- Page 1 INSTRUCTION MANUAL 81cm Tower Fan with Remote Model: DCTF81R For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your fan for the first time and keep them in a safe place.
- Page 3 • Never use the mains lead as a carrying strap or pulling lead. • To avoid a fire or electrocution hazard, NEVER put the cord near heat registers, radiator, stoves or heaters. • DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.
- Page 4 WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN • Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. • If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons Information Centre on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
- Page 5 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left unattended lead may become cable may be overloaded damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 6: Specification
Specification Model no. DCTF81R Colour Black Power supply 220-240V~, 50Hz Rated power Speed settings Modes Timer 0-7.5 hours Air volume 18.10m³/min Oscillating 70 degrees Controls Button or remote Cord storage Noise level (MAX) 54dB(A) Weight (net) 1.9kg Dimensions (w x d x h) 240 x 240 x 810mm •... - Page 7 Parts Remote control & storage slot LED Display Air outlet Rear cover Base Remote POWER POWER SPEED/ON SPEED/ON TIMER MODE TIMER MODE...
- Page 8 Assembly Please refer to the below instructions & diagram to assemble the base to the body of the tower fan. 1. Remove the base locking collar (4) (twist anti-clockwise). 2. Position the two base shells together (2 & 3) and feed the power cord (1) through the opening.
-
Page 9: Operation
Operation This tower fan can be operated by the control panel or remote control. Please refer to 0.5h Mode the below diagrams for descriptions. 0.5h Mode Button Controls Remote storage Mode button On/Speed button Oscillation button Timer button OFF button 0.5h Mode LED Display... -
Page 10: Mode Description
Operation Note: All functions of the unit can be operated by the control panel or remote control. 1. Place the fan on a flat stable surface and plug into a power outlet. 2. Press the SPEED/ON button to turn the unit ON and select the desired speed setting. - Page 11 Cleaning Over time, dust can accumulate on the fan grille, which can affect the fans performance. It is recommended to clean the fan at least once a month. 1. Turn the unit OFF and disconnect the appliance from the power supply. 2.
-
Page 12: Maintenance
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,... - Page 14 Supplied by Glen Dimplex Australia 1340 Ferntree Gully Road, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
