Uniden UH6000 Owner's Manual

Compact uhf cb transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

UH6000
Compact
UHF CB Transceiver
For more exciting new products please visit our website:
Australia: www.uniden.com.au

Advertisement

Table of Contents
loading

Related Manuals for Uniden UH6000

Summary of Contents for Uniden UH6000

  • Page 1 UH6000 Compact UHF CB Transceiver For more exciting new products please visit our website: Australia: www.uniden.com.au...

  • Page 2: Table Of Contents

    Contents Introduction Controls & Connectors Indicators Included with your UH6000 Transceiver Connecting the Microphone Mounting the MIC Hanger Operation Turning on the Power Setting the Squelch Level Monitor Selecting a Channel Programming the Instant Priority Channel Recalling the Instant Channel...

  • Page 3: Introduction

    Introduction The Uniden UH6000 is designed to provide you with years of trouble free service. Its rugged components and materials are capable of withstanding harsh environments. Please read this Operating Manual carefully to ensure you gain the optimum performance of the unit.

  • Page 4: Controls & Connectors

    Controls & Connectors UNIDEN UH6000 UHF CB Transceiver...
  • Page 5 PTT - Push To Talk Button Liquid Crystal Display (LCD) RJ45 type plug Channel Scan button /Scan Memory (press & hold) MIC Jack Cover MIC - Microphone Jack Speaker EXT SP - External Speaker Jack Power Input Connection (13.8VDC) UNIDEN UH6000 UHF CB Transceiver...

  • Page 6: Indicators

    - Receive Signal Level (Channel Busy Indicator) - Transmit Signal Power Level - Channel Number / Menu Item Setting - CTCSS/DCS Code number / Menu Item - Scan mode - Channel in Memory - Instant Channel UNIDEN UH6000 UHF CB Transceiver...

  • Page 7: Included With Your Uh6000 Transceiver

    Bracket with screws with fuse Optional Accessories: • UHF Antenna • External Speaker • Speaker Mic Visit the UH6000 page on the website for more information on the availability of optional accessories; www.uniden.com.au for Australia UNIDEN UH6000 UHF CB Transceiver...

  • Page 8: Connecting The Microphone

    MIC plug towards the MIC cord and at the same time tug on the MIC cord to draw back the MIC plug. UNIDEN UH6000 UHF CB Transceiver...

  • Page 9: Mounting The Mic Hanger

    Secure the front and back pieces of the MIC Hanger using the supplied binding screws. Locate a suitable mounting position. Remove (peel off) the plastic covering the adhesive tape on the flat area of the MICHanger back piece and then press firmly to the mounting position. UNIDEN UH6000 UHF CB Transceiver...

  • Page 10: Operation

    If the input voltage falls below 10VDC, dc Lo flashes for 5 seconds. The power turns off automatically if voltage falls below 8.5VDC. Switch your UH6000 OFF and disconnect it from the power source, before locating the cause of the power supply problem. Setting the Squelch Level The Squelch circuit determines when the radio’s audio output (speaker)
  • Page 11 If unwanted weak and noisy signals are getting through increase the squelch level (‘Squelch Gate’) to a medium level. Now only medium and strong signals get through. UNIDEN UH6000 UHF CB Transceiver...

  • Page 12: Monitor

    35 are reserved for Emergency Calls. Programming the Instant Priority Channel Turn the Channel Selector to select the Priority Channel you prefer. Press and hold [INST] on the microphone for 2 seconds to store the new setting. icon appears. UNIDEN UH6000 UHF CB Transceiver...

  • Page 13: Recalling The Instant Channel

    UHF CB Repeaters are used to retransmit or relay your signal. Repeaters will extend the range of your radio and overcome the shielding effect caused by solid obstructions. In normal Simplex operation, your radio transmits on one particular frequency and receives on that same frequency. UNIDEN UH6000 UHF CB Transceiver...
  • Page 14 CH02 on Duplex Mode will Receive on CH02 but Transmit on CH32 etc... If you transmit on CH01 Duplex mode, you are actually transmitting on CH31 the repeater station down-converts your signal and retransmits on CH01. UNIDEN UH6000 UHF CB Transceiver...

  • Page 15: Operating The Uhf Cb Radio In Duplex Mode

    NOTE Scanning The scan feature allows you to search for active channels automatically. The UH6000 has two types of scanning; Open Scanning (OS) and Group Scanning (GS), to give you flexibility and allow you to use the radio more effectively.

  • Page 16: Open Scan (Os) Mode

    GS. 3. Press to store the setting. 4. Press and hold to save & exit the menu mode. GS Scanning checks the Instant Priority Channel for activity every 1.5 seconds. UNIDEN UH6000 UHF CB Transceiver...

  • Page 17: Add/Remove Channels From Scan Memory

    - o4). To turn off CTCSS/DCS select the oF code. 3. Press to store the setting. 4. Press & hold to save & exit menu mode. The CTCSS/DCS code displays for the selected channel. UNIDEN UH6000 UHF CB Transceiver...

  • Page 18: Busy Channel Lockout

    1. Press 2. Turn the Channel Selector or press to change the setting between 1, 2, 3, 4 and 5. 3. Press to store the setting. 4. Press and hold to exit from the menu mode. UNIDEN UH6000 UHF CB Transceiver...

  • Page 19: Roger Beep

    2. Turn the Channel Selector or press to change the setting between Blue, Red, Purple (magenta), Green, Cyan, Yellow and Clear (white). 3. Press to store the setting. 4. Press and hold to exit from the menu mode. UNIDEN UH6000 UHF CB Transceiver...

  • Page 20: Backlight Brightness

    10 times. The Flip setting flashes. 1. Press to change the flip 2. Turn the Channel Selector or press orientation. 3. Press to store the setting. 4. Press and hold to save & exit menu mode. UNIDEN UH6000 UHF CB Transceiver...

  • Page 21: Ctcss Codes Table

    88.5 218.1 91.5 225.7 94.8 233.6 97.4 241.8 100.0 250.3 103.5 69.4 107.2 159.8 110.9 165.5 114.8 171.3 118.8 177.3 123.0 183.5 127.3 189.9 131.8 196.6 136.5 199.5 141.3 206.5 146.2 229.1 151.4 254.1 156.7 UNIDEN UH6000 UHF CB Transceiver...

  • Page 22: Dcs Codes Table

    DCS codes table DCS Code DCS Code DCS Code Code No. Code No. Code No. (Octal) (Octal) (Octal) 100 (do0) 101 (do1) 102 (do2) 103 (do3) 104 (do4) UNIDEN UH6000 UHF CB Transceiver...

  • Page 23: Uhf Cb Channel Guidelines

    The above situations are not a fault of the radio but a symptom of mixed wideband and narrowband radios in current use. It is expected that as the number of older wideband radios in use drops this issue will be reduced. UNIDEN UH6000 UHF CB Transceiver...

  • Page 24: Uhf Cb Channels & Frequencies

    477.300 (CH36) 477.050 476.575 477.325 (CH37) 477.075 476.600 477.350 (CH38) 477.100 476.625 477.125 476.650 477.150 476.675 477.175 476.700 477.200 476.725 477.225 476.750 477.250 476.775 477.275 476.800 477.300 476.825 477.325 476.850 477.350 476.875 477.375 476.900 477.400 UNIDEN UH6000 UHF CB Transceiver...
  • Page 25 477.0625 476.5875 477.3375 (CH 77) 477.0875 476.6125 477.3625 (CH 78) 477.1125 476.6375 477.1375 476.6625 477.1625 476.6875 477.1875 476.7125 477.2125 476.7375 477.2375 476.7625 477.2625 476.7875 477.2875 476.8125 477.3125 476.8375 477.3375 476.8625 477.3625 476.8875 477.3875 476.9125 477.4125 UNIDEN UH6000 UHF CB Transceiver...

  • Page 26: Warranty

    IMPORTANT: Satisfactory evidence of the original purchase is required for warranty service Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor: The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”).
  • Page 27 Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
  • Page 28 THANK YOU FOR BUYING A UNIDEN PRODUCT. © 2020 Uniden Australia Pty Limited. Printed in PRC...
