Page 3 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 4: Table Of Contents
TABLE OF CONTENTS For your information .......8 Operation of Reading this manual.....12 each component How to search ......13 Pictorial index .......14 3-1. Key information Keys ........128 For safety and security 3-2. Opening, closing and locking the doors Side doors ......134 1-1.
Page 5 4-5. Using the driving support Driving systems Toyota Safety Sense..367 PCS (Pre-Crash Safety 4-1. Before driving system) ......373 Driving the vehicle .....264 LDA (Lane Departure Cargo and luggage ....276 Alert) ....... 386 Trailer towing Dynamic radar cruise (with towing hitch)....279 control ......
Page 6 TABLE OF CONTENTS 4-6. Driving tips 5-7. “SETUP” menu Off-road precautions ..556 Using the “SETUP” menu (“Bluetooth ” menu) ..612 Winter driving tips ....561 Using the “SETUP” menu Eco-friendly driving tips..565 (“PHONE” menu) .... 616 ® 5-8. Bluetooth Audio Audio system ®...
Page 7 6-2. Using the interior lights Maintenance and care Interior lights list....680 • Interior lights ....681 • Personal lights ....682 7-1. Maintenance and care 6-3. Using the storage features Cleaning and protecting List of storage features ..684 the vehicle exterior..728 •...
Page 8 TABLE OF CONTENTS If you have a flat tire When trouble arises (vehicles with an emergency tire puncture repair kit) ......884 8-1. Essential information If the engine will Emergency flashers ...836 not start ......896 If your vehicle has to If the electronic key does be stopped in an not operate properly...
Page 9 Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...914 Fuel information ....947 9-2. Customization Customizable features ..950 9-3. Initialization Items to initialize ....964 Appendix What to do if... (Troubleshooting) .....966 For vehicles with a navigation system or a multimedia system, refer to the “Navigation system Owner’s manual”, “Navigation and Multi- media System Owner’s Manual”...
Page 10: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and acces-...
Page 11 SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail- able on request at your Toyota dealer.
Page 12 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 13 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search Searching installation ■ position • Pictorial index....P. 14 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 966 Searching by title ■ • Table of contents .... P. 2 LC200_OM_OM60R59W_(WE)
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior (lift-up back door type) Side doors ........P. 134 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 346 Rear window wiper ....... . P. 356 Precautions against winter season .
Page 18 Pictorial index ■ Exterior (double back door type) Side doors ........P. 134 Locking/unlocking .
Page 19 Pictorial index Windshield wipers ....... . . P. 346 Rear window wiper ....... . P. 356 Precautions against winter season .
Page 20 Pictorial index ■ Instrument panel (Left-hand drive vehicles) Engine switch ....... . P. 303, 306 Starting the engine/changing the modes .
Page 21 Pictorial index Multi-information display ......P. 115 Display......... . . P. 115 When the warning messages are displayed .
Page 22 ..... . . P. 335 Toyota parking assist-sensor switch ....P. 414 Headlight cleaner switch .
Page 23 Pictorial index Tire pressure warning reset switch ....P. 778 VIEW switch ........P. 488 PCS (Pre-Crash Safety system) switch .
Page 24 Pictorial index 1, 2 Audio remote control switches ....P. 572 Meter control switches ......P. 117 Vehicle-to-vehicle distance switch .
Page 25 Pictorial index Automatic transmission  Heated steering wheel switch ..... . P. 677 Front seat heater switches/Seat ventilator switches . . . P. 678 Four-wheel drive control switch .
Page 26 Pictorial index Manual transmission  Four-wheel drive control switch (vehicles with smart entry & start system) ... . . P. 468 LC200_OM_OM60R59W_(WE)
Page 27 Pictorial index ■ Interior (Left-hand drive vehicles) SRS airbags ........P. 50 Floor mats .
Page 28 Pictorial index Inside rear view mirror ......P. 247 Sun visors ........P. 697 Vanity mirrors .
Page 29 Pictorial index ■ Instrument panel (Right-hand drive vehicles) Engine switch ....... . P. 303, 306 Starting the engine/changing the modes .
Page 30 Pictorial index Multi-information display ......P. 115 Display......... . . P. 115 When the warning messages are displayed .
Page 31 ......P. 362 Toyota parking assist-sensor switch ....P. 414 Automatic High Beam switch .
Page 32 Pictorial index VIEW switch ........P. 488 PCS (Pre-Crash Safety system) switch .
Page 33 Pictorial index 1, 2 Audio remote control switches ....P. 572 Meter control switches ......P. 117 Vehicle-to-vehicle distance switch .
Page 34 Pictorial index Automatic transmission (type A)  Heated steering wheel switch ..... . P. 677 Front seat heater switches/Seat ventilator switches .
Page 35 Pictorial index Automatic transmission (type B)  ECT switch ........P. 316 Crawl Control switch.
Page 36 Pictorial index ■ Interior (Right-hand drive vehicles) SRS airbags ........P. 50 Floor mats .
Page 37 Pictorial index Inside rear view mirror ......P. 247 Sun visors ........P. 697 Vanity mirrors .
Page 38 Pictorial index LC200_OM_OM60R59W_(WE)
Page 39: For Safety And Security
For safety and security 1-1. For safe use Before driving.......38 For safe driving ....40 Seat belts......42 SRS airbags......50 Airbag manual on-off system .......65 Safety information for children......67 Child restraint systems ..68 Installing child restraints ..78 Exhaust gas precautions ..89 1-2. Theft deterrent system Engine immobilizer system .......90 Double locking system..93...
Page 40: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 41 When installing the driver’s floor mat Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 42: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 43 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 247, 250) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’s seat while driving.
Page 44: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ◆ 3-point type seat belt ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 45 1-1. For safe use Fastening and releasing the seat belt (except for the third center seat) To fasten the seat belt, push the plate into the buckle until a click sound is heard. To release the seat belt, press the release button. Release button Fastening and releasing the third center seat belt (if equipped) Pull out the tabs.
Page 46 1-1. For safe use Releasing and stowing the third center seat belt (if equipped) Push the release button on buckle A. Buckle A Push either the mechanical key or tab A into buckle B. When releasing and storing the seat belt, hold the belt while wind- ing it back gently.
Page 47 1-1. For safe use Adjusting the seat belt shoulder anchor height (front and second outboard seats [if equipped]) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 48 1-1. For safe use  Vehicles with SRS side and curtain shield airbags The pretensioners help the seat belts to quickly restrain the occu- pants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal col- lision or a vehicle rollover.
Page 49 ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. To achieve a proper seating position, do not recline the seat more than ●...
Page 50 Seat belt pretensioners If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. Adjustable shoulder anchor ■ Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 51 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 52: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. LC200_OM_OM60R59W_(WE)
Page 53 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS knee airbag (if equipped) Can help provide driver and front passenger protection ◆...
Page 54 1-1. For safe use SRS airbag system components Knee airbags (if equipped) Safing sensor (rear) equipped) Curtain shield airbags equipped) Airbag sensor assembly Front passenger airbag Front impact sensors Side impact sensors (front Seat belt pretensioners and door) (if equipped) force limiters (front seats) Front side airbags (if equipped) Driver’s seat position sensor...
Page 55 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
Page 56 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 57 1-1. For safe use WARNING SRS airbag precautions ■ ● Vehicles without SRS curtain shield air- bags: Do not lean against the front door. Vehicles with SRS curtain shield air- bags: Do not lean against the door, the roof side rail or the front, side and rear pil- lars.
Page 58 1-1. For safe use WARNING SRS airbag precautions ■ ● Vehicles with SRS curtain shield air- bags: Do not attach anything to areas such as a door, windshield glass, side door glass, front, side or rear pillars, roof side rail and assist grip. (Except for the speed limit sticker P.
Page 59 ● If the areas where the SRS airbags are stored, such as the steering wheel pad, are damaged or cracked, have them replaced by your Toyota dealer. Vehicles with SRS curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front, side and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 60 ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. Installation, removal, disassembly and repair of the SRS airbags ●...
Page 61 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 62 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS side and curtain shield airbags (if equipped) may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 63 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 64 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● ●...
Page 65 1-1. For safe use ● Vehicles with SRS side airbags: The surface of the seats with the side airbag is scratched, cracked or other- wise damaged. Vehicles with SRS curtain shield air- ● bags: The portion of the front, side and rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked or otherwise...
Page 66 1-1. For safe use ■ This switch only should be used In a situation where the inflation is not desired (such as during extreme off road driving). ■ Operating conditions when the “RSCA OFF” indicator is on ● The curtain shield airbags and seat belt pretensioners will not activate in a vehicle rollover.
Page 67: Airbag Manual On-Off System
1-1. For safe use  Airbag manual on-off system This system deactivates the front passenger airbag, front pas- senger side airbag and front passenger knee airbag. Only deactivate the airbags when using a child restraint system on the front passenger seat. “PASSENGER AIRBAG”...
Page 68 IGNITION ON mode). ■ “PASSENGER AIRBAG” indicator information If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by your Toyota dealer. Neither ON nor OFF comes on. ● ●...
Page 69: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 70: Child Restraint Systems
General installation instructions are provided in this manual. (P. 78) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. ● Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44.
Page 71 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44: Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0+: Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
Page 72 1-1. For safe use Child restraint system suitability for various seating positions If your child restraint system is of “universal” category, you can install it on the positions mentioned by U or UF in the table below (UF is for forward-facing child restraint systems only).
Page 73 1-1. For safe use Seating position Front passenger seat Third seat Second seat With airbag Mass groups (if equipped) Without manual on-off airbag switch manual on-off Out- Out- Center Center switch board board Up to 10 kg (22 lb.) (0 - 9 months) Up to 13 kg (28 lb.) (0 - 2 years)
Page 74 1-1. For safe use Key of letters inserted in the above table: X: Not suitable seat position for children in this mass group. U: Suitable for “universal” category child restraint systems approved for use in this mass group. UF: Suitable for forward-facing “universal” category child restraint sys- tems approved for use in this mass group.
Page 75 1-1. For safe use Child restraint system suitability for various seating positions (with ISOFIX rigid anchors) ISOFIX child restraint systems are divided in different “size class”. According to this “size class”, you will be allowed to use it in the vehi- cle seating position mentioned in the table below.
Page 76 1-1. For safe use Seating position Front Third seat Size Second seat Mass groups seat (if equipped) class Passen- Outboard Center Outboard Center ger seat Carrycot Up to 10 kg (22 lb.) Up to 13 kg (28 lb.) 9 to 18 kg (20 to 39 lb.) Key of letters inserted in the above table: Not suitable seat position for ISOFIX child restraint systems in...
Page 77 1-1. For safe use When securing some types of child restraint systems in second or third row seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affect- ing seat belt effectiveness.
Page 78 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 79 1-1. For safe use WARNING When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 80: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using a seat belt or ISOFIX rigid anchor (ISOFIX child restraint system). Attach the top strap when installing a child restraint. Seat belts (An ELR belt requires a locking clip.) ISOFIX rigid anchor (ISOFIX child...
Page 81 1-1. For safe use Installing child restraints using a seat belt Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Fold the seatback while pull- ing the seatback angle lever. Return the seatback and secure it at the first lock posi- tion.
Page 82 1-1. For safe use Forward-facing Child seat (convertible seat) ■ Fold the seatback while pull- ing the seatback angle lever. Return the seatback and secure it at the first lock posi- tion. (P. 222) Place the child restraint sys- tem on the second seat fac- ing the front of the vehicle.
Page 83 1-1. For safe use Junior seat (booster seat) ■ Fold the seatback while pull- ing the seatback angle lever. Return the seatback and secure it at the first lock posi- tion. Place the child restraint sys- tem on the seat facing the front of the vehicle.
Page 84 1-1. For safe use Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint sys- tem) Fold the seatback forward and then back to the 1st lock posi- tion (most upright position) until it locks into place.
Page 85 1-1. For safe use Check the positions of the exclusive fixing bars, and install the child restraint system to the seat. The bars are installed in the clear- ance between the seat cushion and seatback. If the child restraint system has a top strap, the top strap should be latched onto the anchors.
Page 86 1-1. For safe use Adjust the head restraint to the downmost position.  Second center seat Secure the child restraint sys- tem using a seat belt, and remove head restraint (vehicles with rear armrest) or adjust the head restraint to the upmost position (vehicles with- out rear armrest).
Page 87 You need a locking clip to install the child restraint system. Follow the instruc- tions provided by the manufacturer of the system. If your child restraint sys- tem does not provide a locking clip, you can purchase the following item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119-22010) WARNING ■...
Page 88 1-1. For safe use WARNING When installing a child restraint system ■ ● Vehicles without airbag manual on-off switch: Never install a rear-facing child restraint system on the front passenger seat. The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 89 If child restraint system regulations exist in the country where you reside, ● please contact your Toyota dealer for the child restraint system installation. ● When installing a child restraint system on the second center seat, adjust both seat cushions to the same position and align both seatbacks at the same angle.
Page 90 1-1. For safe use WARNING When installing a child restraint system ■ ● Ensure that the belt and plate are securely locked and the seat belt is not twisted. Shake the child restraint system left and right, and forward and backward ●...
Page 91: Exhaust Gas Precautions
Keep the back door closed. If you smell exhaust gases in the vehicle even when the back door is ● closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking If the vehicle is in a poorly ventilated area or a closed area, such as a ●...
Page 92: Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 93 1-2. Theft deterrent system Vehicles with a smart entry & start system: The indicator light flashes after the engine switch has been turned off to indicate that the system is operating. The indicator light stops flashing after the engine switch has been turned to ACCESSORY or IGNITION ON mode to indicate that the system has been canceled.
Page 94 1-2. Theft deterrent system  For vehicles sold in Vietnam  For vehicles sold in Jamaica  For vehicles sold in the Dominican Republic NOTICE To ensure the system operates correctly ■ Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 95: Double Locking System
1-2. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this system have labels on the window glass of both front doors.
Page 96: Alarm
1-2. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function (vehicles with smart entry &...
Page 97 1-2. Theft deterrent system Setting the alarm system  Type A  Type B  Type C Close the doors and hood, and lock all the doors using the entry func- tion or wireless remote control. The system will be set automatically after 30 seconds.
Page 98 1-2. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. ● Unlock the doors using the entry function (vehicles with smart entry & start system) or wireless remote control. ● Turn the engine switch to ACCESSORY or IGNITION ON mode. (The alarm will be deactivated or stopped after a few seconds.) ●...
Page 99 1-2. Theft deterrent system ● The battery is recharged or replaced when the vehicle is locked. (P. 902) Vehicles with intrusion sensor and tilt ● sensor: The battery is disconnected when the vehicle is locked. ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ●...
Page 100: Instrument Cluster
1-2. Theft deterrent system Intrusion sensor and tilt sensor (if equipped) ● The intrusion sensor detects an intruder or movement in the vehi- cle. ● The tilt sensor detects changes in vehicle inclination, such as when the vehicle is towed away. This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.
Page 101 1-2. Theft deterrent system ■ Intrusion sensor considerations The sensor may trigger the alarm in the following situations: ● People or pets are in the vehicle. A window or the moon roof (if equipped) ● is open. In this case, the sensor may detect the following: •...
Page 102 ● Do not spray air fresheners or other products directly into the sensor holes. ● Installing accessories other than genuine Toyota parts or leaving objects between the driver’s seat and front passenger’s seat may reduce the detection performance. LC200_OM_OM60R59W_(WE)
Page 103 Instrument cluster Instrument cluster Warning lights and indicators ......102 Gauges and meters ...109 Multi-information display ..115 Fuel consumption information.......124 LC200_OM_OM60R59W_(WE)
Page 104: Instrument Cluster Warning Lights And
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 105 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Master warning light Open door warning light (P. 851) (P. 849) (if equipped) Unlocked spare tire Brake system warning carrier warning light light (P.
Page 106 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer.
Page 107 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Dynamic radar cruise Turn signal indicator control indicator (P. 325) (P. 395) (if equipped) 1, 2 Headlight high beam Slip indicator (P. 550) indicator (P.
Page 108 There may be a malfunction in a system if a light does not turn on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 109 If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction with the system. If this occurs, have the vehicle inspected by your Toyota dealer. : This light illuminates on the outside rear view mirrors.
Page 110 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 111: Gauges And Meters
2. Instrument cluster Gauges and meters  Vehicles without multi-information display Vehicles with multi-information display  LC200_OM_OM60R59W_(WE)
Page 112 2. Instrument cluster Engine oil pressure gauge Displays the engine oil pressure Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Voltmeter Displays the charge state Fuel gauge Displays the quantity of fuel remaining in the tank Engine coolant temperature gauge Displays the engine coolant temperature Multi-information display...
Page 113 2. Instrument cluster Odometer/trip meter display change button Switches between odometer and trip meter displays Instrument cluster light control dial (vehicles with multi-information display) The brightness of the instrument cluster light can be adjusted Changing the display Vehicles without multi-information display ...
Page 114 2. Instrument cluster Instrument cluster light control (vehicles with multi-information display) The brightness of the instrument cluster lights can be adjusted by turning the dial. Darker Brighter Eco Driving Indicator Light customization (vehicles without multi-information display) Eco Driving Indicator Light can activated or deactivated. While the odometer is being displayed, press and hold the odometer/trip...
Page 115 2. Instrument cluster ■ The meters and display illuminate when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode. ■...
Page 116 When the oil pressure drops even though the engine oil amount has not decreased, or if the oil pressure does not increase when engine oil is added, contact your Toyota dealer, as there may be a problem with the lubri- cation system.
Page 117: Multi-Information Display
2. Instrument cluster  Multi-information display Display contents The following information will be displayed when a menu icon is selected. (P. 117) Some of the information may be displayed automatically depend- ing on the situation. Drive information Select to display various drive data. (P. 118) Vehicle information display (if equipped) Select to display the vehicle information.
Page 118 2. Instrument cluster Driving assist system information (if equipped) Select to display the operational status of the following systems: • Dynamic radar cruise control (P. 395) • When the vehicle is in constant speed control mode (P. 404), the menu icon will change to •...
Page 119 2. Instrument cluster Operating the meter control switches The multi-information display is operated using the meter control switches. Switching displayed items Operate up and down: Switches screens and moves the cursor Press: Enters, moves to next screen and turns functions on/off : For some functions Press: Displays the screen registered as the top screen When no screen has been registered, the drive information screen will be...
Page 120 2. Instrument cluster Drive information Items displayed can be switched by operating up and down. Drive information ■ 4 of the following items can be registered and displayed as the drive information 1 and the drive information 2 (2 items on each screen).
Page 121 2. Instrument cluster Eco Indicator (Eco Driving Indicator Zone Display) ■ P. 122 Speed ■ Displays the vehicle speed. Sway warning (if equipped) ■ Detects the sway of the vehicle within a lane, which is often associ- ated with a decrease in the driver’s attention level, and displays the decrease in attention using a bar display.
Page 122 2. Instrument cluster Vehicle information Items displayed can be switched by operating up and down. Front tire angle (if equipped) ■ Displays the direction of the front tires. The tire direction is displayed in 3 stages for both left and right, in accor- dance with the angle of the tire.
Page 123 2. Instrument cluster Setting items ■ LDA (Lane Departure Alert) ● Select to set up LDA. (P. 950) • Alert sensitivity • Sway warning • Sway sensitivity BSM (Blind Spot Monitor) ● Select to activate/deactivate BSM. (P. 950) • BSM on/off •...
Page 124 2. Instrument cluster • Pop-up display Select to set the pop-up displays (P. 122), which may appear in some situations, on/off. • Accent color Select to change the accent colors on the screen, such as the cursor color. • Initialization Select to reset the meter display settings.
Page 125 2. Instrument cluster ■ Tire inflation pressure It may take a few minutes to display the tire inflation pressure after the ● engine switch is turned to IGNITION ON mode. It may also take a few min- utes to display the tire inflation pressure after inflation pressure has been adjusted.
Page 126: Fuel Consumption Information
2. Instrument cluster  Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the trip information or past record screen Press the “INFO”/“INFO/APPS” button, and then select “Fuel Con- sumption”...
Page 127 2. Instrument cluster Past record Reset the past record data Best recorded fuel consumption Average fuel consumption Previous fuel consumption record Update the past record data These images are examples only, and may vary slightly from actual conditions. Resetting the data ■...
Page 128 2. Instrument cluster LC200_OM_OM60R59W_(WE)
Page 129: Operation Of Each Component
Operation of each component 3-1. Key information Keys........128 3-2. Opening, closing and locking the doors Side doors......134 Back door (Lift-up type) ..144 Back door (Double type) ..158 Smart entry & start system ......163 3-3. Adjusting the seats Front seats......219 Rear seats ......222 Driving position memory ..234 Head restraints ....238 3-4.
Page 130: 3-1. Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle.  Vehicles without a smart entry & start system Master keys Operating the wireless remote con- trol function (P. 129) Valet key Key number plate  Vehicles with a smart entry &...
Page 131 Unlocks the doors (P. 135) 1, 2 Opens the windows and moon roof (P. 135) Opens/closes the back door (P. 145) Sounds the alarm (P. 130) : These settings must be customized at your Toyota dealer. : If equipped LC200_OM_OM60R59W_(WE)
Page 132 3-1. Key information Using the mechanical key (vehicles with a smart entry & start system)  Type A  Type B To take out the mechanical key, To take out the mechanical key, slide the release lever and take slide the release lever and take the key out.
Page 133 If you lose your keys ■ New genuine keys can be made by your Toyota dealer using a master key (vehicles without a smart entry & start system) or the other key (vehicles with a smart entry & start system) and the key number stamped on your key num- ber plate.
Page 134 Replacing the key battery P. 802 Confirmation of the registered key number ■ The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer. Certification for the wireless remote control ■  For vehicles sold in Paraguay ...
Page 135 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. LC200_OM_OM60R59W_(WE)
Page 136: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Locking and unlocking the doors from the outside ◆ Smart entry & start system (if equipped) Carry the electronic key to enable this function.
Page 137 Press and hold to close the windows and moon roof. Unlocks all the doors 1, 2 Press and hold to open the windows and moon roof. : These settings must be customized at your Toyota dealer. (vehicles with a smart entry & start system only) : If equipped LC200_OM_OM60R59W_(WE)
Page 138 3-2. Opening, closing and locking the doors ◆  Vehicles without a smart entry & start system Locks all the doors Unlocks all the doors  Vehicles with a smart entry & start system The doors can also be locked and unlocked with the mechanical key.
Page 139 3-2. Opening, closing and locking the doors ■ If the smart entry & start system or the wireless remote control does not operate properly Vehicles with smart entry & start system: Use the mechanical key to lock ● and unlock the doors. (P. 898) ●...
Page 140 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock button Locks the door Unlocks the door The driver’s door and front pas- senger’s door (for some models only) can be opened by pulling the inside door handle even if...
Page 141 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without a smart entry & start system ...
Page 142 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems (if equipped) The following functions can be set or canceled: For instructions on customizing, refer to P. 950. Function Operation Shift position linked door Shifting the shift lever out of P locks all the locking function doors.
Page 143 3-2. Opening, closing and locking the doors Setting and canceling the functions ■ To switch between setting and canceling, follow the procedure below. Close all the doors and turn the engine switch to IGNITION ON mode. (Perform step 2 within 20 seconds.) Shift the shift lever to P or N, and press and hold the driver’s...
Page 144: Information
3-2. Opening, closing and locking the doors ■ Changing the door unlock function setting (vehicles with a smart entry & start system) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. Cancel the intrusion sensor and tilt sensor of the alarm system (if equipped) to prevent unintended triggering of the alarm during the setting change.
Page 145 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system (if equipped) In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 146: Back Door (Lift-Up Type)
3-2. Opening, closing and locking the doors Back door (Lift-up type) The back door can be locked/unlocked and opened by the fol- lowing procedures. Locking and unlocking the back door ◆ Smart entry & start system (if equipped) Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
Page 147 3-2. Opening, closing and locking the doors Opening/closing the back door with the wireless remote control (vehicles with power back door) Press and hold the switch. The power back door can be oper- ated only when the back door is unlocked.
Page 148 3-2. Opening, closing and locking the doors Opening the back door from the outside Vehicles with back door mounted spare tire ■ Pull the lock release lever and swing the spare tire car- rier. The warning indicator appears on the multi-information display (vehicles with Optitron...
Page 149 3-2. Opening, closing and locking the doors Open the upper back door Vehicles without power  back door When the back door is unlocked: Raise the back door while pressing up the back door opener switch. When the back door is locked: While carrying an electronic key, raise the back door while pressing up the...
Page 150 3-2. Opening, closing and locking the doors Vehicles without back door mounted spare tire ■ Open the upper back door Vehicles without power  back door When the back door is unlocked: Raise the back door while pressing up the back door opener switch.
Page 151 3-2. Opening, closing and locking the doors Power back door switch (if equipped) Pressing the switch closes upper back door automatically. buzzer sounds.) Pressing the switch while the upper back door is closing opens it again. Canceling the power back door system (if equipped) Turn the main switch off to disable the power back door system.
Page 152 3-2. Opening, closing and locking the doors Rear step bumper (if equipped) The rear step bumper is for rear end protection and easier step-up loading. Power back door operating conditions (vehicles with power back door) ■ When the engine switch is off or in accessory mode, the power back door ●...
Page 153 3-2. Opening, closing and locking the doors ■ If the back door opener is inoperative The back door can be operated from the inside. Remove the cover on the back door trim. Use a cloth to prevent scratches. Remove the screw and cover. (Vehicles without power back door) Push the lever for the back door motor, open the back door.
Page 154 3-2. Opening, closing and locking the doors ■ Jam protection function (vehicles with power back door) If anything obstructs the power back door while it is closing/opening, the back door will automatically operate in the opposite direction. When re-connecting the battery (vehicles with power back door) ■...
Page 155 3-2. Opening, closing and locking the doors WARNING While driving ■ ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 156 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. LC200_OM_OM60R59W_(WE)
Page 157 3-2. Opening, closing and locking the doors WARNING While parking (vehicles with back door mounted spare tire) ■ If the swung spare tire carrier hides the stop and tail lights, rear turn signal lights or rear retro reflectors while you are parked, other road users must be warned of the presence of your vehicle by a warning reflectors or other device.
Page 158 When installing an accessory part to the back door, using a genuine Toyota part is recom- mended. Jam protection function (vehicles with power back door) ■...
Page 159 ● gloves or other fabric items. ● Do not attach any accessories other Damper stay than genuine Toyota parts to the back door. Do not place your hand on the damper stay or apply lateral forces to it. ● ■...
Page 160: Back Door (Double Type)
3-2. Opening, closing and locking the doors Back door (Double type) The back door can be locked/unlocked and opened by the fol- lowing procedures. Locking and unlocking the back door ◆ Wireless remote control P. 135 ◆ Door lock switch P.
Page 161 3-2. Opening, closing and locking the doors Opening the back door from the outside Open the left side door. Pull the handle Open Open the right side door. Pull the lever Open LC200_OM_OM60R59W_(WE)
Page 162 3-2. Opening, closing and locking the doors Opening the back door from the inside Open the left side door. Pull the handle Open Open the right side door. Pull the lever Open Back door child-protector lock The door cannot be opened from inside the vehicle when the lock is set.
Page 163 3-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step-up loading. When closing the back door ■ Before closing the left side door, ensure that the right side door has been closed first.
Page 164 ● Do not attach any accessories other than genuine Toyota parts to the back door. Doing so could cause the door to become heavy, which could inter- fere with opening/closing.
Page 165: Smart Entry & Start System
3-2. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 166 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators Vehicles without multi-information display: A combination of exterior and inte- rior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures for the warning light that comes on.
Page 167 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 168 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
Page 169 3-2. Opening, closing and locking the doors ● As long as the electronic key is within the effective range, the doors may be locked or unlocked by anyone. However, only the doors detecting the elec- tronic key can be used to unlock the vehicle. Even if the electronic key is not inside the vehicle, it may be possible to start ●...
Page 170 3-2. Opening, closing and locking the doors ■ To operate the system properly Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.
Page 171 3-2. Opening, closing and locking the doors ■ Certification for the smart entry & start system  For vehicles sold in Federated States of Micronesia LC200_OM_OM60R59W_(WE)
Page 172 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 173 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 174 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 175 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 176 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 177 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 178 3-2. Opening, closing and locking the doors  For vehicles sold in Pakistan LC200_OM_OM60R59W_(WE)
Page 179 3-2. Opening, closing and locking the doors  For vehicles sold in Federated States of Micronesia LC200_OM_OM60R59W_(WE)
Page 180 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 181 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 182 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 183 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 184 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 185 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 186 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 187 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 188 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 189 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 190 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 191 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 192 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 193 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 194 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 195 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 196 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 197 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 198 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 199 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 200 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 201 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 202 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 203 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 204 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 205 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 206 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 207 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 208 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 209 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 210 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 211 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 212 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 213 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 214 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 215 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 216 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 217 3-2. Opening, closing and locking the doors LC200_OM_OM60R59W_(WE)
Page 218 3-2. Opening, closing and locking the doors  For vehicles sold in Indonesia  For vehicles sold in Vietnam For vehicles sold in the United Arab Emirates  LC200_OM_OM60R59W_(WE)
Page 219 3-2. Opening, closing and locking the doors  For vehicles sold in Jamaica For vehicles sold in South Africa   For vehicles sold in the Dominican Republic and Federated States of Micronesia For vehicles sold in Vietnam  LC200_OM_OM60R59W_(WE)
Page 220 (P. 163) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 221: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever Seat cushion (front) angle adjustment knob Lumbar support control switch : if equipped on driver’s side LC200_OM_OM60R59W_(WE)
Page 222 3-3. Adjusting the seats  Power seat Seat position control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumbar support control switch (driver’s side only) Active head restraint (if equipped) When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
Page 223 3-3. Adjusting the seats ■ Active head restraint (if equipped) Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
Page 224: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedure Second seat ■  Bench seat  Separated seat Seatback angle adjustment lever Seat position adjustment lever Third seat (if equipped) ■ Transverse type seat without center seat  Seatback angle adjustment lever LC200_OM_OM60R59W_(WE)
Page 225 3-3. Adjusting the seats  Transverse type seat with center seat Seatback angle adjustment lever Longitudinal type seat  LC200_OM_OM60R59W_(WE)
Page 226 3-3. Adjusting the seats Tumbling the second seats and third seat entry (Bench seat) Vehicles with third seat: For easy access to the third seat, perform in “Tumbling the second seats”. (P. 225) Before tumbling the second seats ■ Stow the seat belt buckles and lower the head restraints to the lowest position.
Page 227 3-3. Adjusting the seats Tumbling the second seats ■ Pull the lever and fold the seatback down. Pull the lock release lever and swing the whole seat up and forward. Hook the holding strap to the assist grip and secure the seat by pulling its free end.
Page 228 3-3. Adjusting the seats Tumbling the second seats and third seat entry (Separated seat) Vehicles with third seat: For easy access to the third seat, perform in “Tumbling the second seats”. (P. 227) Before tumbling the second seats ■ Stow the seat belt buckles and lower the head restraints to the lowest position.
Page 229 3-3. Adjusting the seats Tumbling the second seats ■ Fold down seatback while pulling the seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the assist grip and secure the seat by pulling its free end. When returning the second seat to its original position, stow the holding strap.
Page 230 3-3. Adjusting the seats Folding up the third seats (vehicles with transverse type seat) Before folding up the third seats ■ Stow the seat belt buckles. Without center seat With center seat   Lower outside head restraints to the lowest posi- tion.
Page 231 3-3. Adjusting the seats Folding up the third seats ■ Fold down head restraints while pulling the head restraint angle levers. (Type A only: P. 239) Push the seatback angle levers and fold the third seat- backs. Pull the seat leg lock release levers.
Page 232 3-3. Adjusting the seats Remove the seat hook cov- ers from the back of the seat cushion, and install them on the seat hooks. Returning the third seats ■ Remove the seat hook cov- ers from the floor and install them into the back of the seat cushion.
Page 233 3-3. Adjusting the seats Pull the handle and raise the seatbacks. Fix the handle securely in its original position after use. Raise the head restraints. (Type A only) LC200_OM_OM60R59W_(WE)
Page 234 3-3. Adjusting the seats Folding up the third seats (vehicles with longitudinal type seat) Folding the third seats ■ Swing the seat cushion fully Take the holding strap of its pocket on the back of the seatback and secure the seat hooking the strap onto the hook in the back of the seat cushion.
Page 235 3-3. Adjusting the seats WARNING Seat adjustment (if equipped) ■ To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Page 236: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat, steering wheel and outside rear view mirrors to make entering and exit- ing the vehicle easier or to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be recorded and recalled by pressing a button.
Page 237 3-3. Adjusting the seats Recall procedure ■ Check that the shift lever is in P. Turn the engine switch to IGNITION ON mode. Press one of the buttons for the driving position you want to recall until the buzzer sounds. To stop the position recall operation part-way through ■...
Page 238 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. Registering procedure ■ Record your driving position to button “1”, “2” or “3” before perform- ing the following: Carry only the key you want to register, and then close the driver’s door.
Page 239 3-3. Adjusting the seats Cancelation procedure ■ Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
Page 240: Head Restraints
3-3. Adjusting the seats Head restraints Front seats Vertical adjustment Down Push the head restraint up or down while pressing the lock release but- ton. Lock release button Angle adjustment (if equipped) Second seats Bench seat  Pull the head restraint up. Down Press and hold the lock release button when lowering the head...
Page 241 3-3. Adjusting the seats  Separated seat Pull the head restraint up. Down Press and hold the lock release button when lowering the head restraint. Lock release button Third outboard seats (vehicles with transverse type seat)  Type A To fold the head restraints, pull the head restraint angle lever ...
Page 242 3-3. Adjusting the seats ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Using the second center seat head restraint (vehicles without second ■...
Page 243 3-3. Adjusting the seats  Third center seats (vehicles with transverse type seat) Pull the head restraint up while pressing the lock release button. Lock release button  Third outboard seats (vehicles with type A of transverse type seat) Push a flathead screwdriver into the slot.
Page 244 3-3. Adjusting the seats WARNING Head restraint precautions ■ Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 245: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure (manual adjustment type A) Hold the steering wheel and pull the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 246 3-4. Adjusting the steering wheel and mirrors  To change the column length Hold the steering wheel and push down the lock release lever. Set the steering wheel to the desired length and return the lever to its original position. Adjustment procedure (power adjustment type) Operating the switch moves the steering wheel in the following direc- tions:...
Page 247 3-4. Adjusting the steering wheel and mirrors Auto tilt away (power adjustment type) When the engine switch is turned off, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry and exit. Switching to ACCESSORY IGNITION ON mode will return the...
Page 248 3-4. Adjusting the steering wheel and mirrors WARNING Caution while driving ■ Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. After adjusting the steering wheel (manual adjustment type) ■...
Page 249: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view in accordance with the driver’s seating posture. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 250 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF Vehicles without a smart entry &...
Page 251 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 252: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors (Manual type) Push the mirror back in the direc- tion of the vehicle’s rear.
Page 253 3-4. Adjusting the steering wheel and mirrors Folding and extending the mirrors (Power type) Using the switch ■ Extends the mirrors Folds the mirrors Setting automatic mode ■ The door mirrors can be automatically folded and extended by link- ing them to the lock and unlock operations of the smart entry & start system and wireless remote control.
Page 254 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (if equipped) When the mirror select switch is in the L or R position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. To disable this function, move the mirror select switch to the neutral position (between L and R).
Page 255 3-4. Adjusting the steering wheel and mirrors WARNING Important points while driving ■ Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 256: Power Windows
3-5. Opening and closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the following switches. Type A  Closing One-touch closing (driver’s win- dow only) Opening One-touch opening (driver’s window only) : To stop the window partway, oper-...
Page 257 3-5. Opening and closing the windows and moon roof ■ The power windows can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 258 ● The power windows can be opened and closed using the wireless remote control. (P. 134) : The settings must be customized at your Toyota dealer. Power windows open warning buzzer (vehicles with multi-information ■ display) The buzzer sounds and a message is shown on the multi-information display in the instrument cluster when the engine switch is turned off and the driver’s...
Page 259 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Closing the windows The driver is responsible for all the power window operations, including the ●...
Page 260: Moon Roof
3-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 261 ● The moon roof can be opened and closed using the mechanical key. (P. 898) The moon roof can be opened using the wireless remote control. ● (P. 134) : The settings must be customized at your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 262 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. Moon roof open reminder function (vehicles with multi-information dis- ■...
Page 263 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 264 3-5. Opening and closing the windows and moon roof LC200_OM_OM60R59W_(WE)
Page 265: Driving
Driving 4-1. Before driving 4-5. Using the driving support systems Driving the vehicle .....264 Toyota Safety Sense ..367 Cargo and luggage ....276 PCS (Pre-Crash Safety Trailer towing system) ......373 (with towing hitch)....279 LDA (Lane Departure Pintle hook......289 Alert) ........386 Electric winch.....290 Dynamic radar cruise 4-2.
Page 266: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 303, 306 Driving  Automatic transmission With the brake pedal depressed, shift the shift lever to D. (P. 316) Release the parking brake. (P. 326) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 267 4-1. Before driving Parking the vehicle  Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake (P. 326), and shift the shift lever to P (P. 316). Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 268 4-1. Before driving Starting off on a steep uphill  Automatic transmission Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake.  Manual transmission With the parking brake firmly set and the clutch pedal fully depressed, shift the shift lever to 1.
Page 269 This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding-down operation. ■ Idling time before stopping the engine (diesel engine) To prevent damage to the turbocharger, allow the engine to idle immediately after high-speed driving or driving up a hill.
Page 270 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle On vehicles with an automatic transmission, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehi- cle from creeping.
Page 271 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle During normal driving, do not turn off the engine. Turning the engine off ● while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 272 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and ● reduce your ability to control the vehicle. Sudden acceleration, engine braking due to shifting, or changes in engine ●...
Page 273 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 274 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in ● the vehicle when it is in the sun. Doing so may result in the following: •...
Page 275 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 276 4-1. Before driving NOTICE When driving the vehicle ■  Automatic transmission ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. Do not use the accelerator pedal or depress the accelerator and brake ●...
Page 277 Short in electrical components Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 278: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Roof rack (if equipped) WARNING Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compartment: ●...
Page 279 4-1. Before driving WARNING Storage precautions ■ Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or pas- sengers, possibly causing an accident. Stow cargo and luggage in the luggage compartment whenever possible.
Page 280 4-1. Before driving WARNING When loading cargo on the roof rack (if equipped) ■ Observe the following precautions: ● Place the cargo so that its weight is distributed evenly between the front and rear axles. If loading long or wide cargo, never exceed the vehicle overall length or ●...
Page 281: Trailer Towing (With Towing Hitch)
To tow a trailer safely, use extreme care and drive the vehicle in accordance with the trailer’s characteristics and operating con- ditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about addi- tional requirements such as towing kits, etc.
Page 282 MPAC (Maximum Permissible Axle Capacity), and permissible drawbar load before towing. (P. 916) ◆ Towing hitch/bracket Toyota recommends the use of the Toyota hitch/bracket for your vehicle. Other products of a suitable nature and comparable quality may also be used. Connecting trailer lights Use the wire harness stored in the rear end.
Page 283 4-1. Before driving Information tag (manufacturer’s label) ■ Gross vehicle mass The combined weight of the driver, passengers, luggage, towing hitch, total curb mass and drawbar load should not exceed the gross vehicle mass by more than 100 kg (220.5 lb.). Exceeding this weight is danger- ous.
Page 284 4-1. Before driving Removing hitch cover Remove the clip. Grasp the lower edge of the hitch cover and raise the cover. When reattaching cover, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 285 4-1. Before driving ■ Connecting and disconnecting a trailer (vehicles with 4-Wheel AHC) Stop your vehicle and a trailer in line and perform the following: ● Connecting a trailer Put the 4-Wheel AHC in the “LO” (low) mode. Turn off the engine switch or the 4-Wheel AHC. Connect a trailer.
Page 286 ■ Break-in schedule Toyota recommends that vehicles fitted with new power train components should not be used for towing trailers for the first 800 km (500 miles). ■ Safety checks before towing Check that the maximum load limit for the towing hitch/bracket hitch ball is ●...
Page 287 4-1. Before driving ■ If trailer sway occurs One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely affect handling of your vehicle and trailer, causing instability. If trailer swaying occurs: ● • Firmly grip the steering wheel. Steer straight ahead. Do not try to control trailer swaying by turning the steering wheel.
Page 288 4-1. Before driving NOTICE When the rear bumper strengthening material is aluminum ■ Ensure the steel bracket part does not come directly in contact with that area. When steel and aluminum come into contact, there is a reaction similar to corrosion, which will weaken the section concerned and may result in dam- age.
Page 289 4-1. Before driving Sudden acceleration/steering input/cornering ■ Executing sharp turns when towing may result in the trailer colliding with your vehicle. Decelerate well in advance when approaching turns and take them slowly and carefully to avoid sudden braking. Important points regarding turning ■...
Page 290 4-1. Before driving If the engine overheats ■ Towing a loaded trailer up a long, steep incline in temperatures exceeding 30C (85F) may result in the engine overheating. If the engine coolant temperature gauge indicates that the engine is over- heating, turn the air conditioning off immediately, leave the road and stop the vehicle in a safe place.
Page 291: Pintle Hook
4-1. Before driving  Pintle hook The pintle hook can be used for towing. Pull the pintle hook lock lever Lift the upper half of the hook After attaching the trailer, let the upper half of the pintle hook lower to its original position, and lower the pintle hook lock lever.
Page 292: Electric Winch
4-1. Before driving  Electric winch Winch cover Hook holder Winch clutch opening Winch opening Remote control terminal Dust cap Hook Winch clutch lever Remote control You can find the winch clutch lever and remote control in the storage bag in the glove box. ...
Page 293 4-1. Before driving Remote control “POWER” indicator light This light indicates that the winch is ready to use. With the remote control plugged into the winch terminal, this light comes on when the engine is started. If the “POWER” indicator light dims noticeably, stop operation and allow the battery to recharge.
Page 294 4-1. Before driving Removing the winch cover Grasp the lower edge of the winch cover and raise the cover. Squeeze the cover fastener and remove the cover as shown in the illustration. When reattaching the winch cover, reverse the steps listed. Preparing to use the winch Park the vehicle straight ahead of the object you want to pull.
Page 295 4-1. Before driving Remove the hook holder and pull out the cable by hand. Hold the hook and extend the cable as far as necessary. Operating the winch Pulling out the cable (with power) ■ Turn the winch clutch lever clockwise to the lock posi- tion.
Page 296 4-1. Before driving When using the winch with the vehicle parked, shift the shift lever to “P” (automatic transmission) or “N” (manual transmission) and set the parking brake firmly. Block the front wheels. Start the engine and run it at higher engine rpm than idling. Make sure the “POWER”...
Page 297 4-1. Before driving To pull an object that is more than 15 degrees offset from the center of the winch opening, use a block and tackle as shown in the illustration. Attaching the cable ■ Attach the cable hook securely to the object to be pulled or to a Separate cable standing tree.
Page 298 4-1. Before driving How to hook the cable ■ The allowable load is as follows. Cable Pulling Force Less than Single line 1000 kg (2204 lb.) Less than Double line 2000 kg (4409 lb.) Less than Triple line 3000 kg (6613 lb.) Freeing the vehicle when stuck, or ascending a steep incline ■...
Page 299 4-1. Before driving After using the winch With another person holding the hook and pulling it lightly to maintain some tension on the cable, wind the cable one loop at a time starting from the edge of the drum. Stop the remote control switch when about 1 m (3 ft.) of cable is left.
Page 300 4-1. Before driving Install the hook holder in the winch opening. Rewind the cable so that it is under slight tension. ITY25C035 Disconnect the remote control wire plug from the terminal and install the dust cap on the terminal. Put the winch clutch lever and remote control in the storage bag in the glove box.
Page 301 If the remote control lead wire is shorted, the winch may begin operating without warning. If you detect any abnormality with the winch equipment, do not use the winch, and consult your Toyota dealer. Never use the winch to lift or move people, or to lift objects.
Page 302 4-1. Before driving WARNING Apply the parking brake and place the wheel blocks in front of the front ● wheels when using the winch with your vehicle parked. ● Rewind the cable in the direction shown on the winch assembly. Winding in the opposite direction is dangerous because the brake does not work and the control switch will rewind the cable on the “OUT”...
Page 303 4-1. Before driving NOTICE To prevent damage to the vehicle or the electric winch ■ ● Do not operate the winch with the hook holder still fixed in place. ● Do not continue operation if the “OVER TEMP” warning light is lit and the warning buzzer sounds.
Page 304 4-1. Before driving NOTICE Do not leave the remote control switch in the “IN” position. When rewind- ● ing is no longer possible (because the object being moved has hit a rock, etc.), turn the remote control switch to off. ●...
Page 305: Engine (Ignition) Switch (Vehicles Without A
4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine  Automatic transmission Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “ON”...
Page 306 Shift the shift lever to P (automatic transmission) or N (manual transmis- sion). (P. 316, 323) Push in the key and turn it to the “LOCK” position. ■ If the engine does not start The engine immobilizer system may not have been deactivated. (P. 90) Contact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 307 Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring system. ● Do not race a cold engine. If the engine becomes difficult to start or stalls frequently, have your vehi- ● cle checked by your Toyota dealer immediately. LC200_OM_OM60R59W_(WE)
Page 308: Engine (Ignition) Switch (Vehicles With A Smart Entry & Start System)
4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine  Automatic transmission Check that the parking brake is set.
Page 309 4-2. Driving procedures  Manual transmission Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal. The smart entry & start system indicator (green) will turn on. If the indicator does not turn on, the engine cannot be started. Press the engine switch.
Page 310 4-2. Driving procedures Stopping the engine  Automatic transmission Stop the vehicle. Set the parking brake (P. 326), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that the display on the instru- ment cluster is off.
Page 311 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal (vehicles with an automatic transmission) or clutch pedal (vehi- cles with a manual transmission) released. (The mode changes each time the switch is pressed.) ...
Page 312 4-2. Driving procedures  Vehicles with a multi-information display The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used. “ACCESSORY” will be displayed on the multi-information display. IGNITION ON mode All electrical components can be used.
Page 313 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (Vehicles with an automatic transmission) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 314 ■ ● The engine immobilizer system may not have been deactivated. (P. 90) Contact your Toyota dealer. Automatic transmission: Check that the shift lever is securely set in P. The ● engine may not start if the shift lever is displaced out of P.
Page 315 When the smart entry & start system indicator light flashes in yellow (vehicles without a multi-information display) The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ When “Smart Entry & Start System Malfunction See Owner’s Manual” is...
Page 316 4-2. Driving procedures WARNING When starting the engine ■ Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Caution while driving ■...
Page 317 ● ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. Symptoms indicating a malfunction with the engine switch ■ If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 318: Automatic Transmission
4-2. Driving procedures  Automatic transmission Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 319 4-2. Driving procedures Shift position purpose Shift position Purpose and condition Parking the vehicle/starting the engine Reversing Neutral (Condition in which the power is not transmitted) Normal driving S mode driving (P. 319) : Shifting to the D position allows the system to select a gear suitable for the driving conditions.
Page 320 4-2. Driving procedures Selecting a driving mode (vehicles without drive mode select switch) The following patterns can be selected to suit current driving and operating conditions. Type A  Power mode For powerful acceleration and driv- ing in mountainous regions. Normal mode For normal driving.
Page 321 4-2. Driving procedures Second start mode ■ For starting on slippery road surfaces, such as on snow. Press the button again to cancel second start mode. Changing shift ranges in S mode When the shift lever is in the S position, the shift lever can be oper- ated as follows: Upshifting Downshifting...
Page 322 4-2. Driving procedures Shift ranges and their functions ■ ● Automatically selecting gears as follows according to vehicle speed and driving conditions. But, the gear is limited according to selected shift range. • Between 1 and 8 (8-speed models) • Between 1 and 6 (6-speed models) ●...
Page 323 If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 324 If the “S” indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. ■ Downshift restriction warning buzzer in the S mode To help ensure safety and driving performance, downshifting operation may sometimes be restricted.
Page 325: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 326 4-2. Driving procedures ■ Maximum downshifting speeds Observe the downshifting speeds in the following table to prevent over-rev- ving the engine. km/h (mph) Maximum speed Transfer Shift position position Gasoline engine Diesel engine 43 (27) 37 (23) 79 (49) 68 (42) 131 (81) 113 (70) 196 (122)
Page 327: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The turn signal lever can be used to show the following intentions of the driver: Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 328: Parking Brake
4-2. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Parking the vehicle P.
Page 329: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows:  Left-hand drive vehicles (type A) Vehicles without day- time running light sys- tem: Off.
Page 330 4-3. Operating the lights and wipers  Left-hand drive vehicles (type B) The front position, tail, license plate and instru- ment panel lights turn The headlights and all lights listed above turn LC200_OM_OM60R59W_(WE)
Page 331 4-3. Operating the lights and wipers  Right-hand drive vehicles (type A) Vehicles without day- time running light sys- tem: Off. Vehicles with daytime running light system: daytime running lights turn on. The front position, tail, license plate and instru- ment panel lights turn The headlights and all lights...
Page 332 4-3. Operating the lights and wipers  Right-hand drive vehicles (type B) The front position, tail, license plate and instru- ment panel lights turn The headlights and all lights listed above turn LC200_OM_OM60R59W_(WE)
Page 333 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 334 4-3. Operating the lights and wipers Guide to dial settings ■ Occupancy and luggage load conditions Dial position Occupants Luggage load Driver only, or driver and one passenger in None the front seat Driver, front passenger and all passengers in None the rear seats farthest to the rear...
Page 335 4-3. Operating the lights and wipers : VDJ200R-GNTAZ, VDJ200R-GNMAZ, VDJ200L-GNTAZ and VDJ200L-GNMAZ models : GRJ200L-GNMAK The model code is indicated on the manufacturer’s label or Certifica- tion Regulation label. (P. 917) Daytime running light system (if equipped) ■ To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the engine is started and the parking brake is released.
Page 336 If the automatic headlight leveling system warning light flashes (if ■ equipped) It may indicate a malfunction in the system. Contact your Toyota dealer. Light reminder buzzer ■ A buzzer sounds when the engine switch is turned to ACCESSORY or OFF mode and the driver’s door is opened while the tail lights are turned on.
Page 337: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 338 ● Do not modify the vehicle. Do not replace windshield with a non-genuine windshield. ● Contact your Toyota dealer.  Vehicles with PCS (Pre-Crash Safety system): P. 371 Activating the Automatic High Beam system...
Page 339 4-3. Operating the lights and wipers Press the Automatic High Beam switch. The Automatic High Beam indica- tor will come on when the head- lights are turned on automatically to indicate that the system is active. Turning the high beam on/off manually Switching to low beam ■...
Page 340 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 40 km/h (25 mph). •...
Page 341 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. If a warning message of the Automatic High Beam is displayed... ■ It may indicate a malfunction in the system. Contact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 342: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Front fog light switch ■ Left-hand drive vehicles (type A)  Front fog lights on ...
Page 343 4-3. Operating the lights and wipers  Left-hand drive vehicles (type B) Front fog lights on  Right-hand drive vehicles (type A) Front fog lights on LC200_OM_OM60R59W_(WE)
Page 344 4-3. Operating the lights and wipers  Right-hand drive vehicles (type B) Front fog lights on LC200_OM_OM60R59W_(WE)
Page 345 4-3. Operating the lights and wipers Front and rear fog light switch ■ Left-hand drive vehicles (type A)  Front fog lights on Front and rear fog lights Releasing switch ring returns it to Operating the switch ring again turns only the rear fog lights off. Left-hand drive vehicles (type B) ...
Page 346 4-3. Operating the lights and wipers  Right-hand drive vehicles Front fog lights on Front and rear fog lights Releasing switch ring returns it to Operating the switch ring again turns only the rear fog lights off. Rear fog light switch ■...
Page 347 4-3. Operating the lights and wipers  Left-hand drive vehicles (type B) Rear fog lights on Fog lights can be used when ■  Vehicles with front and rear fog lights Front fog lights: The headlights or front position lights are turned on. Rear fog lights: The front fog lights are turned on.
Page 348: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows. Intermittent windshield wipers without interval adjuster ■ Left-hand drive vehicles (type A)  Intermittent operation Low speed operation High speed operation Temporary operation Washer/wiper...
Page 349 4-3. Operating the lights and wipers  Left-hand drive vehicles (type B) Intermittent operation Low speed operation High speed operation Temporary operation Washer/wiper dual operation Pulling the lever operates the wipers and washer. LC200_OM_OM60R59W_(WE)
Page 350 4-3. Operating the lights and wipers  Right-hand drive vehicles (type A) Intermittent operation Low speed operation High speed operation Temporary operation Washer/wiper dual operation Pulling the lever operates the wipers and washer. LC200_OM_OM60R59W_(WE)
Page 351 4-3. Operating the lights and wipers  Right-hand drive vehicles (type B) Intermittent operation Low speed operation High speed operation Temporary operation Washer/wiper dual operation Pulling the lever operates the wipers and washer. LC200_OM_OM60R59W_(WE)
Page 352 4-3. Operating the lights and wipers Intermittent windshield wipers with interval adjuster ■ Left-hand drive vehicles  Intermittent operation Low speed operation High speed operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected. Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper...
Page 353 4-3. Operating the lights and wipers  Right-hand drive vehicles Intermittent operation Low speed operation High speed operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected. Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual operation...
Page 354 4-3. Operating the lights and wipers Rain-sensing windshield wipers ■ Left-hand drive vehicles  Rain-sensing opera- tion (“AUTO”) Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain.
Page 355 4-3. Operating the lights and wipers  Right-hand drive vehicles Rain-sensing opera- tion (“AUTO”) Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accor- dance with rain volume and vehicle speed.
Page 356 4-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 357 4-3. Operating the lights and wipers WARNING Caution regarding the use of windshield wipers in “AUTO” mode (vehi- ■ cles with rain-sensing windshield wipers) The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO” mode. Take care that your fingers or anything else does not become caught in the windshield wipers.
Page 358: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Without intermittent type ■  Left-hand drive vehicles Operating the switch operates the rear window wiper or washer as follows: Normal operation Washer/wiper dual operation Washer operation LC200_OM_OM60R59W_(WE)
Page 359 4-3. Operating the lights and wipers  Right-hand drive vehicles Operating the “REAR” switch operates the rear window wiper or washer as follows: Normal operation Washer/wiper dual operation Washer operation LC200_OM_OM60R59W_(WE)
Page 360 4-3. Operating the lights and wipers With intermittent type ■ Left-hand drive vehicles (type A)  Operating the switch operates the rear window wiper as fol- lows: Intermittent operation Normal operation Washer/wiper dual operation Pushing the lever operates the wiper and washer. LC200_OM_OM60R59W_(WE)
Page 361 4-3. Operating the lights and wipers  Left-hand drive vehicles (type B) Operating the switch operates the rear window wiper or washer as follows: Intermittent operation Normal operation Washer/wiper dual operation Washer/wiper dual operation LC200_OM_OM60R59W_(WE)
Page 362 4-3. Operating the lights and wipers  Right-hand drive vehicles (type A) Operating the switch operates the rear window wiper as fol- lows: Intermittent operation Normal operation Washer/wiper dual operation Pushing the lever operates the wiper and washer. LC200_OM_OM60R59W_(WE)
Page 363 4-3. Operating the lights and wipers  Right-hand drive vehicles (type B) Operating the “REAR” switch operates the rear window wiper or washer as follows: Intermittent operation Normal operation Washer/wiper dual operation Washer/wiper dual operation The rear window wiper and washer can be operated when ■...
Page 364: Headlight Cleaner Switch
4-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaners can be operated when ■ The engine switch is in IGNITION ON mode and the headlight switch is turned on.
Page 365: Tank Cap
● Confirm the type of fuel. ■ Fuel types P. 947 Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. LC200_OM_OM60R59W_(WE)
Page 366 4-4. Refueling WARNING When refueling the vehicle ■ Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. After exiting the vehicle and before opening the fuel door, touch an ● unpainted metal surface to discharge any static electricity.
Page 367: Refueling
4-4. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. Opening the fuel tank cap Pull the lever.
Page 368 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 369: Using The Driving Support
■ Toyota Safety Sense The Toyota Safety Sense is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 370 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 371 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor LC200_OM_OM60R59W_(WE)
Page 372 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. Do not disassemble the radar sensor.
Page 373 ● ● Replace the windshield if it is damaged or cracked. If the windshield needs to be replaced, contact your Toyota dealer. Do not get the camera sensor wet. ● Do not allow bright lights to shine into the camera sensor.
Page 374 Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. If a surfboard or other long object is to be mounted on the roof, make sure ●...
Page 375: Pcs (Pre-Crash Safety System)
The countries and areas for each region listed in the table are cur- rent as of August 2019. However, depending on when the vehicle was sold, the countries and areas of each region may be different. Contact your Toyota dealer for details.  : If equipped...
Page 376 4-5. Using the driving support systems ◆ Pre-crash warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 377 4-5. Using the driving support systems WARNING Limitations of the pre-crash safety system ■ ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-crash safety system instead of normal braking opera- tions under any circumstances.
Page 378 4-5. Using the driving support systems WARNING When to disable the pre-crash safety system ■ In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: When the vehicle is being towed ●...
Page 379 4-5. Using the driving support systems Changing settings of the pre-crash safety system Disabling the pre-crash safety system ■ Press the PCS switch for 3 sec- onds or more. The PCS warning light will turn on and a message will be displayed on the multi-information display.
Page 380 4-5. Using the driving support systems ■ Operational conditions Availability of the pedestrian detection function depends on the region in which the vehicle was sold. (For specific countries/areas: P. 373) Read the following for details:  Region A (The pedestrian detection function is available) The pre-crash safety system is enabled and the system determines that the possibility of a frontal collision with a vehicle or pedestrian is high.
Page 381 4-5. Using the driving support systems  Region B (The pedestrian detection function is not available) The pre-crash safety system is enabled and the system determines that the possibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: Pre-crash warning: ●...
Page 382 4-5. Using the driving support systems ■ Cancelation of the pre-crash braking If either of the following occur while the pre-crash braking function is operat- ing, it will be canceled: The accelerator pedal is depressed strongly. ● ● The steering wheel is turned sharply or abruptly. Conditions under which the system may operate even if there is no pos- ■...
Page 383 4-5. Using the driving support systems • When there is a vehicle, pedes- trian , or object by the roadside at the entrance of a curve • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge •...
Page 384 4-5. Using the driving support systems • When driving through under objects that may contact the vehicle, such as thick grass, tree branches, or a banner • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead •...
Page 385 4-5. Using the driving support systems • If a vehicle ahead is irregularly shaped, such as a tractor or side car • If the sun or other light is shining directly on a vehicle ahead • If a vehicle cuts in front of your vehicle or emerges from beside a vehicle •...
Page 386 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 387 ● warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled If VSC is disabled (P. 550), the pre-crash brake assist and pre-crash brak- ●...
Page 388: Lda (Lane Departure Alert)
4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of functions When driving on roads with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visi- ble white (yellow) lines with the camera sensor on the upper por- tion of the front windshield.
Page 389 4-5. Using the driving support systems ◆ Vehicle sway warning function When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 390 Toyota dealer. Do not install or place anything on the hood or grille. Also, do not install a ● grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 391 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates. Press the LDA switch again to turn the LDA system off. When the LDA system is turned on or off, operation of the LDA system continues in the same condition the next time the engine is started.
Page 392 4-5. Using the driving support systems Indications on multi-information display Lane departure alert function dis- play Displayed when the multi-informa- tion display is switched to the driv- assist system information screen.  Inside of displayed white lines  Inside of displayed white lines is white is black Indicates that the system is recog-...
Page 393 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 50 km/h (32 mph) or more. •...
Page 394 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. There are shadows on the road that run parallel with, or cover, the white ●...
Page 395 The system may not be operating Alert properly.  Have the vehicle inspected at your Malfunction Visit Your Dealer” Toyota dealer. Dirt, rain, condensation, ice, snow, etc. are present on the windshield in “Forward Camera front of the camera sensor. System ...
Page 396 4-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert function Adjust alert sensitivity Turn function on and off Vehicle sway warning function Adjust alert sensitivity For how to change settings, refer to P. 950. LC200_OM_OM60R59W_(WE)
Page 397: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 398 4-5. Using the driving support systems WARNING Before using dynamic radar cruise control ■ ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 399 4-5. Using the driving support systems WARNING Cautions regarding the driving assist systems ■ Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. Assisting the driver to measure following distance ●...
Page 400 4-5. Using the driving support systems WARNING Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 401 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 402 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 403 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 404 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 405 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 406 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 407 The center differential lock/unlock is not completed within 5 seconds while the cruise control system is on. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■...
Page 408 4-5. Using the driving support systems ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard. This does not indicate a malfunction. ■...
Page 409 4-5. Using the driving support systems ● Preceding vehicle has an extremely high ground clearance ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary.
Page 410: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 411 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 412 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 413 4-5. Using the driving support systems WARNING To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 414: Driving Mode Select Switches
4-5. Using the driving support systems  Driving mode select switches The driving modes can be selected to suit driving condition. Normal mode For normal driving. Press the “NORM” switch to change the driving mode to normal mode when not in normal mode. Comfort mode By controlling the suspension, riding comfort is further enhanced.
Page 415 4-5. Using the driving support systems Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. When in comfort mode and the “COMF ECO” switch is pressed, the “ECO” indicator comes on in the multi-information display. Sport mode •...
Page 416: Toyota Parking Assist-Sensor
Types of sensors Front corner sensors Rear corner sensors Rear center sensors Toyota parking assist-sensor switch On/off To turn the system on, press the switch. The indicator light comes on and the buzzer sounds to inform the driver that the system is opera- tional.
Page 417 Rear center sensor operation  Multimedia system or navigation system screen (if equipped) Toyota parking assist-sensor display When the rear view monitor sys- , Toyota parking assist moni- or Multi-terrain Monitor is not displayed. A graphic is automatically dis- played...
Page 418 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Multi-infor- Navigation Insert dis- mation dis- system Rear center sen- play Corner sensor play screen 150 cm (4.9 ft.)
Page 419 4-5. Using the driving support systems Buzzer operation and distance to an obstacle ■ A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
Page 420 You can change the buzzer sound volume and the screen operating conditions. Press the “SETUP” button on the multimedia system or navigation system. Select “Vehicle” on the “Setup” screen and select “TOYOTA Park Assist Settings”. Select the desired item. The buzzer sound volume can be adjusted.
Page 421 ■ Toyota parking assist-sensor display When an obstacle is detected while the Toyota parking assist monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the upper corner of the screen even if the display setting has been set to off.
Page 422 When the system malfunctions (vehicles with a multimedia system or ■ navigation system) ● displays on the screen, have the vehicle inspected by your Toyota dealer. displays on the screen, clean the sensors with soft cloth. ● ■...
Page 423 In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● A beep does not sound when you turn the Toyota parking assist-sensor ● If the area around a sensor collides with something, or is subjected to strong impact.
Page 424: Rear View Monitor System
4-5. Using the driving support systems  Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 425 The line shows distance behind the vehicle, a point approximately 1 m (3 ft.) from the edge of the bumper. Toyota parking assist-sensor display (if equipped) If an obstacle is detected while the Toyota parking assist-sensor is on, a display is shown at the top right corner of the screen. LC200_OM_OM60R59W_(WE)
Page 426 4-5. Using the driving support systems Rear view monitor system precautions Area displayed on screen ■ The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga- tion system Owner’s manual”,...
Page 427 4-5. Using the driving support systems Rear view monitor system camera ■ ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the cam- era, it cannot transmit a clear image. In this case, flush it with a large quantity of water and wipe the camera lens clean with a soft and wet...
Page 428 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 429 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixation guide lines on the screen and the actual dis- A margin of error...
Page 430 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 431 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 432  The fixed guide lines are very far out of alignment The camera position is out of align- Have the vehicle inspected by your ment. Toyota dealer. • The vehicle is tilted (there is a If this happens due to these causes, heavy load on the vehicle, tire it does not indicate a malfunction.
Page 433 4-5. Using the driving support systems WARNING When using the rear view monitor system ■ The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 434 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC200_OM_OM60R59W_(WE)
Page 435: Toyota Parking Assist Monitor
4-5. Using the driving support systems  Toyota parking assist monitor The parking assist monitor assists the driver by displaying an image of the view behind the vehicle while backing up, for exam- ple while parking. The parking assist monitor assists with the following 2 backing-up operations: •...
Page 436 Display mode switch screen button Switches the display mode. (P. 435) Toyota parking assist-sensor display If an obstacle is detected while the Toyota parking assist-sensor is on, a display is shown in the top right corner of the screen. Parking mode switch screen button...
Page 437 4-5. Using the driving support systems Using the system when perpendicular parking ■ Use any of the following modes when perpendicular parking (for example, when parking in a garage). Each time you select the dis- play mode switch screen but- ton, the display mode switches in the following order: Estimated course...
Page 438 4-5. Using the driving support systems ● Estimated course line display mode (P. 438) Estimated course lines are displayed which move in accordance with the opera- tion of the steering wheel. ● Parking assist guide line display mode (P. 440) The steering wheel return points (parking assist guide lines) are displayed.
Page 439 4-5. Using the driving support systems Using the system when parallel parking ■ Screen display beep sounds provide an estimation of the point at which you should turn the steering wheel when parallel parking. If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used.
Page 440 4-5. Using the driving support systems Perpendicular parking (estimated course line display mode) Screen description ■ Vehicle width extension guide line The line indicates a guide path when the vehicle is being backed straight up. The displayed width is wider than the actual vehicle width. The line aligns with the estimated course lines when the steering wheel is straight.
Page 441 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Turn the steering wheel so that the estimated course lines are within the parking...
Page 442 4-5. Using the driving support systems Once the vehicle width extension guide lines and the parking space lines are parallel, straighten the steering wheel and back up slowly until the vehicle has completely entered the parking space. Stop the vehicle in an appropriate place, and finish parking. Perpendicular parking (parking assist guide line display mode) Screen description ■...
Page 443 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Back up until the parking assist guide line meets the edge of the left-hand divid-...
Page 444 4-5. Using the driving support systems Parallel parking Vehicle movement procedure ■ Approx. 1 m (3 ft.) Keeping parallel with the road, stop the vehicle leaving a gap of approximately 1 m (3 ft.) between your vehicle and the parked vehicle (Step in “Parking operation”).
Page 445 4-5. Using the driving support systems Parking operation ■ The following example describes the procedure for pulling into a parking space on the right. For pulling into a parking space on the left, substitute left for right and vice versa in all steps. Stop the vehicle in the position as described below, and straighten the steering wheel.
Page 446 4-5. Using the driving support systems With the steering wheel straight, back up slowly to a position at which the black and yellow vertical pole just overlaps the rear end of the parked vehicle. Then stop the vehicle. Black and yellow vertical pole Back the vehicle up to here...
Page 447 4-5. Using the driving support systems Turn the steering wheel with the vehicle stopped until the blue outline meets the desired parking space. Blue outline Black and yellow vertical pole Extended line If the extended line from the blue outline is displayed, the parallel parking assist is oper- ational.
Page 448 4-5. Using the driving support systems A curved blue line will appear on the screen. Keep the steering wheel in its current position and back up slowly. Stop when the curved blue line meets the corner of the desired parking space. Curved blue line Back up keeping the steer- ing wheel in its current...
Page 449 If Toyota parking assist-sensor detects an object while you attempt to park in a parking space on the left, the black and yel- low vertical pole could be obscured by Toyota parking assist-sen- sor display. In this event, turn Toyota parking assist-sensor switch off (P.
Page 450 4-5. Using the driving support systems Narrow mode ■ If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used. Normal mode Narrow mode The engine switch is turned off when the parking assist monitor is canceled with narrow mode, the caution screen is displayed first when the parallel parking...
Page 451 4-5. Using the driving support systems ● Operating narrow mode Select while in parallel parking assist mode. Confirm the warning on the caution screen. If you agree, select “I Agree”. To cancel narrow mode, select When the system is switched to narrow mode, the indicator on will be turned on.
Page 452 4-5. Using the driving support systems Toyota parking assist monitor precautions Area displayed on screen ■ The parking assist monitor dis- plays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga-...
Page 453 4-5. Using the driving support systems Toyota parking assist monitor camera ■ ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the cam- era, it cannot transmit a clear image. In this case, flush it...
Page 454 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 455 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the guide lines on the screen and the actual distance/course on A margin of error...
Page 456 4-5. Using the driving support systems ● Distance guidelines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 457 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 458  The guide lines are very far out of alignment The camera position is out of align- Have the vehicle inspected by your ment. Toyota dealer. • The vehicle is tilted (there is a If this happens due to these causes, heavy load on the vehicle, tire it does not indicate a malfunction.
Page 459 4-5. Using the driving support systems WARNING When using the Toyota parking assist monitor system ■ The parking assist monitor is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 460 Estimated course line display mode: If the steering wheel is straight and the vehicle width extension guide lines and the estimated course lines are not in alignment, have the vehicle inspected by your Toyota dealer. When using the parallel parking assist screen ■...
Page 461 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC200_OM_OM60R59W_(WE)
Page 462: 4-Wheel Ahc (Active Height Control Suspension)
4-5. Using the driving support systems 4-Wheel AHC (Active Height Control  Suspension) The 4-Wheel AHC adjusts the vehicle height in accordance with driving conditions. There are 3 selectable modes, “HI” (high), “N” (normal), and “LO” (low). Height select switch/Height control OFF switch “”...
Page 463 4-5. Using the driving support systems Vehicle height modes Press “” to step up one height mode, and “” to step down one height mode. (Ex. When in the low height mode, press “” once to switch to the normal height mode, and twice to switch to the high height mode.) “HI”...
Page 464 4-5. Using the driving support systems Conditions for changing the vehicle height mode Some modes may not be selectable depending on the vehicle speed when the four-wheel drive control switch is in the “H4” position. Refer to the following table. Low mode Normal mode High mode...
Page 465 4-5. Using the driving support systems ■ Automatic change in vehicle height when the four-wheel drive control switch is in the L4 position If the vehicle speed exceeds 3 km/h (2 mph) while driving on an uneven road with the four-wheel drive control switch in the L4 position, high mode is auto- matically selected.
Page 466 4-5. Using the driving support systems ■ Automatic leveling function The vehicle is adjusted to a fixed height for each mode, regardless of the number of occupants and the luggage load. However the vehicle cannot be raised if the vehicle load exceeds the follow- ●...
Page 467 4-Wheel AHC cannot be activated until the malfunction is corrected. Stop the engine and start it again. If the warning message turns off, the sys- tem is operating correctly. If the warning message continues to be displayed, have the vehicle checked at Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 468 4-5. Using the driving support systems WARNING When switching the vehicle height mode ■ Before lowering the vehicle height, check that there are no people under or around the vehicle, and check for obstacles. If you do not do this, body parts may be caught in the vehicle, possibly lead- ing to an accident.
Page 469 4-5. Using the driving support systems NOTICE When parking in areas with limited overhead height ■ After leaving the vehicle or unloading the luggage, the vehicle height may be slightly higher than normal. Take care when overhead height is limited. To avoid damage to the vehicle ■...
Page 470: Four-Wheel Drive System
4-5. Using the driving support systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/unlock switch (if equipped) to select the following transfer and center differential modes. Four-wheel drive control switch Type A Type B  ...
Page 471 4-5. Using the driving support systems Center differential lock/unlock switch (if equipped)  Type A  Type B Lock the center differential when your vehicle’s wheels get stuck in a ditch or when driving on a slippery or bumpy surface. The center differential lock indicator and indicator in the differential lock/ unlock display will come on.
Page 472 4-5. Using the driving support systems Shifting from L4 to H4 ■ Stop the vehicle completely. Automatic transmission: Shift the shift lever to N. Manual transmission: Depress and hold the clutch pedal. Turn the four-wheel drive control switch counterclockwise. Maintain this condition until the low speed four-wheel drive indicator turns off.
Page 473 In this case, you may not be able to shift between H4 and L4, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60R59W_(WE)
Page 474 4-5. Using the driving support systems WARNING While driving ■ Never move the four-wheel drive control switch if the wheels have lost trac- tion. Doing so may cause an accident resulting in death or serious injury. When the vehicle is parked ■...
Page 475: Rear Differential Lock System
4-5. Using the driving support systems  Rear differential lock system Use the rear differential lock system only when wheel spinning occurs in a ditch or on a slippery or ragged surface. This system is effective in case one of the rear wheels is spinning. Rear differential lock switch Lock Push and turn the switch clockwise...
Page 476 4-5. Using the driving support systems ■ For easy locking (vehicles with manual transmission) Depress the clutch pedal, turn the lock switch and slowly release the clutch pedal. For easy unlocking ■ Slightly turn the steering wheel in either direction while the vehicle is in motion.
Page 477: Crawl Control (With Turn Assist Function)
4-5. Using the driving support systems  Crawl Control (with Turn Assist function) Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Mini- mizes loss of traction or vehicle slip when driving on slippery road surfaces, allowing for stable driving.
Page 478 4-5. Using the driving support systems Mode Road condition Rock, mogul (downhill) and gravel (downhill) Lo-Med Mogul (uphill) Snow, mud, gravel (uphill), sand, dirt, mogul (uphill) Med-Hi and grass Turn Assist function This function assists cornering performance in accordance with steer- ing operation when driving through a tight corner.
Page 479 4-5. Using the driving support systems  Turn Assist function Press the Turn Assist switch while the Turn Assist function is operat- ing. When the switch is pressed, the Turn Assist indicator will go off, and a message stating that the Turn Assist function has been turned off will be displayed on the multi-information display for several sec- onds.
Page 480 4-5. Using the driving support systems ■ Function limitations  Crawl Control In the following situations, brake control can be used to drive downhill at a ● constant speed. However, engine control is not available when driving uphill at a constant speed. •...
Page 481 4-5. Using the driving support systems WARNING When using Crawl Control and Turn Assist function ■ Do not rely solely on the Crawl Control and Turn Assist function. This func- tion does not extend the vehicle’s performance limitations. Always thor- oughly check the road conditions, and drive safely.
Page 482: Multi-Terrain Select
4-5. Using the driving support systems  Multi-terrain Select Multi-terrain Select is a system that improves drivability in off- road situations. When the Crawl Control is turned off  Select a mode that most closely matches the type of terrain on which you are driving from among 5 modes.
Page 483 4-5. Using the driving support systems Selectable modes When the Crawl Control is turned off, a mode which matches the road conditions can be selected from among the following 5 modes. MUD & SAND LOOSE ROCK MOGUL ROCK & DIRT ROCK When the Crawl Control is turned on, the most suitable mode is auto- matically selected according to the Crawl Control mode selected.
Page 484 After a short time, the “TRC OFF” indicator display will go off, and you will be able to use Multi-terrain Select. ■ When there is a malfunction in the system The slip indicator light will come on. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60R59W_(WE)
Page 485 4-5. Using the driving support systems WARNING When using the Multi-terrain Select ■ Observe the following precautions to avoid an accident that could result in death or serious injuries: There is a chance that the selected mode may not be the most appropriate ●...
Page 486: Multi-Terrain Monitor
4-5. Using the driving support systems  Multi-terrain Monitor The Multi-terrain Monitor helps the driver to check the vehicle surroundings. It assists in determining the conditions around the driver in a variety of situations, such as when judging condi- tions during off-road driving or checking for obstacles when parking.
Page 487 4-5. Using the driving support systems Screens when the four-wheel drive control switch is in L4 ■ ● When checking the area to the front and sides of the vehicle  Front view & dual side view  Front view & dual side view (front magnified) P.
Page 488 4-5. Using the driving support systems ● When checking the area to the rear of the vehicle Rear view & dual side view Wide rear view   P. 499 P. 499 Screens when the four-wheel drive control switch is in H4 ■...
Page 489 4-5. Using the driving support systems ● When checking the area to the rear of the vehicle Panoramic view & rear view Wide rear view   P. 506 P. 506 ● When checking the area to the sides, front and rear of the vehicle (with outside rear view mirrors retracted) ...
Page 490 4-5. Using the driving support systems Using the Multi-terrain Monitor screen Displaying the Multi-terrain Monitor screen ■ The Multi-terrain Monitor screen will be displayed when the camera switch is pressed while the engine switch is in IGNITION ON mode. When the vehicle speed exceeds a certain value for a specific amount of time, the display returns to the navigation or information display screen.
Page 491 4-5. Using the driving support systems Switch operations ■ On some screens, the display mode or display settings can be changed using the switches. ● Automatic display mode switch When automatic display mode is turned on, the Multi-terrain Monitor screen is displayed in the following conditions, even if the camera switch has not been operated.
Page 492 4-5. Using the driving support systems Changing the Multi-terrain Monitor screen The screen display can be switched by operating the switches as fol- lows while the Multi-terrain Monitor screen is displayed. (Screens that can be displayed will vary depending on the positions of the shift lever and four-wheel drive control switch) Screens when the four-wheel drive control switch is in L4 ■...
Page 493 4-5. Using the driving support systems Front view & dual side view Under vehicle terrain view & (front magnified): P. 493 dual side view: P. 497 Under vehicle terrain view & Rear view & dual side view: P. 499 dual side view (front magnified): P.
Page 494 4-5. Using the driving support systems Screens when the four-wheel drive control switch is in H4 ■ : Press : Select : Operate the shift lever Navigation screen, information Panoramic view & rear view: P. 506 settings screen, etc. Side views: P. 503 Wide rear view: P.
Page 495 4-5. Using the driving support systems ■ Multi-terrain Monitor screen display The amount of time that the Multi-terrain Monitor screen is displayed changes as follows according to the vehicle speed at the time the camera switch was pressed. The Multi-terrain Monitor screen is displayed if the vehicle speed is approxi- mately 20 km/h (12 mph) or less when the camera switch is pressed.
Page 496 4-5. Using the driving support systems ● Screen description Under vehicle terrain view 2 m (6 ft.) distance guide line selection switch (blue) Switches between front view and Items indicate the esti- under vehicle terrain view display mated distance from the front end each time the switch is selected.
Page 497 4-5. Using the driving support systems ● Front view rotating display function (vehicles with VSC) This function operates when the four-wheel drive control switch is in L4. The front view image is automatically adjusted to be parallel and assist the driver to check road surface conditions regardless of the vehicle inclination.
Page 498 Tilt meter/slip display ■ When the Toyota parking assist-sensor or RCTA detects an obstacle or another vehicle, a warning message pops up in the tilt meter/slip display area. LC200_OM_OM60R59W_(WE)
Page 499 4-5. Using the driving support systems Under vehicle terrain view & dual side view ■ Lines indicating current vehicle and tire position are displayed in a composite view on an image taken approximately 3 m (10 ft.) behind the current vehicle position and assists the driver to check conditions underneath the vehicle or determine the position of the front tires.
Page 500 4-5. Using the driving support systems ■ Under vehicle terrain view & dual side view ● The screen can be displayed when the shift lever is in D or N. ● While the under vehicle terrain view is displayed, if the vehicle speed reaches or exceeds approximately 5 km/h (3 mph), the screen automatically returns to the front view display.
Page 501 4-5. Using the driving support systems Rear view & dual side view/wide rear view ■ Guide lines are displayed in a composite view on an image of the area to the rear of the vehicle to use as a reference when deciding a course of movement and assist the driver to check the safety of the area to the rear of the vehicle or to park the vehicle.
Page 502 If the back door is not closed, guide lines will not be displayed. If the guide lines do not display even when the back door is closed, have the vehicle inspected at your Toyota dealer. Toyota parking assist-sensor pop-up display ■...
Page 503 4-5. Using the driving support systems Panoramic view & wide front view ■ The image looking down at the vehicle from above and the image from the front camera are displayed simultaneously and assist the driver to check conditions in front, and to the right and left, of the vehicle at intersections or T-junctions with poor visibility.
Page 504 Switch display ■ Panoramic view & wide front view The screen can be displayed when the shift lever is in P, D or N. Toyota parking assist-sensor pop-up display ■ P. 414 WARNING ■ Guide lines...
Page 505 Indicates the estimated front tire position on the image. Automatic display mode selection switch P. 489 Toyota parking assist-sensor When the Toyota parking assist-sensor is on, an icon will pop up when an obstacle is detected. (Refer to P. 414 for information about the Toyota parking assist-sensor.) LC200_OM_OM60R59W_(WE)
Page 506 4-5. Using the driving support systems ● Using the vehicle width lines The relative distance of obstacles from the vehicle width lines can be confirmed. Example 1: When there is an obstacle in front of the vehicle Operate the steering wheel so that the vehicle width line and the obstacle do not overlap.
Page 507 The screen can be displayed when the shift lever is in P, D or N. ● When the outside rear view mirrors are retracted, the displayed area changes (the area on the screen that is not masked in black). (P. 510) ■ Toyota parking assist-sensor pop-up display P. 414 WARNING Guide lines ■...
Page 508 Switches the screen to the panoramic & rear view display when you touch the display. Toyota parking assist-sensor When the Toyota parking assist-sensor is turned on, an icon will pop up when an obstacle is detected. (Refer to P. 414 for information about the Toyota parking assist-sensor.)
Page 509 4-5. Using the driving support systems ● Switching modes The display mode switches and the icon display changes each time the guide line display selection switch is selected. Parking assist Projected course Distance guide Selected mode guide line display line display mode line display mode mode Icon display...
Page 510 4-5. Using the driving support systems Distance guide line display  mode Front distance guide line (blue) Indicates a distance approximately 1 m (3 ft.) from the front end of the vehicle. Rear vehicle width extension guide lines Indicate the estimated course of the vehicle when backing up straight. •...
Page 511 4-5. Using the driving support systems Toyota parking assist-sensor When the Toyota parking assist-sensor is on, an icon will be displayed when an obstacle is detected. (Refer to P. 414 for information about the Toyota parking assist-sensor.) Vehicle center line (blue) Indicates the estimated vehicle center on the ground.
Page 512 4-5. Using the driving support systems Display when the outside rear view mirrors are retracted (side ■ view and side views) When the outside rear view mirrors are retracted, one of the follow- ing screens is displayed and assists the driver to confirm the safety of the area around the vehicle, or park alongside and close to another object.
Page 513 4-5. Using the driving support systems For information about other than the side view and side views display area, refer to the page for the respective screen. Front distance guide line (red) Indicates a distance approximately 0.5 m (1.5 ft.) from the front end of the vehicle.
Page 514 • After confirming the distance to the shoulder, maneuvering the vehicle so that the vehicle width line and the curb or other obstacle are parallel allows the vehicle to be parked evenly. Toyota parking assist-sensor pop-up display ■ P. 414 WARNING ■...
Page 515 & dual side view or rear view & dual side view ■ Toyota parking assist-sensor pop-up display While the Toyota parking assist-sensor is in use, a pop-up is displayed when an obstacle is detected (P. 414). However, this function only informs the driver that an obstacle is close to the vehicle and the detected obstacle is not displayed on the screen.
Page 516 4-5. Using the driving support systems When using the Multi-terrain Monitor Observe the following precautions. Failure to do so may result in an unexpected accident. Also, when driving, make sure to directly con- firm the safety of your surroundings and the area to the rear of the vehicle.
Page 517 4-5. Using the driving support systems NOTICE Panoramic view ■ ● In the panoramic view, the system combines images taken from the front, back, left and right side cameras into a single image. There are limits to the range and content that can be displayed. Understand the characteris- tics of this system before using.
Page 518 4-5. Using the driving support systems Display range ■ ● Panoramic view Not displayed. Not displayed. (Displayed in black around the vehicle icon.) ● Wide front view Masking Parts of the vehicle (such as the bumper or grille) are displayed on the screen.
Page 519 4-5. Using the driving support systems ● Side views The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera ● Side view The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera LC200_OM_OM60R59W_(WE)
Page 520 4-5. Using the driving support systems ● Rear view The corners of the bumper are not seen on the screen. ● Wide rear view The corners of the bumper are not seen on the screen. LC200_OM_OM60R59W_(WE)
Page 521 4-5. Using the driving support systems ■ Panoramic view display range ● In the panoramic view, the system processes and displays images acquired form the 4 cameras under the assumption that the vehicle is on a flat road surface. Therefore, the display may appear as follows. •...
Page 522 4-5. Using the driving support systems Multi-terrain Monitor cameras ■ ● Camera positions The cameras of the Multi-terrain Monitor system are installed as follows. Side camera (left and right sides) Front camera Rear camera ● Using the cameras If dirt or foreign matter (such as water droplets, snow, mud, etc.) is adhering to the camera, it cannot transmit a clear image.
Page 523 If the camera is accidentally subjected to an impact, have the vehicle inspected at your Toyota dealer. • Do not remove, disassemble or modify the camera or surrounding parts Doing so may result in the camera malfunctioning. This also may result in a loss of waterproof performance.
Page 524 4-5. Using the driving support systems Differences between the panoramic view screen and the actual ■ road The distance guide lines, the combined panoramic view image, guide lines, etc., indicate estimated distances on a flat road sur- face. In the following situations, actual distances and vehicle course will differ from the guide lines on the screen.
Page 525 4-5. Using the driving support systems ● When the ground behind the vehicle slopes down sharply The distance guide lines are displayed further away than the actual distance. Therefore, obstacles on a downward slope appear closer than the actually are. In the same way, the actual course of the vehicle will differ from the course indicated by the guide lines.
Page 526 WARNING ■ Toyota parking assist-sensor pop-up display When the Toyota parking assist-sensor pop-up display is red, park the vehi- cle and make sure to confirm the safety of your surroundings. Failure to do so may lead to an unexpected accident.
Page 527 4-5. Using the driving support systems ● Projected course lines Projected course lines are displayed under the assumption that the vehicle is on a flat road surface. Therefore, the position of three-dimensional objects higher than the road surface (such as a vehicle bumper) cannot be determined.
Page 528 4-5. Using the driving support systems Differences between the rear view or wide rear view and actual ■ roads The guide lines on the screen are intended for flat surfaces (such as the road). Be aware of the following points when three-dimen- sional objects with protrusions (obstacles such as the cargo bed of a truck) are nearby.
Page 529 4-5. Using the driving support systems Differences between the panoramic view, rear view and wide ■ rear view and actual roads ● Distance guide lines Guide lines are displayed in reference to the road surface and cannot be used to determine the distance of three-dimensional objects from the vehicle.
Page 530 4-5. Using the driving support systems ■ Using under vehicle terrain view ● The images displayed were previously taken approximately 3 m (10 ft.) behind the current vehicle position. Therefore, actual conditions may differ from those shown on the screen in the following situations.
Page 531 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 532 There is a malfunction in the signals Have the vehicle inspected by your being output by the steering sensor Toyota dealer.  Guide lines are not displayed Close the back door. If this does not resolve the symptom,...
Page 533 • The camera can be damaged by flying rocks and other debris. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC200_OM_OM60R59W_(WE)
Page 534: Bsm (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The BSM (Blind Spot Monitor) function Assists the driver in making the decision when changing lanes ●...
Page 535 4-5. Using the driving support systems Multi-information display The BSM function/RCTA function can be turned on/off. (P. 533) The RCTA function is available when the BSM function is on. Outside rear view mirror indicator BSM function: When a vehicle is detected in a blind spot of the outside rear view mirrors or approaching rapidly from behind into a blind spot, the outside rear view mirror indicator on the detected side will illuminate.
Page 536 ■ When “Blind Spot Monitor System Malfunction” is shown on the multi- information display There may be a sensor malfunction or voltage abnormality. Have the vehicle inspected at your Toyota dealer. ■ Certification for the Blind Spot Monitor  For vehicles sold in South Africa ...
Page 537 4-5. Using the driving support systems  For vehicles sold in Bahrain  For vehicles sold in Qatar  For vehicles sold in Jordan  For vehicles sold in Lebanon  For vehicles sold in Indonesia  For vehicles sold in Vietnam LC200_OM_OM60R59W_(WE)
Page 538 4-5. Using the driving support systems  For vehicles sold in Philippines  For vehicles sold in El Salvador LC200_OM_OM60R59W_(WE)
Page 539 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. Do not modify the sensor or surrounding area on the bumper. ● ● Do not paint the rear bumper any color other than an official Toyota color. LC200_OM_OM60R59W_(WE)
Page 540: Bsm Function
4-5. Using the driving support systems BSM function The BSM function uses radar sensors to detect the following vehicles traveling in adjacent lanes and advises the driver of the presence of such vehicles via the indicators on the outside rear view mirrors. Vehicles that are traveling in areas that are not visible using the out- side rear view mirrors (the blind spots) Vehicles that are approaching rapidly from behind in areas that are...
Page 541 4-5. Using the driving support systems BSM function detection areas The areas that vehicles can be detected in are outlined below. The range of each detection area is: Approximately 0.5 m (1.6 ft.) to 3.5 m (11.5 ft.) from either side of the vehicle : The area between the side of the vehicle and 0.5 m (1.6 ft.) from the side of the vehicle cannot be detected.
Page 542 4-5. Using the driving support systems ■ The BSM function is operational when The BSM function is operational when all of the following conditions are met: ● The BSM function is on. ● The shift lever is in a position other than R. The vehicle speed is greater than approximately 16 km/h (10 mph).
Page 543 4-5. Using the driving support systems • When driving on roads with sharp bends, consecutive curves, or uneven surfaces • When vehicle lanes are wide, or when driving on the edge of a lane, and the vehicle in an adjacent lane is far away from your vehicle •...
Page 544: Rcta Function
4-5. Using the driving support systems RCTA function (if equipped) The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 545 4-5. Using the driving support systems RCTA icon display ■ When a vehicle approaching from the right or left at the rear of the vehicle is detected, the following will be displayed on the monitor screen Display Content A vehicle is approaching from the left at the rear of the vehicle A vehicle is approaching from the right at the rear of the vehicle...
Page 546 4-5. Using the driving support systems The RCTA function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 547 4-5. Using the driving support systems ■ Conditions under which the RCTA function will not detect a vehicle The RCTA function is not designed to detect the following types of vehicles and/or objects: Vehicles approaching from directly behind ● ● Vehicles backing up in a parking space next to your vehicle Vehicles that the sensors cannot detect ●...
Page 548 4-5. Using the driving support systems • When backing up on a slope with a sharp change in grade • When backing out of a shallow angle parking spot • Immediately after the RCTA function is turned on • Immediately after the engine is started with the RCTA function on •...
Page 549 4-5. Using the driving support systems ● Instances of the RCTA function unnecessarily detecting a vehicle and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
Page 550: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 551 4-5. Using the driving support systems ◆ Hill-start assist control (if equipped) Helps to reduce the backward movement of the vehicle when start- ing on an incline or slippery slope ◆ KDSS (Kinetic Dynamic Suspension System) (if equipped) KDSS enhances ride comfort and handling response by using a hydraulic control system to control the suspension stabilizer bars in response to road surface and driving conditions during cornering or off-road driving...
Page 552 4-5. Using the driving support systems When the VSC/Trailer Sway Control/Active TRC/hill-start assist control systems are operating The slip indicator light flashes to indicate that the VSC/Trailer Sway Control/Active TRC/hill-start assist control systems have been engaged. The stop lights and high mounted stoplight turn on when the hill-start assist control system or Trailer Sway Control is operating.
Page 553 4-5. Using the driving support systems ■ Turning off Active TRC, VSC and Trailer Sway Control To turn the TRC and VSC/Trailer Sway Control systems off, press and hold the switch for 3 seconds and more while the vehicle is stopped. The VSC OFF indicator and “TRC OFF”...
Page 554 4-5. Using the driving support systems ■ Sounds and vibrations caused by the Multi Terrain ABS, brake assist, Active TRC, VSC, Trailer Sway Control, hill-start assist control and VGRS A sound may be heard from the engine compartment when the engine is ●...
Page 555 4-5. Using the driving support systems WARNING Any of the following conditions may result in an accident which could cause death or serious injury: ■ The Multi Terrain ABS does not operate effectively when The limits of tire gripping performance have been exceeded (such as ●...
Page 556 The Multi Terrain ABS, Active TRC, VSC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 557 In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer immediately. When turning a corner, the vehicle’s body seems to roll further than nor- ●...
Page 558: 4-6. Driving Tips
4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle features ●...
Page 559 4-6. Driving tips WARNING Off-road vehicle precautions ■ Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die ●...
Page 560 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 561 4-6. Driving tips WARNING Off-road driving precautions ■ Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving ●...
Page 562 4-6. Driving tips NOTICE To prevent the water damage ■ Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. Water entering the engine air intake will cause severe engine damage. ●...
Page 563: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 564 *: The shift lever will be locked if it is attempted to be shifted from P to any other position without depressing the brake pedal. If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60R59W_(WE)
Page 565 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the snow chains. Chain size is regulated for each tire size. Side chain (5 mm [0.20 in.] in diameter) Cross chain (6.3 mm [0.25 in.] in diameter) Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road.
Page 566 Repairing or replacing snow tires (vehicles with the tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 567: Eco-Friendly Driving Tips
4-6. Driving tips Eco-friendly driving tips For improved fuel economy and reduced CO2 emissions, pay attention to the following points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 568 4-6. Driving tips ◆ Highway driving Control and maintain the vehicle at a constant speed. Before stop- ping at a toll booth or similar, allow plenty of time to release the accelerator pedal and gently apply the brakes. ◆ Air conditioning Use the air conditioning only when necessary.
Page 569 4-6. Driving tips ◆ Regular maintenance ● Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel economy. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel economy. Use tires that are appropriate for the season and road conditions.
Page 570 4-6. Driving tips LC200_OM_OM60R59W_(WE)
Page 571: Audio System
Audio system 5-1. Basic Operations 5-5. Using an external device Audio system types ...570 Listening to an iPod ...588 Steering wheel audio Listening USB memory switches......572 device ......596 AUX port/USB port ....573 Using the AUX port ....604 ® 5-2. Using the audio system 5-6.
Page 572: Basic Operations
5-1. Basic Operations  Audio system types  Vehicles with a navigation system or a multimedia system Refer to the “Navigation system Owner’s manual”, “Navigation and Multimedia System Owner’s Manual” or “Multimedia Owner’s Man- ual”.  Vehicles without a navigation system or multimedia system CD player with AM/FM radio ●...
Page 573 5-1. Basic Operations ● Type B These illustrations are for left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles. Using cellular phones ■ Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 574: Steering Wheel Audio Switches
5-1. Basic Operations  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 575: Aux Port/Usb Port
5-1. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Press the “MODE” button to select “iPod”, “USB” or “AUX”. Connecting using the AUX port/USB port iPod ■...
Page 576: 5-2. Using The Audio System
5-2. Using the audio system Optimal use of the audio system The sound quality, volume balance and ASL settings can be adjusted. Displays the “SETUP” menu/ Selecting the mode Changes the following settings • Sound quality and volume bal- ance P.
Page 577 5-2. Using the audio system Using the audio control function Changing sound quality modes ■ Press the tune/scroll knob. Turn the knob to select “Sound Setting”. Press the knob. Turn the knob as corresponds to the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” can be selected. Press the knob.
Page 578: 5-3. Using The Radio
5-3. Using the radio Radio operation Press the “MODE” button until “AM” or “FM” is displayed. Type A  AM/FM mode button Seeking the frequency Tune/scroll knob Power/volume knob Adjusting the frequency Press: Turning the audio sys- tem on or off Station selectors Turn: Adjusting the volume LC200_OM_OM60R59W_(WE)
Page 579 5-3. Using the radio  Type B AM/FM mode button Station selectors Tune/scroll knob Power/volume knob Press: AF/region code/TA Press: Turning the audio sys- mode setup tem on or off Turn: Adjusting the frequency Turn: Adjusting the volume Seeking the frequency Setting station presets Search for the desired stations by turning the tune/scroll knob or pressing the “<”...
Page 580 5-3. Using the radio ■ When the battery is disconnected Stations presets are erased. ■ Reception sensitivity ● Maintaining perfect radio reception at all times is difficult due to the continu- ally changing position of the antenna, differences in signal strength and sur- rounding objects, such as trains, transmitters, etc.
Page 581: Cd Player Operation
5-4. Playing an audio CD and MP3/WMA discs CD player operation Insert a disc, press the “MODE” button to begin listening to a Type A  Disc eject Displaying track/folder list Changing the audio source/ Displaying text message playback Selecting a track/file, fast-for- Tune/scroll knob warding or rewinding Selecting a track/file...
Page 582 5-4. Playing an audio CD and MP3/WMA discs  Type B Disc eject Selecting a folder (MP3/WMA discs only) Changing the audio source/ playback Displaying track/folder list Tune/scroll knob Displaying text message Selecting a track/file Power/volume knob Selecting a track/file, fast-for- Press: Turning the audio sys- warding or rewinding tem on or off...
Page 583 5-4. Playing an audio CD and MP3/WMA discs Using the CD player Selecting a track ■ Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to move up or down until the desired track number is dis- played.
Page 584 5-4. Playing an audio CD and MP3/WMA discs Playing back MP3 and WMA discs Selecting folders one at a time ■ Press the “<” or “>” button of “FOLDER” (type A) or (<FOLDER) or (FOLDER>) (type B) to select the desired folder.
Page 585 ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or •...
Page 586 5-4. Playing an audio CD and MP3/WMA discs ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
Page 587 5-4. Playing an audio CD and MP3/WMA discs ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 588 5-4. Playing an audio CD and MP3/WMA discs ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 589 5-4. Playing an audio CD and MP3/WMA discs NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs. Also, do not use 8 cm (3 in.) disc adapters, DualDiscs or printable discs. Doing so may damage the player and/or the disc insert/eject function. ●...
Page 590: Using An External Device
5-5. Using an external device Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “iPod” is displayed. Connecting an iPod P. 573 Control panel  Type A Changing the audio source/ Displaying song list playback Displaying text message...
Page 591 5-5. Using an external device  Type B Changing the audio source/ iPod menu mode, playback playback Displaying song list Tune/scroll knob Displaying text message Selecting an iPod menu/song Power/volume knob Selecting a song, fast-forward- Press: Turning the audio sys- ing or rewinding tem on or off Random play or back button...
Page 592 5-5. Using an external device Play mode list ■ First Second Third Fourth Play mode selection selection selection selection Playlists “Playlists” Songs select select Albums “Artists” Artists select Songs select select Albums “Albums” Songs select select “Songs” Songs select Podcasts Episodes “Podcasts”...
Page 593 5-5. Using an external device Selecting songs Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to select the desired song. Selecting a song from the song list Press (LIST). The song list will be displayed. Turn the tune/scroll knob to select a song.
Page 594 5-5. Using an external device ■ About iPod ● Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer to meet Apple performance standards.
Page 595 Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the iPod or its con- “ERROR”...
Page 596 5-5. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. Made for ● • iPhone 5 •...
Page 597 5-5. Using an external device WARNING While driving ■ Do not connect iPod or operate the controls. Doing so may cause an acci- dent, resulting in death or serious injury. NOTICE ■ To prevent damage to iPod or its terminal ●...
Page 598: Listening Usb Memory Device
5-5. Using an external device Listening USB memory device Connecting a USB memory enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “USB” is dis- played. Connecting a USB memory P. 573 Control panel Type A ...
Page 599 5-5. Using an external device  Type B Changing the audio source/ Selecting a folder playback Displaying folder list Tune/scroll knob Displaying text message Selecting a file Power/volume knob Selecting a song, fast-forward- Press: Turning the audio sys- ing or rewinding tem on or off Random play or back button Turn: Adjusting the volume...
Page 600 5-5. Using an external device Selecting a folder Selecting folders one at a time ■ Press the “<” or “>” button of “FOLDER” (type A) or (<FOLDER) or (FOLDER>) (type B) to select the desired folder. Selecting a folder and file from folder list ■...
Page 601 5-5. Using an external device Fast-forwarding and rewinding files Press and hold the “<” or “>” button of “SEEK TRACK”. Random play Pressing (RDM) changes modes in the following order: Folder randomAll folder randomOff Repeat play Pressing (RPT) changes modes in the following order: Off File repeatFolder repeat : Available except when RDM (random play) is selected...
Page 602 ■ If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the USB memory “ERROR”...
Page 603 5-5. Using an external device ● MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 604 5-5. Using an external device ● File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
Page 605 5-5. Using an external device ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
Page 606: Using The Aux Port
5-5. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Press the “MODE” button until “AUX” is displayed. Connecting a portable player P.
Page 607: Using Bluetooth Devices
® 5-6. Using Bluetooth devices  ® Bluetooth audio/phone ® The following can be performed using Bluetooth wireless com- munication: ® ◆ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication.
Page 608 ® 5-6. Using Bluetooth devices Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio system (P. 611) ® 2. Connect the registered Bluetooth device to be used (P. 612, 613) 3. Set automatic connection of the device (P.
Page 609 ® 5-6. Using Bluetooth devices Audio unit Power/volume knob Press: Turning the audio sys- tem on or off Turn: Adjusting the volume ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc.
Page 610 ® 5-6. Using Bluetooth devices ® Menu list of the Bluetooth audio/phone To enter a menu, press the tune/scroll knob and navigate menus by using the knob. First menu Second menu Third menu Operation details Registering “Pairing” ® Bluetooth device Listing the registered “List Phone”...
Page 611 ® 5-6. Using Bluetooth devices First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
Page 612: Using The Steering Wheel Switches
® 5-6. Using Bluetooth devices Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone, or portable digital audio player (portable player). ® Operating Bluetooth phone using the steering wheel switches Volume The voice guidance volume cannot be adjusted using this button.
Page 613: Registering A Bluetooth ® Device
® 5-6. Using Bluetooth devices ® Registering a Bluetooth device ® Before using the Bluetooth audio/phone, it is necessary to reg- ® ister a Bluetooth device in the system. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Press the tune/scroll knob and select “Bluetooth ”...
Page 614: Using The "Setup" Menu
5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth*” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: Registering a portable player Select “Pairing” using the tune/scroll knob (P. 608), and perform the procedure for registering a portable player.
Page 615: Setup" Menu
5-7. “SETUP” menu Listing the registered portable players Select “List Audio” using the tune/scroll knob. (P. 608) The list of registered portable players will be displayed. ● Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the tune/scroll knob.
Page 616 5-7. “SETUP” menu Changing the passkey Select “Passkey” using the tune/scroll knob. (P. 608) Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
Page 617 5-7. “SETUP” menu Initialization Select “Initialize” using the tune/scroll knob. (P. 608) ● Initializing the sound settings Select “Sound setting” using the tune/scroll knob and press (YES). For details about sound settings: P. 616 ● Initializing the device information Select “Car device info” using the tune/scroll knob and press (YES).
Page 618: Using The "Setup" Menu ("Phone" Menu)
5-7. “SETUP” menu Using the “SETUP” menu (“PHONE” menu) Adding a new phone number Select “Add contacts” using the tune/scroll knob. (P. 608) ● Transferring all contacts from the cellular phone Select “Overwrite all” using the tune/scroll knob and press (YES).
Page 619 5-7. “SETUP” menu ● Deleting incoming call history Select “Incoming Calls” using the tune/scroll knob. Select the desired phone number using the knob and press (YES). To delete all incoming call history data, press (ALL) and then press (YES). ● Deleting missed call history Select “Missed Calls”...
Page 620 5-7. “SETUP” menu Deleting a registered phone number Select “Delete contacts” using the tune/scroll knob. (P. 608) Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES).
Page 621 5-7. “SETUP” menu Setting ring tone volume Select “Ringtone volume” using the tune/scroll knob. (P. 608) Change the ring tone volume. To decrease the volume: Turn the knob counterclockwise. To increase the volume: Turn the knob clockwise. To set the volume, press (BACK).
Page 622: Bluetooth Audio
® 5-8. Bluetooth Audio ® Operating a Bluetooth enabled portable player Changing the audio source/ Selecting an album playback Playback/pause Selecting a track, fast-forward- Displaying text message ing or rewinding Power/volume knob Random play or back button Press: Turning the audio sys- Repeat play tem on or off Turn: Adjusting the volume...
Page 623 ® 5-8. Bluetooth Audio Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Selecting a track Press the “<” or “>” button of “SEEK TRACK” to select the desired track. Fast-forwarding and rewinding tracks Press and hold the “<” or “>” button of “SEEK TRACK”. Repeat play Pressing (RPT) changes modes in the following order:...
Page 624: Bluetooth Phone
® 5-9. Bluetooth Phone Making a phone call To enter the “PHONE” mode, press the off-hook switch. Dialing by selecting a name Select “Phonebook” using the tune/scroll knob. Select the desired name using the knob and press the off-hook switch. By pressing (Add S.
Page 625 ® 5-9. Bluetooth Phone Dialing by entering the number Select “Dial by number” using the tune/scroll knob. Enter the phone number and press the off-hook switch. Dialing from call histories Select “All Calls”, “Missed Calls”, “Incoming Calls” or “Outgoing Calls” using the tune/scroll knob. Select a desired number using the knob and press the off-hook switch.
Page 626: Receiving A Phone Call
® 5-9. Bluetooth Phone Receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch. Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the power/volume knob counterclock- wise.
Page 627: Speaking On The Phone
® 5-9. Bluetooth Phone Speaking on the phone Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the following methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the operation of the phone.
Page 628 ® 5-9. Bluetooth Phone ■ When talking on the phone ● Do not talk simultaneously with the other party. ● Keep the volume of the received voice down. Otherwise, voice echo will increase. ■ Automatic volume adjustment When vehicle speed is 80 km/h (50 mph) or more, the volume automatically increases.
Page 629: Bluetooth
® 5-10. Bluetooth ® Bluetooth ® When using the Bluetooth audio/phone ■ ● In the following situations, the system may not function. ® • The portable player does not support Bluetooth • The cellular phone is located outside the service area ®...
Page 630 ® 5-10. Bluetooth ■ When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (P. 615) ® ■ About Bluetooth The Bluetooth word mark and logos are registered trademarks owned Bluetooth SIG, Inc.
Page 631 ® 5-10. Bluetooth ® ■ Certification for Bluetooth  For vehicles sold in Saint Martin LC200_OM_OM60R59W_(WE)
Page 632 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 633 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 634 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 635 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 636 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 637 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 638 ® 5-10. Bluetooth LC200_OM_OM60R59W_(WE)
Page 639 ® 5-10. Bluetooth  For vehicles sold in Jamaica  For vehicles sold in the Dominican Republic  For vehicles sold in Paraguay LC200_OM_OM60R59W_(WE)
Page 640 ® 5-10. Bluetooth WARNING While driving ■ Do not use the portable audio player, cellular phone or connect a device to ® the Bluetooth system. Caution regarding interference with electronic devices ■ ® Your audio unit is fitted with Bluetooth antennas.
Page 641: Interior Features
Interior features 6-1. Using the air conditioning 6-2. Using the interior lights system and defogger Interior lights list....680 Front manual air • Interior lights....681 conditioning system ..640 • Personal lights....682 Front automatic air 6-3. Using the storage features conditioning system List of storage features ..684 (vehicles without •...
Page 642: Front Manual Air
6-1. Using the air conditioning system and defogger  Front manual air conditioning system Adjusting the temperature setting ■ Press “>” to increase the temperature and “<” to decrease the tem- perature on If the “A/C” indicator is turned off, the system will blow ambient tempera- ture air or heated air.
Page 643 6-1. Using the air conditioning system and defogger Adjusting the fan speed ■ Press “” (increase) or “” (decrease) on The fan speed is shown on the display. (7 levels) Press to turn the fan off. Changing the air outlets ■...
Page 644 6-1. Using the air conditioning system and defogger Defogging the rear window and outside rear view mirrors ■ Vehicles without outside rear view mirror defoggers  Defoggers are used to defog the rear window.  Vehicles with outside rear view mirror defoggers Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors.
Page 645 6-1. Using the air conditioning system and defogger ■ Fogging up of the windows ● The windows will easily fog up when the humidity in the vehicle is high. Turning “A/C” on will dehumidify the air from the outlets and defog the wind- shield effectively.
Page 646 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 647: Front Automatic Air Conditioning System (Vehicles Without Navigation System)
6-1. Using the air conditioning system and defogger Front automatic air conditioning system (vehicles without navigation system) Air outlets and fan speed are automatically adjusted according to the temperature setting. The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles.
Page 648 6-1. Using the air conditioning system and defogger  Type B Adjusting the temperature setting ■ Press “” (increase) or “” (decrease) on the “TEMP” button. If the “A/C” indicator is turned off, the system will blow ambient tempera- ture air or heated air. Adjusting the fan speed setting ■...
Page 649 6-1. Using the air conditioning system and defogger Changing the air flow mode ■ Press (type A) or (type B). The air flow mode switches each time the button is pressed.  Type A  Type B Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air flows to the feet and the windshield defogger operates...
Page 650 6-1. Using the air conditioning system and defogger Adjusting the temperature for driver and passenger seats sepa- rately “DUAL” mode (without rear air conditioning system)  The temperature for the driver’s seat and front passenger’s seat can be adjusted separately. To turn on the “DUAL”...
Page 651 6-1. Using the air conditioning system and defogger Changing the rear seat settings  With rear cooler system Press to turn on/off the rear cooler system.  With rear air conditioning system Press to switch to the rear air conditioning setting mode. “REAR”...
Page 652 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■  Type A Press to switch to recirculated air mode and press to switch to outside air mode.  Type B Press The mode switches between (recirculated air mode) and...
Page 653 6-1. Using the air conditioning system and defogger Pollen removal mode ■ Press (type A) or (type B). Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body. Usually the system will turn off automatically approximately 1 to 3 min- utes.
Page 654 6-1. Using the air conditioning system and defogger Heater idle up (if equipped) ■ This feature is used to boost heating effect in extremely cold condi- tions when the vehicle is not moving. Left-hand drive vehicles Right-hand drive vehicles  ...
Page 655 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. Adjusting the air flow direction and opening/closing the air ■ outlets  Front outlets ...
Page 656 6-1. Using the air conditioning system and defogger ■ While the cool box is on (vehicles with cool box)  GCC countries , Lebanon, Jordan, Yemen, Nigeria and Egypt The front air conditioning system cannot be turned off. However, air flow to the occupants can be stopped by pressing the “OFF”...
Page 657 6-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode Setting to the recirculated air mode temporarily is recommended in prevent- ● ing dirty air from entering the vehicle interior and helping to cool the vehicle when the outside air temperature is high. ●...
Page 658 6-1. Using the air conditioning system and defogger ■ The rear window defogger, outside rear view mirror defogger (if equipped) and windshield wiper de-icer (if equipped) can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position. ...
Page 659 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up ■ ● Do not use (type A) or (type B) during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 660: Front Automatic Air Conditioning System (Vehicles With Navigation System)
6-1. Using the air conditioning system and defogger Front automatic air conditioning system (vehicles with navigation system) Air outlets and fan speed are automatically adjusted according to the temperature setting. Press to display the air conditioning control screen. The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles.
Page 661 6-1. Using the air conditioning system and defogger Changing the air flow mode ■ Press The air flow mode switches each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air flows to the feet and the windshield defogger oper-...
Page 662 6-1. Using the air conditioning system and defogger Option control screen Select to set cooling and dehumidification function on/ temperature driver, front passenger and rear seats (P. 673) can be adjusted separately (Individ- ual mode) (P. 661) Prevent ice from building up on the windshield and wiper blades (if equipped) (P.
Page 663 6-1. Using the air conditioning system and defogger Adjusting the temperature for driver and passenger seats sepa- rately (Individual mode) The temperature for the driver’s, front passenger’s and rear seats (P. 673) can be adjusted separately. To turn on the individual mode, perform any of the following proce- dures: ●...
Page 664 6-1. Using the air conditioning system and defogger Changing the rear seat settings Press on the control screen to display the rear air con- ditioning control screen. Adjust the temperature setting (left-hand rear seat) Adjust the fan speed setting Adjust the temperature setting (right-hand rear seat) Select to set automatic mode Turn the fan off...
Page 665 6-1. Using the air conditioning system and defogger Adjusting the fan speed setting ■ Press (increase) or (decrease). The fan speed is shown on the display. (7 levels) Press “REAR OFF” to turn the fan off. Turning the rear air conditioning system off ■...
Page 666 6-1. Using the air conditioning system and defogger Pollen removal mode ■ Press on the control screen. Press Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body. Usually the system will turn off automatically approximately 1 to 3 min- utes.
Page 667 6-1. Using the air conditioning system and defogger Heater idle up (if equipped) ■ This feature is used to boost heating effect in extremely cold condi- tions when the vehicle is not moving. Left-hand drive vehicles Right-hand drive vehicles  ...
Page 668 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. Adjusting the air flow direction and opening/closing the air ■ outlets  Front outlets ...
Page 669 6-1. Using the air conditioning system and defogger ■ While the cool box is on (vehicles with cool box)  GCC countries , Lebanon, Jordan, Yemen, Nigeria and Egypt The front air conditioning system cannot be turned off. However, air flow to the occupants can be stopped by pressing the “OFF”...
Page 670 6-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode Setting to the recirculated air mode temporarily is recommended in prevent- ● ing dirty air from entering the vehicle interior and helping to cool the vehicle when the outside air temperature is high. ●...
Page 671 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into ●...
Page 672 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up ■ ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 673: Rear Cooler System
6-1. Using the air conditioning system and defogger  Rear cooler system Press the “REAR” button on the front air conditioning control panel to use the rear cooler system. Rear cooler on/off switch Fan speed control knob Adjusting the fan speed setting Press to turn on the system.
Page 674 6-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Direct air flow to the left or right, up or down. Turn the knob fully to the back of the vehicle to close the vent. NOTICE ■...
Page 675: Rear Air Conditioning System
6-1. Using the air conditioning system and defogger  Rear air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Adjusting the temperature setting ■ Press “” to increase the temperature and “” to decrease the tem- perature on The temperature for the right-hand and left-hand seats can be set sepa- rately.
Page 676 6-1. Using the air conditioning system and defogger Changing the air flow mode ■ Press The air flow mode switches each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air conditioning controls Using the automatic mode...
Page 677 6-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air out- ■ lets Direct air flow to the left or right, up or down. Turn the knob fully to the back of the vehicle to close the vent.
Page 678: Heated Steering Wheel/ Seat Heaters/ Seat Ventilators
6-1. Using the air conditioning system and defogger   Heated steering wheel /seat heaters /seat  ventilators Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats. Seat ventilators maintain good airflow by blowing air from the seats. WARNING ●...
Page 679 If the indicator light flashes, press the switch to turn the heated steering wheel off and then press the switch again. If the indicator light still flashes, a malfunction may be occurring. Turn the heated steering wheel off and have the vehicle inspected by your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 680 The engine switch is in IGNITION ON mode. ■ Replacing the air filters Filters are installed in the seat ventilators. For replacement of the filters, con- tact your Toyota dealer. Customization ■ The automatic mode settings for the seat heaters and ventilators can be changed.
Page 681 6-1. Using the air conditioning system and defogger Second outboard seat heaters (if equipped) For left-hand second seat For right-hand second seat High heating temperature Low heating temperature To turn on the seat heater, press “HI” or “LO”. The seat heaters can be used when ■...
Page 682: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Front interior lights (P. 681) Footwell lights Front personal lights Scuff lights (P. 682) Engine switch light Rear interior lights (P. 681) Door courtesy lights Rear personal lights (P. 682) Running board lights Inside door handle lights Door trim lights : if equipped...
Page 683: Interior Lights
6-2. Using the interior lights Interior lights (if equipped)  Front Door position on/off Turns the light on/off  Rear (type A) Door position Rear (type B)  Door position LC200_OM_OM60R59W_(WE)
Page 684: Personal Lights
6-2. Using the interior lights  Rear (type C) On/door position on Personal lights (if equipped)  Front Turns the light on/off  Rear Turns the light on/off LC200_OM_OM60R59W_(WE)
Page 685 6-2. Using the interior lights ■ Illuminated entry system  Vehicles without a smart entry & start system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed.
Page 686: 6-3. Using The Storage Features
6-3. Using the storage features List of storage features Card holder (P. 691) Console box (P. 686) Cool box (if equipped) Overhead console (P. 695) (if equipped) (P. 687) Cup holders (P. 688) Glove box (P. 685) Auxiliary box (if equipped) Bottle holders (P.
Page 687: Glove Box
6-3. Using the storage features Glove box Open (push button) Lock with the master key or the mechanical key Unlock with the master key or the mechanical key Glove box light (if equipped) ■ The glove box light turns on when the tail lights are on. ■...
Page 688: Console Box
6-3. Using the storage features Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to page 695. Upper console box  Press the tab to open.  Lower console box (if equipped) Lift the lever to open.
Page 689: Overhead Console
6-3. Using the storage features Overhead console (if equipped) Press the button. WARNING ■ Items unsuitable for storing Do not store items heavier than 0.2 kg (0.4 lb.). Doing so may cause the overhead console to open and the items inside may fall out, resulting in an accident.
Page 690: Cup Holders
6-3. Using the storage features Cup holders  Front seats  Second seats (if equipped) Press down and release the lid. To open, pull down the armrest, press the button and release the You can adjust or remove the sep- rear cup holder on the armrest.
Page 691 6-3. Using the storage features ■ Removing the cup holder insert (front cup holders) Pull up the insert. Cup holder insert may be removed for cleaning. WARNING Items unsuitable for the cup holder ■ Do not place anything other than cups or beverage cans in the cup holders. Even with the lid is closed, items must not be stored in the cup holders.
Page 692: Bottle Holders
6-3. Using the storage features Bottle holders  Front seats  Second seats NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
Page 693: Card Holder
6-3. Using the storage features Card holder Auxiliary boxes Your vehicle is equipped with either a front auxiliary box or wireless charger. For vehicles with wireless charger, refer to page 704. Front (if equipped) Rear (type A)   Press the lid to open. ...
Page 694: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items. Storage compartment (if equipped) Remove the cover. Warning reflector holder (if equipped) Remove the cover. Hold the warn- ing reflector with the bands.
Page 695 6-3. Using the storage features First-aid kit holder (if equipped) Remove the cover. Hold the first- aid kit with a band. The first-aid kit itself is not included as an original equipment. Luggage cover (if equipped) Using the luggage cover ■...
Page 696 6-3. Using the storage features ■ When installing the luggage cover (if equipped) Keep the “TOP” mark on the luggage cover ends upward. WARNING To avoid injury, always return the cargo hooks to their positions when not ● in use. ●...
Page 697: Other Interior Features
6-4. Using the other interior features Other interior features Cool box (if equipped) While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lid while pulling up the knob to release the lock. Turns the cool box on/off When on, the indicator light comes If the front air conditioning system is not in use...
Page 698 6-4. Using the other interior features ■ While the cool box is on  GCC countries , Lebanon, Jordan, Yemen, Nigeria and Egypt The front air conditioning system cannot be turned off. However, air flow to ● the occupants can be stopped by pressing the “OFF” button on the air con- ditioning control panel.
Page 699: Sun Visors
6-4. Using the other interior features Sun visors  Main sun visor To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender (if equipped), place the visor in the side position, then slide it back-...
Page 700 6-4. Using the other interior features NOTICE To prevent battery discharge, do not leave the vanity lights on for extended periods when the engine is not running. LC200_OM_OM60R59W_(WE)
Page 701: Clock
6-4. Using the other interior features Clock  Type A Refer to the “Navigation system Owner’s manual” or “Navigation Multimedia System Owner’s Manual” for adjust- ment.  Type B  Type C The clock can be adjusted by pressing the buttons. Adjusts the hours Adjusts the minutes Rounds the nearest hour...
Page 702: Outside Temperature Display
Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode. ■ When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. Display ■ In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 703: Power Outlet
6-4. Using the other interior features Power outlet (if equipped) The power outlet can be used for the following components: 12 V DC: Accessories that run on less than 10 A. 220 V AC: Accessories that use less than 100 W. Center of console ■...
Page 704 6-4. Using the other interior features Luggage compartment ■ Type A (12 V DC) Type B (220 V AC)   The power outlet can be used when ■  Vehicles without smart entry & start system 12 V DC: The engine switch is in the “ACC” or “ON” position. ...
Page 705 6-4. Using the other interior features NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.
Page 706: Wireless Charger
6-4. Using the other interior features Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smart phones and mobile batteries, etc., on the charge area.
Page 707 6-4. Using the other interior features Using the wireless charger ■ Press the lid to open. Press power supply switch of the wireless char- ger. Switches on and off with each press of the power supply switch. When turned on, the operation indicator light (green) comes on.
Page 708 Handle the error based on the following table. Operation indicator Suspected causes Handling method light Flashing repeatedly Vehicle to charger com- Contact your Toyota once every second munication failure. dealer. (Orange) Remove foreign A foreign substance is substance...
Page 709 6-4. Using the other interior features ■ The wireless charger can be operated when The engine switch is in ACCESSORY or IGNITION ON mode. ■ Usable portable devices Qi standard wireless charge standard can be used on compatible devices. However, not all Qi standard devices and compatibility are guaranteed. Starting with mobile phones and smart phones, it is aimed for low power elec- trically supplied portable devices of no more than 5W.
Page 710 6-4. Using the other interior features ■ Certification for the wireless charger  For vehicles sold in Guatemala LC200_OM_OM60R59W_(WE)
Page 711 6-4. Using the other interior features  For vehicles sold in Paraguay LC200_OM_OM60R59W_(WE)
Page 712 6-4. Using the other interior features WARNING Caution while driving ■ When charging a portable device, for safety reasons, the driver should not operate the portable device while driving. Caution regarding interference with electronic devices ■ People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the usage of the wireless charger.
Page 713 When other wireless keys (that emit radio waves) are being used nearby In addition, excluding the above-mentioned, when the charger does not per- form normally or the operation indicator light is flashing continuously, it is considered that the wireless charger is malfunctioning. Contact your Toyota dealer. ■...
Page 714: Armrest
6-4. Using the other interior features Armrest (if equipped) Fold down the armrest for use. NOTICE To prevent damage, do not apply too much load on the armrest. Coat hooks (if equipped) The coat hooks are provided with the second seat assist grips. WARNING Vehicles with SRS curtain shield airbags: Do not hang coat hangers or other hard or sharp objects on the hook.
Page 715: Assist Grips
6-4. Using the other interior features Assist grips (if equipped) An assist grip (Type A) can be used to support your body while sitting on the seat. An assist grip (Type B) can be used when getting in or out of the vehi- cle and others.
Page 716: Ashtray
6-4. Using the other interior features Ashtrays (if equipped) Press in and release the lid to open. Press down on the lock spring plate to remove. Press the lid to close. WARNING ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident.
Page 717: Cigarette Lighter
6-4. Using the other interior features Cigarette lighter (if equipped) Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. The cigarette lighter can be used when ■  Vehicles without a smart entry & start system The engine switch is in the “ACC”...
Page 718: Garage Door Opener
6-4. Using the other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® Programming HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 719 6-4. Using the other interior features ® Programming HomeLink ■ ® Press and release the HomeLink button you want to program ® and check that the HomeLink indicator light flashes (orange). Perform within 60 seconds of , or the indicator light will stop flash- ing and programming will not be able to be completed.
Page 720 6-4. Using the other interior features ● Device with rolling code: If the indicator light flashes rapidly, your garage door opener motor (or other device) is equipped with a rolling code. Complete the programming process by ® firmly pressing and holding the programmed HomeLink but- ton for 2 seconds and then release the button.
Page 721 6-4. Using the other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor ®...
Page 722 6-4. Using the other interior features ® Within 1 minute of pressing the HomeLink button, after the garage door operation has stopped, press the “Learn” or “Smart” button on the garage door opener motor. Within 5 seconds of the establishment of 2-way communication with the garage door opener, both garage door operation indicators in the vehicle will flash rapidly (green) and the light on the garage door opener motor will blink twice, indicating that 2-way communication is...
Page 723 6-4. Using the other interior features Garage door operation indicators The status of the opening and closing of a garage door is shown by the indicators. Opening Closing This function is only available if the garage door opener motor used is a compatible device.
Page 724 6-4. Using the other interior features ® Erasing the entire HomeLink memory (all three codes) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit (orange) rapidly flashing (green). If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 725: Compass
6-4. Using the other interior features  Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. Operation To turn the compass on or off, push and hold the button for lon- ger than 3 seconds.
Page 726 6-4. Using the other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 727 6-4. Using the other interior features Circling calibration ■ If “C” appears on the display, drive the vehicle at 8 km/h (5 mph) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 728 6-4. Using the other interior features NOTICE To avoid compass malfunctions ■ Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause the compass sensor to malfunction. To ensure normal operation of the compass ■...
Page 729: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior ..728 Cleaning and protecting the vehicle interior ...732 7-2. Maintenance Maintenance requirements....735 Scheduled maintenance ....738 7-3. Do-it-yourself maintenance Do-it-yourself service precautions ......753 Hood ........756 Engine compartment..757 Electric winch.....775 Tires........776 Tire inflation pressure ..795 Wheels.......797...
Page 730: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 731 7-1. Maintenance and care ■ Automatic car washes ● Fold the mirrors back before washing the vehicle. Start washing from the front of the vehicle. Make sure to extend the mirrors before driving. ● Brushes used in automatic car washes may scratch the vehicle surface and harm your vehicle’s paint.
Page 732 ■ Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 733 7-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 734: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 735 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 736 Vehicle systems such as the audio system may be damaged if water comes into contact with electrical components such as the audio system above or under the floor of the vehicle. Water may also cause the body to rust. When cleaning the inside of the windshield (vehicles with Toyota ■ Safety Sense) Do not allow glass cleaner to contact the lens.
Page 737: Maintenance Requirements
● Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for maintenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips and in-dealership train- ing programs.
Page 738 Engine coolant temperature continually higher than normal (P. 110) ● ● Engine continually runs hot, oil pressure gauge stays low If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. LC200_OM_OM60R59W_(WE)
Page 739 7-2. Maintenance WARNING If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. Handling of the battery ■ Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 740: Scheduled Maintenance
7-2. Maintenance Scheduled maintenance Perform maintenance by the schedule as follows: Maintenance schedule requirements Your vehicle needs to be serviced according to the normal maintenance schedule. (See “Maintenance schedule”.) If you mainly operate your vehicle under one or more of the spe- cial operating conditions below, some of the maintenance sched- ule items need to be serviced more frequently in order to keep your vehicle in good condition.
Page 741 7-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 742 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 743 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 744 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 745 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 746 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque C = Cleaning SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 747 7-2. Maintenance NOTE: 1. Replace both the engine oil and oil filter, even when the maintenance reminder does not appear, after 12 months have passed, or when driven over 10000 km (6000 miles) since the last oil change. This may cause the maintenance reminder appear even when driven less than 10000 km (6000 miles).
Page 748 7-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe condi- tions. (For outline, see “Maintenance schedule requirements”.) A-1: Operating on rough or muddy roads, or roads with melted snow ...
Page 749 7-2. Maintenance A-2: Operating on dusty roads (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.)  1VD-FTV engine except for South Africa and Philippines: Every 2500 km (1500 miles) or 3 months ...
Page 750 7-2. Maintenance A-2: Operating on dusty roads (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.)  STD grade: R: Every 15000 km (9000 miles)  Replacement or cleaning of air ...
Page 751 7-2. Maintenance B-1: Heavily loaded vehicle (Example: Towing a trailer, using a camper, using a car top carrier, etc.)  1VD-FTV engine except for South Africa and Philippines: Every 2500 km (1500 miles) or 3 months  Replacement of engine oil ...
Page 752 7-2. Maintenance B-1: Heavily loaded vehicle (Example: Towing a trailer, using a camper, using a car top carrier, etc.)  Inspection of front and rear sus- Every 5000 km (3000 miles) or pensions 3 months  Tightening of bolts and nuts on Every 10000 km (6000 miles) or chassis and body 6 months...
Page 753 7-2. Maintenance B-3: Extensive idling and/or low speed driving for a long distance such as police, professional/private use like taxi or door-to-door delivery use  1VD-FTV engine except for South Africa and Philippines: Every 2500 km (1500 miles) or 3 months ...
Page 754 7-2. Maintenance NOTE: 1. Lubricate within 24 hours after submerging. 2. For seat mounting bolts, suspension member retaining bolts and leaf springs retaining U bolts. LC200_OM_OM60R59W_(WE)
Page 755: Do-It-Yourself Maintenance
• Grease Electric winch (P. 775) • Automatic transmission fluid • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology. “Toyota Super level (P.
Page 756 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions: ■ When working on the engine compartment Keep hands, clothing and tools away from the moving fan and engine ●...
Page 757 7-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner filter ■ Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. If the fluid level is low or high ■ It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 758: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Lift the hood catch and lift the hood. WARNING ■ Pre-driving check Check that the hood is fully closed and locked.
Page 759: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment  3UR-FE engine Air cleaner (P. 773) Engine oil filler cap (P. 763) Engine oil level dipstick Fuse box (P. 806) (P. 762) Washer fluid tank (P. 771) Engine coolant reservoir Battery (P. 767) (P. 765) Condenser (P.
Page 760 7-3. Do-it-yourself maintenance  1UR-FE engine Air cleaner (P. 773) Engine oil filler cap (P. 763) Engine oil level dipstick Fuse box (P. 806) (P. 762) Washer fluid tank (P. 771) Engine coolant reservoir Battery (P. 767) (P. 765) Condenser (P.
Page 761 7-3. Do-it-yourself maintenance  1GR-FE engine Air cleaner (P. 773) Engine oil filler cap (P. 763) Engine oil level dipstick Fuse box (P. 806) (P. 762) Washer fluid tank (P. 771) Engine coolant reservoir Battery (P. 767) (P. 765) Condenser (P.
Page 762 7-3. Do-it-yourself maintenance  1VD-FTV engine Air cleaner (P. 773) Fuse box (P. 806) Engine coolant reservoir Fuel filter (P. 772, 909) (P. 765) Washer fluid tank (P. 771) Engine oil level dipstick Battery (P. 767) (P. 762) Condenser (P. 767) Engine oil filler cap (P.
Page 763 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure the cover is securely installed in its original position. LC200_OM_OM60R59W_(WE)
Page 764 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 765 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 766 ● not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 767 7-3. Do-it-yourself maintenance Engine coolant  Gasoline engine The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir when the engine is cold. Reservoir cap “F” line “L” line If the level is on or below the “L” line, add coolant up to the “F”...
Page 768 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system.
Page 769 Radiator, condenser and intercooler (if equipped) Check the radiator, condenser and intercooler and clear any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING When the engine is hot ■...
Page 770 7-3. Do-it-yourself maintenance Battery exterior ■ Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Checking battery fluid ■ Check that the level is between the upper and lower lines. Upper line Lower line If the fluid level is at or below the...
Page 771 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts at both methods, con- tact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 772 7-3. Do-it-yourself maintenance WARNING Chemicals in the battery ■ Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near battery: Do not cause sparks by touching the battery terminals with tools.
Page 773 7-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display (vehi- cles with multi-information dis- play) or the warning indicator light comes on (vehicles without multi- information display), the washer tank may be empty.
Page 774 Fuel filter (diesel engine only) You may drain the fuel filter yourself. However, as the operation is dif- ficult, we recommend having it drained by your Toyota dealer. Even if you decide to drain it yourself, contact your Toyota dealer.
Page 775 7-3. Do-it-yourself maintenance Air cleaner filter Use compressed air to remove dust or sand etc. from the area sur- rounding the air cleaner filter case. Release the clips. Lift the cover and take out the filter. Inspect the outer surface of the fil- ter, and replace the filter if it is extremely dirty.
Page 776 7-3. Do-it-yourself maintenance NOTICE To prevent damaging the engine ■ ● Do not drive with the air cleaner filter removed. Doing so may cause excessive engine wear. Do not hit or drop the filter, as it may contain dust or sand etc. ●...
Page 777: Electric Winch
● Before using the electric winch, check that the vehicle’s battery ter- minals are tight and the battery fluid level is sufficient. NOTICE When replacing cable ■ If replacing the cable with a new one, use a genuine Toyota product.  : If equipped LC200_OM_OM60R59W_(WE)
Page 778: Tires
Replace the tires if the treadwear indicators are showing on a tire. Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate your tires Front approximately every 5000 (3000 miles).
Page 779 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 779) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■...
Page 780 7-3. Do-it-yourself maintenance How to initialize the tire pressure warning system ■ Park the vehicle in a safe place and turn the engine switch to off. Initialization cannot be performed while the vehicle is moving. Adjust the tire inflation pressure to the specified cold tire inflation pressure level.
Page 781 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with the tire pressure warning sys- tem) ...
Page 782 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 783 7-3. Do-it-yourself maintenance ■ The initialization operation (vehicles with the tire pressure warning sys- tem) Make sure to carry out initialization after adjusting the tire inflation pressure. ● Also, make sure the tires are cold before carrying out initialization or tire inflation pressure adjustment.
Page 784 It is not necessary to register the ID codes when replacing normal tires with snow tires, if the ID codes for the wheels of both normal tires and snow tires are registered beforehand. For information about changing ID codes, ask your Toyota dealer. ■ Certification for tire pressure warning system ...
Page 785 7-3. Do-it-yourself maintenance  For vehicles sold in Saint Martin LC200_OM_OM60R59W_(WE)
Page 786 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 787 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 788 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 789 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 790 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 791 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 792 7-3. Do-it-yourself maintenance LC200_OM_OM60R59W_(WE)
Page 793 7-3. Do-it-yourself maintenance  For vehicles sold in Indonesia  For vehicles sold in Vietnam  For vehicles sold in the United Arab Emirates  For vehicles sold in Jordan  For vehicles sold in Argentina LC200_OM_OM60R59W_(WE)
Page 794 7-3. Do-it-yourself maintenance  For vehicles sold in Paraguay  For vehicles sold in South Africa  For vehicles sold in Morocco LC200_OM_OM60R59W_(WE)
Page 795 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 796 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 797: Tire Inflation Pressure
Reduced safety ● ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 798 7-3. Do-it-yourself maintenance WARNING Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: Excessive wear ●...
Page 799: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 800 ■ When replacing wheels (vehicles with the tire pressure warning system) The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and transmitters must be installed.
Page 801 ● Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 802: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Vehicles without a smart entry & start system: Turn the engine switch to the “ON” position and switch to recircu- lated air mode, then turn the engine switch to the “LOCK”...
Page 803 2 minutes at 500 kPa (5.0 kgf/cm or bar, 72 psi). If it is not available, have the filter cleaned by your Toyota dealer. Replacement method Remove the air conditioning filter and replace it with a new one. The “UP” marks shown on the fil- ter should be pointing up.
Page 804: Wireless Remote Control/Electronic Key Battery
7-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver (vehicles with a smart entry & start sys- tem) ●...
Page 805 7-3. Do-it-yourself maintenance Open the case cover using a coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up.  Vehicles with a smart entry & start system (type A) Take out the mechanical key.
Page 806 7-3. Do-it-yourself maintenance  Vehicles with a smart entry & start system (type B) Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. When removing the cover, if the battery cannot be seen due to the electronic key module attaching to...
Page 807 Vehicles without a smart entry & start system: CR2016 Vehicles with a smart entry & start system: CR2032 ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. Replace only with the same or equivalent type recommended by the manu- ●...
Page 808: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 809 7-3. Do-it-yourself maintenance  Passenger’s side instrument panel (left-hand drive vehicles) (if equipped) Remove cover. equipped) Remove the lid.  Driver’s side instrument panel (right-hand drive vehicles) (if equipped) Remove the lid. LC200_OM_OM60R59W_(WE)
Page 810 7-3. Do-it-yourself maintenance  Passenger’s side instrument panel (right-hand drive vehicles) Remove cover. equipped) Remove the lid. Remove the fuse with the pull- out tool. Only type A fuse can be removed using the pullout tool. LC200_OM_OM60R59W_(WE)
Page 811 Type A and B: Replace the blown fuse with one of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Toyota dealer. Type A Type B ...
Page 812 The fuses are designed to blow, protecting the wiring harness from damage. ■ When replacing light bulbs Toyota recommends that you use genuine Toyota products designed for this vehicle. Because certain bulbs are connected to circuits designed to prevent overload, non-genuine parts or parts not designed for this vehicle may be unusable.
Page 813: Light Bulbs
Light bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 814 7-3. Do-it-yourself maintenance Bulb locations Front ■  Vehicles with halogen headlight Headlight high beam Front position light Headlight low beam Side turn signal light (front fender type) Front turn signal light  Vehicles with LED headlight Headlight high beam (halogen Running board light...
Page 815 7-3. Do-it-yourself maintenance Rear ■ Lift-up back door type (vehicles with back door mounted spare  tire) Rear turn signal light License plate lights Back-up light (left-hand side Rear fog light (if equipped) only)  Lift-up back door type (vehicles without back door mounted spare tire) Rear turn signal light Rear fog light (if equipped)
Page 816 7-3. Do-it-yourself maintenance  Double back door type Stop/tail light Rear fog light (if equipped) Rear turn signal light Back-up light License plate light LC200_OM_OM60R59W_(WE)
Page 817 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams (vehicles with halogen headlight) ■ left side only: Remove the securing clip and move the washer fluid filler opening. Unplug the connector while depressing the lock release. Turn the light bulb counter- clockwise.
Page 818 7-3. Do-it-yourself maintenance Turn and secure the light bulb. Set the connector. Shake the light bulb gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. When replacing the left side bulb, install by conducting with the directions reversed.
Page 819 7-3. Do-it-yourself maintenance Replace the light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the light bulb. Set the connector. Shake the light bulb gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 820 7-3. Do-it-yourself maintenance Unplug the connector while pulling the lock release. Turn the light bulb counter- clockwise. Replace the light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the light bulb. LC200_OM_OM60R59W_(WE)
Page 821 7-3. Do-it-yourself maintenance Set the connector. Shake the light bulb gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. When reinstalling the cover, reverse the procedure in step Front position lights (vehicles with halogen headlight) ■...
Page 822 7-3. Do-it-yourself maintenance Front turn signal lights ■ Vehicles with halogen headlight  left side only: Remove the securing clip and move the washer fluid filler opening. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 823 7-3. Do-it-yourself maintenance  Vehicles with LED headlight left side only: Remove the securing clip and move the washer fluid filler opening. Unplug the connector while depressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 824 7-3. Do-it-yourself maintenance Side turn signal lights (front fender type) ■ Push it to the front of the vehicle as shown. ITY43C055 Turn the bulb base counter- clockwise. ITY43C056 Remove the light bulb. ITY43C057 When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 825 7-3. Do-it-yourself maintenance Back-up lights ■ Vehicles with lift-up back door  Open the back door and remove the nuts and lamp assembly. Unplug the connector while pressing the lock release. Remove the cover. Unclip the connector wire and turn the bulb bases counterclockwise.
Page 826 7-3. Do-it-yourself maintenance Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 827 7-3. Do-it-yourself maintenance  Vehicles with double back door To allow enough working space, remove the under cover screws and hold the under cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 828 7-3. Do-it-yourself maintenance Rear turn signal lights (vehicles with lift-up back door) ■ Open the back door and attach protective tape under the light unit. (Use masking tape. Do not use any duct tape, as duct tape may leave markings.) Remove the cover.
Page 829 7-3. Do-it-yourself maintenance Turn the bulb bases counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 830 7-3. Do-it-yourself maintenance Stop/tail and rear turn signal lights (vehicles with double back ■ door) Open the back door and remove the bolts. Close the back door half way and remove the lamp assem- bly. Unplug the connector while pushing the lock release. Rear turn signal light only: Unclip the connector wire.
Page 831 7-3. Do-it-yourself maintenance Turn the bulb bases counter- clockwise. Rear turn signal light Stop/tail light Remove the light bulb. Rear turn signal light Stop/tail light When installing, reverse the steps listed. Rear fog lights (if equipped) ■ Vehicles with lift-up back door ...
Page 832 7-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 833 7-3. Do-it-yourself maintenance  Vehicles with double back door To allow enough working space, remove the under cover screws and hold the under cover. Turn the bulb base counter- clockwise. Remove the light bulb. ITY43C065 When installing, reverse the steps listed. LC200_OM_OM60R59W_(WE)
Page 834 7-3. Do-it-yourself maintenance License plate lights (lift-up back door type [vehicles with back ■ door mounted spare tire] and double back door type) Remove the screw and the license plate light unit. Turn the bulb base counter- clockwise. ITY43C103 Remove the light bulb. When installing, reverse the steps listed.
Page 835 Lights other than the above ■ If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (vehicles with LED headlight) ● Headlight high beams (LED type) ● Front position lights/daytime running lights (vehicles with LED headlight) ●...
Page 836 (lift-up back door type [vehicles with back door mounted spare tire] and double back door type) consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 837: When Trouble Arises
When trouble arises 8-1. Essential information 8-2. Steps to take in an emergency Emergency flashers...836 If your vehicle needs If your vehicle has to to be towed ......840 be stopped in an emergency.......837 If you think something is wrong ......845 If the vehicle is trapped in rising water ....839 Fuel pump shut off system...
Page 838: Essential Information
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 839: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 840 8-1. Essential information Vehicles with a smart entry & start system: To stop the engine, press and hold the engine switch for 2 consecutive seconds or more, or press it briefly 3 times or more in succession. Press and hold for 2 seconds or more, or press briefly 3 times or more Stop the vehicle in a safe place by the road.
Page 841: If The Vehicle Is Trapped In Rising Water
However, an emergency hammer can not shatter the windshield as it is lam- inated glass. : Contact your Toyota dealer or aftermarket accessory manufacturer for fur- ther information about an emergency hammer. Escaping the vehicle from the window ■...
Page 842: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 843 8-2. Steps to take in an emergency Towing with a wheel-lift type truck  From the front  From the rear Use a towing dolly under the rear Use a towing dolly under the wheels. front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the...
Page 844 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing hooks. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
Page 845 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with all four wheels raised off the ground. If the vehicle is towed with the tires contacting the ground, the drivetrain or related parts may be damaged, the vehicle may fly off...
Page 846 8-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle when towing using a wheel-lift type ■ truck ● Do not tow the vehicle from the rear when the engine switch is off. The steering lock mechanism is not strong enough to hold the front wheels straight.
Page 847: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 848: Fuel Pump Shut Off System (Gasoline Engine Only)
8-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 849: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or • The brake system is malfunctioning.  Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Page 850 SRS warning light Indicates a malfunction in: • The SRS airbag system; or • The seat belt pretensioner system.  Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: • The Multi Terrain ABS; or •...
Page 851 P and wait until the light goes off. If the light goes off, you may start the vehicle again. If the warning light do not go off, contact your Toyota dealer. • Indicates a malfunction in the automatic transmission system if the light flashes.
Page 852  Refuel the vehicle. Vehicles with diesel engine only: Indicates a malfunction in the fuel tank system if the light flashes.  Have the system checked by your Toyota dealer. Driver’s seat belt reminder light (warning buzzer) equipped) Warns the driver to fasten his/her seat belt.
Page 853 The LED headlights will not normally illuminate when there is a malfunction, however it may be able to illuminate depending on the nature of the problem.  Have the vehicle inspected by your Toyota dealer immediately. Automatic headlight leveling system warning light (if...
Page 854 8-2. Steps to take in an emergency : Brake system warning buzzer: The buzzer sounds to indicate that the brake fluid level is low (with the vehicle reached a speed of 5 km/h [3 mph]). : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 5 km/h [3 mph]).
Page 855 8-2. Steps to take in an emergency Smart entry & start system warning light and buzzer procedures (vehicles without multi-information display) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning Details/Actions buzzer...
Page 856 8-2. Steps to take in an emergency Interior Exterior Warning Details/Actions buzzer buzzer light Indicates that a door other than the driver’s door has been opened or closed with the engine switch in any mode other than off, the shift lever was in P (auto- Sounds matic transmission) or N (manual trans- Once...
Page 857 If the fuel tank is empty, refuel the vehicle imme- diately. The malfunction indicator lamp will go off after several trips. If the mal- function indicator lamp does not go off, contact your Toyota dealer. ■ Front passenger detection sensor and passenger seat belt reminder ●...
Page 858 (P. 777) If the warning light does not turn off even after several minutes have elapsed, have the vehicle inspected by your Toyota dealer immediately.  If the tire pressure warning light flashes for 1 minute then stay on There may be a malfunction in the tire pressure warning system.
Page 859 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 860: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the mes- sage on the multi-information dis- play. If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer.  : If equipped LC200_OM_OM60R59W_(WE)
Page 861 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 862 ● If “Smart Entry & Start System Malfunction” is shown, this may be a mal- function. Immediately have the vehicle inspected by your Toyota dealer. If “Transmission Fluid Temp High” is shown, it indicates that the automatic ● transmission fluid temperature is too high.
Page 863 Indicates that the engine oil should be changed. (The indicator will not work properly unless the message has been reset.) Check and change the engine oil, and oil filter by your Toyota dealer. After changing the engine oil, the message should be reset. (P. 764) ■...
Page 864 8-2. Steps to take in an emergency ■ If “Fuel Filter Maintenance Required” is shown The fuel filter need to be replaced. For Indonesia: If the engine is operated with biodiesel blended fuel with more than 5% FAME(B5), fuel filter replacement intervals may become shorter. ■...
Page 865: If You Have A Flat Tire (Vehicles With A Spare Tire)
8-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For detail about tires: P. 776 WARNING ■...
Page 866 8-2. Steps to take in an emergency Location of the spare tire, jack and tools  Type A Jack Tool box Spare tire Type B  Jack Tool box Spare tire LC200_OM_OM60R59W_(WE)
Page 867 8-2. Steps to take in an emergency  Type C Jack Tool box Spare tire Type D  Jack Tool bag Spare tire LC200_OM_OM60R59W_(WE)
Page 868 8-2. Steps to take in an emergency  Type E Jack Tool bag Spare tire  Type F Jack Tool bag Spare tire LC200_OM_OM60R59W_(WE)
Page 869 8-2. Steps to take in an emergency WARNING Using the tire jack ■ Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or install- ●...
Page 870 8-2. Steps to take in an emergency Taking out the jack (type A, B and C) Remove the cover. Unhook the rubber band and take out the jack. Loosen Tighten Loosen and remove the jack. LC200_OM_OM60R59W_(WE)
Page 871 8-2. Steps to take in an emergency Taking out the tool box (type A, B and C) Remove the cover. IN82LA044 Take out the tool box. Taking out the jack and tool bag (type D, E and F) Remove the cover. LC200_OM_OM60R59W_(WE)
Page 872 8-2. Steps to take in an emergency Unhook the strap and remove the tool bag. Loosen and remove the jack. Loosen Tighten Taking out the spare tire (Models with back door mounted spare tire) Insert the key into the cylinder and remove the lock on the hold-down bolt.
Page 873 8-2. Steps to take in an emergency Turn the hold-down nuts coun- terclockwise with the wheel nut wrench and remove them. Taking out the spare tire (Models with under floor mounted spare tire) Assembling the jack handle. Remove the jack handle and the jack extension bar from the tool box and assemble by following these steps.
Page 874 8-2. Steps to take in an emergency Open the cover. (if equipped) Insert the jack handle extension into the lowering screw. Lower Raise Place a rag under the jack han- dle extension to protect the back door. Lower the spare tire completely to the ground.
Page 875 8-2. Steps to take in an emergency Aluminum wheels: Remove the spare wheel cover. Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear...
Page 876 8-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assembling the jack handle. Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 877 8-2. Steps to take in an emergency Position the jack at the jack points as shown. Front Under the chassis frame side rail Rear Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 878 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving.
Page 879 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 880 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque Aluminum wheels: 131 N•m (13.4 kgf•m, 97 ft•lbf) Steel wheels: 209 N•m (21.3 kgf•m, 154 ft•lbf) Reinstall the wheel ornament.
Page 881 8-2. Steps to take in an emergency WARNING Stowing the flat tire ■ Failure to follow steps listed under stowing the tire may result in damage to the spare tire carrier and loss of the tire, which could result in death or seri- ous injury.
Page 882 8-2. Steps to take in an emergency  Vehicles with under floor mounted spare tire Lay down the tire with the valve stem facing up Aluminum wheels: Install the spare wheel cover. Install holding bracket, inserting the claw into the wheel lug nut hole.
Page 883 8-2. Steps to take in an emergency Raise the tire. While raising, secure the tire, tak- ing care that the tire goes straight up without catching on any sur- rounding part, to prevent it from fly- ing forward during a collision or sudden braking.
Page 884 8-2. Steps to take in an emergency Confirm that the tire is not loose after tightening: Push and pull the tire Try rotating Visually check to ensure the tire is not hung on surrounding parts. If looseness or misassembly exists, repeat step and step Repeat step , any time the tire is lowered or disturbed.
Page 885 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 886: If You Have A Flat Tire (Vehicles With An Emergency Tire Puncture Repair Kit)
8-2. Steps to take in an emergency If you have a flat tire (vehicles with an  emergency tire puncture repair kit) Your vehicle is not equipped with a spare tire, but instead is equipped with an emergency tire puncture repair kit. A puncture caused by a nail or screw passing through the tire tread can be repaired temporarily with the emergency tire punc- ture repair kit.
Page 887 ■ A flat tire that cannot be repaired with the emergency tire repair kit Emergency repair with the sealant in the kit is not possible in the following cases. Contact your Toyota dealer. ● When the wheel is damaged When two or more tires have been punctured ●...
Page 888: Emergency Tire Puncture
8-2. Steps to take in an emergency Location of the emergency tire puncture repair kit, jack and tools Emergency tire puncture Tool box repair kit Jack  : Use of the jack ( P. 869) LC200_OM_OM60R59W_(WE)
Page 889 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Sealant Valve core (spare) Injection hose Stickers Valve core tool Compressor LC200_OM_OM60R59W_(WE)
Page 890 8-2. Steps to take in an emergency Emergency repair method Position the nail or screw that has punctured the tire at the bottom, in contact with the ground. Remove the cap from the valve. Valve Bring the protruding part of the valve core tool into contact with the valve to discharge air.
Page 891 8-2. Steps to take in an emergency Remove the plug from the injec- tion hose. Plug Injection hose Connect the injection hose to the valve. Valve Injection hose Inject the sealant that is in the bottle. Hold and tilt the bottle, then squeeze sealant out of the bottle as shown.
Page 892 8-2. Steps to take in an emergency Remove the injection hose from the valve and screw the valve Valve core in the valve securely by core tool turning it clockwise with the valve core tool. Valve core Connect the air compressor Compressor hose by threading it on the Hose...
Page 893 If the inflation pressure is not attained within 5 minutes, emergency repair is not possible due to severe damage. Contact your Toyota dealer. After completely filling the tire with air, disconnect the hose from the valve on the tire.
Page 894 If the pressure is less than 130 kPa (1.3 kgf/cm or bar, 18 psi), the emergency repair that has been performed is not safe for use as damage to the tire is too severe. Do not continue to drive vehicle. Contact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 895 ● If the sealant gets on your clothes, it may stain. ● After using the sealant, bring the empty bottles of sealant to your Toyota dealer and purchase a new bottle. Keep the new bottles of sealant in your vehicle.
Page 896 8-2. Steps to take in an emergency WARNING Precaution for children ■ Keep the emergency tire puncture repair kit out of the reach of children and store it properly. Sealant precautions ■ The sealant in the emergency tire puncture repair kit is not for human con- ●...
Page 897 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 898: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 303, 306), consider each of the fol- lowing points: The engine will not start even when the starter motor operates normally.
Page 899 ● There may be a malfunction in the steering lock system. (vehicles with a smart entry & start system) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart entry & start...
Page 900: If The Electronic Key Does Not Operate Properly (Vehicles With A Smart Entry & Start System)
Locks all doors Closes the windows and moon 1, 2 roof (turn and hold) Unlocks all doors Opens the windows and moon 1, 2 roof (turn and hold) : If equipped : These settings must be customized at your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 901 ACCESSORY mode. Firmly depress the brake pedal and check that is shown on the instrument cluster. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. LC200_OM_OM60R59W_(WE)
Page 902 ACCESSORY mode. Firmly depress the clutch pedal and check that is shown on the instrument cluster. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. ■ Stopping the engine ...
Page 903 8-2. Steps to take in an emergency ■ Changing engine switch modes  Vehicles with an automatic transmission Release the brake pedal and press the engine switch in step above. The engine does not start and modes will be changed each time the switch is pressed.
Page 904: If The Vehicle Battery Is Discharged
You can also call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Toyota following the steps below. Confirm that the electronic key is being carried.
Page 905 8-2. Steps to take in an emergency  1UR-FE engine 1GR-FE engine  1VD-FTV engine  Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle Connect the jumper cable to ground on your vehicle as shown in the illustration.
Page 906 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were connected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Starting the engine when the battery is discharged (vehicles with auto- ■...
Page 907 8-2. Steps to take in an emergency WARNING Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it ●...
Page 908: If Your Vehicle Overheats
(radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “FULL” and “LOW”/“F” and “L” lines on the reservoir. Reservoir “FULL” or “F”...
Page 909 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 910 8-2. Steps to take in an emergency WARNING When inspecting under the hood of your vehicle ■ Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until ●...
Page 911: If You Run Out Of Fuel And The Engine Stalls (Diesel Engine Only)
If the engine does not start after the above steps have been performed, wait for 10 seconds and try step again. If the engine still does not start, contact your Toyota dealer. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
Page 912: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and shift the shift lever to P (automatic transmission) or N (manual transmission).
Page 913 8-2. Steps to take in an emergency WARNING When attempting to free a stuck vehicle ■ If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 914 8-2. Steps to take in an emergency LC200_OM_OM60R59W_(WE)
Page 915: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...914 Fuel information ....947 9-2. Customization Customizable features ..950 9-3. Initialization Items to initialize ....964 LC200_OM_OM60R59W_(WE)
Page 916: 9-1. Specifications
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 1, 6 5325 mm (209.6 in.) 1, 7 5305 mm (208.9 in.) 1, 8 5250 mm (206.7 in.) 2, 3, 6 5170 mm (203.5 in.) 2, 3, 7 5150 mm (202.8 in.) 2, 3, 8 5095 mm (200.6 in.) Overall length...
Page 917 9-1. Specifications 1645 mm (64.8 in.) 22, 23 Front 1650 mm (65.0 in.) 1680 mm (66.1 in.)* Tread 1640 mm (64.6 in.) 22, 23 Rear 1645 mm (64.8 in.) 1675 mm (65.9 in.)* : Vehicles with back door mounted spare tire : Vehicles without back door mounted spare tire : Vehicles with pintle hook : Vehicles with towing hitch...
Page 918 9-1. Specifications Weights (with towing hitch) Gross vehicle mass 3350 kg (7385 lb.) 1630 kg (3593 lb.) Front Maximum permissible 1700 kg (3747 lb.) axle capacity Rear 1950 kg (4299 lb.) Drawbar load 140 kg (309 lb.) With brake 3500 kg (7716 lb.) Towing capacity Without brake 750 kg (1653.5 lb.)
Page 919 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. It is forbidden to cover, paint, weld, drill, alter or remove the vehicle identification number (VIN).
Page 920 9-1. Specifications This number is also on the manufacturer’s label (except GCC countries , Yemen, Iraq, Lebanon and Jordan) or the Certification Regulation label (GCC countries , Yemen, Iraq, Lebanon and Jordan). : Saudi Arabia, Sultanate of Oman, Bahrain, United Arab Emirates, Qatar, Kuwait Year of manufacture and country of origin (GCC countries ■...
Page 921 9-1. Specifications Engine  Gasoline engine Model 3UR-FE, 1UR-FE, 1GR-FE  3UR-FE and 1UR-FE engines 8-cylinder V type, 4-cycle, gasoline Type  1GR-FE engine 6-cylinder V type, 4-cycle, gasoline  3UR-FE engine 94.0  102.0 mm (3.70  4.02 in.) ...
Page 922 9-1. Specifications  3UR-FE engine 530 N•m @ 3200 rpm  1UR-FE engine Maximum torque (NET) 439 N•m @ 3400 rpm  1GR-FE engine 385 N•m @ 4400 rpm  3UR-FE engine 270 kW @ 5600 rpm  1UR-FE engine Maximum output (NET) 227 kW @ 5500 rpm ...
Page 923 9-1. Specifications  Vehicles with an automatic transmission 173 kW @ 3200 rpm Maximum output (NET)  Vehicles with a manual transmission 162 kW @ 3600 rpm : For vehicles with model code that has “V” as the last letter : The model code is indicated on the manufacturer’s label or the Certifica- tion Regulation label.
Page 924 9-1. Specifications  Diesel engine Fuel type Diesel fuel only  Vehicles with diesel exhaust gas recirculation system 48 or higher  Vehicles without diesel exhaust gas recirculation system (Below altitude Except for 1500 m [4922 ft.]) Argentina 44 or higher Cetane number ...
Page 925 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 926 9-1. Specifications Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 927 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 928 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 929 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 930 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 931 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 932 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 933 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 934 9-1. Specifications Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 935 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 936 9-1. Specifications Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 937 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: API CF-4, CF or ACEA B3, B4, B5 or JASO DL-0...
Page 938 9-1. Specifications How to read oil container label: Japanese Automobile Standard Organization (JASO) DL-0 Mark is added to some oil containers to help you select the oil you should use. Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability.
Page 939 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
Page 940 9-1. Specifications Cooling system Capacity (Reference)  With rear heater 16.2 L (17.1 qt., 14.3 Imp.qt.) 3UR-FE engine  Without rear heater 13.4 L (14.2 qt., 11.8 Imp.qt.)  With rear heater 17.0 L (18.0 qt., 15 Imp.qt.) With ATF warmer ...
Page 941  Without rear heater heater 14.8 L (15.6 qt., 13.0 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-...
Page 942 Toyota Genuine Differential Gear Oil LT viscosity differential 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification.
Page 943 Toyota dealer. NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Manual transmission Oil capacity 3.0 L (3.2 qt., 2.6 Imp.qt.)
Page 944 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 945 9-1. Specifications Chassis lubrication Spider Lithium base chassis grease, NLGI No.2 Propeller Molybdenum-disulfide lithium base shafts Slide yoke chassis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 30 mm (1.18 in.) ® Automatic transmission fluid DEXRON Power steering fluid type II or III Electrical winch...
Page 946 9-1. Specifications Tires and wheels  20-inch tires Tire size 285/50R20 112V Front tire Rear tire Vehicle speed kPa (kgf/cm kPa (kgf/cm or bar, psi) or bar, psi) Tire inflation pressure More than (Recommended cold 160 km/h 230 (2.3, 33) 260 (2.6, 38) tire inflation pressure) (99 mph)
Page 947 9-1. Specifications  17-inch tires (type A) Tire size 285/65R17 116H Front tire Rear tire Tire inflation pressure (Recommended cold (kgf/cm or bar, psi) (kgf/cm or bar, psi) tire inflation pressure) 230 (2.3, 33) 230 (2.3, 33) 17  8J Wheel size ...
Page 948 9-1. Specifications Light bulbs Light bulbs Type Headlights Low beam (Halogen bulbs High beam (Halogen bulbs Front turn signal lights Front position lights Side turn signal lights (Front fender type) Exterior Rear turn signal lights Back-up lights Stop/tail lights (Double back door) 21/5 Rear fog lights Running board lights...
Page 949: Fuel Information
9-1. Specifications Fuel information ◆ Gasoline engine 3UR-FE and 1UR-FE engines:  Except for GCC countries , Yemen, Iraq, Lebanon and Jordan You must only use unleaded gasoline. Select unleaded gasoline with a Research Octane Number of 91 (octane rating 87) or higher for optimum engine performance. For GCC countries , Yemen, Iraq, Lebanon and Jordan ...
Page 950 ■ Use of biodiesel blended fuel in a diesel engine (for Indonesia) Toyota recommends the use of diesel fuel blended with up to 5% biodiesel FAME (B5). If the engine is operated with biodiesel blended fuel with more than 5% FAME (B5), fuel filter replacement intervals tend to become shorter.
Page 951 TOYOTA ARGENTINA S.A. declina toda responsabilidad por daños debidos al empleo de gasoil con contenido de azufre superior a 50 ppm. Verifique esta información en la estación de servicio antes de cargar combustible.
Page 952: 9-2. Customization
Your vehicle includes a variety of electronic features that can be personalized to suit your preferences. The settings of these fea- tures can be changed by using the navigation system, the multi- media system or the multi-information display, or at your Toyota dealer. Customizing vehicle features...
Page 953 9-2. Customization Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using navigation system Settings that can be changed using the multi-information display Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, –...
Page 954 9-2. Customization Customized Function Default setting setting Open: short press with the back door unlocked Close: short press Open: Press Open: Press twice with the Opening/closing for 1 second back door power back door using with the back unlocked — —...
Page 955 9-2. Customization (  P. 163) and wireless remote Smart entry & start system ■ control (  P. 128) Customized Function Default setting setting Operation signal (Emer- — gency flashers) Operation signal (Buzz- — — ers) 1 to 7 Open door warning func- tion (when locking the —...
Page 956 9-2. Customization Door lock (  P. 134) ■ Customized Function Default setting setting Driver’s door All doors unlocked in Unlocking using a key unlocked in one step, all — — one step doors unlocked in two steps Speed linked door locking —...
Page 957 9-2. Customization Power windows (  P. 254) ■ Customized Function Default setting setting Mechanical linked — — 1, 2 operation (close) Mechanical linked — — 1, 2 operation (open) Wireless remote control — — 1, 2 linked operation (close) Wireless remote control...
Page 958 9-2. Customization (  P. 258) Moon roof ■ Customized Function Default setting setting Mechanical linked — — 1, 2 operation (open) Mechanical linked — — 1, 2 operation (close) Linked operation of com- ponents when door key is Slide only Tilt only —...
Page 959 9-2. Customization Illumination (  P. 680) ■ Customized Function Default setting setting Interior lights illumination — — control Time period before the 15 seconds 7.5 seconds — interior lights turn off 30 seconds Operation after the engine — — switch is turned off Operation when the doors —...
Page 960 Standard Long — — Welcome lighting illumina- — — tion control : If equipped (  P. 414) Toyota parking assist-sensor ■ Customized Function Default setting setting Detection distance of the Near — rear center sensor Alert Volume (alert volume 1 to 5 —...
Page 961 9-2. Customization (  P. 658) Automatic air conditioning system ■ Customized Function Default setting setting Switching between out- side air and recirculated air Auto Manual — mode linked to “AUTO” switch operation A/C Auto switch operation Auto Manual — : If equipped ( ...
Page 962 9-2. Customization Front seat heaters and ventilators (P. 676) ■ Customized Function Default setting setting Adjustment of the front seat heater temperature or the ventilator fan speed Level 3 Level 1 (low) to — — during automatic opera- (standard) level 5 (high) tion (individual seat adjust- ment available) : If equipped...
Page 963 9-2. Customization Multi-information display (P. 115) ■ Default Customized Function setting setting Language English — — km (km/L) Units km (L/100km) — miles (MPG) Eco Driving Indicator Light — — Drive Desired status switch settings — — information 1 screen Current fuel Drive information screen consumption...
Page 964 9-2. Customization LDA (Lane Departure Alert) (P. 386) ■ Default Customized Function setting setting Alert sensitivity Standard High — — Vehicle sway warning — — Vehicle sway warning Standard — — sensitivity High : If equipped BSM (Blind Spot Monitor) (P.
Page 965 9-2. Customization ■ Vehicle customization ● If the smart entry & start system is turned off, unlock door cannot be selected. ● If the doors are not opened after unlocking and are then automatically re- locked, a signal will be given if Operation signal (Emergency flashers) or Operation signal (Buzzer) are set to on.
Page 966: 9-3. Initialization
9-3. Initialization Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference • When rotating the tires on vehicles differing with front and rear tire inflation pres- sures.
Page 967: Appendix
Appendix What to do if... (Troubleshooting) .....966 For vehicles with a navigation system or a multimedia sys- tem, refer to the “Navigation system Owner’s manual”, “Navi- gation and Multimedia System Owner’s Manual” or “Multimedia Owner’s Manual” for information regarding the equipment listed below.
Page 968 You lose your keys ● If you lose your keys or mechanical keys, new genuine keys or mechanical keys can be made by your Toyota dealer. (P. 131) ● Vehicles with a smart entry & start system If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 969 What to do if... (Troubleshooting) The rear door cannot be opened ● Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock.
Page 970 What to do if... (Troubleshooting) The engine does not start (vehicles with a smart entry & start system) ● Did you press the engine switch while firmly depressing the brake pedal? (P. 306) ● Vehicles with an automatic transmission Is the shift lever in P? (P. 306) ●...
Page 971 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without a smart entry & start system It is locked to prevent theft of the vehicle if the key is removed from the engine switch.
Page 972 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 850) ● The brake system warning light is on Is the parking brake released? (P.
Page 973 What to do if... (Troubleshooting) A warning light turns on or a warning message is displayed ● When a warning light turns on or a warning message is displayed, refer to P. 847, 858. When a problem has occurred If you have a flat tire ●...

Toyota LAND CRUISER LC200 Owner's Manual

1 For Safety and Security

2 Instrument Cluster

4 Wheel AHC (Active Height Control Suspension)

5 Audio System

6 Interior Features

7 Maintenance and Care

8 When Trouble Arises

9 Vehicle Specifications

Appendix

Quick Links

Related Manuals for Toyota LAND CRUISER LC200

Summary of Contents for Toyota LAND CRUISER LC200
