Samsung SGH-M620 User Manual

SGH-M620
User's Guide
Some of the contents in this guide may differ from your phone depending on the
software of the phone or your service provider.
Bluetooth QD ID: B013825
Printed in Korea
World Wide Web Code No.: GH68-18237A
http://www.samsungmobile.com
English (EU). 04/2008. Rev.1.0
Silent Press and hold in Idle mode to disable all sounds on the phone.
mode To exit, press and hold this key again.
When you close the phone, it locks the exposed keys to ignore
Keypad
accidental key pressing. To unlock, press the Unlock soft key and
lock mode
then the OK soft key.
With the phone closed, press the Volume keys 4 times to send an
SOS
SOS message to preset phone numbers. Once the SOS message is
mode
sent, the phone will change to SOS mode and will receive calls only
from the registered recipients. Upon receiving a call from the SOS
message recipients, the phone will automatically answer the call.
Press to exit SOS mode.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Menu Contacts Soft key function indicators
Using the menus
In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key ( ) or
right soft key ( ) to perform the function indicated.
To exit the menu
without changing
the menu settings,
press this key.
Use the 4-way navigation keys as shortcuts to
access your favourite menus. Up is fixed as a
shortcut to My menu mode.
1. In Idle mode, press the Menu soft key.
2. Select Settings → Phone settings →
Shortcuts.
3. Select a key.
4. Select a menu to be assigned to the key.
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery cover
2. Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description Icon Description
SOS message feature
Signal strength
active
GPRS (2.5G) network
Bluetooth active
Connecting to GPRS
Bluetooth hands-free car
(2.5G) network
kit or headset connected
Transferring data in GPRS
Memory card inserted
(2.5G) network
Alarm set
Call in progress
FM radio on
Connected to secured web
page
Silent mode (Vibration)
Connected with PC
Silent mode (Mute)
Call diverting active
Call ringer set to vibrate
Home Zone
Whisper mode, during a
call
Office Zone
Mute mode, during a call
Roaming network
Battery power level
New message
New voice mail
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press
the Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select soft key or
enter the submenu.
If the selected menu contains additional submenus, repeat this step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1. Plug the supplied travel adapter into the phone and a power outlet.
With the triangle
facing up
2. When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. Press and hold for more than two seconds to switch off the phone.
Changing the display language
1. In Idle mode, press the Menu soft key.
2. Select Settings → Phone settings → Language.
3. Select a language.
Making a call
1. In Idle mode, enter an area code and phone number, and press
2. Press to end the call.
Answering a call
1. When the phone rings, press the Accept soft key or
call.
Press the Reject soft key or to reject the call.
2. Press to end the call.
Menu map
1. Call log
3.11 Timer
3.12 Stopwatch
1.1 Recent contacts
3.13 SIM application
1.2 Missed calls
toolkit *
1.3 Dialled calls
1.4 Received calls
4. Browser/Google**
1.5 Delete all
1.6 Call manager
5. Messages
2. Phonebook 5.1 Create message
to
5.2 My messages
2.1 Contact list
5.3 Templates
2.2 Create contact
5.4 Delete all
2.3 Group
5.5 Settings
2.4 Speed dial
5.6 SOS messages
2.5 My namecard
5.7 Memory status
2.6 Own numbers
2.7 Management
6. My files
2.8 Service number*
6.1 Images
6.2 Videos
3. Applications
6.3 Music
3.1 Alarm
6.4 Sounds
3.2 Music player
6.5 Other files
3.3 Voice recorder
6.6 Memory card***
3.4 FM radio
6.7 Memory status
3.5 Browser**
3.6 Java world
7. Calendar
3.7 Memo
3.8 World clock
8. Camera
3.9 Calculator
3.10 Converter
Phone layout and key functions
Web access/
Confirm key
In Idle mode, accesses
the web browser.
In Menu mode, selects the
highlighted option or
confirms input.
Soft keys
Perform functions indicated
by the text above the key.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send an SOS message
when pressed four times
with the keypad locked.
SOS mode
Dial key
Makes and answers a call.
In Idle mode, retrieves
the most recent calls.
Music player key
Accesses the Music
player menu.
Voice mail server key
In Idle mode, accesses
your voice mail server
when held down.
Alphanumeric keys

Adjusting the volume

1. In Idle mode, press the Menu
2. Select Settings Sound settings
→
volume.
3. Press Left or Right to adjust the volume level.
4. Press the Save soft key.
While a call is in progress, press the Volume keys to adjust the earpiece
volume.
Changing a ringtone for calls
1. In Idle mode, press the Menu
.
2. Select Settings → Sound settings
3. Select a ringtone category → a ringtone and press the
Redialling recent numbers
to answer a
1. In Idle mode, press .
2. Press Left or Right to select a call type.
3. Press Up or Down to scroll to the number you want.
4. Press to dial the number.

Entering text

9. Settings
Changing the text input mode
9.1 Time and date
• Press and hold to switch between T9 mode and ABC mode.
9.2 Phone settings
Depending on your country, you may be able to access an input mode for
9.3 Display settings
9.4 Sound settings
your specific language.
9.5 Light settings
• Press to change case or switch to Number mode.
9.6 Network services
9.7 Bluetooth
• Press and hold to switch to Symbol mode.
9.8 Security
9.9 Connection
T9 mode
settings
9.10 Memory status
1. Press 2 to 9 to start entering a word. Press each key once for one letter.
9.11 Reset settings
The word you are entering appears on the display. It may change with
* Available only if supported
by your SIM card.
each keypress. Finish entering the word before editing or deleting any
** If the Google service is keystrokes.
not available, Browser
will display in menu 4
Example: To enter "Hello" in T9 mode, press
instead of appearing in
Applications.
2. To display another word choices, press 0.
*** Available only if a
memory card is
3. Press to insert a space and enter the next word.
inserted. Your phone
accepts microSD TM
memory cards up to 2
ABC mode
GB (depending on
memory card
Press the keys labeled with the letter you want once for the first letter,
manufacturer and
type).
twice for the second letter, and so on.
For example, press 2 three times to enter "C" and
4-way navigation keys
In Idle mode, access the
following menus or
functions directly:
• Up: My menu mode
• Down/Left/Right:
your favourite menus
In Menu mode, scroll
through menu options.
Camera key
In Idle mode, turns on the
camera when held down.
Power/End key
Turns the phone on or
off when held down.
Also, ends a call.
Bluetooth key
Accesses the Bluetooth
menu.
Delete key
Deletes characters from
the display or items in an
application.
Silent mode key
Silent mode
soft key.
Incoming call Call alert
→ →
soft key.
→ Incoming call → Ringtone.
Save soft key.
4, 3, 5, 5, and 6.
5 two times to enter "K."
