWN7630LR
Outdoor Long Range 802.11ac
Wave-2 4x4:4 Wi-Fi Access Point
GWN7605LR
Outdoor Long-Range 802.11ac
Wave-2 2×2:2 Wi-Fi Access Point
GWN7600LR
Outdoor Long Range 802.11ac
Wave-2 Wi-Fi Access Point

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks GWN76 Series

Summary of Contents for Grandstream Networks GWN76 Series

  • Page 1 Grandstream Networks, Inc. GWN76XX Wi-Fi Access Points User Manual GWN7630 GWN7630LR Enterprise 802.11ac Wave-2 Outdoor Long Range 802.11ac 4x4 Wi-Fi Access Point Wave-2 4x4:4 Wi-Fi Access Point GWN7615 Enterprise 802.11ac Wave-2 3×3:3 Wi-Fi Access Point GWN7610 GWN7605LR Enterprise 802.11ac Outdoor Long-Range 802.11ac Wi-Fi Access Point Wave-2 2×2:2 Wi-Fi Access Point...
  • Page 2 Grandstream Networks, Inc. is not permitted. The latest electronic version of this guide is available for download here: http://www.grandstream.com/support Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc. in the United States, Europe and other countries. CAUTION Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this guide, could void your manufacturer warranty.
  • Page 3 FCC Caution Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radio électrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. ISEDC Warning This equipment complies with ISEDC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator&...
  • Page 5 GWN7610 GWN7600 TX/RX Frequency TX/RX Frequency 2.4G Wi-Fi: 2412-2472MHz; 2.4G Wi-Fi: 2412-2472MHz; 5G Wi-Fi: 5150-5250MHz 5G Wi-Fi: 5150-5250MHz Output power Output power WLAN 2.4G < 20dBm; WLAN 2.4G < 20dBm; WLAN 5150-5250MHz< 23dBm WLAN 5150-5250MHz< 23dBm Modulation Modulation DSSS, OFDM DSSS, OFDM GWN7615 GWN7600LR...
  • Page 6 WLAN 5150-5250MHz< 23dBm WLAN 5150-5250MHz< 23dBm WLAN 5250-5350 MHz< 20dBm WLAN 5250-5350 MHz< 20dBm WLAN 5470-5725 MHz< 27dBm WLAN 5470-5725 MHz< 27dBm Modulation Modulation DSSS, OFDM DSSS, OFDM The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows: Hereby, [Grandstream Networks,...
  • Page 7 GNU GPL INFORMATION GWN76XX firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license. Grandstream GNU GPL related source code can be downloaded from Grandstream web site: http://www.grandstream.com/support/faq/gnu-general-public-license P a g e...

  • Page 8: Table Of Contents

    Table of Contents DOCUMENT PURPOSE ....................17 CHANGE LOG ......................18 Firmware Version 1.0.19.25 ........................18 Firmware Version 1.0.19.23 ........................18 Firmware Version 1.0.19.22 ........................18 Firmware Version 1.0.19.15 ........................18 Firmware Version 1.0.19.9 ........................18 Firmware Version 1.0.15.20 ........................19 Firmware Version 1.0.15.18 ........................19 Firmware Version 1.0.15.5 ........................19 Firmware Version 1.0.15.4 ........................19 Firmware Version 1.0.15.6 ........................19 Firmware Version 1.0.11.10 ........................19...
  • Page 9 Firmware Version 1.0.1.27 ........................22 WELCOME ........................23 PRODUCT OVERVIEW ....................25 Technical Specifications ........................25 INSTALLATION ......................38 Equipment Packaging .........................38 GWN76XX Access Point Ports ......................40 Power and Connect GWN76XX Access Point ..................41 Warranty ..............................42 Wall/Ceiling Mount Installation GWN7630/GWN7605/GWN7610/GWN7600 ........42 Wall Mount ...........................42 Ceiling Mount ..........................43 Mounting Instructions for GWN7600LR ....................44 Mounting Instructions for GWN7630LR/GWN7605LR ...............45...
  • Page 10 USING GWN76XX AS STANDALONE ACCESS POINT ..........54 Connect to GWN76XX Default Wi-Fi Network ..................54 USING GWN76XX AS MASTER ACCESS POINT CONTROLLER ......55 Login Page ............................56 Discover and Pair Other GWN76XX Access Point ................56 AP Location ............................60 Transfer AP – Transfer Network Group ....................60 Failover Master ...........................60 Failover Mode ..........................61 Takeover Feature ..........................62...
  • Page 11 Guest..............................86 Policy List ............................87 Internal Splash Page ........................88 External Splash Page ........................91 Splash Page ............................92 Vouchers .............................93 Voucher Feature Description .......................93 Voucher Configuration .........................94 Using Voucher with GWN Captive Portal ..................96 RADIO .......................... 98 SECURITY ......................... 102 Rogue AP ............................102 Firewall ..............................104 SERVICE ........................
  • Page 12 Email ............................120 Alert Configure ...........................122 SCHEDULE ....................... 123 LED SCHEDULE ....................... 125 UPGRADING AND PROVISIONING ................. 126 Upgrading Firmware .........................126 Upgrading via Web GUI ......................126 Upgrading Slave Access Points ......................127 Sequential Upgrade ........................128 Provisioning and Backup ........................129 Download Configuration ......................129 Upload Configuration .........................129 Configuration Server ........................130 Reset and reboot ..........................130...
  • Page 13 Table of Tables Table 1: GWN7630 Technical Specifications .................... 25 Table 2: GWN7615 Technical Specifications .................... 26 Table 3: GWN7610 Technical Specifications .................... 28 Table 4: GWN7600LR Technical Specifications ..................34 Table 5: GWN7630LR Technical Specifications ..................36 Table 6: GWN7630/GWN7610/GWN7615/GWN7605/GWN7600 Equipment Packaging ......38 Table 7: GWN7600LR Equipment Packaging ...................
  • Page 14 Table of Figures Figure 1: GWN7630 or GWN7610 or GWN7605 or GWN7600 Equipment Packaging ......38 Figure 2: GWN7600LR Equipment Package .................... 39 Figure 3: GWN7630LR/GWN7605LR Equipment Package ..............40 Figure 4: GWN7630/GWN7615 ........................ 40 Figure 5: GWN7610/GWN7600 Ports ....................... 40 Figure 6: GWN7600LR Ports ........................
  • Page 15 Figure 38: Failover Mode GUI ........................62 Figure 39: Takeover - Step 1 ........................63 Figure 40: Takeover - Step 2 ........................63 Figure 41: Takeover - Step 3 ........................64 Figure 42: Switch to Master ........................64 Figure 43: Transfer Master Role to another device confirmation message ..........65 Figure 44: Then new assigned Master AP web interface................
  • Page 16 Figure 80: Rogue AP-Detection ......................102 Figure 81: Firewall-Outbound ......................... 104 Figure 82: Firewall-inbound........................104 Figure 83: Hotspot 2.0 ..........................106 Figure 84: SNMP ............................. 109 Figure 85: DHCP Binding ......................... 111 Figure 86: Access Points Status ......................113 Figure 87: Mesh settings for GWN76XX ....................113 Figure 88: MAC Address Bandwidth Rule ....................

  • Page 17: Document Purpose

    DOCUMENT PURPOSE This document describes how to configure the GWN76XX via Web GUI in standalone mode, with other GWN76XX Access Points as Master/Slave architecture and more. The intended audiences of this document are network administrators. Please visit http://www.grandstream.com/support to download the latest “GWN76XX User Manual”.

  • Page 18: Change Log

    CHANGE LOG This section documents significant changes from previous versions of the GWN76XX user manuals. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware Version 1.0.19.25  No major changes Firmware Version 1.0.19.23 Product Name: GWN7610 / GWN7600 / GWN7600LR...

  • Page 19: Firmware Version 1.0.15.20

     Added support of Active IGMP for feature Convert IP multicast to unicast enhancement. [Convert IP multicast to unicast]  Allow DHCP Option43 to override GWN Manager Address. [Allow DHCP Option 43 to override GWN Manager Address] Firmware Version 1.0.15.20 Product Name: GWN7610 / GWN7600 / GWN7600LR / GWN7630 / GWN7630LR ...

  • Page 20: Firmware Version 1.0.11.8

    Firmware Version 1.0.11.8 Product Name: GWN7610 / GWN7600 / GWN7600LR / GWN7630  Added support of DFS channel in EU for GWN7630. [Scene]  Added support for Client Steering. [Client Steering]  Added support for Minimum Rate Control. [RADIO]  Added support for batch operations for Takeover.

  • Page 21: Firmware Version 1.0.4.12

     Added support for Syslog server [Syslog]  Added support for Configurable Web UI access port [Web HTTP Access]  Added support for E-mail notifications [Email] Firmware Version 1.0.4.12 Product Name: GWN7600 / GWN7600LR  Added support for Timed Client Disconnect and Enhanced Client Blocking [CLIENTS] ...

  • Page 22: Firmware Version 1.0.2.108

    Firmware Version 1.0.2.108 Product Name: GWN7610  Added Controller protocol security enhancement. [Controller Protocol Security Enhancement]  Added support for LED control. [LED SCHEDULE]  Added support for Captive Portal. [CAPTIVE PORTAL]  Added support for Wi-Fi schedule. [SCHEDULE]  Added Client Isolation enhancement.

  • Page 23: Welcome

    WELCOME Thank you for purchasing Grandstream GWN76XX Enterprise Wireless Access Point. The GWN7630/ GWN7610/GWN7610 are high-performance 802.11ac Wi-Fi access points for small to medium sized businesses, multiple floor offices, commercial locations and branch offices. GWN7630 and GWN76105/GWN7610 offers respectively a dual-band 4x4:4 MIMO and a 3x3:3 MIMO technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range.
  • Page 24 The GWN7605/GWN7605LR is a high-performance-to-price 802.11ac Wave-2 Wi-Fi access point for small to medium sized businesses, multiple floor offices, commercial locations and branch offices. It offers dual- band 2x2:2 MU-MIMO with beam-forming technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range.

  • Page 25: Product Overview

    PRODUCT OVERVIEW Technical Specifications Table 1: GWN7630 Technical Specifications Wi-Fi Standards IEEE 802.11 a/b/g/n/ac (Wave-2). 4x 2.4 GHz, gain 4dBi, internal antenna Antennas 4x 5 GHz, gain 5dBi, internal antenna IEEE 802.11ac: 6.5 Mbps to 1733Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n: 6.5Mbps to 600Mbps IEEE 802.11b: 1, 2, 5.5, 11Mbps Wi-Fi Data Rates...

  • Page 26: Table 2: Gwn7615 Technical Specifications

    802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9; * Receiver sensitivity varies by frequency band, channel width and MCS rate SSIDs 16 SSIDs per access point 200+ Concurrent Clients Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock Indoor wall mount or ceiling mount, kits included Mounting LEDs...
  • Page 27 IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network 2.4 GHz Radio: 2412 – 2484 MHz Frequency Bands 5 GHz Radio: 5180-5825 MHz 2.4G: 20 and 40MHz...

  • Page 28: Table 3: Gwn7610 Technical Specifications

    Energy Efficiency Max Consumption: 12.5W Operation: 0°C to 40°C Storage: -10°C to 60°C Environmental Humidity: 10% to 90% Non-condensing Unit Dimension: 205.4 x 205.4 x 45.9mm; Unit Weight: 500g Physical Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 867.3g GWN7615 802.11ac Wireless AP, Mounting Kits, Quick Start Guide Package Content FCC, CE, RCM, IC...
  • Page 29 2.4G 802.11b:-92dBm@11Mbps; 802.11g:-76dBm@54Mbps; 802.11n 20MHz: -73dBm@MCS7; 802.11n 40MHz:-70dBm@MCS7 Receiver Sensitivity 802.11a:-94dBm@6Mbps; 801.11a:-77dBm@54Mbps; 802.11ac 20MHz: -69dBm@MCS8; 802.11ac HT40:-65dBm@MCS9; 802.11ac 80MHz: 1dBm@MCS9 * Receiver sensitivity varies by frequency band, channel width and MCS rate 16 SSIDs per access point SSIDs Concurrent Clients 250+ Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports...
  • Page 30 Table 3: GWN7605 Technical Specifications Wi-Fi Standards IEEE 802.11 a/b/g/n/ac (Wave-2) 2 dual band internal antennas Antennas 2.4GHz, gain 3dBi 5 GHz, gain 4dBi IEEE 802.11ac: 6.5 Mbps to 867 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps.
  • Page 31 16 SSIDs per Access Point. SSIDs *GWN7605 when deployed as Master can only be added to 8 SSIDs. 100+ Concurrent Clients Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock Mounting Indoor wall mount or ceiling mount, kits included LEDs 3 multi-color LEDs for device tracking and status indication Network Protocols...
  • Page 32 2.4GHz Radio: 2412 – 2484 MHz Frequency Bands 5 GHz Radio: 5180-5825 MHz 2.4G: 20 and 40MHz Channel Bandwidth 5G: 20, 40 and 80 MHz WEP, WPA3, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot Wi-Fi and System and critical data/control lockdown via digital signatures, unique security certificate Security and random default password per device 2×2:2 2.4GHz (MIMO)
  • Page 33 Operation: -30°C to 60°C Storage: -30°C to 70°C Environmental Humidity: 10% to 90% Non-condensing Physical Unit Dimension: 358.3mm(L)*115mm(W)*45.3mm(H); Unit Weight: 500g Physical Entire Package Dimension: 258 × 247× 86mm; Entire Package Weight:655.3g GWN7605LR 802.11ac Wave-2 Wireless AP, Mounting Kits, Quick Start Guide Package Content IP66-level weatherproof capability when installed vertically Water Proof...

  • Page 34: Table 4: Gwn7600Lr Technical Specifications

    2.4G 802.11b:-99dBm @1Mbps,-91dBm @11Mbps;802.11g:-93dBm @6Mbps,- 75dBm @54Mbps; 80.11n 20MHz:-72dBm @MCS7;802.11n 40MHz:-69dBm Receiver Sensitivity @MCS7 802.11a:-91dBm @6Mbps,-74dBm @54Mbps;802.11ac 20MHz:-67dBm @MCS8;802.11ac HT40:-63dBm @MCS9;802.11ac 80MHz:-60dBm @MCS9 16 SSIDs per access point BSSID Concurrent Clients 450+ Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports Auxiliary Ports 1x USB 2.0 port, 1x Reset Pinhole, 1x Kensington lock Mounting...
  • Page 35 IEEE 802.11ac: 6.5 Mbps to 867 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400Mbps with 256-QAM on 2.4GHz IEEE 802.11b: 1, 2, 5.5, 11 Mbps Wi-Fi Data Rates IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network...

  • Page 36: Table 5: Gwn7630Lr Technical Specifications

    Embedded controller in GWN7600LR allows it to auto-discover, auto-provision and Network manage up to 30 GWN76XX s in a network Management GWN.Cloud offers a free cloud management platform for unlimited GWN APs Power and Green Power over Ethernet 802.3af and 802.3at compliant Maximum Power Consumption: 12.9 W (PoE supply) | 23.0 W (PoE+ supply) Energy Efficiency Operation: -30°C to 60°C...
  • Page 37 MIMO 4x4:4 2.4G (MIMO), 4x4:4 5G (MU-MIMO) Up to 984ft. (300 meters) Coverage Range *Coverage range can vary based on environment 2.4G: 27 dBm Maximum TX 5G: 25 dBm Power *Maximum power varies by country, frequency band and MCS rate 2.4G 802.11b: -96dBm@1Mbps, -88dBm@11Mbps;...

  • Page 38: Installation

    INSTALLATION Before deploying and configuring the GWN76XX, the device needs to be properly powered up and connected to the network. This section describes detailed information on installation, connection and warranty policy of the GWN76XX. Equipment Packaging Table 6: GWN7630/GWN7610/GWN7615/GWN7605/GWN7600 Equipment Packaging Main Case (GWN7630 or GWN7610 or Yes (1) GWN7615 or GWN7605 or GWN7600)

  • Page 39: Table 7: Gwn7600Lr Equipment Packaging

    Below is the equipment packaging for GWN7600LR model. Table 7: GWN7600LR Equipment Packaging Main Case Yes (1) Yes (1) Cover Interface Base Bracket Yes (1) Cover Bracket Yes (1) Assembled Screw Yes (4) Yes (4) Locknut Anchors + Screws Yes (4) Screw (PM8 x 115) Yes (4) Quick Installation Guide...

  • Page 40: Gwn76Xx Access Point Ports

    Below is the equipment packaging for GWN7630LR/ GWN7605LR model. Table 8: GWN7630LR Equipment Packaging Main Case Yes (1) Antenna GWN7630LR: Yes (4) GWN7605LR: Yes (2) Base Bracket Yes (1) Yes (4) Screw (PM 3.0x7) Yes (4) Expansion Screw Metal Strap Yes (2) Quick Installation Guide Yes (1)

  • Page 41: Power And Connect Gwn76Xx Access Point

    Table 9: GWN76XX AP Ports Description Port Description Power adapter connector (24V, 1A) Power * Available on GWN7610 and GWN7600 only Ethernet RJ45 port (10/100/1000Mbps) supporting PoE/PoE+. NET/PoE * GWN7600 supports PoE (802.3af) only Ethernet RJ45 port (10/100/1000Mbps) to your router or another GWN76XX series.

  • Page 42: Warranty

    Step 4: Wait for the GWN76XX to boot up and acquire an IP address from the DHCP Server. Figure 8: Connecting GWN AP - GWN7600 as example Warranty If the GWN76XX Wireless Access Point was purchased from a reseller, please contact the company where the device was purchased for replacement, repair or refund.

  • Page 43: Ceiling Mount

    Step 4: Connect the power cable and the Ethernet cable (RJ45) to the correct ports of your GWN7630/GWN7610/GWN7615/ GWN7605 /GWN7600. Step 5: Align the arrow on the GWN AP with the arrow on the locking tab of the mounting bracket and ensure that your GWN is firmly seated on the mounting bracket.

  • Page 44: Mounting Instructions For Gwn7600Lr

    Step 6: Turn the GWN clockwise until it locks into place and fits the locking tab. Note: Ceiling mounting is recommended for optimal coverage performance. Figure 15: Ceiling Mount – Steps 5 & 6 Mounting Instructions for GWN7600LR Please refer to the following steps for the mounting your GWN7600LR correctly. 1.

  • Page 45: Mounting Instructions For Gwn7630Lr/Gwn7605Lr

    Figure 17: GWN7600LR Horizontal Mounting Mounting Instructions for GWN7630LR/GWN7605LR GWN7630LR can be mounted on the wall or on a metal bar. Please refer to the following steps for the appropriate installation. 1. Connect the Ethernet cable (RJ45) to correct port your GWN7630LR/GWN7605LR and insert the cover bracket.
