Summary of Contents for Samsung DVD-HD950
-
Page 1: Dvd Player
DVD Player DVD-HD950 ELECTRONICS AK68-00640C... -
Page 2: Precautions
Precautions 1. Setting up - Refer to the identification label located on the rear of your player for its proper operating voltage. - Install your player in a cabinet with adequate ventilation holes. (7~10cm) Do not block ventilation holes on any of the components for air circulation. -
Page 3: Table Of Contents
Before you start Accessories Video/Audio HDMI Cable Remote Batteries for User’s Manual Cable Control Remote Control (AAA Size) Install Batteries in the Remote control Open the battery cover on the back of the remote control. Insert two AAA batteries. Make sure that the polarities (+ and -) are aligned correctly. -
Page 4: General Features
DVD. CUSTOMER SERVICE CENTER.” ENG-6 Disc Type and Characteristics This DVD player is capable of playing the following types of discs with the corresponding logos: Disc Types (Logos) DVD-VIDEO • DVD-RAM • CDV •... -
Page 5: Description
E T U P Description Front Panel Controls 1. STANDBY/ON ( 6. STOP ( When the unit is first plugged in, the indicator lights. Stops disc play. When STANDBY/ON is pressed on, the indicator goes out 7. REMOTE CONTROL RECEIVER and the player is turned on. -
Page 6: Tour Of The Remote Control
In this case, it is necessary to use a TV or display with an HDCP-compatible DVI input. - There may be no image output if the DVD player is connected to a TV or display that is not compatible with the above format. -
Page 7: Choosing A Connection
- If there is one audio input terminal on the TV, connect it to the [AUDIO OUT][left] (white) terminal of the DVD player. - If you press the VIDEO SEL. button when DVD Player is in stop mode or no disc is inserted, the Video COMPOSITE/S-VIDEO... - Page 8 COMPONENT IN terminals of your TV. Using the audio cables, connect the AUDIO (red and white) OUT terminals on the rear of the DVD player to the AUDIO (red and white) IN terminals of your TV. Turn on the DVD player and TV.
- Page 9 - Please refer to the user's manual of your TV. - If HDMI or HDMI-DVI cable is plugged into TV, the DVD player’s output is set to HDMI/DVI within 10 seconds. - If you set the HDMI output resolution 720p or 1080i, HDMI output provides better picture quality.
- Page 10 TV remote control. - This function works only for models supporting the Anynet. - Using Anynet, you can easily control a DVD Player with your TV. - For detailed operation steps and connections, refer to the user’s manual that supports Anynet.
- Page 11 Connection to an Audio System (Dolby digital, MPEG2 or DTS Amplifier) If using an optical cable (not included), connect the DIGITAL AUDIO OUT (OPTICAL) terminal on the rear of the DVD player to the DIGITAL AUDIO IN (OPTICAL) terminal of the Amplifier.
-
Page 12: Playing A Disc
C h a p t e r 3 A S I C U N C T I O N S Playing a Disc Before Play - Turn on your TV and set it to the correct Video Input on the TV's remote control. - If you connected an external Audio System, turn on your Audio System and set it to the correct Audio Input. -
Page 13: Using The Search And Skip Functions
A S I C U N C T I O N S Using the Search and Skip Functions During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection. Searching through a Chapter or Track During play, press the SEARCH ( During play, turn the... -
Page 14: Using The Disc And Title Menu
A S I C U N C T I O N S You may use the number buttons of the remote control to directly access a title, chapter or to start the playback from a desired time. Press the ➛/❿ buttons to make the desired setup and then press the ENTER button. -
Page 15: Using The Function Menu
A S I C U N C T I O N S Using the Function Menu Using the Function Menu (DVD/VCD) Press the MENU button during playback. Info Press the /❷ buttons to Zoom select Function, then press Bookmark the ❿ or ENTER button. Repeat - Info (See pages 25 to 26) EZ View... -
Page 16: Slow Repeat Play
A S I C U N C T I O N S Slow Repeat Play This feature allows you slowly to repeat scenes containing sports, dancing, musical instruments being played etc., so you can study them more closely. When playing a DVD/VCD During play, press the PLAY/PAUSE ( ) button. -
Page 17: Adjusting The Aspect Ratio (Ez View)
C h a p t e r 4 D VA N C E D U N C T I O N S Adjusting the Aspect Ratio (EZ View) To play back using aspect ratio (DVD) Press the EZ VIEW button. - The screen size changes when the button is pressed... -
Page 18: Selecting The Audio Language
D VA N C E D U N C T I O N S Selecting the Audio Language You can select a desired audio language quickly and easily with the AUDIO button. Using the AUDIO button (DVD/VCD/CD/MPEG4) Press the AUDIO button. The Audio changes when the button is pressed repeatedly. -
Page 19: Changing The Camera Angle
D VA N C E D U N C T I O N S Changing the Camera Angle When a DVD contains multiple angles of a particular scene, you can use the ANGLE function. Using the ANGLE button (DVD) If the disc contains multiple angles, the ANGLE appears on the screen. Press the ANGLE button, then the ANGLE icon will appear with the current... -
Page 20: Using The Zoom Function
D VA N C E D U N C T I O N S Recalling a Marked Scene During play, press the BOOKMARK button on the remote control. Press the ➛/❿ buttons to select a marked scene. Press the PLAY/PAUSE ) button to skip to the marked scene. -
Page 21: Dvd Audio Playback
D VA N C E D U N C T I O N S DVD AUDIO Playback Open the disc tray. Place the DVD AUDIO disc on the tray. - Place the DVD AUDIO disc with the labeled side up. Close the tray. -
Page 22: Super Audio Cd Playback
D VA N C E D U N C T I O N S REPEAT Play Press the REPEAT button on the remote control. Repeat screen appears. Track ( ): repeats the track that is playing. DVD-AUDIO Group ( ): repeats the group that is playing. Press the ➛/❿... - Page 23 D VA N C E D U N C T I O N S Super Audio CD Clips Menu Off Play Function In Stop mode, press the DISC MENU button until the Clips menu is off. You can select Info in the function menu by pressing the MENU button.
-
Page 24: Clips Menu For Mp3/Wma/Jpeg/Mpeg4
D VA N C E D U N C T I O N S Clips Menu for MP3/WMA/JPEG/MPEG4 Discs with MP3/WMA/JPEG/MPEG4 contain individual songs and/or pictures that can be organized into folders as shown below. They are similar to how you use your computer to put files into different folders. -
Page 25: Mpeg4 Playback
The above recommendations cannot be taken as a Sound quality with MP3 files basically depends on the rate guarantee that the DVD player will play MP3 recordings, or of compression/decompression you choose. Getting CD as an assurance of sound quality. You should note that... -
Page 26: Picture Cd Playback
D VA N C E D U N C T I O N S MPEG4 Function Description CD-R AVI file Function Description Reference page This unit can play the following video compression formats During play, press the within the AVI file format: Skip button, it moves forward - DivX 3.11 contents... -
Page 27: Picture Cd Playback For Hd-Jpeg
D VA N C E D U N C T I O N S Picture CD Playback for HD-JPEG Must connect to HDMI or DVI. Resolution should be 720p/768p/1080i, and HD-JPEG should be in HD mode. (See page 67) Note HDMI SETUP - Only available in HDMI/COMPONENT(P-SCAN) Resolution... -
Page 28: Using The Setup Menu
E T U P M E N U Using the Setup Menu The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have. -
Page 29: Setting Up The Language Features
H A N G I N G E T U P M E N U EZ SETUP PCM Down Sampling Press the /❷ buttons to select the PCM Down Sampling On or Off, then press the ENTER button. (See page 62) EZ SETUP AV Receiver Connected? If an AV Receiver is... - Page 30 H A N G I N G E T U P M E N U Using the Disc Menu Language This function changes the text language only on the disc menu screens. With the unit in Stop mode, press the MENU button.
-
Page 31: Setting Up The Audio Options
H A N G I N G E T U P M E N U Using the Subtitle Language With the unit in Stop mode, press the MENU button. ❿ Language Setup Press the /❷ buttons to Audio Setup ❿ select Setup, then press Display Setup ❿... - Page 32 H A N G I N G E T U P M E N U Dolby/DTS Digital Out - PCM : Converts to PCM(2CH) audio. - Bitstream : Outputs Dolby Digital or DTS Bitstream via digital output. Select Bitstream when connecting to a Dolby Digital and DTS Decoder. MPEG-2 Digital Out - PCM : Converts to PCM(2CH) audio.
-
Page 33: Setting Up The Display Options
H A N G I N G E T U P M E N U The default settings : FRONT L, R (Small), CENTER (Small), SURROUND (Small). Select the size of the speakers to be connected. Front (FL, FR) - Large: Normally select this. - Small: When the sound distorts or the surround sound effects are difficult to hear, select this. - Page 34 H A N G I N G E T U P M E N U TV Aspect 2. PAL Disc : In case of using PAL disc Depending on a type of television you have, • If your TV system only has NTSC-Video you may want to adjust the screen setting input, you must choose “NTSC Output”.
-
Page 35: Setting Up The Parental Control
H A N G I N G E T U P M E N U Setting Up the Parental Control The Parental Control function works in conjunction with DVDs that have been assigned a rating, which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. -
Page 36: Controlling A Tv With The Remote
The remote control may not be able to control every model TV of the brands listed. If you replace the remote control's batteries, set the brand code again. e.g) For Samsung 2 TVs While holding down the TV POWER button, enter 0 and then 1. -
Page 37: Firmware Upgrade
Firmware upgrade Introduction Samsung will often support the software upgrade to improve the performance of this unit to the latest status, through Samsung Internet Site (www.samsung.com). Because the specially new MPEG4 codec continues and it is appearing. What improvements are made depends on the upgrade software you are using as well as the software that your DVD-player contained before the upgrade. -
Page 38: Specifications
*Frequency Response Output *S/N Ratio *Dynamic Range *Total Harmonic Distortion - Samsung Electronics Co., Ltd reserves the right to change the specifications with out notice. - Weight and dimensions are approximate. AC 110 - 240V ~ 60/50 Hz 2.3 Kg 430mm (W) X 250mm (D) X 49mm (H) +5°C to +35°C...
