- Page 1 REFRIGERATOR ZA 26 S INSTRUCTION BOOKLET 2222 109-51...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 3: Table Of Contents
CONTENTS Instructions for the User Important Safety Information Description of the Appliance Operation Before use Setting the temperature Freezing fresh food Storage of frozen food Thawing Making ice cubes Fresh food refrigeration Dual purpose meat box Movable shelves Positioning the door shelves Hints and Tips Maintenance and Cleaning Internal cleaning... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Frozen food storage B- Thermostat control C- Cooked foods storage glass shelf D- Cooked foods storage glass shelves E- Salad crisper (to keep fruit and vegetables fresh) F- Bottle storage shelf G- Can storage shelf H- Can storage shelf I- Can storage shelf with egg tray J- Dairy compartment... -
Page 5: Operation
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and one ÇOFFÈ... -
Page 6: Thawing
Thawing Frozen food, prior to being used, can be thawed in the fridge or at room temperature depending on the time available. Small food items may even be cooked from frozen; in this case cooking will take longer. Any frozen food which is allowed to thaw accidentally should either be eaten as soon as possible or thrown away. -
Page 7: Movable Shelves
Movable shelves The walls of the refrigerator are equipped with runners so that shelves can be positioned as desired. For better use of space, the front half-shelves can lie over the rear ones. D338 Positioning the inner shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. -
Page 8: Hints And Tips
HINTS AND TIPS Normal Operating Sounds ¥ You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or tubing at the rear, to the cooling plate/evaporator. ¥ When the compressor is on, the refrigerant is being pumped round, and you will hear a whirring sound or pulsating noise from the compressor. -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX... -
Page 10: Freezer Compartment
Freezer Compartment When the frost has reached a thickness of up to 4mm it can be removed using a plastic scraper. During this operation it is not necessary to disconnect the appliance from the mains and remove the food. Never use metal tools for this operation. For complete defrosting (once or twice a year) proceed as follows: turn the thermostat dial to the ÇOFFÈ... -
Page 11: Something Not Working
Noise Water under the salad bin If after the above checks your appliance still does not operate correctly, contact your local Zanussi Service Force Centre. Please note that it will be necessary to provide proof of purchase for any in-guarantee service calls. -
Page 12: Service And Spare Parts
The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk... -
Page 15: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 16: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. Height Width Depth... -
Page 17: Installation
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 18: Electrical Connection
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression. -
Page 19: Door Reversal
Door reversal 1. Unplug the appliance from the power supply before carrying out the below-mentioned operations. 2. Remove the ventilation grill (D). 3. Unscrew the bottom hinge (E). 4. Remove the door by releasing it from the top hinge pin (A). 5. - Page 20 © Electrolux Household Appliances Limited 2001...
