  • Page 1: User Manual

    User Manual C23A750X / C27A750X The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. BN46-00037E-01...

  • Page 2: Before Using The Product

    2011 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.
  • Page 3 Before Using the Product Activities marked by this symbol are prohibited. Instructions marked by this symbol must be followed. Before Using the Product...

  • Page 4: Cleaning

    Before Using the Product Cleaning Cleaning Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. Take the following steps when cleaning. 1. Power off the monitor and computer. 2. Disconnect the power cord from the monitor. 3.

  • Page 5: Securing The Installation Space

    High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used nearby. Be sure to contact Samsung Customer Service Center (page91) if the inside of the monitor needs cleaning. (service fee will be charged). Safety Precautions Electricity and Safety The following images are for reference only.
  • Page 6 Before Using the Product Warning Do not use a damaged power cord or plug, or a loose power socket. An electric shock or fire may result. Do not plug many products into the same power socket. Otherwise, the socket may overheat and cause a fire. Do not touch the power plug with wet hands.

  • Page 7: Installation

    The product may become damaged by an electric shock. Do not use the power cord for products other than authorized products supplied by Samsung. An electric shock or fire may result. Keep the power socket where the power cord is connected unobstructed.
  • Page 8 Before Using the Product Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.). The product may fall and break or cause a personal injury. Using the product in an area with excess vibration may damage the product or cause a fire.

  • Page 9: Operation

    Be sure to consult Samsung Customer Service Center (page91) before installation if you want to install the product at such a place.
  • Page 10 Before Using the Product Do not put a heavy object, toy, or sweets on top of the product. The product or heavy objects may fall as children try to reach for the toy or sweets resulting in a serious injury. During a lightning or thunderstorm, remove the power cord and do not touch the antenna cable.
  • Page 11 (paper, match, etc.) into the vent or ports of the product. If water or any foreign substance enters the product, be sure to power off the product, remove the power cord, and contact Samsung Customer Service Center (page91). Product failure, an electric shock or fire may result.
  • Page 12 Before Using the Product Do not let water enter the DC power device or get the device wet. An electric shock or fire may result. Avoid using the product outdoors where it can be exposed to rain or snow. Be careful not to get the DC power adapter wet when you wash the floor. Do not put the DC power adapter near to any heating apparatus.

  • Page 13: Correct Posture To Use The Product

    Before Using the Product Exercise caution when adjusting the product angle or stand height. Do not place heavy objects on the product. Correct posture to use the product Use the product in the correct posture as follows: Straighten your back. Allow a distance of 45 to 50cm between your eye and the screen, and look slightly downward at the screen.

  • Page 14: Table Of Contents

    Adjusting the Product Tilt and Height About "HUB Monitor" Software Installation for Using "HUB Monitor" Installing "SAMSUNG HUB Monitor Setup" Connecting the Product to a PC to Use "HUB Monitor" Connecting to a PC via Wireless USB Connecting to a PC via the USB Cable Utilizing "HUB Monitor"...
  • Page 15 Setting Optimum Resolution Changing the Resolution Using a PC Connecting to a Video Device Connection Using an HDMI Cable Connecting Headphones MAGIC SAMSUNG MAGIC Angle SAMSUNG MAGIC Bright Configuring SAMSUNG MAGIC Color Brightness Configuring Brightness Contrast Configuring Contrast Sharpness Configuring Sharpness Coarse...
  • Page 16 Table Of Contents CONFIGURING TINT RESIZING OR RELOCATING THE SCREEN Response Time Configuring Response Time HDMI Black Level Configuring Red Green Configuring Green Blue Configuring Blue Color Tone Configuring the Color Tone Settings Gamma Configuring Gamma Auto Adjustment Configuring the Auto Adjustment Settings Size Changing the Picture Size Horizontal Position...
  • Page 17 Table Of Contents SETUP AND RESET INFORMATION MENU AND OTHERS Auto Wireless Detection Wireless Connection USB Connection Analog HDMI USB Super Charging Wireless ID Eco Saving Configuring Eco Saving Menu Transparency Changing Menu Transparency Language Changing the Language PC/AV Mode Configuring PC/AV Mode Auto Source Configuring Auto Source...
  • Page 18 Configuring Brightness in the Startup Screen Configuring Volume in the Startup Screen Configuring HUB in the Initial Screen Requirements Before Contacting Samsung Customer Service Center Testing the Product Checking the Resolution and Frequency Check the followings. Q & A General...

  • Page 19: Preparations

    Preparations Checking the Contents 1.1.1 Removing the Packaging Open the packaging box. Be careful not to damage the product when you open the packaging with a sharp instrument. Remove the Styrofoam from the product. Check the components and remove the Styrofoam and plastic bag. The appearance of actual components may differ from the image shown.

  • Page 20: Checking The Components

    Preparations 1.1.2 Checking the Components Contact the dealer from whom you purchased the product if any item is missing. The appearance of the components and items sold separately may differ from the image shown. Components Quick Setup Guide Wireless Connection Dongle USB 3.0 cable Cleaning cloth Components may differ in different locations.
  • Page 21 Preparations Items sold separately The following items can be purchased at your nearest retailer. LAN cable HDMI-DVI cable USB cable 1 Preparations...

  • Page 22: Parts

    Preparations Parts 1.2.1 Frontal Buttons The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. This is a touch-type button. Tap the button lightly with a finger. The printed board assembly (PBA) inside this product may heat the stand. A hot stand does not indicate a problem with the product.
  • Page 23 Preparations Icons Description Open or close the onscreen display (OSD) menu, or return to the last menu. OSD control lock: Maintain the current settings, or lock the OSD control to prevent unintended changes to settings. To lock the OSD control, press the MENU button [ seconds.

  • Page 24: Reverse Side

    Preparations 1.2.2 Reverse Side The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Port Description Connects to a PC using the D-SUB cable. Connects to a network using the LAN cable. Connects to a PC via a USB cable.

  • Page 25: Left Side View

    Preparations 1.2.3 Left Side View The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Port HDMI IN HDMI IN Description Connects to an audio output device such as headphones. Connects to a source device using an HDMI cable.

  • Page 26: Right Side View

    Preparations 1.2.4 Right Side View The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Port Description Connects to a source device via a USB cable. Compatible with a USB cable version 2.0 or lower.

  • Page 27: Adjusting The Product Tilt And Height

    Preparations 1.2.5 Adjusting the Product Tilt and Height The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. The monitor tilt and height can be adjusted. Hold the top center of the product and adjust the tilt carefully. 1 Preparations...

  • Page 28: Using "Hub Monitor

    Insert the installation CD into the CD-ROM drive. Click the "SAMSUNG HUB Monitor Setup" installation program. If a software installation window does not appear in the main screen, install using the "SAMSUNG HUB Monitor Setup > CA750X_HUB_Monitor.exe" execution file on the CD-ROM.

  • Page 29: Connecting The Product To A Pc To Use "Hub Monitor

    Using "HUB Monitor" After installing the integrated PC driver "Samsung HUB Monitor Setup," customize the audio output port settings as required. (Control Panel->Audio->Speaker->Speaker Setup) "SAMSUNG HUB Monitor Setup" software consists of "Samsung Wireless HUB Monitor" and "Samsung Wireless Monitor". To delete the software, go to Start and double-click Add or Remove Programs on the PC.

  • Page 30: Connecting To A Pc Via Wireless Usb

    Using "HUB Monitor" according to this priority, from left to right: mode. If the product connects to a PC for the first time, the optimum resolution (1920 x 1080) will be selected automatically and a message will appear confirming that you want to set the display to extended mode. The same resolution will be applied from the next time the product connects to the PC.
  • Page 31 This product cannot connect to multiple PCs wirelessly at the same time and vice versa. Connecting to a PC via Wireless USB Install "Samsung HUB Monitor Setup" on the PC, and attach the dongle to the USB port on the PC. Press [ ] to change the input source for the product to Wireless.
  • Page 32 "Monitor device" matches the wireless ID on the is a unique ID assigned to a monitor. The “SAMSUNG HUB Monitor Setup” ] will appear over the signal intensity ] does not appear, the menu menu.

  • Page 33: Connecting To A Pc Via The Usb Cable

    Using "HUB Monitor" Rename: Customize the name of the connected monitor. The program will automatically activate to allow you to use the Wireless USB connection even when the "Wireless Display" window is closed. Automatic/manual Wireless USB connection Auto Wireless Detection connection will automatically be established if the product is within 1.5 m from the PC.

  • Page 34: Utilizing "Hub Monitor

    Using "HUB Monitor" Utilizing "HUB Monitor" HUB Monitor is only available when the product is connected to a PC via Wireless USB or a USB cable. 2.4.1 Using the Product as a USB HUB Using the product as a hub, connect and use various source devices with the product at the same time. A PC cannot connect to multiple source devices at the same time as it has a limited number of input/ output ports available.

  • Page 35: Connecting To A Lan

    Using "HUB Monitor" An external mass-storage HDD requires external power supply. Be sure to connect it to a power source. Connect a mobile IT device such as an MP3 player or smart phone to the product when connected to a PC.

  • Page 36: Configuring The Hub Monitor Ip

    Using "HUB Monitor" This is achieved by an internal chip that transmits data received via the LAN cable to the PC as a converted USB signal. Connecting to a LAN via Wireless USB Connecting to a LAN via USB cable This product cannot connect to multiple source PCs at the same time and vice versa.
  • Page 37 Using "HUB Monitor" network information such as the IP address to the PC, and the transmitted network information is automatically registered to the network settings on the PC. The DHCP service is convenient and useful especially in an environment where multiple PCs are used. Theoretically, the IP address changes each time the PC boots up (or an IP allotment request is sent);...

  • Page 38: Static Ip

    Using "HUB Monitor" Select Properties 2.5.2 Static IP To configure the IP address (private or official) on your PC, someone (mostly a server system) must distribute and allot an IP address to the PC. An official IP address is allotted by your Internet service provider, and a private IP address is allotted by your Internet router.
  • Page 39 Using "HUB Monitor" LAN9514 USB 2.0 to Ethernet 10/100 Adapter #7”), select Properties Version 4 (TCP/IPv4) After configuring the IP, click OK. The following message will appear. A static IP must be allotted to only one network device. The following message will appear if the same static IP is allotted to the network devices of both the notebook PC and HUB Monitor.

  • Page 40: Notice Before Your Use Of Wireless Usb Or Usb Mode

    Using "HUB Monitor" Notice before your use of Wireless USB or USB Mode Most of the games require high resolution and fast response time. When you play a game, we recommend to use Analog Game and Movie clips on Windows XP or VISTA is not supported. When Wireless USB/USB may take some time to acknowledge for...

  • Page 41: Connecting And Usinga Source Device

    Connecting and Using a Source Device Before Connecting 3.1.1 Pre-connection Checkpoints Before connecting a source device, read the user manual provided with it. The number and locations of ports on source devices may differ from device to device. Do not connect the power cable until all connections are completed. Connecting the power cable during connection may damage the product.

  • Page 42: Connecting And Using A Pc

    Connecting and Using a Source Device Connecting and Using a PC 3.2.1 Connecting to a PC Select a connection method suitable for your PC. Connecting parts may differ in different products. Connection using the D-SUB cable (Analogue type) Connect the D-SUB cable to the D-SUB port on the back of the product and the RGB port on the Connect the DC power adapter to the product and a power socket, and turn on the power switch on the PC.
  • Page 43 Connecting and Using a Source Device Connection Using an HDMI Cable (Digital Type) Connect an HDMI cable to the HDMI port on the side of the product and the HDMI port on the PC. Connect the DC power adapter to the product and a power socket, and turn on the power switch on the PC.

  • Page 44: Driver Installation

    An installation driver is contained on the CD supplied with the product. If the file provided is faulty, visit the Samsung homepage (http://www.samsung.com) and download the file. Insert the user manual CD provided with the product into the CD-ROM drive.

  • Page 45: Setting Optimum Resolution

    Connecting and Using a Source Device 3.2.3 Setting Optimum Resolution An information message about setting optimum resolution will appear if you power on the product for the first time after purchase. Select a language and change the resolution to the optimum value. Press [ ] to move to the language you want and press the [ To hide the information message, press [...

  • Page 46: Changing The Resolution Using A Pc

    Connecting and Using a Source Device 3.2.4 Changing the Resolution Using a PC Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture quality. The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected. Changing the Resolution on Windows XP Go to Control Panel Display...
  • Page 47 Connecting and Using a Source Device Changing the Resolution on Windows Vista Go to Control Panel → Personalization → Display Settings and change the resolution. 3 Connecting and Using a Source Device...
  • Page 48 Connecting and Using a Source Device Changing the Resolution on Windows 7 Go to Control Panel → Display → Screen Resolution and change the resolution. 3 Connecting and Using a Source Device...

  • Page 49: Connecting To A Video Device

    Connecting and Using a Source Device Connecting to a Video Device The product can be connected to a video device. Connecting parts may differ in different products. 3.3.1 Connection Using an HDMI Cable Connect an HDMI cable to the HDMI ports on the product and video device. Press [ ] to change the input source to HDMI.

  • Page 50: Screen Setup

    Configure the screen settings such as brightness and color tone. MAGIC This feature provides the viewing angle, brightness, and tint to suit your preferences. 4.1.1 SAMSUNG MAGIC Angle Angle allows you to configure the settings to obtain the optimum picture quality according to your viewing angle.

  • Page 51: Samsung Magic Bright

    Press [ ] to move to the option you want and press the [ The selected option will be applied. 4.1.2 SAMSUNG MAGIC Bright This menu provides an optimum picture quality suitable for the environment where the product will be used.

  • Page 52: Configuring Samsung Magic Color

    The selected option will be applied. 4.1.3 Configuring SAMSUNG MAGIC Color Color is a new picture-quality improvement technology developed independently by Samsung, which delivers vivid natural colors without picture quality degradation. This menu is not available when Not available when...

  • Page 53: Brightness

    Press [ ] to move to Press [ ] to move to Adjust the Brightness Color and press [ ] on the product. The following screen will MAGIC SAMSUNG Angle MAGIC SAMSUNG MAGIC Bright Custom SAMSUNG MAGIC Color Demo Full...

  • Page 54: Contrast

    Screen Setup Contrast Adjust the contrast between the objects and background. (Range: 0~100) A higher value will increase the contrast to make the object appear clearer. This option is not available when 4.3.1 Configuring Contrast Press [ ] on the product. Press [ ] to move to Press [...

  • Page 55: Coarse

    Screen Setup Press [ ] to move to Adjust the Sharpness Coarse Adjust the screen frequency. Only available in Analog 4.5.1 Adjusting Coarse Press [ ] on the product. Press [ ] to move to Press [ ] to move to Adjust the Coarse using the [...

  • Page 56: Fine

    Screen Setup Fine Fine-adjust the screen to obtain a vivid picture. Only available in Analog 4.6.1 Adjusting Fine Press [ ] on the product. Press [ ] to move to Press [ ] to move to Adjust the Fine using the [ Response Time Accelerate the panel response rate to make video appear more vivid and natural.

  • Page 57: Hdmi Black Level

    Screen Setup Press [ ] to move to appear. Press [ ] to move to the option you want and press the [ The selected option will be applied. HDMI Black Level If you use the product by connecting to a DVD player or set-top box with a color may degrade and the picture may be darker.

  • Page 58: Configuring Tint

    Configuring Tint Adjust the tint of the screen. This option is not available when Dynamic Contrast mode. Adjust the value of the color red in the picture. (Range: 0~100) A higher value will increase the intensity of the color. This option is not available when 5.1.1 Configuring Red Press [ ] on the product.

  • Page 59: Blue

    Configuring Tint Press [ ] to move to Adjust the Green using the [ Blue Adjust the value of the color blue in the picture. (Range: 0~100) A higher value will increase the intensity of the color. This option is not available when 5.3.1 Configuring Blue Press [ ] on the product.

  • Page 60: Color Tone

    Configuring Tint Color Tone Adjust the general color tone of the picture. This option is not available when This option is not available when 5.4.1 Configuring the Color Tone Settings Press [ ] on the product. Press [ ] to move to Press [ ] to move to Cool2: Set the color temperature to be cooler than Cool1.

  • Page 61: Gamma

    Configuring Tint Gamma Adjust the mid-range brightness (Gamma) of the picture. This option is not available when 5.5.1 Configuring Gamma Press [ ] on the product. Press [ ] to move to Press [ ] to move to Press [ ] to move to the option you want and press the [ The selected option will be applied.

  • Page 62: Resizing Or Relocating The Screen

    Resizing or Relocating the Screen Auto Adjustment This function can be used to automatically adjust the Coarse, This function can be used to automatically detect and remove noise on the screen and correct the screen position. This function will automatically run if the screen resolution is changed. Only available in Analog 6.1.1 Configuring the Auto Adjustment Settings...

  • Page 63: Horizontal Position

    Resizing or Relocating the Screen Auto: Display the picture according to the aspect ratio of the input source. Wide: Display the picture in full screen regardless of the aspect ratio of the input source. mode 4:3: Display the picture with an aspect ratio of 4:3. Suitable for videos and standard broadcasts. 16:9: Display the picture with an aspect ratio of 16.9.

  • Page 64: Vertical Position

    Resizing or Relocating the Screen Press [ ] to move to Adjust the H-Position Vertical Position Move the screen up or down. Only available in H-Position V-Position 6.4.1 Configuring V-Position Press [ ] on the product. Press [ ] to move to Press [ ] to move to Adjust the...

  • Page 65: Menu H-Position

    Resizing or Relocating the Screen Menu H-Position Move the menu position to the left or right. 6.5.1 Configuring Menu H-Position Press [ ] on the product. Press [ ] to move to Press [ ] to move to appear. Adjust the Menu H-Position SIZE&POSITION and press [...

  • Page 66: Menu V-Position

    Resizing or Relocating the Screen Menu V-Position Move the menu position up or down. 6.6.1 Configuring Menu V-Position Press [ ] on the product. Press [ ] to move to Press [ ] to move to appear. Adjust the Menu V-Position SIZE&POSITION and press [ ] on the product.

  • Page 67: Setup And Reset

    Setup and Reset Configure the settings to use the HUB function on the product. Refer to "2.1 About "HUB Monitor"" for details about how to use the To open the 7.1.1 Auto Wireless Detection If the product is connected to a PC via Wireless USB, it will automatically detect the Wireless USB signal and change the input source to Configuring Auto Wireless Detection Press [...

  • Page 68: Usb Connection

    Setup and Reset Activating Wireless Connection Press [ ] on the product. Press [ ] to move to Press [ ] to move to Wireless USB connection is established or disconnected. If a Wireless USB connection is established, press [ ].

  • Page 69: Analog

    Setup and Reset 7.1.4 Analog You can view the Analog cable connection status between the product and a PC. The connection status will be shown even when the input source is not Selecting the Analog Analog mode. Configuring Analog Press [ ] on the product.

  • Page 70: Usb Super Charging

    Setup and Reset If an HDMI cable is connected, press [ change to HDMI mode. 7.1.6 USB Super Charging A source device's battery can be charged quickly via USB 3.0 port on the product. Data transmission is not available if To enable standard charging or data transmission, set The input source does not need to be changed.

  • Page 71: Wireless Id

    ID assigned to a monitor. The "Samsung HUB Monitor Setup" program reads the ID and identifies each of nearby monitors. The ID is shown in the "Samsung HUB Monitor Setup" program and in the lower part of the Eco Saving Adjust the power consumption of the product to save energy.

  • Page 72: Menu Transparency

    Setup and Reset Menu Transparency Set the transparency for the menu windows: 7.3.1 Changing Menu Transparency Press [ ] on the product. Press [ ] to move to Press [ ] to move to appear. Press [ ] to move to the option you want and press the [ The selected option will be applied.

  • Page 73: Pc/Av Mode

    Setup and Reset Press [ ] to move to Press [ ] to move to the option you want and press the [ The selected option will be applied. PC/AV Mode PC/AV Mode to AV. The picture size will be enlarged. This option is useful when you view a movie. PC/AV Mode is only available in 7.5.1 Configuring PC/AV Mode...

  • Page 74: Auto Source

    Setup and Reset Auto Source Activate Auto Source. 7.6.1 Configuring Auto Source Press [ ] on the product. Press [ ] to move to Press [ ] to move to appear. Auto: The input source is automatically recognized. Manual: Manually select an input source. Press [ ] to move to the option you want and press the [ The selected option will be applied.

  • Page 75: Key Repeat Time

    Setup and Reset Press [ ] to move to appear. Press [ ] to move to the option you want and press the [ The selected option will be applied. Key Repeat Time Control the response rate of a button when the button is pressed. 7.8.1 Configuring Key Repeat Time Press [ ] on the product.

  • Page 76: Off Timer On/Off

    Setup and Reset Off Timer On/Off Enable or disable the off timer that automatically powers off the product. 7.9.1 Configuring Off Timer On/Off Press [ ] on the product. Press [ ] to move to Press [ ] to move to appear.

  • Page 77: Reset

    Setup and Reset Press [ ] to move to appear. Press [ ] to configure 7.11 Reset Return all the settings for the product to the default factory settings. 7.11.1 Initializing Settings (Reset) Press [ ] on the product. Press [ ] to move to Press [ ] to move to...

  • Page 78: Information Menu And Others

    INFORMATION Menu and Others INFORMATION View the current input source, frequency and resolution. 8.1.1 Displaying INFORMATION Press [ ] on the product. Press [ ] to move to INFORMATION. The current input source, frequency and resolution will appear. Configuring Brightness in the Startup Screen Adjust Brightness using the [...

  • Page 79: Configuring Volume In The Startup Screen

    INFORMATION Menu and Others Configuring Volume in the Startup Screen Adjust Volume using the [ available. Only available in HDMI Press [ ] in the startup screen. The following screen will appear. Adjust the Volume using the [ ] button in the startup screen where there is no on screen display menu mode.

  • Page 80: Configuring Hub In The Initial Screen

    INFORMATION Menu and Others Configuring HUB in the Initial Screen The HUB settings screen can be opened by pressing the [ screen (that displays no OSD menu) is displayed. Press the [ ] button when the initial screen is displayed. You can configure the settings for Analog, HDMI...

  • Page 81: Troubleshooting Guide

    Requirements Before Contacting Samsung Customer Service Center 9.1.1 Testing the Product Before calling Samsung Customer Service Center, test your product as follows. If the problem persists, contact Samsung Customer Service Center. Check if your product is operating normally by using the product test function.
  • Page 82 Troubleshooting Guide "Not Optimum Mode" is displayed. The images on the screen look distorted. The screen is not clear. The screen is blurry. The screen appears unstable and shaky. There are shadows or ghost images left on the screen. The screen is too bright. The screen is too dark. Screen color is inconsistent.
  • Page 83 Troubleshooting Guide The volume is too low. A beeping sound is heard when my PC is booting. If a beeping sound is heard when your PC is Sound issue Adjust the volume. If the volume is still low after turning it up to the maximum level, adjust the volume on your PC sound card or software program.
  • Page 84 Troubleshooting Guide Q & A Question How can I change the frequency? Answer Set the frequency on your graphics card. Windows XP: Select Control Panel Themes Display Settings → → adjust Refresh rate under Monitor settings. Windows ME/2000: Select Control Panel Display Settings...
  • Page 85 Troubleshooting Guide Question How can I change the resolution? How do I set power-saving mode? Refer to the user manual for your PC or graphics card for further instructions on adjustment. Answer Windows XP: Go to Control Panel → Themes Display Settings and adjust the resolution.

  • Page 86: Specifications

    Specifications 10.1 General Model Name Panel Size Display area Synchroni Horizontal zation Frequency Vertical Frequency Display Color Resolution Optimum resolution Maximum resolution Maximum Pixel Clock Power Supply Signal connectors Dimensions (W x H x D) / Weight Environme Operating ntal considerat Storage ions...

  • Page 87: Powersaver

    Hereby, Samsung Electronics, declares that this [MONITOR] is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The official Declaration of Conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.
  • Page 88 Specifications To reduce the power consumption to 0 watts, turn off the power switch on the back of the product or disconnect the power cable. Be sure to disconnect the power cable when you will not be using the product for an extended period of time. To reduce the power consumption to 0 watts when the power switch is not available, disconnect the power cable.

  • Page 89: Standard Signal Mode Table

    Specifications 10.3 Standard Signal Mode Table This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Therefore, a resolution other than the specified resolution may degrade the picture quality.

  • Page 90: Pc Dongle Specification (Uwb : Ultra Wide Band)

    Specifications 10.4 PC Dongle Specification (UWB : Ultra Wide Band) Standard Host Interface Frequency Range Security Data Rate Sensitivity / Output Power Power Consumption Supported Models Dimension USB 2.0 Downstream Interface 3.1GHz ~ 10.6Ghz (Operating 3.16GHz ~ 8.97Ghz, BG1, BG2, BG6) AES128 53.3 to 480 Mbps Transmitted signal PSD -41.3 dBm/MHz...

  • Page 91: Appendix

    Appendix Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. ALBANIA AUSTRIA BELGIUM BOSNIA BULGARIA CROATIA CZECH DENMARK FINLAND FRANCE GERMANY GREECE HUNGARY ITALIA KOSOVO LUXEMBURG MACEDONIA MONTENEGRO...
  • Page 92 ± GLQ RULFH UH HD WDULI QRUPDO SERBIA 0700 Samsung (0700 726 7864) SLOVAKIA 0800 - SAMSUNG (0800-726 786) SPAIN 902 - 1 - SAMSUNG (902 172 678) SWEDEN 0771 726 7864 (SAMSUNG) SWITZERLAND 0848-SAMSUNG (7267864, CHF 0.08/min) 0330 SAMSUNG (7267864)

  • Page 93: Correct Disposal Of This Product

    Appendix Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

  • Page 94: Terminology

    Appendix Terminology OSD(On Screen Display) On screen display (OSD) allows you to configure on-screen settings to optimize the picture quality as required. It allows you to change the screen brightness, tint, size and many other settings using menus displayed on the screen. HUB refers to a device that is a common connection point for multiple devices connected over a network.
  • Page 95 Appendix the screen refreshes 60 times per second. The screen scanning rate depends on the performance of the graphics cards in your PC and monitor. Horizontal Frequency Characters or images displayed on the monitor screen consist of numerous dots (pixels). Pixels are transmitted in horizontal lines, which are then arranged vertically to create an image.
  • Page 96 Connecting and Using a PC Connecting Headphones Connecting the Product to a PC to Use "HUB Monitor" Connecting to a Video Device Contact SAMSUNG WORLDWIDE Contrast Copyright Correct Disposal of This Product Correct posture to use the product Display Time...
  • Page 97 Index Off Timer Setting Parts PC/AV Mode PowerSaver Q & A Requirements Before Contacting Samsung Customer Service Center Reset Response Time Safety Precautions Sharpness Size Software Installation for Using "HUB Monitor" Standard Signal Mode Table Terminology Utilizing "HUB Monitor" Vertical Position...
