EN1-PD22EO 12/2/02 11:35 PM Page 1 LCD TV 22 LW22A13W Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS TELETEXT PICTURE IN PICTURE...
Page 2
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
EN1-PD22EO 12/2/02 11:35 PM Page 3 Safety Instructions These illustrations represent precautions concerning your TV. 35¡ 5¡ Do NOT expose the TV to extreme temperature conditions (below 5°C and above 35°C) or to extreme humidity conditions (less than 10% and more than 75%). If the TV is broken, do not try to During a storm conditions repair it yourself.
Connecting the Headphones ...29 Adjusting Your Headphone Preferences ...29 Selecting the Sound...30 English-4 Thank you for buying a SAMSUNG TV. Please take the time to read these instructions, as they will help you to operate your TV with ease. Contents...
Page 5
EN1-PD22EO 12/2/02 11:35 PM Page 5 ETTING THE ICTURE Picture In Picture Feature ...30 Selecting the Blue Screen Mode ...32 ETTING THE Setting the Sleep Timer ...32 Setting and Displaying the Current Time ...33 Switching the Television On and Off Automatically ...34 ETTING THE Connecting to the PC Input...35 Adjusting the Screen Quality ...36...
EN1-PD22EO 12/2/02 11:35 PM Page 6 Control Panels POWER SWITCH POWER INDICATOR REMOTE CONTROL SENSOR TV/VIDEO Using the Buttons on the Panel If the remote control no longer works or you have lost it, you can use controls on the panel of the TV to: Switch on the TV when it is in Standby mode and select channels ( Access the local menu ( MENU )
Page 8 Infrared Remote Control TELEVISION STANDBY BUTTON MODE : SELECTS A TARGET DEVICE TO CONTROLLED BY THE SAMSUNG REMOTE CONTROL (TV, VCR, CABLE BOX, OR DVD). NUMERIC BUTTONS ONE/TWO-DIGIT CHANNEL SELECTION SELECT TO THE PC MODE DIRECTLY SOUND STANDARD SELECTION...
EN1-PD22EO 12/2/02 11:35 PM Page 9 Connecting to an Aerial or Cable Television Network To view TV channels correctly, a signal must be received by the set from one of the following sources: An outdoor aerial A cable TV network A satellite network (see page 10 for further details) In the first three cases, connect the aerial or network input cable to the 75 coaxial socket on the rear of the TV.
EN1-PD22EO 12/2/02 11:35 PM Page 10 Connecting a Satellite Receiver Rear of the TV Satellite Receiver Connecting a Decoder Rear of the TV Decoder English-10 In order to watch TV programmes broadcast via a satellite network, you must connect a satellite receiver to the TV set. If you wish to connect both a satellite receiver and a VCR, you should connect the: Receiver to the VCR...
EN1-PD22EO 12/2/02 11:35 PM Page 11 Connecting to an Audio System and Sub-woofer Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and the AUDIO OUTPUT L, R jacks on the TV. Connect an audio cable between the INPUT jack on an active(powered) Sub woofer and the WOOFER OUT jack on the TV.
EN1-PD22EO 12/2/02 11:35 PM Page 12 Switching Your TV On and Off Placing Your Television in Standby Mode English-12 The mains lead is attached to the rear of your TV. If you have purchased this TV in the United Kingdom, refer to page 43 for further instructions on plug wiring.
EN1-PD22EO 12/2/02 11:35 PM Page 13 Becoming Familiar with the Remote Control The remote control is used mainly to: Change channels and adjust the volume Set up the TV using the on-screen menu system The following table presents the most frequently used buttons and their functions.
EN1-PD22EO 12/2/02 11:35 PM Page 14 Plug and Play Feature Plug & Play Ant. Input Check Enjoy Your Watching English-14 When the TV is initially powered ON, two basic customer settings proceed automatically and subsequently. The follwing settings are available. If the TV is in Standby mode, press the POWER button ( remote control.
EN1-PD22EO 12/2/02 11:35 PM Page 15 Plug and Play Feature If you want to reset this feature... Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button to select the Function. Press the LEFT/RIGHT button. Result: The options available in the Function group are displayed.
EN2-PD22EO 12/2/02 11:35 PM Page 16 Automatic Storing of Channels English-16 You can scan for the frequency ranges available to you, (availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However you can sort numbers manually and clear any channels you do not wish to watch (see pages 17~19 for further details).
EN2-PD22EO 12/2/02 11:35 PM Page 17 Sorting the Stored Channels The Sort operation allows you to change the programme numbers of stored channels. This operation may be necessary after using ATM. You can delete those channels you do not want to keep. Press the MENU button.
EN2-PD22EO 12/2/02 11:35 PM Page 18 Manual Storing of Channels English-18 You can store up to 100 TV channels, including those received via cable networks. When storing channels manually, you can choose: Whether or not to store each of the channels found The programme number by which you wish to identify each stored channel Press the MENU button.
Page 19
EN2-PD22EO 12/2/02 11:35 PM Page 19 Manual Storing of Channels If you... Know the number of the the channel to be stored Do not know the channel the numbers Result: The tuner scans the frequency range until the first channel or the channel that you selected is received on your screen.
EN2-PD22EO 12/2/02 11:35 PM Page 20 Assigning Names to Channels English-20 Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names. Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button to select the Channel.
EN2-PD22EO 12/2/02 11:35 PM Page 21 Skipping Unwanted Channels You can exclude the channels of your choice from the channel scan operation. When you scan through the stored channels, those you have chosen to skip are not displayed. All channels that you do not specifically choose to skip are displayed during scanning.
EN2-PD22EO 12/2/02 11:35 PM Page 22 Fine Tuning Channels English-22 Use fine tuning to manually adjust a particular channel for optimal reception. Press the MENU button Result: The main menu is displayed. Press the UP/DOWN button to select the Channel. Press the LEFT/RIGHT button.
EN2-PD22EO 12/2/02 11:35 PM Page 23 Changing the Picture Standard You can use your remote control to select the type of picture which best corresponds to your viewing requirements. The following picture effects are available: Custom, Dynamic, Standard, Movie. To select the required picture effect, simply press the P.STD( on the remote control.
EN3-PD22EO 12/3/02 8:37 PM Page 24 Selecting the Picture Format Freezing the Picture English-24 You can select the picture format which best corresponds to your viewing requirements by simply pressing the P.SIZE button. The following picture formats are available in the order given: Auto wide Wide Panorama...
EN3-PD22EO 12/3/02 8:37 PM Page 25 Adjusting the Volume You can adjust the volume using your remote control. To... hold down the... Increase the volume button. Result: A horizontal bar is displayed and the volume increases until you release the button.
EN3-PD22EO 12/3/02 8:37 PM Page 26 Selecting the Sound Standard Adjusting the Sound Settings English-26 You can use your remote control to select the type of special sound effect to be used when watching a given broadcast. The following sound effects are available: Custom, Standard, Music, Movie, Speech.
EN3-PD22EO 12/3/02 8:37 PM Page 27 Selecting the Sound Mode You can set the Audio mode by using DUAL I/II. When you press this button, current sound mode is displayed on the upper right corner of the screen. DUAL I/II Audio Type Mono Mono...
EN3-PD22EO 12/3/02 8:37 PM Page 28 Virtual Dolby Adjusting the Volume Automatically English-28 This feature allows the TV’s L/R speakers to provide a home Theater-like Dolby effect. The center and surround sounds are mixed into the L/R speakers. Press the MENU button. Result: The main menu is displayed.
EN3-PD22EO 12/3/02 8:37 PM Page 29 Connecting Headphones You can connect a set of headphones to your TV if you wish to watch a TV programme without disturbing the other people in the room. Plug a set of headphones into the 3.5 mm mini-jack socket on the panel of the TV.
EN3-PD22EO 12/3/02 8:37 PM Page 30 Selecting the Sound Picture in Picture Feature English-30 Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button to select Sound. Press the LEFT/RIGHT button. Result: The options available in the Sound group are displayed. Press the UP/DOWN button to select the Sound select.
Page 31
EN3-PD22EO 12/3/02 8:37 PM Page 31 Press the UP/DOWN button to select Size. Then, select a size of the sub to Double Screen1, Double Screen2 or Small by pressing the LEFT/RIGHT Press the UP/DOWN button to select Prog.No. You can select the channel that you want to view through sub picture by pressing the LEFT/RIGHT To return to normal viewing, press the MENU button.
EN3-PD22EO 12/3/02 8:37 PM Page 32 Setting the Blue Screen Mode Setting the Sleep Timer S l e e p T i m e r 3 0 English-32 If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background.
EN3-PD22EO 12/3/02 8:37 PM Page 33 Setting and Displaying the Current Time You can set the TV’s clock so that the current time is displayed when you press the “DISPLAY" button. You must also set the time if you wish to use the automatic On/Off timers.
EN3-PD22EO 12/3/02 8:37 PM Page 34 Switching the Television On and Off Automatically English-34 You can set the On/Off timers so that the TV will: Switch on automatically and tune to the channel of your choice at the time you select Switch off automatically at the time you select The first step is to set the TV’s clock (refer to “Setting and Displaying the Current Time”...
Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) First, click on “Settings” on the Windows start menu.
EN3-PD22EO 12/3/02 8:37 PM Page 36 Adjusting the Screen Quality Changing the Screen Position English-36 The propose of picture quality adjustment is to remote or reduce picture noise. If the noise is not removed by fine tuning alone, then do the frequency adjustments to the utmost and fine tune again. After the noise has been reduced, re-adjust the picture so that it is aligned on the center of screen.
EN3-PD22EO 12/3/02 8:37 PM Page 37 Changing the Screen Colour Standard Preset to the PC/DVI mode by using the PC button. Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button to select PC/DVI. Press the LEFT/RIGHT button.
EN3-PD22EO 12/3/02 8:37 PM Page 38 Teletext Decoder Displaying Teletext Information English-38 Most TV channels carry “teletext,” pages of written information that provide information such as: Television programme times News bulletins Weather forecasts Sports results Subtitles for the hard of hearing The teletext pages are organized according to six categories: Part Contents...
EN3-PD22EO 12/3/02 8:37 PM Page 39 Selecting a Specific Teletext Page Press the number buttons on the remote control to enter the page number directly: Enter the three-digit page number listed in the contents by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed.
EN3-PD22EO 12/3/02 8:37 PM Page 40 Using FLOF to Select a Teletext Page Storing Teletext Pages English-40 The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control. Display the teletext contents page by pressing the Text/Mix ( ) button.
EN3-PD22EO 12/4/02 4:22 AM Page 41 Connecting to the AV1 or 2 SCART Input/Outputs AV1 is used for equipment with an RGB output, such as video game devices and video disc players or a VCR. Rear of TV SCART 2 SCART 1 This end can be fitted with: A SCART connector...
EN3-PD22EO 12/4/02 4:22 AM Page 42 Connecting to the S-Video Input The S-VIDEO/RCA(AUDIO-L+R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR. Rear of the TV To play pictures and sound both the S-VIDEO and the RCA connections must be used. Viewing Pictures From External Sources English-42 Once you have connected up your various audio and video systems,...
EN3-PD22EO 12/3/02 8:37 PM Page 43 Wiring the Mains Power Supply Plug (UK Only) IMPORTANT NOTICE The mains lead on this equipment is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BSI1362 of the same rating must be used.
Page 44 Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer.
Page 45
EN3-PD22EO 12/3/02 8:37 PM Page 45 Image is not stable and may appear to vibrate. Image is not centered on the screen. Dot Defect TFT LCD panel manufactured by using advanced semiconductor technology with precision of 99.999% above is used for this product. But the pixels of RED, GREEN, BLUE and WHITE colour seem to be bright sometimes or some of black pixels could be seen.
EN3-PD22EO 12/3/02 8:37 PM Page 46 Display Modes If the signal from the system equals to the standard signal mode, the screen is adjusted automatically. If the signal from the system doesn’t equal to the standard signal mode, adjust the mode with refering to the Videocard user guide because the screen might not display or only the power LED might be on.
EN3-PD22EO 12/3/02 8:37 PM Page 47 Attaching a wall or Arm mounting Device The TV supports VESA mounting standard for use with various VESA mounting devices. To install any VESA mounting device, please follow the instructions given. < A > Remove all cable connected on the TV.
EN3-PD22EO 12/3/02 8:37 PM Page 48 Installing VESA Compliant mounting Device Align the mounting interface pad with the holes in the rear cover mounting pad and secure it with the four screws that came with the arm-type base, wall mount hanger or other bases. Mounting pad Rear cover English-48...
EN3-PD22EO 12/3/02 8:37 PM Page 49 Kensington Slot Cable Figure2 Figure1 The Kensington lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer.
EN3-PD22EO 12/3/02 8:37 PM Page 50 Specification Model Name Panel Size Display Size Type Pixel pitch Viewing Angle *Frequency Horizontal Vertical Display Colour Display Maximum Mode Resolution Input Signal Sync. Video signal Colour system Sound system Colour system Video Video system Video In/output Scart 1 Audio In/output...
EN3-PD22EO 12/4/02 4:23 AM Page 51 Specification Model Name Power Maximum Consumption Power Saving Dimensions/ Unit (WxDxH) : Weight TV body With stand Environmental Operating Considerations Temperature Operating Humidity Storage Temperature Storage Humidity Audio Input 1 Audio Audio Input 2 Characteristics Headphone Frequency...
Page 52
EN3-PD22EO 12/3/02 8:37 PM Page 52 THIS APPLIANCE IS DISTRIBUTED BY: ELECTRONICS BN68-00349D-02...
