TP-Link TC-W7960 Quick Installation Manual

Quick Installation Guide
300Mbps Wireless N DOCSIS 3.0
Cable Modem Router
Connect the Hardware
Activate the Modem Router
Enjoy the Internet
1
Connect the coaxial cable and power adapter to the modem
router, then power on your modem router.
TC-W7960
7106505475 REV1.0.0
Power adapter
1
Get your account information and the provided Information
Card ready.
Information Card
For additional con guration, log into the web-based management
page at http://tplinkmodem.net or http://192.168.1.1, and enter
admin (all lowercase) for both username and password.
Internet
Coaxial cable
Serial Number
MAC Address
Wireless Password/PIN
SSID
2
Wait for about 1 minute until the following LEDs are solid on.
Notes: 1. Keep the power on at all times during this process.
2. If the Internet LED is blinking or o , please call your ISP's customer service.
3. If the wireless LED is o , please press the WiFi button
then check the LEDs again.
3
Connect your computer to the modem router via a wired or
wireless connection.
Wired: Connect the computer to the modem router's LAN port via an Ethernet cable.
Wireless: On your computer, select and connect to the modem router's wireless network.
The default wireless network name (SSID) and password are on the provided
Information Card.
Or you can set up a connection via the WPS button
panel of the modem router. For more information about WPS, refer to the User
Guide at www.tp-link.com.
2
Launch a web browser, and visit any website. You will be
automatically redirected to your service provider's
self-activation page.
3
Follow the on-screen instructions to activate the modem
router.
If you are unable to self-activate your modem router, call your ISP's
customer service.
For Comcast and Time Warner Cable (TWC):
Comcast X nity 1-800-934-6489 www.comcast.com
Time Warner Cable 1-855-704-4503 www.timewarnercable.com
The contact information listed might change. You can also nd the contact number in your
monthly Internet service billing statement.
Note: If the Internet is not accessible, contact your ISP and make sure that the modem
router is activated.
on the front panel,
, which is on the front
