Page 1: Quick Start Guide
Prestige 660H Series ADSL 2+ 4-Port Gateway Prestige 660HW Series ADSL 2+ 4-Port Gateway with 802.11g Wireless Quick Start Guide Version 3.40 5/2005... -
Page 2: Hardware Connections
Overview The Prestige 660H (P660H) and Prestige 660HW (P660HW) are ADSL routers with a built-in switch. The Prestige 660HW also has IEEE 802.11g wireless capability. All wireless features pertain to the P660HW series only. You may need your Internet access information. See your User’s Guide for background information on all features. - Page 3 1 DSL: Connect the Prestige to a telephone jack using a telephone wire. 2 LAN: Use an Ethernet cable to connect a computer to a LAN 10/100M port for initial configuration and/or Internet access. 3 POWER: Use the included power adaptor to connect the POWER socket to an appropriate power source (see the User’s Guide for power adaptors specifications by region).
-
Page 4: Zero Configuration
2.1 Configuration Genie From the included CD, click “Multimedia Auto Provisioner” (the installation and configuration assistant) and then click “Installation Tutorial”. After you’ve viewed the tutorial, click “Configuration Genie” at the end of the installation tutorial or from “Multimedia Auto Provisioner” in the CD. 2.2 Zero Configuration Launch your web browser and navigate to any web site (for... - Page 5 Note: If you do not see the next screen, then please read 2 Click Login. 4 In the MAIN MENU screen, click WIZARD SETUP. 2.3.1 Internet Access Setup Note: Enter the Internet access information given to you by your ISP exactly in each wizard screen and then click Next to continue or click Back to return to the previous screen.
- Page 6 1 From the Mode drop-down list box, select Routing (default) if you want to use routing features such as NAT. 2 The next wizard screen varies depending on the Encapsulation you chose in the first wizard screen. From the Network Address Translation drop-down list box, select SUA Only if you have one public IP address, Full Feature if you have more than one public IP address (for translation) or None to disable NAT.
-
Page 7: Wireless Configuration
Note: You will only see the next two screens in Routing mode. • PPPoA 3 Verify your LAN and settings. To change the LAN settings, click Change Configuration; otherwise click Save Settings to save the configuration and go to the final wizard screen.If you change the... - Page 8 Note: Wireless clients and the Prestige must use the same SSID, channel ID, WEP or WPA-PSK key (if enabled). 1 Click the Wireless LAN link under Advanced Setup. 3 Click Advanced Setup, Wireless LAN, Wireless. In the ESSID field, enter up to 32 printable characters to uniquely identify the Prestige.
- Page 9 3.1 OTIST Configure this screen only if you have OTIST-aware wireless clients. OTIST (One-Touch Intelligent Security Technology) allows you to transfer your Prestige’s SSID and WEP or WPA-PSK security settings to wireless clients that support OTIST and are within transmission range. You can also choose to have OTIST generate a WPA-PSK key for you if you didn’t configure one manually.
- Page 10 4 NAT NAT (Network Address Translation - NAT, RFC 1631) means the translation of an IP address in one network to a different IP address in another. For example, you could translate one public IP address to multiple private IP addresses on your LAN (SUA Only).
-
Page 11: Troubleshooting
6 Troubleshooting PROBLEM None of the LEDs turn on when you connect the Prestige’s power. Cannot access the Prestige from my computer. Cannot access the Internet. 6.1 Set Up Your Computer’s IP Address This section shows you how to set your Windows NT/2000/XP computer to automatically get an IP address. This ensures that your computer can connect with your Prestige. - Page 12 4 Select Internet Protocol (TCP/IP) (under the General tab in Windows XP) and click Properties. 5 The Internet Protocol TCP/IP Properties screen opens (the General tab in Windows XP). 6 Select the Obtain an IP address automatically and Obtain DNS server address automatically options. 7 Click OK to close the Internet Protocol (TCP/IP) Properties window.
