- Page 1 Wheeze Detector WheezeScan WHEEZE (HWZ-1000T-E) NO WHEEZE Instruction Manual Mode d’emploi Gebrauchsanweisung Manuale di istruzioni Manual de instrucciones Gebruiksaanwijzing Руководство по эксплуатации Kullanım Kılavuzu دليل اإلرشادات 19M2882...
-
Page 2: Table Of Contents
Table of Contents Introduction ................EN2 Safety Instructions ......................EN2 Intended Use ........................EN2 Receiving and Inspection ..................EN2 Important Safety Information ................EN3 1. Know Your Device .............EN7 1.1 Contents ........................EN7 1.2 Part Names ......................EN8 2. Installing Batteries ............EN9 3. Detecting Wheeze ............EN10 3.1 Taking a Measurement ..................EN10 3.2 Checking Result ....................EN14 4. -
Page 3: Introduction
Environment of use: home, clinic Receiving and Inspection Remove this device and other items from the packaging and inspect for damage. If this device or any other items are damaged, DO NOT USE and consult with your OMRON retail outlet or distributor. -
Page 4: Important Safety Information
Important Safety Information Read the Important Safety Information in this instruction manual before using this device. Follow this instruction manual thoroughly for your safety. Keep for future reference. For specific information about patient’s symptoms, CONSULT WITH A PHYSICIAN. Indicates a potentially hazardous situation which, if not WARNING avoided, could result in death or serious injury. - Page 5 • DO NOT use this device in places with high or low humidity or high or low temperatures. Refer to “Operating conditions” in section 7. • This device may not work when the sound sensor is damaged. If it happens, contact your OMRON retail outlet or distributor.
- Page 6 • Ensure that this device has acclimated to room temperature before taking a measurement. Taking a measurement after an extreme temperature change could lead to an inaccurate indication. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when the device is used in an environment within the temperature specified as operating conditions after it is stored either at the maximum or at the minimum storage temperature.
- Page 7 Important Safety Information • If battery fluid should get in patient’s or your eyes, immediately rinse with plenty of clean water. Consult with a physician immediately. • If battery fluid should get on patient’s or your skin, wash the skin immediately with plenty of clean, lukewarm water.
-
Page 8: Know Your Device
1. Know Your Device 1.1 Contents WHEEZE NO WHEEZE Device Storage case 2 “AAA” alkaline Instruction manual batteries Quick reference guide... -
Page 9: Part Names
1.2 Part Names WHEEZE NO WHEEZE Sound sensor Connection indicator Display [Connection] button Error symbol Battery symbol Low: flashes / Depleted: lights Power indicator [Power] button Battery compartment... -
Page 10: Installing Batteries
2. Installing Batteries When the “ ” symbol flashes, it is recommended that you replace the batteries. To replace batteries, turn the device off and remove batteries. Then replace with 2 new alkaline batteries. Note • Replacing batteries does not delete previous results recorded in the device. •... -
Page 11: Detecting Wheeze
3. Detecting Wheeze 3.1 Taking a Measurement Do not use the device in locations exposed to extreme temperatures, humidity, direct sunlight, dust or corrosive vapors such as bleach. CAUTION This device cannot be used in an environment with noise at 60 dB or above, such as: - near working vacuum cleaners, hair dryers or washing machines;... - Page 12 3.1 Taking a Measurement Remove clothes to expose patient’s chest. Being naked from the waist up is recommended. WARNING DO NOT place the sound sensor on clothes and DO NOT let clothes touch the device. This may cause an inaccurate result. ALWAYS place the sound sensor directly on the patient’s skin.
- Page 13 3.1 Taking a Measurement Press the button. The device will beep and the power indicator will Beep light green. Note WHEEZE • When the power is turned on, all indicators NO WHEEZE will light up for 2 seconds. Then, the previous measurement result (refer to section 3.2) will be Power indicator displayed for 2 seconds.
- Page 14 3.1 Taking a Measurement Apply the sound sensor to the patient’s skin. Place and adhere the sound sensor firmly. Place and adhere firmly Not adhering The device will beep twice and begin measuring. When the sound sensor is correctly placed on the body, the device gives twice the sound “beep”...
-
Page 15: Checking Result
3.2 Checking Result After the measurement, the result will be shown as pictured below. If wheezing is not detected, “No Wheeze” will light white. If wheezing is detected, “Wheeze” will light orange. WHEEZE WHEEZE NO WHEEZE NO WHEEZE Wheezing is NOT detected Wheezing is detected Note •... -
Page 16: Managing Results With Your Smart Device
4. Managing Results with Your Smart Device This device can pair with your smart device and you can manage the measurement results with your smart device using the “OMRON Asthma Diary” app. Review the list of compatible smart devices at: www.omron-healthcare.com/asthma-diary-compatibility... -
Page 17: Maintenance
5. Maintenance 5.1 Maintenance To protect the device from damage, please follow the directions below: • Store the device in a clean, safe location. • Changes or modifications not approved by the manufacturer will void the user warranty. WARNING • DO NOT disassemble or attempt to repair this device. This may cause an inaccurate result. -
Page 18: Troubleshooting
6. Troubleshooting If any of the below problems occur, check to make sure that no other electrical device is within 30 cm. If the problem persists, refer to the table below. Problem Possible cause Solution The sound sensor The measurement Place the sound sensor on the patient’s body within 30 seconds flashes orange and... - Page 19 NEVER diagnose or treat a patient taking measurements always changing. based only on the result. Consult with repeatedly. a physician if you are concerned. If you are not able to solve the problem, contact your OMRON retail outlet or distributor. EN18...
-
Page 20: Specifications
7. Specifications Product category Wheeze Detectors Product description Wheeze Detector Model (code) WheezeScan (HWZ-1000T-E) Patient age range From 4 months to 7 years old Power source 2 “AAA” alkaline batteries 3 V (2 x 1.5 V) Battery life Approx. 450 measurements (using new alkaline batteries) Durable period (service life) 5 years Bluetooth®... - Page 21 7. Specifications • These specifications are subject to change without notice. • IP classification is degrees of protection provided by enclosures in accordance with IEC 60529. This device is protected against solid foreign objects of 12.5 mm diameter and greater such as a finger, and against oblique falling water drops which may cause issues during a normal operation.
-
Page 22: Limited Warranty
This product is warranted by OMRON for a period of 3 years after the date of purchase. The proper construction, workmanship and materials of this product are warranted by OMRON. -
Page 23: Guidance And Manufacturer's Declaration
• The full text of the EU declaration of conformity is available at the following internet address: www.omron-healthcare.com • This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co., Ltd., Japan. • Please report to the manufacturer and the competent authority of the Member State in which you are established about any serious incident that has occurred in relation to this device. - Page 24 HWZ-1000T-E conforms to EN60601-1-2:2015 Electromagnetic Compatibility (EMC) standard. Further documentation in accordance with this EMC standard is available at www.omron-healthcare.com. Refer to the EMC information for HWZ-1000T-E on the website. Correct Disposal of This Product (Waste Electrical & Electronic Equipment) This marking shown on the product or its literature, indicates that it should not be disposed of, with other household wastes at the end of its working life.
-
Page 25: How The Device Works
10. How the Device Works What is asthma? Asthma is a condition in which the airways narrow and swell and produce extra mucus. This can make breathing difficult and trigger coughing, wheezing and shortness of breath. Asthma can’t be cured, but its symptoms can be controlled. Because asthma often changes over time, it’s important that you work with your doctor to track the signs and symptoms and adjust the treatment as needed. - Page 26 OMRON HEALTHCARE Co., Ltd. Manufacturer 53, Kunotsubo, Terado-cho, Muko, KYOTO, 617-0002 JAPAN OMRON HEALTHCARE EUROPE B.V. EU-representative Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS www.omron-healthcare.com Importer in EU OMRON DALIAN Co., Ltd. Production facility No. 3, Song Jiang Road, Economic and Technical Development Zone, Dalian 116600, China OMRON HEALTHCARE UK LTD.
- Page 27 The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by OMRON HEALTHCARE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
