- Page 1 Product Description HUAWEI E5373s-155 Mobile WiFi V200R001 Issue Date 2014-05-15 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang...
- Page 3 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description About This Document Summary This document provides information about the major functions, supported services and system architecture. The following table lists the contents of this document. Chapter Details 1 Overview The supported network modes, basic services and functions, and the appearance of the product.
- Page 4 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description History Issue Details Date First release. 2014-05-15 Issue 01 (2014-05-15) Commercial in Confidence Page 4 of 20...
-
Page 5: Table Of Contents
3.1.3 LTE/3G/Wi-Fi Auto Offload ....................14 3.2 SMS ..............................15 3.3 Sharing Data Stored on the microSD card ..................15 3.4 Connecting an Android Device to the E5373s-155 Using a 2D Barcode ........15 4 System Architecture ..................... 16 ... -
Page 6: Overview
Short Message Service (SMS) You can connect the E5373s-155 with the USB interface of a computer, or connect the E5373s-155 with the Wi-Fi. In the service area of the LTE FDD/LTE TDD/DC-HSPA+/HSPA+/HSPA/UMTS or EDGE/GPRS/GSM network, you can surf the Internet and send/receive messages/emails cordlessly. -
Page 7: Optional Features
Optional features refer to features that are not supported by the standard version or are disabled by default. These features can be customized according to operator or customer requirements. The E5373s-155's optional feature is as follows: IPv6/IPv4 dual stack (optional) ... -
Page 8: Features
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Features 2.1 Main Features The E5373s-155 mainly supports the following features: LTE FDD (DL) data service of up to 150 Mbit/s LTE FDD (UL) data service of up to 50 Mbit/s ... -
Page 9: Technical Specifications
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8, Windows 8.1 (does not support Windows RT), MAC OS X 10.7, 10.8 and 10.9 with latest upgrades 2.2 Technical Specifications 2.2.1 Hardware Table 2-1 lists the hardware specifications. - Page 10 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Item Specifications 802.11g: Up to 54 Mbit/s 802.11n HT20: Support MCS0–MCS7; Up to 72.2 Mbit/s. Support MCS8–MCS15; Up to 144.4 Mbit/s. HT40: Support MCS0–MCS7; Up to 150 Mbit/s. Support MCS8–MCS15; Up to 300 Mbit/s.
-
Page 11: Software
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description 2.2.2 Software Table 2-2 lists the software specifications. Table 2-2 software specifications Item Description Writing/Sending/Receiving Sending/Receiving extra-long messages Storage: Up to 500 messages can be saved in the internal memory of the E5373s-155. - Page 12 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Item Description LTE/3G/Wi-Fi auto Accessing to WAN via LTE/3G or Wi-Fi offload Automatic offload between LTE/3G and Wi-Fi IPv6/IPv4 dual stack DHCPv6/v4 server and client (optional) DNSv6/v4 server and client ...
-
Page 13: Services And Applications
WLAN with the access point (AP) function. Functioning as a USB Modem After you connect the E5373s-155 and PC with a USB data cable or AF18, you can directly use the default settings (or configure APN on the E5373s-155 Web page) and set up a network connection. -
Page 14: Accessing The Internet Using Ethernet
The E5373s-155 allows you to access the Internet via LTE/3G or Wi-Fi. When you are using the E5373s-155 in areas with a Wi-Fi hotspot, for example, an airport, a cafe, a hotel, or your home, the E5373s-155 switches to Wi-Fi connection automatically, saving your LTE/3G network traffic fees. -
Page 15: Sms
3.4 Connecting an Android Device to the E5373s-155 Using a 2D Barcode If you are using an Android device and has the HUAWEI Mobile WiFi App installed, you can quickly connect your device to the E5373s-155 to access the Internet by scanning a 2D Barcode on the E5373s-155 label. -
Page 16: System Architecture
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description System Architecture 4.1 System Architecture Figure 4-1 shows the system architecture. Figure 4-1 System architecture Mobile WiFi Software module Hardware module Application systerm Web page Web server Protocol stack Radio frequency module Bottom layer drivers... -
Page 17: Functional Modules
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description 4.2 Functional Modules Radio frequency module: It sends/receives radio signals and modulates/demodulates the radio frequency (RF) signals and baseband signals Baseband signal processing: It processes LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM baseband digital signals, including: Modulating/Demodulating LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM baseband signals Encoding/Decoding LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM ... -
Page 18: Packing List
HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Packing List This chapter describes the items contained in the package of the E5373s-155. Table 5-1 lists the items contained in the package of the E5373s-155. Table 5-1 Packing list of the E5373s-155... - Page 19 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Acronyms and Abbreviations The Third Generation access control list Advanced Encryption Standard application level gateway access point name ARPU average revenue per user ASCII American Standard Code for Information Interchange dynamic frequency selection...
- Page 20 HUAWEI E5373s-155 Mobile WiFi V200R001 Product Description Modem Modulator Demodulator Network Address Translation Operating System personal computer personal identification number Plug and Play packet switched PIN unblocking key subscriber identity module short messaging service SOHO small office home office SSID...
